Moxa Technologies ETHERDEVICE EDS-308 Manual

Moxa EtherDevice Switch
EDS-308/309
Hardware Installation Guide
Eighth Edition, September 2010
©2010 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan,
R.O.C.
TEL: [phone]
P/N: 1802003083010

- 2 -
Overview
Moxa EtherDevice™ EDS-308/309 Series, which consists of 9-,and 8-port
smart Ethernet switches, provides an economical solution for your Ethernet
connections. As an added bonus, the built-in smart alarm function helps system
maintainers monitor the health of your Ethernet network.
EDS-308/309 switches have a wide operating temperature range of -40 to 75°C,
and are designed to withstand a high degree of vibration and shock. The rugged
hardware design makes EDS-308/309 Series perfect for ensuring that your
Ethernet equipment can withstand critical industrial applications, and complies
with FCC and CE Standards.
NOTE Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Moxa EDS-308/309 is shipped with the following items. If any of these items
is missing or damaged, please contact your customer service representative for
assistance.
yMoxa EtherDevice™ Switch
yHardware Installation Guide
yMoxa Product Warranty booklet
yProtective caps for unused ports
Features
High Performance Network Switching Technology
y10/100BaseT(X) (RJ45), 100BaseFX (SC/ST-type, Multi/Single mode)
yIEEE802.3/802.3u/802.3x
yStore and Forward switching process type, with 1024 address entries
y10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
Industrial Grade Reliablity
yPower failure, port break alarm by relay output
yRedundant dual DC power inputs
Rugged Design
yOperating temperature range from 0 to 60ºC, or extended operating
temperature from -40 to 75ºC for “-T” models
yIP30, rugged high-strength case
yDIN-rail or panel mounting ability
WARNING
The power for this product is intended to be supplied by a Listed
Power Supply, with output marked LPS, and rated to deliver 12 to
48 VDC at a maximum of 0.6A.
The DC jack should be used with an LPS unit that is rated to
deliver 12 to 48 VDC at a minimum of 1.1A. The product should
not be disassembled by operators or service people.

- 3 -
EDS-308 Panel Layout
5
6
7
9
10
2
EDS-308
Front Panel View
8
11
V1 V2 INPUTS: 24 VDC
PWR2
V2+
V2-
V1-
V1+
54
3
21
PID
NO
PORT ALARM
FAULT
PWR1
Top Panel View
1
2
3
4
1
Rear Panel View
2
13
12
12
1. Grounding screw
2. Terminal block for power inputs
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. TP port’s 100 Mbps LED
10. TP port’s 10 Mbps LED
11. Model Name
12. Screw holes for wall mounting kit
13. DIN-Rail Kit

- 4 -
EDS-308 Panel Layout (SC-type)
EDS-308-MM-SC
Front Panel View
12
EDS-308-M-SC
Front Panel View
12
13
8
9
10
11
2
13
5
6
7
V1 V2 INPUTS: 24 VDC
PWR2
V2+
V2-
V1-
V1+
12345
ON DIP
PORT ALARM
FAULT
PWR1
Top Panel View
1
2
3
4
Rear Panel View
2
15
14
14
1
NOTE: The appearance of EDS-308-S-SC
is identical to EDS-308-M-SC, and the
appearance of EDS-308-SS-SC is identical
to EDS-308-MM-SC.
1. Grounding screw
2. Terminal block for power inputs
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. TP port’s 100 Mbps LED
10. TP port’s 10 Mbps LED
11. Model Name
12. 100BaseFX Port
13. FX port’s 100 Mbps LED
14. Screw holes for wall mounting kit
15. DIN-Rail Kit

- 5 -
EDS-309 Panel Layout (SC-type)
EDS-309-3M-SC
Front Panel View
12
15
17
16
5
6
7
9
10
11
2
8
V1 V2 INPUTS: 24 VDC
PWR2
V2+
V2-
V1-
V1+
5
4
3
21
P
ID
NO
PORT ALARM
FAULT
PWR1
Top Panel View
1
2
3
4
Rear Panel View
2
14
13
13
1
1. Grounding screw
2. Terminal block for power inputs
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. TP port’s 100 Mbps LED
10. TP port’s 10 Mbps LED
11. Model Name
12. 100BaseFX Port
13. Screw holes for wall mounting kit
14. DIN-Rail Kit
15. 100 Mbps LED for FX port 7
16. 100 Mbps LED for FX port 8
17. 100 Mbps LED for FX port 9

- 6 -
EDS-308/309 Panel Layout (ST-type)
EDS-308-MM-ST
Front Panel View
12
13
5
6
7
9
10
11
2
8
EDS-309-3M-ST
Front Panel View
16
18
17
5
6
7
9
10
V1 V2 INPUTS: 24 VDC
PWR2
V2+
V2-
V1-
V1+
12345
ON DIP
PORT ALARM
FAULT
PWR1
Top Panel View
1
2
3
4
1
Rear Panel View
2
15
14
14
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. DIP switches
5. Power input PWR1 LED
6. Power input PWR2 LED
7. Fault LED
8. 10/100BaseT(X) Port
9. TP port’s 100 Mbps LED
10. TP port’s 10 Mbps LED
11. Model Name
12. 100BaseFX Port
13. 100 Mbps LEDfor FX port
14. Screw hole for wall mounting kit
15. DIN-Rail Kit
16. 100 Mbps LED for FX port 7
17. 100 Mbps LED for FX port 8
18. 100 Mbps LED for FX port 9

- 7 -
Mounting Dimensions (unit = mm)
Rear View
Side View Front View
DlN-Rail Kit
DlN-Rail Kit
DlN-Rail
105.00
9.00 19.80
00.53
30.00
00.531
13.10 25.40
15.10
53.60
00.531
17.5273.9377.6451.32
13 18 13
02.72 03.84
Wall Mounting Kit
3.5
6
13.9 18.2
6
13.9
10
10
5
7.75 30.50 7.75
08.6650.75
++
++
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be fixed to the back
panel of EDS-308/309 when you take it out of the box. If you need to reattach
the DIN-Rail attachment plate, make sure the stiff metal spring is situated
towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN-Rail into the
slot just below the stiff metal spring.
STEP 2:
The DIN-Rail attachment unit will
snap into place as shown below.
metal
spring
DIN-Rail
metal
spring
DIN-Rail
To remove Moxa EtherDevice Switch from the DIN-Rail, simply reverse Steps
1 and 2 above.

- 8 -
Wall Mounting (optional)
For some applications, you will find it convenient to mount EDS-308/309 on
the wall, as illustrated below.
STEP 1:
Remove the aluminum
DIN-Rail attachment plate from
EDS-308/309’s rear panel, and
then attach the wall mount
p
lates, as shown in the diagram
below.
⇒
top
plate
bottom
plate
STEP 2:
Mounting EDS-308/309 on the wall requires 4 screws. Use
the switch, with wall mount plates attached, as a guide to
mark the correct locations of the 4 screws. The heads of
the screws should be less than 6.0 mm in diameter, and the
shafts should be less than 3.5 mm in diameter, as shown in
the figure at the right.
6.0 mm
3.5 mm
NOTE Before tightening screws into the wall, make sure the screw head and
shank size are suitable by inserting the screw into one of the keyhole-
shaped apertures of the Wall Mounting Plates.
Do not screw the screws in all the way—leave about 2 mm to allow room for
sliding the wall mount panel between the wall and the screws.
STEP 3:
Once the screws are fixed in the
wall, insert the four screw heads
through the large parts of the
keyhole-shaped apertures, and then
slide EDS-308/309 downwards, as
indicated. Tighten the four screws
for added stability.
⇒
II 3G
ATEX Information
1. Certificate number DEMKO 08 ATEX 0717913X
2. Ambient range: -40°C ≤Tamb ≤+75°C
3. Certification String: EX nC nL IIC T4
4. Applicable standards: EN60079-0: 2006, EN60079-15:2005
5. The condition of safe usage:
a. The Ethernet Communication Devices are to be mounted in an IP54
enclosure and used in an area of not more than pollution degree 2 as
defined by IEC60664-1.
b. A 4mm² conductor must be used when connection to the external
grounding screw is utilized. Conductors suitable for use in an ambient
temperature of 93°C must be used for the Power Supply Terminal.
c. Provisions shall be made to prevent the rated voltage being exceeded by
the transient disturbances of more than 40%.

- 9 -
Wiring Requirements
WARNING
Do not disconnect modules or wires unless the power supply has
been switched off or the area is known to be non-hazardous. The
devices may only be connected to the supply voltage shown on
the type plate.
The devices are designed for operation with a Safety Extra-Low
Voltage. Thus, they may only be connected to the supply voltage
connections and to the signal contact with the Safety Extra-Low
Voltages (SELV) in compliance with IEC950/ EN60950/
VDE0805.
WARNING
Substitution of components may impair suitability for Class I,
Division 2, and Zone 2. These devices must be supplied by an
SELV source as defined in Low Voltage Directive 73/23/EEC
and 93/68/EEC.
WARNING
This unit is a built-in type. When the unit is installed in another
p
iece of equipment, the equipment enclosing the unit must
comply with fire enclosure regulation IEC 60950/EN60950 (or
similar regulation).
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your Moxa EtherDevice Switch.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
You should also pay attention to the following items:
yUse separate paths to route wiring for power and devices. If power wiring
and device wiring paths must cross, make sure the wires are perpendicular
at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring in
the same wire conduit. To avoid interference, wires with different signal
characteristics should be routed separately.
yYou can use the type of signal transmitted through a wire to determine
which wires should be kept separate. The rule of thumb is that wiring that
shares similar electrical characteristics can be bundled together.
yKeep input wiring and output wiring separated.
yIt is strongly advised that you label wiring to all devices in the system when
necessary.

- 10 -
Grounding Moxa EtherDevice Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Alarm Contact
The Alarm Contact consists of the two middle contacts of the terminal block on
EDS’s top panel. You may refer to the next section for detailed instructions on
how to connect the wires to the terminal block connector, and how to attach the
terminal block connector to the terminal block receptor. In this section, we
explain the meaning of the two contacts used to connect the Alarm Contact.
FAULT
FAULT
Top View
Front View
FAULT: The two middle contacts of the 6-contact
terminal block connector are used to detect both
power faults and port faults. The two wires
attached to the Fault contacts form an open circuit
when:
1. The EDS has lost power from one of the DC
power inputs.
OR
2. One of the ports for which the corresponding
PORT ALARM DIP Switch is set to ON is not
properly connected.
If neither of these two conditions is satisfied, the
Fault circuit will be closed.
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact terminal
block connector on the EDS’s top panel are used for the EDS’s two DC inputs.
Top and front views of one of the terminal block connectors are shown here.
Top View
Front View
STEP 1: Insert the negative/positive DC wires
into the V-/V+ terminals.
STEP 2: To keep the DC wires from pulling
loose, use a small flat-blade screwdriver to tighten
the wire-clamp screws on the front of the terminal
block connector.
STEP 3: Insert the plastic terminal block
connector prongs into the terminal block receptor,
which is located on the EDS’s top panel.

- 11 -
ATTENTION
Before connecting the EDS to the DC power inputs, make sure
the DC power source voltage is stable.
Communication Connections
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the EDS’s front panel are used to
connect to Ethernet-enabled devices.
Below we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports, and also show cable wiring diagrams for
straight-through and cross-over Ethernet cables.
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin Signal Pin Signal
1 Tx+ 1 Rx+
2 Tx- 2 Rx-
3 Rx+ 3 Tx+
6 Rx- 6 Tx-
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring
Straight-Through Cable
RJ45 Plug Pin 1
Switch Port
RJ45
Connector RJ45 Connecto
r
Tx+
Tx-
Rx+
Rx-
NIC Port
Cable Wiring
3 3
6 6
1 1
2 2
Rx+
Rx-
Tx+
Tx-
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
Cross-Over Cable
RJ45 Plug Pin 1
Switch Port
(NIC Port)
RJ45
Connector RJ45 Connector
Tx+
Tx-
Rx+
Rx-
(Rx+)
(Rx-)
(Tx+)
(Tx-)
(Tx+)
(Tx-)
(Rx+)
(Rx-)
Switch Port
(NIC Port)
Cable Wiring
3 1
6 2
1 3
2 6
Rx+
Rx-
Tx+
Tx-
100BaseFX Ethernet Port Connection
The concept behind the SC/ST port and cable is quite straightforward. Suppose
you are connecting devices I and II. Contrary to electrical signals, optical
signals do not require a circuit in order to transmit data. Consequently, one of
the optical lines is used to transmit data from device I to device II, and the
other optical line is used transmit data from device II to device I, for
full-duplex transmission.
1 8

- 12 -
All you need to remember is to connect the Tx (transmit) port of device I to the
Rx (receive) port of device II, and the Rx (receive) port of device I to the Tx
(transmit) port of device II. If you make your own cable, we suggest labeling
the two sides of the same line with the same letter (A-to-A and B-to-B, as
shown below, or A1-to-A2 and B1-to-B2).
SC-Port Pinouts SC-Port to SC-Port Cable Wiring
Tx
Rx
AA
BB
Cable Wiring
A A
B B
ST-Port Pinouts ST-Port to ST-Port Cable Wiring
Tx
Rx
AA
B
Cable Wiring
A A
B B
B
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the Laser Beam.
Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power sources.
If one power source fails, the other live source acts as a backup, and
automatically supplies all of EDS-308/309’s power needs.
Alarm Contact
The Moxa EtherDevice Switch has one Alarm Contact located on the top panel.
For detailed instructions on how to connect the Alarm Contact power wires to
the two middle contacts of the 6-contact terminal block connector, see the
Wiring the Alarm Contact section on page 8. A typical scenario would be to
connect the Fault circuit to a warning light located in the control room. The
light can be set up to switch on when a fault is detected.
The Alarm Contact has two terminals that form a Fault circuit for connecting to
an alarm system. The two wires attached to the Fault contacts form an open
circuit when (1) EDS has lost power from one of the DC power inputs, or (2)
one of the ports for which the corresponding PORT ALARM DIP Switch is set
to ON is not properly connected.
If neither of these two conditions occurs, the Fault circuit will be closed.

- 13 -
DIP Switch Settings
EDS-308 Series DIP Switches EDS-309 Series DIP Switches
12345678
ON DIP
ON DIP
123456789
ON: Enables the corresponding PORT Alarm. If the port’s link fails, the relay
will form an open circuit and the fault LED will light up.
Off: Disables the corresponding PORT Alarm. The relay will form a closed
circuit and the Fault LED will never light up.
LED Indicators
The front panel of the Moxa EtherDevice Switch contains several LED
indicators. The function of each LED is described in the table below.
LED Color State Description
PWR1 AMBER On Power is being supplied to power input
PWR1
Off Power is not being supplied to power
input PWR1
PWR2 AMBER On Power is being supplied to power input
PWR2
Off Power is not being supplied to power
input PWR2
FAULT RED
On When the corresponding PORT alarm is
enabled, and the port’s link is inactive.
Off
When the corresponding PORT alarm is
enabled and the port’s link is active, or
when the corresponding PORT alarm is
disabled.
10M GREEN
On TP port’s 10 Mbps link is active
Blinking Data is being transmitted at 10 Mbps
Off TP Port’s 10 Mbps link is inactive
100M
(TP) GREEN
On TP port’s 100 Mbps link is active
Blinking Data is being transmitted at 100 Mbps
Off 100BaseTX Port’s link is inactive
100M
(FX) GREEN
On FX port’s 100 Mbps is active
Blinking Data is being transmitted at 100 Mbps
Off 100BaseFX port is inactive
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect EDS-308’s
10/100BaseTX ports to any kind of Ethernet device, without needing to pay
attention to the type of Ethernet cable being used for the connection. This
means that you can use either a straight-through cable or cross-over cable to
connect EDS-308/309 to Ethernet devices.

- 14 -
Switching, Filtering, and Forwarding
Each time a packet arrives at one of the switched ports, a decision is made to
either filter or forward the packet. Packets with source and destination
addresses belonging to the same port segment will be filtered, constraining
those packets to one port, and relieving the rest of the network from the need to
process them. A packet with destination address on another port segment will
be forwarded to the appropriate port, and will not be sent to the other ports
where it is not needed. Packets that are used in maintaining the operation of the
network (such as the occasional multi-cast packet) are forwarded to all ports.
EDS-308/309 operates in the store-and-forward switching mode, which
eliminates bad packets and enables peak performance to be achieved when
there is heavy traffic on the network.
Switching and Address Learning
Moxa EDS-308/309 has an address table that can hold up to 1K node addresses,
which makes it suitable for use with large networks. The address tables are
self-learning, so that as nodes are added or removed, or moved from one
segment to another, EDS-308/309 automatically keeps up with new node
locations. An address-aging algorithm causes the least-used addresses to be
deleted in favor of newer, more frequently used addresses. To reset the address
buffer, power down the unit and then power it back up.
Auto-Negotiation and Speed Sensing
All of EDS-308/309’s RJ45 Ethernet ports independently support
auto-negotiation for speeds in the 10BaseT and 100BaseTX modes, with
operation according to the IEEE 802.3u standard. This means that some nodes
could be operating at 10 Mbps, while at the same time, other nodes are
operating at 100 Mbps.
Auto-negotiation takes place when an RJ45 cable connection is made, and then
each time a LINK is enabled. EDS-308/309 advertises its capability for using
either 10 Mbps or 100 Mbps transmission speeds, with the device at the other
end of the cable expected to similarly advertise. Depending on what type of
device is connected, this will result in agreement to operate at a speed of either
10 Mbps or 100 Mbps.
If an EDS-308/309 RJ45 Ethernet port is connected to a non-negotiating device,
it will default to 10 Mbps speed and half-duplex mode, as required by the IEEE
802.3u standard.

- 15 -
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x
Forward and Filtering
Rate
148810 pps
Packet Buffer Memory 256 KB
Processing Type Store and Forward, with IEEE802.3x full duplex,
back pressure flow control
Address Table Size 1K uni-cast addresses
Latency Less than 5 μs
Interface
RJ45 Ports 10/100BaseT(X) auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
Fiber Ports 100BaseFX ports (SC/ST connector)
LED Indicators Power, Fault, 10/100
DIP Switch Port break alarm mask
Alarm Contact One relay output with current carrying capacity of
1A @ 24 VDC
Optical Fiber
Multi
mode
Single
mode, 15
Single
mode, 40
Single
mode, 80
Distance, km 5 15 40 80
Wavelength, nm 1300 1310 1310 1550
Min. TX Output, dBm -20 -15 -5 -5
Max. TX Output, dBm -14 -6 0 0
Sensitivity, dBm -34 to -30 -36 to -32 -36 to -32 -36 to -32
Recommended Diameter
(Core/Cladding) μm 50/125 9/125 9/125 9/125
(1 dB/km, 800 MHz
×
km)
Power
Input Voltage 12 to 48 VDC (EDS-308 Series), redundant inputs
12 to 45 VDC (EDS-309 Series), redundant inputs
Input Current @ 24VDC 1.1A (EDS-308 Series, EDS-309 Series)
Connection Removable “6-pin” Terminal Block
Overload Current
Protection
1.1 A (EDS-308)
1.6 A (EDS-308-M, EDS-308-S, EDS-308-MM,
EDS-308-SS, EDS-309-3M)
Reverse Polarity
Protection
Present
Mechanical
Casing IP30 protection, metal case
Dimensions 53.6 ×135 ×105 mm (W ×H ×D)
Weight 0.63 kg
Installation DIN-Rail, Wall Mounting

- 16 -
Environmental
Operating Temperature 0 to 60ºC (32 to 140ºF)
-40 to 75ºC (-40 to 167ºF) for -T models
Storage Temperature -40 to 85ºC (-40 to 185ºF)
Ambient Relative
Humidity 5 to 95% (non-condensing)
Regulatory Approvals
Safety UL60950, UL 508, CSA C22.2 No. 60950, EN60950
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C and D
ATEX Class I, Zone 2, Ex nC nL IIC T4
EMI FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
Shock IEC60068-2-27
Free Fall IEC60068-2-32
Vibration IEC60068-2-6
WARRANTY 5 years
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: [phone]
Fax: [phone]
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel: [phone]
Fax: [phone]
Moxa Europe:
Tel: [phone]
Fax: [phone]
Moxa Asia-Pacific:
Tel: [phone]
Fax: [phone]
