Alphi IP-FASTDAC User manual

IP-FASTDAC
8 channel 16 bit 2uS Digital to Ananlog Converter
With 4 Quadrant Multiplier
Industry Pack Module
REFERENCE MANUAL
801-10-000-4000
Version 1.0
June 2003
ALPHI TECHNOLOGY CORPORATION
6202 S. Maple Avenue #120
Tempe, AZ 85283 USA
Tel: [phone]
Fax: [phone]

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page ii REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
NOTICE
The information in this document has been carefully checked and is believed to be
entirely reliable. While all reasonable efforts to ensure accuracy have been taken in the
preparation of this manual, ALPHI TECHNOLOGY assumes no responsibility resulting
from omissions or errors in this manual, or from the use of information contain herein.
ALPHI TECHNOLOGY reserves the right to make any changes, without notice, to this or
any of ALPHI TECHNOLOGY’s products to improve reliability, performance, function or
design.
ALPHI TECHNOLOGY does not assume any liability arising out of the application or use
of any product or circuit described herein; nor does ALPHI TECHNOLOGY convey any
license under its patent rights or the rights of others.
ALPHI TECHNOLOGY CORPORATION
All Rights Reserved
This document shall not be duplicated, nor its contents used
for any purpose, unless express permission has been granted in advance.

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page iii REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
TABLE OF CONTENTS
1. GENERAL DESCRIPTION_______________________________________________1
1.1 INTRODUCTION________________________________________________________1
1.2 FUNCTIONAL DESCRIPTION _____________________________________________1
2. INTERNAL ORGANIZATION_____________________________________________2
2.1 IP INTERFACE _________________________________________________________2
2.1.1 IDSPACE ____________________________________________________________________ 2
2.1.2 IOSPACE ____________________________________________________________________ 3
2.1.3 INTSPACE ___________________________________________________________________ 4
2.1.4 Memory space ________________________________________________________________ 4
2.2 ANALOG OUTPUT ______________________________________________________4
3. JUMPER SETTINGS ___________________________________________________6
4. JUMPER LOCATION___________________________________________________6
5. Vref BLOCK DIAGRAM_________________________________________________6
6. OUTPUT CONNECTOR_________________________________________________7

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 1REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
1. GENERAL DESCRIPTION
1.1 INTRODUCTION
The IP-FASTDAC is a high performance DIGITAL TO ANALOG module. The IP-FASTDAC
digitizes 8 channels with 16 bits of resolution at a maximum conversion rate of 2 µS.
The primary features of the IP-FASTDAC are as follows:
•Eight channels-16 bit - 2 µS D/A converters with on-chip 4-quadrant multiplication
resistors for accurate +/-10V bipolar conversion.
•Individual buffer for each output.
•+/-10 volt outputs.
1.2 FUNCTIONAL DESCRIPTION
A functional block diagram of the IP-FASTDAC is presented below in Figure 1-1.
The IP-FASTDAC operates as a slave that is managed by the host processor on the IP bus.
The IP-FASTDAC is supported by ALPHI Technology under Windows NT by a Board
Support Package which is supplied with the card. Other documentation supplied with the
card will describe this support in full detail.
Figure 1.1: Block Diagram
XLA01 - XLA06
IP
50
C
o
n
n
e
c
t
o
r
XLA01 - XLA06
CONTROL
LOGIC
IP
50
C
o
n
n
e
c
t
o
r
CONTROL SIGNALS
EEPROM
XLD00 - XLD07
LA07 - LA11
D/A
16 bits
CH # 01
Line
buffer
D/A
16 bits
CH # 02
Line
buffer
D/A
16 bits
CH # 03
Line
buffer
D/A
16 bits
CH # 04
Line
buffer
D/A
16 bits
CH # 05
Line
buffer
D/A
16 bits
CH # 06
Line
buffer
D/A
16 bits
CH # 07
Line
buffer
D/A
16 bits
CH # 08
Line
buffer
XLD00-XLD07
XLD00 - XLD15 XLD00 - XLD15

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 2REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
2. INTERNAL ORGANIZATION
The IP-FASTDAC card is divided into different sections. Each section and its relationship to
other sections will be discussed. The IP-FASTDAC sections are:
•IP interface
•Analog Output
2.1 IP INTERFACE
2.1.1 IDSPACE
An EEPROM memory that occupies 2 Kbytes of address space is for providing information
about the module to the user. The lower address contains data related to the type of
module, revision, etc...
The Upper space can be used to store information. Only the ODD address is valid. Each IP
conforms to the IP Bus Specification and has 32 bytes of EEPROM that can be read by the
local Host to identify the IP module Manufacturer, type, revision, etc.
Left over memory (2K-32 byte) is available to the user to store information related to the
module offset gain error for eventual software correction
ID space
address Description Value
$01 ASCII “I” $49
$03 ASCII “P” $50
$05 ASCII “A” $41
$07 ASCII “H” $48
$09 Manufacturer identification $11
$0B Module type $17
$0D Revision module $0B
$0F Reserved
$11 Driver ID,low byte
$13 Driver ID,high byte
$15 Number of bytes used $0A
$17 CRC
$19-$3F User space

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 3REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
Table 2-1FLASH byte content
Address $01-$07 identifies “IPAH”. Also this identifies the EEprom beginning.
2.1.2 IOSPACE
2.1.2.1 LOCAL REGISTERS
The IP-FASTDAC module uses 8 - LTC1821 Ultra precise fast setting V-out D/A converters
from Linear Technology. A double buffered interface is used to transfer incoming data to
the output. The first 8 ($00 - $0E) addresses are used to pre-load data into the first stage of
each D/A converter. A write to the address $10 – DAC-OUT will transfer the data to the
outputs in a synchronous manner. The Next 8 ($20 - $2E) addresses are used to transfer
data directly to the output. The eight registers associated, one for each channel are located
in the I/O space.. See I/O memory map below for more details.
Offset Register Name Function
$00 Ch # 1 First register stage pre-load of D/A # 1
$02 Ch # 2 First register stage pre-load of D/A # 2
$04 Ch # 3 First register stage pre-load of D/A # 3
$06 Ch # 4 First register stage pre-load of D/A # 4
$08 Ch # 5 First register stage pre-load of D/A # 5
$0A Ch # 6 First register stage pre-load of D/A # 6
$0C Ch # 7 First register stage pre-load of D/A # 7
$0E Ch # 8 First register stage pre-load of D/A # 8
$10 DAC_OUT Analog Output update of all D/A’s
$18 DAC_RST D/A reset
$1A 8/32Mhz $1 = 8Mhz / $0 = 32Mhz IP-Clock
$20 Ch # 1 Direct transfer of Data to Output D/A # 1
$22 Ch # 2 Direct transfer of Data to Output D/A # 2
$24 Ch # 3 Direct transfer of Data to Output D/A # 3
$26 Ch # 4 Direct transfer of Data to Output D/A # 4
$28 Ch # 5 Direct transfer of Data to Output D/A # 5
$2A Ch # 6 Direct transfer of Data to Output D/A # 6
$2C Ch # 7 Direct transfer of Data to Output D/A # 7
$2E Ch # 8 Direct transfer of Data to Output D/A # 8
Table 2.1: Registers

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 4REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
8/32Mhz register
This IP is designed to run at 32Mhz default, the register address $1A can allow 8Mhz
functionality by writing a $1 to the register. See chart below for each functions wait state.
IP-Clock DAC FUNCTION Wait States
32Mhz Stage Pre-Load 2
32Mhz Analog Output Update 3
32Mhz Direct Transfer 5
8Mhz Stage Pre-Load 2
8Mhz Analog Output Update 3
8Mhz Direct Transfer 1
2.1.3 INTSPACE
Not Used.
2.1.4 Memory space
The on board EEPROM provides 2K – 32bytes space available for the user.
2.2 ANALOG OUTPUT
The IP-FASTDAC has eight analog outputs each with its own buffer.
The outputs are +/- 10 Volts.
DAC
LTC 1821 (16bit Ultra Precise, Fast Settling Vout DAC)
+/-10Volt Bipolar Offset
Input code - Binary only
2us Settling to 0.0015% for 10volt step.
1LSB Max DNL and INL over Industrial Temp range
Low Glitch Impulse: 2nV * s
Low Noise 13nV

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 5REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
+/-10Volt Bipolar Offset Code table
Digital Input
Binary Number
In DAC Register
Analog Output
Vout
MSB LSB
1111 1111 1111 1111
1000 0000 0000 0001
1000 0000 0000 0000
0111 1111 1111 1111
0000 0000 0000 0000
Vref (32,767/32,768)
Vref (1/32,768)
0 volt
-Vref (1/32,768)
- Vref
OUTPUT BUFFER
IP-FASTDAC can be configured with either a high speed, high output current (BUF634) or
High speed, low offset voltage (OPA132) input buffers. The specs are below for each
device.
BUF634 ( 250mA High-Speed Input Buffer)
High Output Current : 250mA
Slew Rate : 2000V/us
Wide Bandwidth mode : 180Mhz
Input offset: Typ. = +/- 30 mV
OPA132 ( High Speed OP-AMP)
Output Current : 4.8 mA
Slew Rate : 20V/us
Bandwidth : 8Mhz
Input offset : Typ = +/-0.25mV

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 6REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
3. JUMPER SETTINGS
The IP-FASTDAC allows the possible of configuring each DAC channel for internal or
external Vref supply. See chart below for configuration possibility. Factory default for Vref
is internal +10 volts. A +5volt internal Vref can be accommodated upon request.
DAC
Channel Internal Vref supply +10v External Voltage supply
DAC1 W8 = 1-2 W8 = 2-3
DAC2 W7 = 1-2 W7 = 2-3
DAC3 W6 = 1-2 W6 = 2-3
DAC4 W5 = 1-2 W5 = 2-3
DAC5 W4 = 1-2 W4 = 2-3
DAC6 W3 = 1-2 W3 = 2-3
DAC7 W2 = 1-2 W2 = 2-3
DAC8 W1 = 1-2 W1 = 2-3
4. JUMPER LOCATION
Square pad on PCB is pin 1.
W1
W2 W3 W4
W5
W6
W7
W8
5. Vref BLOCK DIAGRAM
DAC
Vref BUF
Vin
Vout
5V or
10V
+12V
Vref- External In
I/O OUT

IP-FASTDAC REFERENCE MANUAL
ALPHI TECHNOLOGY CORP. Page 7REV 1.0
Part Number : 801-10-00-4000 Copyright ALPHI Technology Corporation, 2000
6. OUTPUT CONNECTOR
Pin Signal Pin Signal
1 26
2 27 AGND
3DAC # 1 28 AGND
4AGND 29 AGND
5DAC # 2 30 AGND
6AGND 31
7VREFX1 32 VREFX2
8 33 AGND
9DAC # 3 34 AGND
10 AGND 35 AGND
11 DAC # 4 36 AGND
12 AGND 37 VREFX4
13 VREFX3 38 VREFX6
14 VREFX5 39 AGND
15 DAC # 5 40 AGND
16 AGND 41 AGND
17 DAC # 6 42 AGND
18 AGND 43
19 VREFX7 44 VREFX8
20 45 AGND
21 DAC # 7 46 AGND
22 AGND 47 AGND
23 DAC # 8 48 AGND
24 AGND 49
25 50
