Alpine ACF100 Assembly instructions

Installation and Wiring Instructions
Inline Axial Fan
Models: ACF100, ACF150 and ACF200
PLEASE READ AND SAVE THESE INSTUCTIONS
AND WARRANTEE INFORMATION

Inline Axial Fan Installation and Wiring Instructions
Thank you for your selecting our Alpine Ventilation axial inline fan. Please read all of this
document before commencing installation.
This fan is fitted with a plug. Any interconnecting wiring and switches used or use
of another plug must be fitted by a licensed Electrician. The plug supplied must be
connected to a safety socket.
ENVIRONMENT
This exhaust fan is designed for indoor use (or covered outdoor use) only. It is suitable
for supply or exhaustion of air – both conditioned or un-conditioned airstreams. The
temperature range is -10°C to +45°C.
WARNING
1. Use this fan only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons. If you have any
questions, contact the manufacturer or local agent.
2. All wiring must be carried out by a licensed Electrician in accordance with all
applicable National / local codes and safety standards including the Building Code of
Australia. Also check with the local council regulation regarding installation of this fan.
3. Make sure the power is OFF before installation.
4. When locating into the ceiling or wall, do not damage electrical wiring and other
hidden utilities.
5. The fan must be properly earthed.
6. For the purpose of avoiding any dangerous gas leaking into your room, the ventilation
duct of the fan must not be connected with any ducting that exhausts smoke or
fumes from an appliance that uses gas or any other type of fuel.
7. Make sure that the building has sufficient air intakes to assure adequate air
circulation.
8. Fan must always vent air outdoors.
9. The fan must be isolated from the power by means of a plug or all-pole
disconnection switch with a contact separation of at least 3mm in each pole.
10. The power cable must withstand a minimum 10A load.
11. The fan is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
12. Young children should be supervised by a responsible person to ensure that they do
not play with the appliance.
13. Make sure there are no loose elements near the fan, as they could potentially be
sucked up by it. If the fan is going to be installed in ducting, check that ducting is clean
of any particulate that could be sucked up by the fan.

Inline Axial Fan Installation and Wiring Instructions
APPLICATIONS
This axial fan is designed for multiple purposes, including:
- Exhausting air from bathrooms, toilets, laundries
- Air transfer from room to room and
- Exhausting air from cavities such as roofs or sub floor
INSTALLATION
The fan is suitable for mounting in any orientation – horizontal or vertical. Before
installing, ensure that the impeller turns freely and is free of any obstruction. DO NOT
OPERATE THE FAN IF DAMAGED. If installing into a socket, ensure that it is located an
appropriate distance from the fan. Note the WARNING section on the previous page.
1. Ducting
Put two ends of a 100/150/200 mm diameter ducting (not supplied) onto the neck
of this fan using a duct tape and/or steel worm clamps.
2. Locating the unit
Use suitable screws (not supplied) to fasten this unit in the ceiling space or wall.
Secure at all 4 points. Ensure that screws are installed away from any wiring or
other hazards.
3. Wiring (Ensure the mains power is turned off)
Please comply with the local wiring regulations when wiring. Wire the unit as
per the wiring diagram or plug in.
Note: The shortest, smooth surface ventilation duct with the least bends will provide
optimum fan performance. Please keep ducting as straight as possible.
USE
Running the fan can exhaust air in a quick and efficient way.
Note: Shut off power urgently if any abnormalities occur in operation. Then call your
local licensed electrician for inspection or necessary service work.
It is absolutely prohibited to insert finger or any object into the impeller to avoid injuries
or damage the fan.

Inline Axial Fan Installation and Wiring Instructions
MAINTENANCE
1. We recommend an annual inspection to ensure there is no excessive accumulation
of dirt or dust on the impeller.
2. Before cleaning or maintenance, shut off power and disconnect from the
mains supply.
3. Prevent the possibility of anyone else connecting the power while maintenance is
being undertaken.
4. Clean with a damp (not wet) cloth. Do not use abrasive or detergent cleaning
products.
5. All maintenance and repair work must be carried out by a licensed Electrician
in accordance with all applicable National / local codes and safety standards.
DIAGRAM AND DIMENSIONS*
Model A B C D E F
ACF100 168.5 38.5 98 137.8 98 119.5
ACF150 201.5 51.5 146 185.5 146 172
ACF200 210 60 197 227 197 207
*Dimensions are in mm.
201.5
E
F
201.5
B
A
C D

Inline Axial Fan Installation and Wiring Instructions
TECHNICAL SPECIFICATIONS
Model ACF100 ACF150 ACF200
Input Voltage 240v 240v 240v
Frequency 50Hz 50Hz 50Hz
Wattage 26w 46w 70w
Duct Size 100mm (4”) 150mm (6”) 200mm (8”)
IP Rating IP22 IP22 IP22
Pressure 58Pa 118Pa 97Pa
Max Air Flow 41 L/S,
149 m3/H
92 L/S,
330 m3/H
159L/s,
571 m3/H
Electrical Classification Class 1 Class 1 Class 1
Suitability Indoor or covered
outdoor
Indoor or covered
outdoor
Indoor or covered
outdoor
LIST OF COMPONENTS SUPPLIED
Inline fan 1 piece
Installation instruction 1 piece
Power cable with plug (connected) 1 set

Inline Axial Fan Installation and Wiring Instructions
WARRANTY
This fan is warranted against defects in manufacturing and workmanship for a
period of 3 years. The warranty does not extend to installation of the unit or any
associated wiring or any damage caused by installation or wiring.
The installation must be conducted by a licensed electrician and a suitable
certificate of safety is to be issued by the electrician who installed it. Warranty
claims will be voided unless a certificate of safety can be produced when
required, prior to service or repair.
The warranty does not cover damages or loss caused by
1. Any consequential losses arising from incorrect installation or operation or
maintenance of this product.
2. Any consequential losses arising from incorrect wiring of this product
3. Any modifications or changes make to the unit, other than those
recommended by the Manufacturer.
4. An accident or damage caused to the fan after purchase
Note that general wear and tear is not covered by the warranty.
Please ensure that your installer also reads this information.
Proof of purchase of the fan is required.
If you consider there are faults relating to the installation, contact your installer to
rectify. If you consider there is a manufacturing defect to the fan, contact Partner
Pacific on [phone] or email enquiries@partnerpacific.com with
the following information.
ACCC STATEMENT
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to our dealers replacing the product in home
with parts and labor for a major failure. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.

Inline Axial Fan Installation and Wiring Instructions
IMPORTANT
WARRANTY INFORMATION
ON REVERSE SIDE
DO NOT DISCARD
PURCHASE RECORD FOR YOUR REFERENCE
PLEASE FILL IN THIS CARD PRIOR TO FAN INSTALLATION.
INFORMATION IS MANDATORY IN CASE OF WARRANTY CLAIM.
BRAND: .........................................................................
MODEL NUMBER:................................................................
SERIAL/BATCH NUMBER:.........................................................
DATE OF PURCHASE:.............................................................
PURCHASED FROM:..............................................................
INSTALLED BY ELECTRICIAN (IF APPLICABLE)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICIAN LICENCE NUMBER (IF APPLICABLE)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have any queries about the products, please contact us
(03 9758 7844 or enquiries@partnerpacific.com) or your local dealer.
