Overview 1
2015.06.26
UG-01170 Subscribe Send Feedback
The Arria®10 GX FPGA development board provides a hardware platform for evaluating the
performance and features of the Altera®Arria 10 GX device.
General Description
Figure 1-1: Overview of the Development Board Features
©2015 Altera Corporation. All rights reserved. ALTERA, ARRIA, CYCLONE, ENPIRION, MAX, MEGACORE, NIOS, QUARTUS and STRATIX words and logos are
trademarks of Altera Corporation and registered in the U.S. Patent and Trademark Office and in other countries. All other words and logos identified as
trademarks or service marks are the property of their respective holders as described at www.altera.com/common/legal.html. Altera warrants performance
of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any
products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information,
product, or service described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device
specifications before relying on any published information and before placing orders for products or services.
ISO
9001:2008
Registered
www.altera.com
101 Innovation Drive, San Jose, CA 95134

Figure 1-2: Arria 10 GX Block Diagram
FMC
Altera LPC+
x69
CLKIN x8
REFCLK x2
XCVR x16
XCVR x8
x8 XCVRs
PCI Express 128MB
FLASH x32
(FPGA)
CPLD
MAX V
x8 Config
Oscillators
50M, 125M,
Programmable
x1 (SE)
Buttons
Switches
LEDs
x4
x8
x16
x15
Micro-
USB
2.0
JTAG Chain
SMA CLK
IN
NF5-1932C Package
10AX115N2F45
x32
x19 USB Interface
x4
HiLO
External
Memory
x136
x3 LCD
ENET FPGA
(SGMII) x8
EPCQ
On-Board
USB Blaster TM II
& USB Interface
FMC
Altera LPC+
x69
CLKIN x8
REFCLK x2
XCVR x16
x66
x1(PCML)
SMA XCVR
OUT
x1
SMA CLK
OUT
QSFP x23
SFP+ x12
Display Port
(TX) x15
Arria 10 GX
FPGA
MAX II
Related Information
Board Components on page 5-1
For details on the board components.
Recommended Operating Conditions
• Recommended ambient operating temperature range: 0C to 45C
• Maximum ICC load current: 80A
• Maximum ICC load transient percentage: 35%
• FPGA maximum power supported by the supplied heatsink/fan: 100W
1-2 Recommended Operating Conditions UG-01170
2015.06.26
Altera Corporation Overview
Send Feedback

Handling the Board
When handling the board, it is important to observe static discharge precautions.
Caution: Without proper anti-static handling, the board can be damaged. Therefore, use anti-static
handling precautions when touching the board.
UG-01170
2015.06.26 Handling the Board 1-3
Overview Altera Corporation
Send Feedback

Getting Started 2
2015.06.26
UG-01170 Subscribe Send Feedback
Installing the Subscription Edition Software
The Quartus II Subscription Edition Software provides the necessary tools used for developing hardware
and software for Altera devices.
Included in the Quartus II Subscription Edition Software are the Quartus II software, the Nios II EDS, and
the MegaCore IP Library. To install the Altera development tools, download the Quartus II Subscription
Edition Software from the Quartus II Subscription Edition Software page of the Altera website. Alterna‐
tively, you can request a DVD from the Altera IP and Software DVD Request Form page of the Altera
website.
Related Information
Quartus II Subscription Edition Software page
Activating Your License
Purchasing this kit entitles you to a one-year license for the Development Kit Edition (DKE) of the
Quartus II software. After the year, your DKE license will no longer be valid and you will not be permitted
to use this version of the Quartus II software. To continue using the Quartus II software, you should
download the free Quartus II Web Edition or purchase a subscription to Quartus II software.
Before using the Quartus II software, you must activate your license, identify specific users and
computers, and obtain and install a license file. If you already have a licensed version of the subscription
edition, you can use that license file with this kit. If not, follow these steps:
1. Log on at the myAltera Account Sign In web page, and click Sign In.
2. On the myAltera Home web page, click the Self-Service Licensing Center link.
3. Locate the serial number printed on the side of the development kit box below the bottom bar code.
The number consists of alphanumeric characters and does not contain hyphens.
4. On the Self-Service Licensing Center web page, click the Find it with your License Activation Code
link.
5. In the Find/Activate Products dialog box, enter your development kit serial number and click Search.
©2015 Altera Corporation. All rights reserved. ALTERA, ARRIA, CYCLONE, ENPIRION, MAX, MEGACORE, NIOS, QUARTUS and STRATIX words and logos are
trademarks of Altera Corporation and registered in the U.S. Patent and Trademark Office and in other countries. All other words and logos identified as
trademarks or service marks are the property of their respective holders as described at www.altera.com/common/legal.html. Altera warrants performance
of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any
products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information,
product, or service described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device
specifications before relying on any published information and before placing orders for products or services.
ISO
9001:2008
Registered
www.altera.com
101 Innovation Drive, San Jose, CA 95134

6. When your product appears, turn on the check box next to the product name.
7. Click Activate Selected Products, and click Close.
8. When licensing is complete, Altera emails a license.dat file to you. Store the file on your computer and
use the License Setup page of the Options dialog box in the Quartus II software to enable the software.
Related Information
•Altera Software Installation and Licensing
Comprehensive information for installing and licensing Altera software.
•myAltera Account Sign In web page
Installing the Development Kit
1. Download the Arria 10 FPGA Development Kit installer from the Arria 10 FPGA Development Kit
page of the Altera website. Alternatively, you can request a development kit DVD from the Altera Kit
Installations DVD Request Form page of the Altera website.
2. Run the Arria 10 FPGA Development Kit installer.
3. Follow the on-screen instructions to complete the installation process. Be sure that the installation
directory you choose is in the same relative location to the Quartus II software installation.
The installation program creates the development kit directory structure shown in the following figure.
Figure 2-1: Installed Development Kit Directory Structure
<install dir>
documents
board_design_files
The default Windows installation directory is C:\altera\<version>\.
examples
factory_recovery
demos
kits
<device name>
Table 2-1: Installed Directory Contents
Directory Name Description of Contents
board_design_files Contains schematic, layout, assembly, and bill of material board design files.
Use these files as a starting point for a new prototype board design.
demos Contains demonstration applications when available.
documents Contains the documentation.
examples Contains the sample design files for this kit.
2-2 Installing the Development Kit UG-01170
2015.06.26
Altera Corporation Getting Started
Send Feedback

Directory Name Description of Contents
factory_recovery Contains the original data programmed onto the board before shipment. Use
this data to restore the board with its original factory contents.
Installing the USB-Blaster Driver
The development board includes integrated USB-Blaster circuitry for FPGA programming. However, for
the host computer and board to communicate, you must install the On-Board USB-Blaster II driver on
the host computer.
Installation instructions for the On-Board USB-Blaster II driver for your operating system are available on
the Altera website. On the Altera Programming Cable Driver Information page of the Altera website,
locate the table entry for your configuration and click the link to access the instructions.
Related Information
Altera Programming Cable Driver Information
Click on the link for your operating system.
UG-01170
2015.06.26 Installing the USB-Blaster Driver 2-3
Getting Started Altera Corporation
Send Feedback

Development Board Setup 3
2015.06.26
UG-01170 Subscribe Send Feedback
This section describes how to apply power to the board and provides default switch and jumper settings.
Applying Power to the Board
This development kit ships with its board switches preconfigured to support the design examples in the
kit.
If you suspect that your board might not be currently configured with the default settings, follow the
instructions in the Default Switch and Jumper Settings section of this chapter.
1. The development board ships with design examples stored in the flash memory device. To load the
design stored in the factory portion of flash memory, verify SW6.4 is set to OFF. This is the default
setting.
2. Connect the supplied power supply to an outlet and the DC Power Jack (J13) on the FPGA board.
Caution: Use only the supplied power supply. Power regulation circuitry on the board can be
damaged by power supplies with greater voltage.
3. Set the power switch (SW1) to the on position.
When the board powers up, the parallel flash loader (PFL) on the MAX V reads a design from flash
memory and configures the FPGA. When the configuration is complete, green LEDs illuminate signaling
the device configured successfully. If the configuration fails, the red LED illuminates.
©2015 Altera Corporation. All rights reserved. ALTERA, ARRIA, CYCLONE, ENPIRION, MAX, MEGACORE, NIOS, QUARTUS and STRATIX words and logos are
trademarks of Altera Corporation and registered in the U.S. Patent and Trademark Office and in other countries. All other words and logos identified as
trademarks or service marks are the property of their respective holders as described at www.altera.com/common/legal.html. Altera warrants performance
of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any
products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information,
product, or service described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device
specifications before relying on any published information and before placing orders for products or services.
ISO
9001:2008
Registered
www.altera.com
101 Innovation Drive, San Jose, CA 95134

Default Switch and Jumper Settings
This topic shows you how to restore the default factory settings and explains their functions.
Caution: Do not install or remove jumpers (shunts) while the development board is powered on.
Figure 3-1: Default Switch and Jumper Settings on the Top
FMCBFMCA
SW3
PRSNTn
ON
1 2 3 4
X1
X4
X8
FMCB
VCCIO
1.8V
1.5V
1.35V
FMCA
J11 J8
Note for J11 & J 8:
No shunt = 1.2V
1.35V
1.5V
1.8V
3-2 Default Switch and Jumper Settings UG-01170
2015.06.26
Altera Corporation Development Board Setup
Send Feedback

Figure 3-2: Default Switch Settings on the Bottom
SW5
ON
1 2 3 4
MSEL0
MSEL1
MSEL2
VIDEN
SW4
CLK_SEL
CLK_EN
Si516_FS
FACTORY
RZQ_B2K
ON
1
1 0 1 0
2 3 4
ARRIA 10
MAX V
FMCA
FMCB
SW6
ON
1 2 3 4 5
1. Set DIP switch bank (SW3) to match the following table.
Table 3-1: SW3 DIP PCIe Switch Default Settings (Board Top)
Switch Board Label Function Default Position
1 x1 ON for PCIe x1 ON
2 x4 ON for PCIe x4 ON
3 x8 ON for PCIe x8 ON
4 — OFF for 1.35 V MEM_VDD power rail OFF
2. If all of the jumper blocks are open, the FMCA and FMCB VCCIO value is 1.2 V. To change that value,
add shunts as shown in the following table.
Table 3-2: Default Jumper Settings for the FPGA Mezzanine Card (FMC) Ports (Board Top)
Board Reference Board Label Description
J8 pins 1-2 1.35V 1.35 V FMCB VCCIO select
J8 pins 3-4 1.5V 1.5 V FMCB VCCIO select
J8 pins 5-6 1.8V 1.8 V FMCB VCCIO select
J11 pins 1-2 1.35V 1.35 V FMCA VCCIO select
UG-01170
2015.06.26 Default Switch and Jumper Settings 3-3
Development Board Setup Altera Corporation
Send Feedback

Board Reference Board Label Description
J11 pins 3-4 1.5V 1.5 V FMCA VCCIO select
J11 pins 5-6 1.8V 1.8 V FMCA VCCIO select
3. Set DIP switch bank (SW4) to match the following table.
Table 3-3: SW4 JTAG DIP Switch Default Settings (Board Bottom)
Switch Board Label Function Default Position
1 ARRIA 10 OFF to enable the Arria 10 in the JTAG chain OFF
2 MAX V OFF to enable the MAX V in the JTAG chain OFF
3 FMCA ON to bypass the FMCA connector in the JTAG
chain ON
4 FMCB ON to bypass the FMCB connector in the JTAG
chain ON
4. Set DIP switch bank (SW5) to match the following table.
Table 3-4: SW5 DIP Switch Default Settings (Board Bottom)
Switch Board Label Function Default Position
1 MSEL0 ON for MSEL0 = 1; for FPP standard mode OFF
2 MSEL1 ON for MSEL1 = 0; for FPP standard mode ON
3 MSEL2 ON for MSEL2 = 0; for FPP standard mode ON
4 VIDEN OFF for enabling VID_EN for the Smart Voltage ID
(SmartVID) feature ON
5. Set DIP switch bank (SW6) to match the following table.
Table 3-5: SW6 DIP Switch Default Settings (Board Bottom)
Switch Board Label Function Default Position
1 CLK_SEL ON for 100 MHz on-board clock oscillator
selection
OFF for SMA input clock selection
ON
2 CLK_EN OFF for setting CLK_ENABLE signal high to the
MAV V OFF
3 Si516_FS ON for setting the SDI REFCLK frequency to
148.35 MHz
OFF for setting the SDI REFCLK frequency to
148.5 MHz
OFF
3-4 Default Switch and Jumper Settings UG-01170
2015.06.26
Altera Corporation Development Board Setup
Send Feedback

Switch Board Label Function Default Position
4 FACTORY ON to load user hardware1 from flash
OFF to load factory from flash
OFF
5 RZQ_B2K ON for setting RZQ resistor of Bank 2K to 99.17
ohm
OFF for setting RZQ resistor of Bank 2K to 240
ohm
OFF
UG-01170
2015.06.26 Default Switch and Jumper Settings 3-5
Development Board Setup Altera Corporation
Send Feedback

Board Test System 4
2015.06.26
UG-01170 Subscribe Send Feedback
This kit includes an application called the Board Test System (BTS).
The BTS provides an easy-to-use interface to alter functional settings and observe the results. You can use
the BTS to test board components, modify functional parameters, observe performance, and measure
power usage. While using the BTS, you reconfigure the FPGA several times with test designs specific to
the functionality you are testing.
Figure 4-1: Board Test System GUI
©2015 Altera Corporation. All rights reserved. ALTERA, ARRIA, CYCLONE, ENPIRION, MAX, MEGACORE, NIOS, QUARTUS and STRATIX words and logos are
trademarks of Altera Corporation and registered in the U.S. Patent and Trademark Office and in other countries. All other words and logos identified as
trademarks or service marks are the property of their respective holders as described at www.altera.com/common/legal.html. Altera warrants performance
of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any
products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information,
product, or service described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device
specifications before relying on any published information and before placing orders for products or services.
ISO
9001:2008
Registered
www.altera.com
101 Innovation Drive, San Jose, CA 95134

Several designs are provided to test the major board features. Each design provides data for one or more
tabs in the application. The Configure menu identifies the appropriate design to download to the FPGA
for each tab.
After successful FPGA configuration, the appropriate tab appears that allows you to exercise the related
board features. Highlights appear in the board picture around the corresponding components
The BTS communicates over the JTAG bus to a test design running in the FPGA. The Board Test System
and Power Monitor share the JTAG bus with other applications like the Nios II debugger and the
SignalTap®II Embedded Logic Analyzer. Because the Quartus II programmer uses most of the bandwidth
of the JTAG bus, other applications using the JTAG bus might time out. Be sure to close the other applica‐
tions before attempting to reconfigure the FPGA using the Quartus II Programmer.
Preparing the Board
With the power to the board off, follow these steps:
1. Connect the USB cable to your PC and the board.
2. Ensure that the Ethernet patch cord is plugged into the RJ-45 connector.
3. Check the development board switches and jumpers are set according to your preferences. See the
“Factory Default Switch and Jumper Settings” section.
4. Set the load selector switch (SW6.4) to OFF for user hardware1 (page #1).
The development board ships with the CFI flash device preprogrammed with a default:
• Factory FPGA configuration for running the Board Update Portal design example
• User configuration for running the Board Test System demonstration
5. Turn on the power to the board. The board loads the design stored in the user hardware1 portion of
flash memory into the FPGA. If your board is still in the factory configuration, or if you have
downloaded a newer version of the Board Test System to flash memory through the Board Update
Portal, the design loads the GPIO, Ethernet, and flash memory tests.
To ensure operating stability, keep the USB cable connected and the board powered on when running
the demonstration application. The application cannot run correctly unless the USB cable is attached
and the board is on.
Related Information
Default Switch and Jumper Settings on page 3-2
Running the Board Test System
To run the Board Test System (BTS), navigate to the <install dir> \kits\<device name>\examples\board_test_
system directory and run the BoardTestSystem(32-bit).exe or BoardTestSystem(64-bit).exe application.
On Windows, you can also run the BTS from the Start > All Programs > Altera menu.
A GUI appears, displaying the application tab that corresponds to the design running in the FPGA. The
development board’s flash memory ships preconfigured with the design that corresponds to the GPIO tab.
4-2 Preparing the Board UG-01170
2015.06.26
Altera Corporation Board Test System
Send Feedback

Note: The BTS relies on the Quartus II software's specific library. Before running the BTS, open the
Quartus II software. It sets the environment variable $QUARTUS_ROOTDIR automatically. The Board
Test System uses this environment variable to locate the Quartus II library.
UG-01170
2015.06.26 Running the Board Test System 4-3
Board Test System Altera Corporation
Send Feedback

Using the Board Test System
This section describes each control in the Board Test System application.
Using the Configure Menu
Use the Configure menu to select the design you want to use. Each design example tests different board
features. Choose a design from this menu and the corresponding tabs become active for testing.
Figure 4-2: The Configure Menu
To configure the FPGA with a test system design, perform the following steps:
1. On the Configure menu, click the configure command that corresponds to the functionality you wish
to test.
2. In the dialog box that appears, click Configure to download the corresponding design to the FPGA.
3. When configuration finishes, close the Quartus II Programmer if open. The design begins running in
the FPGA. The corresponding GUI application tabs that interface with the design are now enabled.
If you use the Quartus II Programmer for configuration, rather than the Board Test System GUI, you may
need to restart the GUI.
4-4 Using the Board Test System UG-01170
2015.06.26
Altera Corporation Board Test System
Send Feedback

The System Info Tab
The System Info tab shows the board’s current configuration. The tab displays the contents of the MAX V
registers, the JTAG chain, the board’s MAC address, the Qsys memory map, and other details stored on
the board.
Figure 4-3: The System Info Tab
Table 4-1: Controls on the System Info Tab
Controls Description
Board Information Controls The board information is updated once the GPIO design is configured.
Otherwise, this control displays the default static information about
your board.
Board Name Indicates the official name of the board, given by the Board Test
System.
Board P/N Indicates the part number of the board.
Serial Number Indicates the serial number of the board.
UG-01170
2015.06.26 The System Info Tab 4-5
Board Test System Altera Corporation
Send Feedback

Controls Description
Factory Test Version Indicates the version of the Board Test System currently running on
the board.
MAC Indicates the MAC address of the board.
MAX V Control Allows you to view and change the current register values, which take
effect immediately:
System Reset (SRST) — Write only. Click to reset the FPGA.
Page Select Override (PSO) — Read/Write
Page Select Register (PSR) — Read/Write
Page Select Switch (PSS) — Read only
MAX Ver: Indicates the version of MAX V code currently running on
the board.
JTAG Chain Shows all the devices currently in the JTAG chain.
Qsys Memory Map Shows the memory map of the Qsys system on your board.
4-6 The System Info Tab UG-01170
2015.06.26
Altera Corporation Board Test System
Send Feedback
