Altimium MATF16 User manual

MATF16
Single Plug-in Card Matrix Switcher
All Rights Reserved
Version: MATF16_2016V1.0
User Manual

Single Plug-in Card Matrix Switcher
Altimium www.altimium.com
Preface
Read this user manual carefully before using this product. Pictures shown in this manual
is for reference only, different model and specifications are subject to real product.
This manual is only for operation instruction only, not for any maintenance usage. The
functions described in this version are updated till December 2016. Any changes of
functions and parameters since then will be informed separately. Please refer to the
dealers for the latest details.
All product function is valid till 2016-12-5.
Trademarks
Product model and its logo are trademarks. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

Single Plug-in Card Matrix Switcher
Altimium www.altimium.com
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

Single Plug-in Card Matrix Switcher
Altimium www.altimium.com
Contents
1. Introduction.................................................................................................................1
1.1 Introduction to MATF16 .....................................................................................1
1.2 Features ............................................................................................................1
1.3 Package List......................................................................................................1
2. Panel Description........................................................................................................2
2.1 Front Panel........................................................................................................2
2.2 Rear Panel.........................................................................................................4
2.3 Signal Cards......................................................................................................5
2.3.1 I-UH& O-UH.............................................................................................5
2.3.2 I-BT& O-BT..............................................................................................6
3. System Connection.....................................................................................................8
3.1 Usage Precautions............................................................................................8
3.2 System Diagram................................................................................................8
3.3 Connection Procedures.....................................................................................9
3.4 Application.........................................................................................................9
4. Operations................................................................................................................10
4.1 Front Panel Control .........................................................................................10
4.1.1 Switching I/O connection.......................................................................10
4.1.2 EDID Learning.......................................................................................10
4.1.3 Inquiry....................................................................................................11
4.1.4 Clear operation......................................................................................11
4.2 IR Control ........................................................................................................12
4.3 RS232 Control.................................................................................................12
4.3.1 Installation/uninstallation of RS232 Control Software............................12
4.3.2 Basic Settings........................................................................................12
4.3.3 RS232 Communication Commands ......................................................14
4.4 TCP/IP Control.................................................................................................22
4.4.1 Control Modes.......................................................................................22
4.4.2 Control via TCP/IP communication software .........................................23
4.4.3 Control via web-based GUI....................................................................24

Single Plug-in Card Matrix Switcher
Altimium www.altimium.com
4.4.3.1. Switch Control............................................................................27
4.4.3.2. System Setting ...........................................................................28
4.4.4 Port Management..................................................................................32
4.5 Firmware Upgrade...........................................................................................33
5. Specification .............................................................................................................35
5.1 Main Unit .........................................................................................................35
5.1.1 I-UH& O-UH...........................................................................................35
5.1.2 I-BT& O-BT............................................................................................35
6. Panel Drawing ..........................................................................................................37
7. Troubleshooting & Maintenance ...............................................................................38
8. After-sales Service....................................................................................................39

Single Plug-in Card Matrix Switcher
Altimium 1 www.altimium.com
1. Introduction
1.1 Introduction to MATF16
This product is a high-performance seamlessly AV modular matrix switcher providing 12
flexible PCIE slots for single HDMI/HDBaseT input/ output cards and 4 fixed slots for
output signal cards.
With its advanced modularization design, Freedom combination of single HDBaseT、
HDMI input/output card can make up different kinds of matrix. All the cards support
plug-and-play. It supports different video signals with seamless cross switching. Every
video or audio signal is transmitted and switched independently to decrease signal
attenuation. The switcher can handle all the audiovisual management, including the
switching, driving, scaling etc.
1.2 Features
12 card slots for flexible input/ output combination, and 4 slots for output signal
cards.
Comprehensive signal card compatibility: HDMI/HDBaseT.
Automatically recognize input/ output signal card.
Powerful EDID management.
UPnP enables quick-connection to GUI.
HDCP Compliant.
Seamless AV distribution through different AV signal.
Controllable via front panel buttons, IR, RS232 & TCP/IP.
Adjustable output resolution.
Online firmware upgrade via USB port.
1.3 Package List
1 x MATF16
4 x Plastic cushions
1 x IR Receiver
2 x Pluggable Terminal Blocks
2 x Mounting ears
1 x Power Cord
1 x IR Remote
1 x User Manual
Signal cards are sold and packed separately, all the items listed above are for the
Matrix Switcher solely. Confirm all the accessories are included, if not, please
contact with the dealers.

Single Plug-in Card Matrix Switcher
Altimium 2 www.altimium.com
2. Panel Description
2.1 Front Panel
No.
Name
Description
Description
for Touch
Screen
Touch any button to awake touch screen and white
backlight will appear. If without any operations within 8 seconds,
touch screen will enter sleep mode and the white backlight will
goes out.
Note: Due to the buttons may not be able to touch successfully;
the touch screen will not be awakened. In this case, please refer
to the shown below to slide your finger left and right.
When the touch screen is awaking, press any button, the
white backlight of this buttons will turn into blue.
Press the button of IR remote, the corresponding button will
appear blue backlight.
①
LCD screen
Display real-time operation status.
②
FIRMWARE
Micro USB port, used for firmware update.
PWR
IR
INPUT 123456 7 8
1 2 3456 7 8
ALL EDID
CLEAR ENTER
9
9
0
0
ACT
MATF16
136
4
27 8
5

Single Plug-in Card Matrix Switcher
Altimium 3 www.altimium.com
③
PWR
Power indicator:
OFF: No power.
RED: Normal work.
Green: Standby.
④
ACT
RS232 Link indicator:
OFF: No RS232 serial signal.
Blinking Green: Transmit RS232 serial signal.
⑤
IR
IR indicator:
OFF: No IR signal.
Blinking red: when the built-in IR sensor receive IR signal.
⑥
INPUTS
Back-lit buttons for input selection, ranges from 0~9, 12
selectable channels in total.
⑦
OUTPUTS
Back-lit buttons for output selection, ranges from 0 ~ 9, 16
selectable channels in total.
⑧
MENU
ALL: Select all inputs/ outputs.
EDID: EDID management button, enable input port to learn the
EDID data from output devices.
CLEAR: Withdraw an operation before it comes into effect/ exit
inquiry mode.
ENTER: confirm operation/ long-press (3s or more) to enter
inquiry mode.

1) Input/ output channels are recognized as double-digit, so press channel 1~9 as
01~09, besides, the interval should not exceed 8s.
2) Operations will be automatically canceled 8s later unless pressing ENTER to
confirm.

Single Plug-in Card Matrix Switcher
Altimium 4 www.altimium.com
2.2 Rear Panel
No.
Name
Description
①
1~12
Card Slots
Flexible card slots, 12 in total, insert input/ output signal cards
here.
②
13~16
Card Slots
4 in total, insert output signal cards here.
③
RS232
Serial control port, connect with the RS232 port of control device to
control the Matrix Switcher or the 3rd party device connected to
I-BT &O-BT.
④
IR ALL IN
Input port for IR control signal, connect with IR receiver (5V, with
carrier), and work with IR emitters connected to IR OUT of far-end
HDBT receivers.
⑤
IR EYE
Connect with IR receiver (5V, with carrier) to control the switcher.
⑥
TCP/IP
TCP/IP control port, connect with control device (e.g. a PC).
⑦
Ground
Connect to grounding.
⑧
Power port
Connect with 100~240V AC outlet.
Pictures shown in this manual are only for reference.
128
34
5
6
7

Single Plug-in Card Matrix Switcher
Altimium 5 www.altimium.com
2.3 Signal Cards
The Matrix Switcher boasts 12 card slot for flexible input& output signal card
combinations, and 4 card slots for output signal cards, HDMI and HDBT signal card can
be selected, according to specific need. All the signal cards support seamless
distribution and hot-plug.
The chart below shows all signal cards:
Input
Output
Card
Ports
Card
Ports
I-UH
4K HDMI& Analog Audio
O-UH
4K HDMI& Analog Audio
I-BT
4K HDBT& Analog
Audio& RS232&IR
O-BT
4K HDBT& Analog
Audio& RS232&IR
2.3.1 I-UH& O-UH
Single 4K seamless HDMI signal card (refer to 5.2.1 for detailed specification).
HDMI2.0& HDCP2.2 compliant, capable to transmit HDMI/ DVI-I/DVI-D signal;
Auto-detect input resolution;
Max resolution: 4K×2K@60Hz;
The default output resolution is 4K×2K@30Hz and it can be adjusted via commands or
GUI, support 4K×2K@60Hz、1024×768@60Hz、1920×1080p@60Hz、1280×720@60Hz;
Support EDID Management（default EDID: 4K×2K@30Hz）and DDC communication;
Input audio source selectable via command or GUI, including HDMI embedded audio
(default), and external analog audio.
Figure 2- 1 I-UH
Figure 2- 2 O-UH
Pin layout of the HDMI connector (female).
No.
Signal
No.
Signal
1
TMDS Data 2+
11
TMDS Clock Shield
2
TMDS Data 2
Shield
12
TMDS Clock-
3
TMDS Data 2-
13
CEC
4
TMDS Data 1+
14
N.C.
5
TMDS Data 1
15
SCL

Single Plug-in Card Matrix Switcher
Altimium 6 www.altimium.com
Shield
6
TMDS Data 1-
16
SDA
7
TMDS Data 0+
17
DDC/CEC Ground
8
TMDS Data 0
Shield
18
+5V Power
9
TMDS Data 0-
19
Hot Plug Detect
10
TMDS Clock+
TMDS Clock Shield
2.3.2 I-BT& O-BT
4K seamless HDBT signal card (refer to 5.2.2 for detailed specification)
Max resolution: 4K×2K@60Hz;
Adaptive HDCP input and support HDCP2.2, the output signal support HDCP1.4;
Work with HDBTtransmitter/ receiver to attain long-distance transmission (up to 70m via
qualified CAT6 cable for 1080P or 40m for 4K signal);
Real-time work status indicator: yellow LED blinks once powered on; green LED lights
when the port is connected with HDBT devices;
HDBT port supports PoE;
Input audio source selectable via command or GUI, including HDMI embedded audio
(default), and external analog audio;
The default output resolution is 4K×2K@30Hz and it can be adjusted via commands or
GUI, support 4K×2K@60Hz、1024×768@60Hz、1920×1080p@60Hz、1280×720@60Hz;
Support bi-directional RS232 control;
Support bi-directional IR control, compatible with 5V/12V IR receiver (default: 5V);
Support EDID Management（default EDID: 4K×2K@30Hz）and DDC communication.
Figure 2- 3 I-BT
Figure 2- 4 O-BT

Single Plug-in Card Matrix Switcher
Altimium 7 www.altimium.com
Pin layout of the HDBT connector:
Pin
Color
1
orange white
2
orange
3
green white
4
blue
5
blue white
6
green
7
brown white
8
brown
Twist the pure-color cables with their
half-color cables.

Single Plug-in Card Matrix Switcher
Altimium 8 www.altimium.com
3. System Connection
3.1 Usage Precautions
1) System should be installed in a clean environment and has a prop temperature and
humidity.
2) All of the power switches, plugs, sockets and power cords should be insulated and
safe.
3) All devices should be connected before power on.
3.2 System Diagram
The following diagram illustrates typical input and output connections that can be
utilized with the Matrix Switcher:
Figure 3- 1 Connection Diagram
Note: System Diagram shown in this manual are for reference only, more specific
schemes depend on real devices.
OUT PUTS 13 ~16
AUD IO
MIC I N AU DIO OUT
R
L
MIX O UT
R
L
OUT PUT
4K
Tx Rx
R
L
IR OU T
IR IN
RS232 AUDI O
HDBaseT
OUT PUT
4K
Tx Rx
R
L
IR OU T
IR IN
RS232 AUDI O
HDBaseT
OUT PUT
4K
Tx Rx
R
L
IR OU T
IR IN
RS232 AUDI O
HDBaseT
OUT PUT
4K
Tx Rx
R
L
IR OU T
IR IN
RS232 AUDI O
HDBaseT
OUT PUT
HDMI AUDIO
L R
4K
OUT PUT
HDMI AUDIO
L R
4K
INP UT
AUDIO
L R
4K HDMI
INP UT
AUDIO
L R
4K HDMI
4K
RS232 AUDI O
Tx Rx
R
L
INP UT
IR OUT
IR IN
HDBaseT
4K
RS232 AUDI O
Tx Rx
R
L
INP UT
IR OU T
IR IN
HDBaseT
4K
RS232 AUDI O
Tx Rx
R
L
INP UT
IR OU T
IR IN
HDBaseT
4K
RS232 AUDI O
Tx Rx
R
L
INP UT
IR OUT
IR IN
HDBaseT
AUD IO
MIC I N AU DIO OUT
R
L
MIX O UT
R
L
4K 40m
4K 40m
PS4
Blu-ray
Tranmitter
HDTV
System Control
RemoteIR Receiver
Laptop
Pad Wireless Remote
Internet
Receiver
HDMI:
HDBaseT:
Control:
Audio:
VGA:
Displayer
Displayer
Tx Rx
Receiver
Projector
Laptop
4K 40m
Speaker
Speaker

Single Plug-in Card Matrix Switcher
Altimium 9 www.altimium.com
3.3 Connection Procedures
Step1.Insert necessary signal cards to the card slots.
Step2.Connect source device(s) (e.g. Blue-ray DVD) to corresponding input ports.
Step3.Connect displays to corresponding output ports.
Step4.Connect amplifier/ speaker to audio output ports.
Step5.Connect an IR Receiver to IR EYE to enable IR control.
Step6.Connect control device (e.g. a PC) to the RS232 port to enable serial control.
Step7.Connect control device (e.g. a PC) to the TCP/IP port to enable TCP/IP control.
Step8.Insert 100~240V AC outlet via the included power cord.
3.4 Application
Owing to its flexible card design, the Matrix Switcher is an all-in-one solution which is
ideal for different projects such as public display, educational demo, professional
presentation, advertising display or control center. The switcher can handle all the
audiovisual management, including the switching, driving, scaling etc.

Single Plug-in Card Matrix Switcher
Altimium 10 www.altimium.com
4. Operations
4.1 Front Panel Control
The Matrix Switcher provides with convenient front panel button control for I/O switch,
EDID management, and system inquiry. Here we make a brief introduction to the
operations.
4.1.1 Switching I/O connection
Input/ output channels are recognized in double-digit, press 01~09 for channel 1~9.
1) To convert one input to an output:
Operation: “INPUT”+“OUTPUT”+“ENTER”
Example: transfer input 1 to output 5:
INPUT：OUTPUT：
2) To convert an input to several outputs:
Operation: “INPUT” + “OUTPUT” + “OUTPUT” +… + “ENTER”
Example: Switch input 2 to output 2, 4
INPUT：OUTPUT：
3) To convert an input to all outputs:
Operation: “input” + “ALL” + “ENTER”
Example: Convert input 2 to all outputs
INPUT：
4.1.2 EDID Learning
The Matrix Switcher features EDID management to maintain compatibility between all
devices.
One input port learns the EDID data of one output port
Operation: “EDID”+“INPUT”+“OUTPUT”+“ENTER”.
Example: Input 1 learns EDID data from output 10.
INPUT：OUTPUT：

Single Plug-in Card Matrix Switcher
Altimium 11 www.altimium.com
All input ports learn EDID data from one output port
Operation: “EDID”+“ALL”+“OUTPUT”+“ENTER”
Example: All input ports learn EDID data from output 6
OUTPUT：
4.1.3 Inquiry
Press and hold the button “ENTER”for 3 seconds to enter system inquiry mode. The
chart below shows information that can be inquired:
Function Items
Description
Example
Check customer
serial
Interface shown after entering
inquiry mode, customer serial
can be changed via RS232
command.
Check output
resolution
In inquiry mode, press output
channel to check its
resolution
Correspondence
between inputs
and outputs
“OUTPUT”+ “ENTER”
4.1.4 Clear operation
Function: clear the previous operations before pressing ENTER to enforce it. Press
CLEAR can only erase the operations not confirmed by pressing ENTER.

1) Input/ output channels are recognized in double-digit, press 01~09 instead of 1~9.
2) The input delay time between two numbers of every input& output channel must be
less than 8 seconds; otherwise the operation will be cancelled.
3) The input/output channels on the rear panel are counting from left to right no matter
whether there is signal card.

Single Plug-in Card Matrix Switcher
Altimium 12 www.altimium.com
4.2 IR Control
Connect an IR receiver to IR EYE on the rear panel, users can control the switcher with
the included IR remote (shown as below):
①Standby: enter/ exit standby mode
②INPUTS: input selection buttons, channels 1~9
should be pressed as 01~09
③Function Buttons: share the same operation
with front panel buttons
④ENTER:
confirm operation
long-press (3 seconds or more) to enter
inquiry mode
Note: navigation buttons are unavailable.
⑤OUTPUTS: output selection buttons, channels
1~9 should be pressed as 01~09
4.3 RS232 Control
The Matrix Switcher provides with one RS232 port for serial port control. Connect the
Matrix Switcher to the control device (e.g. a PC) with RS232 cable and set the correct
parameters, the control device is capable to control the Matrix Switcher via designed
software.
4.3.1 Installation/uninstallation of RS232 Control Software
Installation: Copy the control software file to the computer connected with the
Matrix Switcher.
Uninstallation: Delete all the control software files in corresponding file path.
4.3.2 Basic Settings
Firstly, connect the Matrix Switcher with an input device and an output device. Then,
connect it with a computer which is installed with RS232 control software. Double-click
the software icon to run this software.

Single Plug-in Card Matrix Switcher
Altimium 13 www.altimium.com
Here we take the software CommWatch.exe as example. The icon is showed as below:
The interface of the control software is showed as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, only then will you be able to send command in Command Sending Area.
Parameter Configuration area
Monitoring area, indicates
whether the command
sent works.
Command Sending area

Single Plug-in Card Matrix Switcher
Altimium 14 www.altimium.com
4.3.3 RS232 Communication Commands

1. Case insensitive.
2. In following commands, “[”and “]” are symbols for easy reading and do not need to
be typed in actual operation.
3. Type in the complete commands including ending symbol “.” or “;”.
4. For input/ output channels 1~9 in the commands, type in 01~09 instead of 1~9.
5. After sending command “%0911.”to restore factory default, wait for 10s or so before
you reboot the device. Or the restoration may fail, and it will prompt “Default failed,
please try again!” in the feedback.
Communication Protocol: Baud rate: 9600; Data bit: 8; Stop bit: 1; Parity bit: none.
Command
Description
Feedback
System Command
/*Type;
Inquire the model
DX16
/%Lock;
Lock the front panel buttons
System Locked!
/%Unlock;
Unlock the front panel buttons
System Unlock!
/^Version;
Inquire the firmware version
VX.X.X
/:MessageOff;
Turn off the feedback from the com
port. It only shows “switcher OK”.
/:MessageOff;
/:MessageOn;
Turn on the feedback from the com
port.
/:MessageOn;
Operation Command
Undo.
Cancel the previous operation.
Undo Ok!
Demo.
Switch to the “demo” mode, 02->01,
2->2, 3->3 … and so on.
Demo Mode
AV: 02-> 01
……
[x]All.
Transfer signal from Input [x] to all
outputs
02 To All.
All@.
Switch on all the outputs
All Open.
All$.
Switch off all the outputs
All Closed.
[x]@.
Switch on output [x]
02 Open.
[x]$.
Switch off output [x]
01 Closed.

Single Plug-in Card Matrix Switcher
Altimium 15 www.altimium.com
[x1]V[x2],[x3],[x4]…
Transfer signal from input [x1] to
output [x2],[x3],[x4].., separate
output channels with “,”
AV: 01->07
AV: 01->08
…
Save[Y].
Save the present operation to the
preset command [Y], [Y]=0~9
Save To F1
Recall[Y].
Recall the preset command [Y]
Recall From F1
AV: 02->04
AV: 02->06
…
Clear[Y].
Clear the preset command [Y]
Clear F1
EDIDMInit.
Reset factory default EDID
EDIDMInit.
EDIDM[X]B[Y].
Manage EDID, enable input [Y]
learn EDID data from output [X]
EDIDM07B03
PWON.
Work normally
PWON
PWOFF.
Enter standby mode
PWOFF
STANDBY.
Enter standby mode, can be awaken
via front panel button operations
STANDBY
