MT312-104 Neutron™Controller User’s Guide
400-0638-001
1
Welcome!
Everyone at Altinex greatly appreciates your purchase of the
MT312-104. We are confident that you will find it to be reliable
and simple to use. If you need support, please do not hesitate to
call us at 714-990-2300.
At Altinex, we are committed to developing unique and state of
the art Signal Management Solutions®for demanding audiovisual
installations. Welcome to the Altinex family of satisfied customers
around the world!
1. Precautions and Safety Warnings
•Please read this manual entirely before using your
MT312-104. You can download a full version of this
manual at www.altinex.com. These instructions are to
ensure the reliable operation of your switcher and to
prevent fire and shock hazards. Please read them
carefully and heed all warnings.
1.1 General
•Qualified Altinex service personnel or their authorized
representatives must perform all service.
1.2 Installation Precautions
•To prevent fire or shock, do not expose this unit to water
or moisture. Do not place the MT312-104 in direct
sunlight, near heaters or heat-radiating appliances, or near
any liquid. Exposure to direct sunlight, smoke, or steam
can harm internal components.
•Handle carefully; dropping or jarring can cause damage.
•Do not pull any cables attached to the MT312-104.
1.3 Cleaning
•Clean the MT312-104 with a dry cloth only. Never use
strong detergents or solvents such as alcohol or thinner.
Do not use a wet cloth or water to clean the card. Do not
clean or touch any component or PCB.
1.4 FCC Notice
•This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
•This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 2 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions found herein, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at their own expense.
•Any changes or modifications to the unit not expressly
approved by Altinex, Inc. could void the user’s authority to
operate the equipment.
2. Installation Procedures
Note: Download and read the full online manual to become familiar with the MT312-104 and for detailed installation instructions.
Step 1: Connect to the MultiTasker enclosure using RS232 at 115k baud or a TCP/IP connection; the IP address is visible on the front
panel LCD. The default IP address is 192.168.10.84 port 23.
Step 2. The MT312-104 is shipped with factory defaults but must be configured at the time of installation.
Step 3. The MT312-104 is identified by its slot number in the command section of this document.
Step 4: Use control commands to set relays, set/read sensors, read/send RS232 data, etc.
Step 5. Gather all accessories included with the Neutron MT312-104 and make terminal block connections.
- Only use the terminal block captive screws for making connections. Do NOT tin the bare wires.
- Use multi-conductor cable, 24-28 AWG, stranded wire, and make note of which equipment is connected to which port.
IR: IR data is output from internal IR memory or the pass-through IN connection; pass-through uses an IR receiver like the
AC301-103 between IN and GND on the terminal block. If needed, +12V provides power for the IR receiver.
RS232: Connect serial devices to the controller RS-232 connector. Configure the card for the correct baud rate on each port.
By default, the Rx ports are disabled to improve system performance. Use the [TRRS] command to enable.
Relays: Wire the relays directly to the external device. There are 2 single-pole-single-throw relays. Verify the load specifications of the
external device do not exceed those of the relays listing in the specification tables.
Sensor: There are 2 sensor inputs and 2 sensor power pins; one or both can power external sensors.
3. Warranty and Return Policies
Please visit the Altinex website at www.altinex.com for details on warranty and return policies. In the case of a unit needing repair,
please complete an RMA (return material authorization) form by clicking the Warranty link located on the bottom of the Altinex
homepage. Once completed, please email the form to s[email protected].

MT312-104 Neutron™Controller User’s Guide
400-0638-001
2
4. Technical Specifications
Specifications are subject to change. See www.altinex.com for up-to-date information.
Features/Description
MT312-104
General
Connectors
Sensors
5-pin Terminal Block (1)
Relays
5-pin Terminal Block (1)
RS-232
5-pin Terminal Block (1)
IR
5-pin Terminal Block (1)
Accessories Included
Hardware
- Terminal blocks (5)
- Cable ties (8)
Optional Accessories
Ceiling Occupancy Sensor
AC301-101
IR Receiver
AC301-103
Occupancy Sensor
AC301-105
Spare Term. Block Connector
AC101-302
Table 1. MT312-104 General
Mechanical
MT312-104
Slots
1
Weight
0.8 lb. (0.36 kg)
actual 0.7 lb.
Connector Panel
Black Anodized
T° Operating
10°C-45°C
Humidity
90% non-condensing
MTBF (calc.)
38,000 hrs.
Table 2. MT312-104 Mechanical
Electrical
MT312-104
Inputs
Sensor Input
0-24 VDC max.
IR IN
Pass-Through to
IR1+ and IR2+
Outputs
Sensor Power, +12 VDC
+12 VDC, 0.15 A max.
Sensor Power, +24 VDC
+24 VDC, 0.15 A max.
Relays (capacity)
+24 VDC, 0.5 A max.
IR1 & IR2 Modulation
38 kHz or 56 kHz
IR Power, +12 VDC
+12 VDC, 0.15 A max.
Control
RS-232 RX1/TX1
RX2/TX2
Baud Rates 1200 to 57600
Data Bits ..... 8 or 9
8 Bit Parity .. None, Odd, or
Even
Stop Bits ..... 1 or 2
Power
+12V Bus Power
0.2 A (2.4W) max.
Table 3. MT312-104 Electrical
Terminal Block Connections

MT312-104 User’s Guide
400-0638-001
3
5. Operation
5.1 Default Settings
After the initial installation and setup, the MT312-104 does
not require adjustments for optimum performance and will
work trouble-free without user intervention.
Following are the default settings:
RS-232 Ports:9600 baud,
8 data bits+ 1 stop bit,
No parity
Sensors: ....... Trigger Level 18V
De-bounce 250 ms
Relays: .........Open
IR Ports: .......Modulation 38 kHz (IR1 and IR2)
All Memory Blank (FFs)
5.2 Output Power
The MT312-104 provides DC voltages for powering
external devices. Check the specifications of the external
devices and make sure they do not exceed the output
ratings on the Neutron.
5.3 IR Control
IR devices can be controlled using 3 different methods with
the Neutron Controller. The first method uses an IR
receiver like the Altinex AC301-103 connected to the IR IN
pin of the controller. This method allows a user to aim a
remote control at a wall-mount or other receiver and have
the remote control's signal redirected to the IR emitters
connected to the IR1 and IR2 pins.
The next 2 methods send IR data from internal memory or
RAM to IR1 or IR2 and allow the control application to send
IR command strings from Altinex's IR library directly to the
Neutron Controller using AVSnap. These command strings
are stored on the computer application side, not within the
Neutron.
The third method uses IR commands stored in internal
memory to control the external devices. This method only
requires the control application to tell the controller to recall
a command stored in a specific memory location. The IR
commands may be uploaded into memory directly from
Altinex's IR library using AVSnap.
See the IR section for details on setting up and using the
IR outputs.
5.4 Relays
The MT312-104 has 2 relays that can be used to control or
trigger devices like projector screens. The relays can also
route power to low-power DC devices, but make sure to
verify the load requirements against the relay
specifications.
The state of each relay can be recalled by a control
application to determine the state of external devices
connected to the relays. See the Relay section for details
on using the relay.
5.5 RS-232 Control
The MT312-104 has two bidirectional RS-232 COM ports
available to communicate with virtually any serial device.
Each port can be individually set with different baud rates,
parity, stop bits, and data bits allowing a control application
to operate different devices from a single remote location.
See the RS232 section for details on setting up and using
the RS-232 COM ports.
5.6 Sensors
The MT312-104 is designed to work with a wide variety of
sensors, including motion sensors, IR detectors, RF
detectors, etc. Altinex offers the following optional sensors
that work for the most common applications and provide
excellence performance.
AC301-101 - Ceiling Occupancy Sensor
AC301-103 - IR Receiver
AC301-105 - Occupancy Sensor
The controller has two sensor inputs that accept sensor
output voltages up to 24 VDC. Each sensor input has an
independent trigger level setting that can be used to
determine if a sensor has been "tripped" or "activated"
based on movement, occupancy, etc. depending on the
type of sensor. Each sensor also has an individually
programmable de-bounce time that can be used to prevent
false sensor "trips" being detected by the control
application.
The control application does not need to query the status of
the sensor inputs to determine if the trigger level has been
reached. The Neutron automatically sends status changes
to the host application. Otherwise, the application must
periodically query the Neutron and request the sensor
status manually. The application can then take actions
based on the status of the sensor.
See the Sensor section for details on setting up and using
the sensor inputs.

MT312-104 User’s Guide
400-0638-001
4
5.7 MT312-104 Control/Communication
The MT312-104 may be controlled using standard TCP/IP
communication or RS232 through the MultiTasker
enclosure.
5.7.1 Unsolicited Feedback
The MT312-104 provides feedback for the following
unsolicited events not related to a command sent to the
controller:
1) Sensor input goes above or below the trigger level
The card sends feedback to the control card.
2) Data is received on one of the RS232 ports
The card sends the data received on the RS232 port to
the control card.
Feedback Examples:
The input for Sensor #1 goes above its trigger level and the
following feedback is received:
(SR11C04)
If the input drops below the trigger level, the Neutron
returns the following feedback:
(SR10C04)
5.8 Description of Commands
The commands in this section are available through the
MultiTasker communication ports on the front or rear of the
enclosure.
The commands in this section are available through the
MultiTasker communication ports on the front or rear of the
enclosure.
All commands have the structure of open bracket, command,
card ID, and close bracket.
[ + command + card id + ]
In this manual, all card IDs are assumed part of the command.
"Cii" references the card ID.
"ii" is the 2-digit card ID or slot number, 01~20.
Examples in this manual use the card ID of "C04" indicating
the card in is in slot 04 of the enclosure. Other slot IDs look like
the following:
C01, C02, C03, C04 …C20
Common Commands
1. [C]
This command displays a user formatted status of the card.
Command Format: [Cii]
Example:
Display the status of the MT312-104 card in slot 4 by
sending the following command:
[C04]
The MT314-104 returns the status in the format shown
below.
MT312-104
NEUTRON CONTROL
RS-232 1: 9600,N,8,1
RS-232 2: 19200,N,8,1
SENSOR 1: 408 11.0v (SET 093, 2.5v, 0.025s)
SENSOR 2: 000 00.0v (SET 111, 3.0v, 0.100s)
RELAY 1: OFF
RELAY 2: ON
IR 1 MOD: 38 kHz
IR 2 MOD: 56 kHz
CARD TEMP: 23 C
CARD PWR: 3011 mW
2. [CiS]
This command saves the current card configuration. The
saved configuration is restored after the system is reset or
powered off, then on.
Command Format: [CiiS]
Cn = Card ID (n = # from 1 to max slots)
S = Save configuration
This command does not apply to the MT312-104.

MT312-104 User’s Guide
400-0638-001
5
3. [?C]
Read the complete controller configuration that includes
RS-232 ports, relay states, and sensor settings. This
configuration is provided in a machine parseable format.
Command: [?Cii]
Feedback: [(MT312-104C04)(VR690-0425-002C04)
(RI4001,4001C04)(SR0930140811101000C04)
(RL00C04)(IR00C04)(TP23C04)(PR03011C04)]
All status feedback is enclosed in brackets, “[ ]“. Each data
field within the status is enclosed in parentheses. The first
two characters identify the status type. The last three
characters are the card’s ID.
The digits in between represent the values and/or settings.
All values are fixed lengths and use leading zeros to allow
easy parsing.
Following is a breakdown of the above example.
[
Start status
(MT312-104C04)
Model number
(VR690-0425-002C04)
Firmware version
(RI4001,5001C04)
RS232: port #1 then #2
4 (9600)
0 (none)
0 (8 bits)
1 (1 stop bit)
Port #1 baud
parity
data bits
stop bits
5 (19200)
0 (none)
0 (8 bits)
1 (1 stop bit)
Port #2 baud
parity
data bits
stop bits
(SR0930140811104000C04)
Sensors: port #1 then #2
093 (2.5 V)
01 (25 ms)
408 (11.0 V)
Sen #1 trigger
de-bounce
value
111 (3.0V)
04 (100 ms)
000 (0.0 V)
Sen #2 trigger
de-bounce
value
(RL01C04)
Relays
0 (off/open)
1 (on/closed)
Relay #1
Relay #2
(IR01C04)
IR frequency
0 (38 kHz)
1 (56 kHz)
Port #1
Port #2
(TP23C04)
Temperature in °C
23
Degrees C
(PR03011C04)
Power in milliwatts
03011(3,011 mW)
Card power, 5-digits
]
End status
4. […S] –SAVE
This command saves the configuration command being
sent in memory. Send [I1O1C8S] and after reset or power
up, Input 1 is connected to Output 1 on C8. This command
only saves the Input 1 to Output 1 connection above. Use
the [CiiS] command to save all current settings.
This command does not apply to the MT312-104.
5. [DISP]
This command returns the card information that is
displayed on the enclosure LCD window.
Command Format: [DISPCii]
Read what is displayed on the LCD by sending [DISPC3].
The feedback displays the text for both the top row and the
bottom row separated by commas.
[MT312-104,NEUTRON CONTROL C04]
6. [DRV]
This command displays the BIOS version.
Command Format: [DRVCii]
Example:
Send the command [DRVC4] to check the version of the
MT312-104 in slot 4. The card returns feedback:
[003C04]
003 = BIOS firmware version
C04 = card ID
7. [FRST]
This command clears the card, restoring the factory default
settings.
Command Format: [FRSTCii]
Example:
To clear the card in slot 4, send [FRSTC4]. The card in slot
4 is now returned to its default factory values.
8. [GROUP]
This command assigns a card to a group of cards. If a
group command is sent to the enclosure and the group
number matches, the group command is executed by all
cards in the group. The is no feedback with group
commands.
Command Format: [GROUPxCii]
x = Group ID (x = # from 1 to 8)
Example:
Assign the card in slot 4 to group 2 by sending
[GROUP2C4]. Execute a group command by sending the
command with a group ID. For example, [ON1G4].

MT312-104 User’s Guide
400-0638-001
6
9. [HWEN]
This command enables or disables the card hardware,
excluding the main microprocessor. Power to video and
audio circuitry is turned off. Use for saving power but to
keep response time short returning to normal operation.
This is not a group command.
Command Format: [HWENxCii]
x = On/off (1 = on, 0 = off)
Example:
Disable the hardware to the scaler card in slot 4 by sending
the following command:
[HWEN0C4]
10. [MOD]
This command returns the card model number.
Command Format: [MODCii]
Example:
Read the model of the card in slot 4 by sending [MODC4];
feedback is similar to the following:
[MT319-401C04]
11. [PRG]
This command puts the card into firmware update mode.
Only use when working with Altinex Technical Support.
Command Format: [PRGCii]
12. [PWR]
This command returns the card power consumption in
watts.
Command Format: [PWRCii]
Example:
Read the power consumption of the card in slot 4 by
sending [PWRC4]; feedback is similar to the following:
[4.59WC04]
13. [PWRM]
This command is the same as the [PWR] command but
returns the power milliwatts.
Command Format: [PWRMCii]
Example:
Read the power consumption (in milliwatts) of the card in
slot 4 by sending [PWRMC4]; feedback is like the following:
[4596mWC04]
14. [SFT]
This command resets the card. It is the equivalent to
powering just the card off and on.
Command Format: [SFTCii]
Example:
Reset the card in slot by sending [SFTC4]. The card
responds with [RSTC04] indicating the card is resetting.
15. [STA]
This command enables and disables automatic feedback
from the card. The feedback format is the same as the [?Ci]
command, but only changes are reported.
Command Format: [STAxCii]
x = On/off (x = 1 to enable, 0 disables)
Feedback Prefix Definitions:
MT Card Model Number
VR Firmware Revision
PR Card power consumption
TP Card Temperature
16. [TEMP]
This command returns the card temperature. The value is
returned in degrees Celsius.
Command Format: [TEMPCii]
Example:
Read the temperature of the card in slot 4 by sending
[TEMPC4]. The card responds with feedback:
[39C04]
17. [VER]
This command displays the software version and card type
for the card.
Command Format: [VERCii]
Example:
Send the command [VERC4] to check the version of the
MT312-104 in slot 4. The card returns feedback:
[690-0425-002C04]
690-0452-002= firmware version
C04 = card ID

MT312-104 User’s Guide
400-0638-001
7
RS232 Commands
18. [MODERS]
Configure the RS-232 ports for baud rate, parity, number of
data bits, and number of stop bits. Once configured, data
sent to or received on a given port is in the set format.
Command Format: [MODERSnbpmsCii]
n –RS-232 port number (1 or 2)
b –baud rate (1 ~ 7)
1 –1200bps
2 –2400bps
3 –4800bps
4 –9600bps
5 –19200bps
6 –38400bps
7 –57600bps
p –parity for 8-bit data (0=none,1=odd,2=even)
m –data bits (0 = 8 bits, 1 = 9 bits)
s –stop bits (1 = 1 stop bit, 2 = 2 stop bits)
Example:
Set the RS232 port #1 to 19200 baud, 8 data bits, 1 stop
bit, and no parity:
[MODERS15001C04]
Once complete, the Neutron sends confirmation.
[C04]
19. [TRRS]
Send a string of data through one of the RS232 ports. The
data sent out of an RS232 port uses the baud rate, parity,
stop, and data bits for which the port is configured. The
default configuration for both RS-232 ports is as follows:
9600 baud, 8 data bits, 1 stop bit, no parity
Command Format: [TRRSn=dddCii]
n = Port number (1 or 2)
ddd = data to be transmitted (keyboard characters)
Use % for HEX value (ex: %0D=carriage return)
Send no data to simply enable the Rx port. For
example, send [TRRS1=C04] to enable the Rx1
port on the card.
Example:
Output “[VER]” on RS-232 port #1 by sending the following
to the controller:
[TRRS1=%5BVER%5DC04]
20. [TRTX]
Send a string of data through one of the RS232 ports and
disable the Rx pin of the same port. Use this command
when data from the device is not used by the control
application and the external device sends excess feedback.
Excess data from external devices uses card processor
time as well as enclosure bus resources. In severe cases,
overall MultiTasker performance may be affected.
The data sent out of an RS232 port uses the baud rate,
parity, stop, and data bits for which the port is configured.
The default configuration for both RS-232 ports is as
follows:
9600 baud, 8 data bits, 1 stop bit, no parity
Command Format: [TRTXn=dddCii]
n = Port number (1 or 2)
ddd = data to be transmitted (keyboard characters)
Use % for HEX value (ex: %0D=carriage return)
Send no data to simply disable the Rx port. For
example, send [TRTX1=C04] to disable the Rx1
port on the card.
Example:
Output “[VER]” on RS-232 port #1 by sending the following
to the controller:
[TRRS1=%5BVER%5DC04]

MT312-104 User’s Guide
400-0638-001
8
21. (RS)
This is unsolicited feedback. RS232 data received by the
MT312-104 is sent to the MultiTasker control when
received on either port. The data is not analyzed; it is
simply relayed to the MultiTasker. Data from the
MultiTasker may be accessed from either the TCP or
RS232 port. The MultiTasker’s RS232 output is 115k baud,
regardless of the MT312-104 baud rate.
Important: Make sure to configure the RS232 ports to
match the baud rate of the equipment connected to each
port. See the [MODERS] command for details.
Feedback Format: (RSndddCii)
n = RS-232 port number (n=1 or 2)
ddd = Data received through RS-232 port
Example:
The Neutron’s port 1 is connected to a projector. In addition
to controlling the projector from the controller, the
application can be used to respond to data received from
the projector; for example, "TEMP1" indicating its internal
temperature is too high. The Neutron receives the data on
port #1 (RX1) then returns the following, or similar:
(RS1TEMP1C04)
Data may be returned in any of the 3 examples below and
depends on how the data is received and string length:
1. (RS1TEMP1C04)
2. (RS1TEC04)(RS1MPC04)(RS11C04)
3. (RS1TC04)(RS1EC04)(RS1MPC04)(RS11C04)
22. [WRIR]
Save an IR command string from Altinex's IR library into
the Neutron's internal memory. A single IR command
requires 10 individual save commands of 100 characters
each. After each command is processed, the Neutron will
return acknowledgement indicating it has finished
processing the previous command.
Command Format: [WRIRxy,ddd…dCii]
x = IR memory location number (01 to 99, 2-digits)
y = Save instructions (1=Overwrite, 0=Append)
ddd = IR data in 100 hex characters
Valid characters are "0123456789ABCDEF"
Example:
An IR library command string is 1,000 characters and
requires 10 save commands to save the IR string. The
following example saves an IR string into memory location
"01". Always wait for acknowledgement from the Neutron
before sending the next command.
[WRIR011,FFFFFFFFFF...C04] Overwrite Mem 01 with
100 char.
[C04] Feedback from the
Neutron.
[WRIR010,AAA000FFF...C04] Append Mem 01 with
100 char.
[C04] Feedback from the
Neutron.
Repeat
[WRIR010,FFFFFFFFFF...C04] Append Mem 01 with
100 char.
[C04] Feedback from the
Neutron.
Note: In the above, memory locations are highlighted in
yellow and the overwrite/append in green.
23. [RDIR]
Read IR data from memory.
Command Format: [RDIRxxCnn]
x = IR memory location (2-digits 01 to 99)
Example:
Send [RDIR21C04] to read the IR data string in memory
location 21.
The Neutron responds with 10 blocks in the format
beginning with "[IR" followed by 100 data characters and
concludes with the card ID and close bracket.
[IR21,01, FFFFFFFFFFFFFF00000000000FFFF...C04]
[IR21,02, FFFFFFFFFFFFFF00000000000FFFF...C04]
etc.
[IR01,10, FFFFFFFFFFFFFF00000000000FFFF...C04]

MT312-104 User’s Guide
400-0638-001
9
24. [RDIR*]
Read all IR memory locations programmed with valid IR
codes; incomplete or blank memory locations are not
displayed. Total time to complete is about 5 seconds per
programmed memory location.
Data is returned in command write format. The data can be
saved to a file and used restore IR codes later or to
program other cards that control the same devices.
Command Format: [RDIR*Cii]
Note: Must send [WRIR0000Cii] when all memory
locations have been read.
Example:
Send [RDIR*C04] to read all programmed IR data strings.
The Neutron responds with 10 blocks in the format
beginning with "[IR" followed by 100 data characters and
concludes with the card ID and close bracket.
[IR21,01, FFFFFFFFFFFFFF00000000000FFFF...C04]
[IR21,02, FFFFFFFFFFFFFF00000000000FFFF...C04]
etc.
[IR01,10, FFFFFFFFFFFFFF00000000000FFFF...C04]
25. [OUTIR]
Output the IR data stored in a memory location to one of
the IR outputs to activate the IR emitter and control an
external device.
Command Format: [OUTIRxmmCii]
x = IR output number (n= 1 or 2)
mm = IR memory location number (01 to 99, 2-digits)
ii = Card ID (1-20)
Example:
Output the IR string stored in memory location 2 on IR
output port #1 by sending the following command:
[OUTIR102C04]
This single command reads the entire IR string from
memory and sends it to the IR port. Once the entire
process is complete, the Neutron sends confirmation.
[C04]
26. [WRIRRAM]
Preset the pass-through IR by loading the data into RAM
from the Altinex library directly from the controller. This
command allows virtually unlimited IR commands to be
used in place of, or in addition to, the built-in IR memory of
the Neutron. This command works in conjunction with the
[OUTRAM] command that instructs the controller to output
the data to the IR ports.
Command Format: [WRIRRAMp,dddCii]
p = Saving instructions (1=Overwrite, 0=Append)
ddd = IR data in ASCII characters (100 per command),
Valid characters are "0123456789ABCDEF"
Example:
An IR library command string is 1,000 characters and
requires 10 save commands to save the IR string into
RAM. The following command samples are used to load an
IR string into RAM. Remember to wait for command
acknowledgement from the Neutron after sending each
command before sending the next.
[WRIRRAM1,FFFFF...C04] Overwrite RAM,100 char.
[C04] Neutron Feedback
[WRIRRAM0,AA00FF...C04] Append RAM,100 char.
[C04] Neutron Feedback
[WRIRRAM0,FF00FF...C04] Append RAM,100 char.
[C04] Neutron Feedback
etc.
27. [LEARNIR]
Learn IR data from a remote control using the built-in
IR Learn capability of the MT312-104. Data is captured and
stored directly to one of 99 memory locations.
Command Format: [LEARNIRmmCii]
mm = Memory location (n= 01 to 99, 2-digits)
Before learning IR codes, plan the features required by
your installation. Document the codes to learn and assign
memory locations. Make note of which device will be
connected to which IR output number. See the table below
as an example.
Device
Mfr/Model
Function
Memory
IR Out
DVD
Panasonic DVD-S54
Power
01
1
DVD
Panasonic DVD-S54
Stop
02
1
DVD
Panasonic DVD-S54
Play
03
1
DVD
Pioneer DVD-V7400
Power
11
2
DVD
Pioneer DVD-V7400
Stop
12
2
DVD
Pioneer DVD-V7400
Play
13
2
TV
Sony Bravia
Power
21
3

MT312-104 User’s Guide
400-0638-001
10
A typical installation sets aside a block of 10 memory
locations per device: 01-10 for DVD player #1, 11-20 for
DVD player #2, and 21-30 for TV #1, etc. This makes
applications easier to write and leaves empty memory
locations in the same block for adding features later.
Example:
If the IR emitters are not already installed, prepare a
terminal block with an IR emitter. Connect the test emitter
to the terminal block for IR1 and place the emitter over the
device's IR receiver. This emitter will be used to test each
code as it is learned.
The IR receiver is located on the front of the MultiTasker
enclosure. Prepare the device and its remote control for
normal operation. Know the function you want to learn and
its memory location and send:
[LEARNIR01C04] Learn IR code to memory 01.
BLAST The Neutron displays BLAST when
ready to receive signal. The Neutron
waits up to 7 s to start receiving an IR
signal.
WAIT WAIT is displayed after a signal is
received while it is processed.
[C04] Once received, the Neutron displays
ID as acknowledgement.
[ERC04] If a valid IR signal is not received
within 7 s, the Neutron times out.
[OUTIR101C04] Send the newly learned code to IR1 if
using a test-cable otherwise use the
actual IR port. Verify the device
responds as expected.
28. [IRM2RAM]
Extract IR data stored in an IR memory location and load it
into RAM for faster response time when needed. Use this
command in conjunction with the [OUTRAM] command that
instructs the controller to output the data to the IR ports.
Command Format: [IRM2RAMmmCii]
mm = IR memory location number (01 to 99, 2-digits)
Example:
Load the IR data from memory location 02 into RAM by
sending the following command:
[IRM2RAM02C4]
The entire IR string is read from memory and loaded into
RAM. Once complete, the Neutron sends confirmation.
[C04]
29. [OUTRAM]
Output the IR data previously preloaded in RAM from 1 to 9
times. This command is especially useful for commands
such and volume, brightness, etc. where single step
increments take too long to make large adjustments.
Command Format: [OUTRAMnpCii]
n = IR output (n= 1 or 2 for outputs IR1+ or IR2+)
p = Number of times to output data (p= 1 to 9)
Example:
A TV’s volume UP command has been loaded into RAM to
more quickly adjust the volume. The control application is
programmed to send the volume command 3 times every
time the application’s volume UP key is pressed. Output
the volume UP command 3 times to IR output #1 by
sending the following:
[OUTRAM13C04]
The entire IR string is sent in rapid succession to the IR
outputs. Once complete, the Neutron sends confirmation.
[C04]
30. [MODEIR]
Set the IR output modulation frequency to 38 or 56 kHz for
outputs IR1+ and IR2+ independently.
Command Format: [MODEIRnpCii]
n = IR output (n= 1 or 2 for output IR1+ or IR2+)
p = IR frequency (0 = 38 kHz, 1 = 56 kHz)
Example:
Set the IR frequency of IR2 to 38 kHz by sending:
[MODEIR20C04]
Once complete, the Neutron sends confirmation.
[C04]
31. [WRIRFF]
Completely clear an IR memory location by writing all
0xFFs to the memory.
Command Format: [WRIRFFmmCii]
m = IR memory location number (01 to 99, 2-digits)
Example:
Erase IR memory location 01 of C4 by sending:
[WRIRFF01C04]
Once complete, the Neutron sends confirmation.
[C04]

MT312-104 User’s Guide
400-0638-001
11
32. [SENLV]
Independently set the trigger level for each of the sensor
inputs from 0 to 24 V in 27 mV steps. The value must be
entered as 3-digits; feedback is sent each time a sensor
input transitions above or below the trigger level.
(SR10C04) Input 1 –HIGH-LOW transition occurred.
(SR21C04) Input 2 –LOW-HIGH transition occurred.
Command Format: [SENLVnvvvCii]
n = Sensor Input number (n= 1 or 2)
v = Trigger level (v=# from 000~999, default= 18V)
Example:
Set the trigger level for sensor input #2 to approximately
2.5 V by sending the following to the Neutron:
[SENLV2093C04]
Once complete, the Neutron sends confirmation.
[C04]
33. (SR)
This is unsolicited feedback from the sensors. Every time
the input voltage goes above or below the trigger level, this
feedback is generated.
Feedback Format: (SRnsCii)
n = Sensor number (n=1 or 2)
s = Sensor state (s=1 or 0)
(SR10C04) Input 1 –HIGH-LOW transition occurred.
(SR21C04) Input 2 –LOW-HIGH transition occurred.
34. [SENDB]
Independently set the de-bouncing time for a sensor input
giving the signal time to settle before triggering an event.
The de-bounce time is 2-digits, set in multiples of 25 ms
with a maximum of 0.5 s.
Command Format: [SENDBnvvCii]
n = Sensor Input number (n= 1 or 2)
v = Time (v= # from 00 to 20, default: 250 ms)
Example:
Set the de-bounce time for sensor input #2 to 100 ms by
sending the following to the controller:
[CSD204C04]
Once complete, the Neutron sends confirmation.
[C04]
35. [RDSEN]
Read the status of a sensor input; "0" means the voltage is
below the trigger level, a "1" means the voltage is above.
The MT312-104 also sends the status automatically when
there is a change in state.
Command Format: [RDSENnCii]
n = Sensor Input number (n= 1 or 2)
Feedback Format: [sCii]
s = Sensor status (n= 0 or 1)
0 - Sensor input is below trigger level
1 - Sensor input is above trigger level
Example:
The trigger level for sensor input #2 is set to 93, or about
2.5 VDC. The input to sensor #2 is 4.5 VDC. Send the
following to read the status:
[RDSEN2C04]
The Neutron responds with the following:
[1C04]
The "1" indicates the voltage level on the sensor input is
above the trigger level voltage of 2.5 VDC.
36. [RDSLV]
Read the current sensor level on a sensor input with each
step representing approximately 27 mV.
Command Format: [RDSLVnCii]
n = Sensor Input number (n= 1 or 2)
Feedback Format: [sCii]
v = Sensor level (v=# from 0 to 999)
The return value can be 1, 2, or 3 digits.
Example:
The voltage level on sensor input #2 is 4.5 VDC. Send the
following to read the sensor level:
[RDSLVC04]
The Neutron responds with the following:
[167C04]
The "167" indicates the sensor level on the sensor input is
about 167 times 27 mV or approximately 4.5 VDC.

MT312-104 User’s Guide
400-0638-001
12
37. [WRRL]
Independently open and close the output relays.
Command Format: [WRRLnsCii]
n = Relay number (n= 1 or 2, * for all)
s = State of relay (s= 0:open or 1:closed)
Example:
Close relay #1 and open relay #2 using the following
commands:
[WRRL11C04] Close relay #1
[WRRL20C04] Open relay #2
38. [RLxTy]
Toggle a relay from its current state to closed, then pause
up to 1 s and then open the relay. The pause time is in
multiples of 100 ms. If the relay is closed when this
command is issued, it will simply remain closed and then
open after the defined pause time.
Command Format: [RLnTvCii]
n = Relay number (n= 1 or 2)
v = Pause time (v= 1 to 9)
Example:
Relay #1 is currently open. Toggle Relay #1 for 0.5 s by
sending the following command:
[RL1T5C04]
Relay #1 closes for 0.5 s then opens. Once the cycle is
complete, the Neutron sends confirmation.
[C04]
39. [RDRL]
Independently read the current state of a relay.
Command Format: [RDRLnCii]
n = Relay number (n= 1 or 2)
Feedback Format: [sCii]
s = Relay status (n= 0 = open, or 1 = closed)
Example:
Check to see if relay #1 is closed by sending the following:
[RDRL1C04]
The Neutron responds with a "1" if the relay is closed and
"0" if open. If relay #1 is closed, the feedback is as follows:
[1C04]
5.9 Summary of Commands
Common Commands
1. [C] Card status
2. [CiS] Save all settings
3. [?C] Parseable card status
4. […S] Save single command
5. [DISP] Return card information
6. [DRV] Return BIOS firmware version
7. [FRST] Factory reset
8. [GROUP] Set or read group number
9. [HWEN] Hardware enable/disable
10. [MOD] Return card model
11. [PRG] Firmware update mode
12. [PWR] Return card power in watts
13. [PWRM] Return card power in milliwatts
14. [SFT] Reset the card
15. [STA] Enable/disable unsolicited feedback
16. [TEMP] Return card temperature
17. [VER] Return firmware version
RS232 Commands
18. [MODERS] Configure RS232 ports
19. [TRRS] Output RS232 data
20. [TRTX] Output RS232 data, disable RX
21. (RS) Unsolicited data received on RS232
ports
IR Commands
22. [WRIR] Write to IR memory
23. [RDIR] Read an IR memory location
24. [RDIR*] Read all IR memory locations with data
25. [OUTIR] Output IR code to IR emitter
26. [WRIRRAM] Write IR code into RAM
27. [LEARNIR] Learn an IR code from a remote control
28. [IRM2RAM] Load IR code from memory into RAM
29. [OUTRAM] Output IR signal from RAM to emitter
30. [MODEIR] Configure modulation frequency
31. [WRIRFF] Blank an IR memory location
Sensor Commands
32. [SENLV] Set sensor trigger level
33. (SR) Unsolicited sensor status change
34. [SENDB] Set sensor de-bounce time
35. [RDSEN] Read the sensor status
36. [RDSLV] Read the sensor level
Relay Commands
37. [WRRL] Turn a relay on or off
38. [RLxTy] Toggle a relay
39. [RDRL] Read the status of a relay
