Altius ATKBTS-SCA User manual
2
We hope you enjoy your purchase!
ALTIUS products are carefully designed and produced to the
highest standards of performance and safety, backed by our
comprehensive 1 Year Warranty.
This user manual will provide all the information required for
you to setup and use your new product.
Welcome
3
contentS
Welcome 2
General Safety Warnings 4
Product Overview 8
Operation 10
Troubleshooting 13
Specications 14
Compliance and Responsible Disposal 15
4
General Safety WarninGS
This product complies with Australian Safety
Standard AS/NZS 62368.1 to ensure the safety
of the product.
important
Electrical safety and cord handling
• Protect from moisture: Do not expose this product, the
power supply cord and plug to rain or moisture. Do not
use it anywhere near water or where water splashes or
drips, such as a bathroom or near a swimming pool. Do
not touch the power plug with wet hands.
Usage conditions and restrictions
• Instructions: Follow the instructions in this user guide
when installing and adjusting this product. Only adjust
controls and settings that are covered in this user
manual, as improper adjustment of other controls may
result in damage. If this happens, unplug the product and
have it serviced by appropriately qualified personnel.
• Battery: Please note that the battery can only reach top
performance level after it has been fully charged and
discharged two or three times.
5
• Usage restriction: The product is not intended for use
by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the product by a person
responsible for their safety.
• Children: Supervise young children to ensure they do
not play with the product. Close supervision is always
necessary when a product is used by or near children.
• Location: When using the product, make sure to place it:
• In a well ventilated area, keeping a clearance of at
least 20cm above and 5cm on each side of the unit to
ensure proper ventilation.
• Away from heat sources such as radiators, heat
registers, stoves or other equipment (including
amplifiers) that produce heat.
• Away from areas with high temperatures, high
humidity or direct sunlight.
• Away from excess dirt and dust.
• Away from strong magnetic fields.
Keep away from babies 3 years and younger,
the speaker contains small parts which are a
choking hazard
6
• Protect the product: Prevent metal objects falling onto
the product. Do not place heavy objects on top of the
product or step on it. Do not place objects filled with
water (such as vases), or naked flame sources (such as
candles), on or near the product. If liquid or metal parts
enter the system, unplug the power cable immediately
and call our After Sales Support centre to arrange a
service before further use.
• Ventilation: Openings on the cabinet are provided for
ventilation and to protect the unit from overheating. To
ensure proper operation, do not cover them with things
such as newspapers, tablecloths, curtains etc.
• Transporting: Unpack the product and keep the original
packaging carton and materials in a safe place. It will
help prevent any damage if the product needs to be
transported in the future, and you can use it to store the
product when it is not in use.
• Storage: When product is not in use, store in a cool, dry
and well ventilated location out of direct sunlight. Ensure
that it is not subject to humidity.
• Cleaning: Unplug the product from the power outlet
before cleaning. Clean the product only with a clean,
dry or slightly damp cloth. Do not use liquid or aerosol
cleaners or volatile solvents.
7
• Service: Refer all servicing to qualified personnel.
Servicing is required when the apparatus has been
damaged in any way, such as when the power supply
cord or plug is damaged, liquid has been spilled or
objects have fallen into the unit, it has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
• Repair: If the product requires repair, contact the After
Sales Support line; never disassemble or modify the unit
or attempt to service it yourself.
• Liability: We accept no liability for any damage caused by
non-compliance with these instructions or mishandling
of the product.
8
A. Kids Bluetooth Speaker
B. Micro USB Cable
C. AUX Cable
What’s in the box:
product overvieW
D. User Manual
E. Warranty Card
9
1. Power button
2. Volume down/play
previous song
3. Volume up/play next song
4. Play/pause button
5. AUX IN port
6. Charging indicator
7. Micro USB port
1
5 6 7
8
9
2 3 4
8. Microphone
9. LED indicator
10
operation
poWer on and charGinG
Bluetooth®Setup
Press and hold the button to turn the speaker on/
o. When on, it will enter Bluetooth®pairing mode
automatically and the LED indicator will ash blue.
To charge the speaker, plug one end of the supplied
Micro USB cable to the Micro USB port on the speaker.
Connect the other end of the cable to a power source.
When charging, the charging indicator will light up red
and turn o once the speaker is fully charged.
On your Bluetooth®device, look for ATKBTS-SCA in
the list of detected devices, and pair with it. Once
successfully paired, the LED indicator will light up blue.
If asked for a password, enter 0000.
The speaker and your Bluetooth device®will remember
each other and automatically connect when they are
both turned on.
11
Bluetooth®mode
aux input mode
• Press and hold the / buttons to play the
previous or next song. You can also control via
your Bluetooth® device.
• Press the button to play/pause the song. You
can also control via your Bluetooth® device.
• To adjust the volume, press the button to
decrease the volume, and press the button to
increase the volume. You can also control via your
Bluetooth® device.
• The LED indicator will ash blue when music is
playing.
• Connect your audio device to the AUX port on the
speaker using the appropriate cable. The speaker
will automatically enter AUX mode.
• To adjust the volume, press the button to
decrease the volume, and press the button to
increase the volume. You can also control via your
audio device.
12
receivinG and endinG phone callS
• When there is an incoming call, the speaker will
pause music playback and ring to alert. To answer
a call, press the button to answer. Press the
button again to end the call.
13
trouBleShootinG
proBlem Solution
Speaker is not
turning on
• Charge the speaker for 3 hours
and try again.
No audio • Turn the speaker on and adjust
the volume level.
Music keeps
dropping out
• Move the speaker closer to the
device.
Failed to connect
to Bluetooth
• Place the phone and speaker
closer together.
• Check the Bluetooth menu
on your phone to ensure it is
connected to the correct device.
• Restart the speaker. On your
device, turn Bluetooth o and
then back on, and search again.
14
Battery capacity 3.7V, 1800mAh
Charging Power
Input DC 5V, 0.5A
Speaker output 8W
Bluetooth Range < 10m
Weight 215 g
Dimensions (mm) 118(W) x 45(H) x 192(D)
SpecificationS
The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG,Inc. and any use of such marks by
Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.
15
compliance and reSponSiBle diSpoSal
Packaging
The packaging of your product has been selected from
environmentally friendly materials and can usually be recycled.
Please ensure these are disposed of correctly. Plastic wrapping
can be a suffocation hazard for babies and young children, please
ensure all packaging materials are out of reach and are safely
disposed of. Please recycle these materials rather than throwing
them away.
Product
At the end of its working life, do not throw this product out with
your household rubbish. An environmentally friendly method of
disposal will ensure that valuable raw materials can be recycled.
Electrical and electronic items contain materials and substances
which, if handled or disposed of incorrectly, could potentially be
hazardous to the environment and human health.
This product complies with the Australian Safety Standard
AS/NZS 62368.1 to ensure the safety of the product.
cuStomer helpline au:
1300 886 649
diStriButed By:
tempo (auSt) pty ltd,
po Box 6056,
frenchS foreSt
dc 2086
