●Superior baking and roasting capability.
●A dependent 60/
40 door system includes a solid stainless steel
door and a double pane thermal window door to view the lighted
oven interior.
●Both doors open beyond a 120-degree angle for easier loading;
include a spring-loaded roller assembly to provide a positive,
pressure-lock seal; and a heavy-duty door hinging system.
●Solid welded construction with stainless steel front, sides, top and
rear enclosure panel.
●Removable oven baffle provides easy cleaning.
●Heavy-duty 3/4 hp, two-speed motor provides a fan speed for high
volume production or delicate baking.
●Easy to clean porcelain enamel oven interior is standard.
●10kW element.
●Durable, low maintenance stainless steel door gaskets.
ASC-4E
THE PLATINUM SERIES
ELECTRIC CONVECTION OVEN
ITEM NO. _______________________
#702 - 09/08
The Platinum Series electric convection oven features solid welded construction, an angle iron frame, and a non-
corrosive stainless steel exterior. The oven interior is constructed of porcelain enamel with coved corners, and a heavy
duty, 14 gauge bottom liner. It is supplied with six (6) chrome plated wire shelves with 2 removable side racks and 12
shelf positions spaced at 1-3/4" (43mm). The oven is furnished with two interior lights, a 10,000 watt heating element
and a heavy duty, 3/4 hp, two-speed fan motor. Control includes a 100°F to 500°F (38°C to 260°C) thermostat and a 60
minute, count-down timer. The control features a oven cool-down function, oven-ready indicator light, and produces
an audible signal when time has expired. The oven is supplied with 25" (635mm) legs with bullet feet.
■■MODEL ASC-4E: MANUAL CONTROL, PORCELAIN ENAMEL INTERIOR
■■MODEL ASC-4E/ e: ELECTRONIC CONTROL WITH FOOD PROBE, PORCELAIN ENAMEL INTERIOR
ASC-4E
WITH OPTIONAL STATIONARY OVEN STAND
AND PAN RACK WITH SHELVES - 5003489
FACTORY INSTALLED OPTIONS
■■Stainless steel oven interior
ADDITIONAL FEATURES
●Stackable design
●Easy access for bulb replacement
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com
DUE TO ONGOING PRODUCT IMPROVEMENT, SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.PRINTED IN U.S.A.

D I M E N S I O N S : H x W x D
EXTERIOR: 57-1/2" x 38" x 44-1/2" (1461mm x 965mm x 1130mm)
INTERIOR: 24" x 29-1/8" x 25" (610mm x 740mm x 635mm)
W E I G H T
NET 393 lb (178 kg)
SHIP 438 lb (199 kg)
CRATE 40" H X44" W X53" D
DIMENSIONS:(1016mm x 1118mm x 1346mm)
MINIMUM ENTRY CLEARANCE 31-1/2" (800mm)
UNCRATED, WITHOUT LEGS
#702 - 09/08
ASC-4E
ELECTRIC CONVECTION OVEN
P R O D U C T \ PA N C A PA C I T Y
72 lb (33 kg) MAXIMUM • 45 qts (43 liters)
12 (twelve): 18" x 26" x 1" FULL-SI E SHEET PANS
6 chrome plated wire shelves with
2 removable side racks and 12 shelf positions
spaced at 1-3/4" (43mm)
I N S TA L L AT I O N R E Q U I R E M E N T S
— This appliance must be installed level and must not be
installed in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any other
severely adverse conditions.
— Mobile appliances must be secured to the building
structure by means of a restraining device (NOT
FACTORY SUPPLIED).
— Hood installation is recommended (CHECK LOCAL CODES).
30-5/8" (778mm)
8" (203mm)
CAVITY VENT
ELECTRICAL
INLET
3-5/32"
(80,1mm)
9-15/16" (252mm)
ELECTRICAL ENTRANCE
123°
129°
29" (737mm)
CAVITY WIDTH
38" (965mm)
31-1/16" (789mm)
4" (102mm)
ELECTRICAL INLET
54-5/8" (1387mm)
44-1/2" (1130mm)
26-1/2" (673mm)
57-1/2" (1461mm)
O P T I O N S & A C C E S S O R I E S
■■CASTER SET, 6" (152mm) FOR MOBILE STACK APPLICATIONS 5003790
■■COOLING RACK FOR OVEN STAND 5003791
LEG SET (4)
■■6" (152mm) with Bullet Feet 5003794
■■6" (6152mm) with Seismic Feet 5003795
■■25" (635mm) with Seismic Feet 5003785
■■PANEL FOR BACK, Stainless Steel 5005876
SHELF, OVEN RACK
■■INTERCHANGEABLE WITH COOLING RACK SH-26795
STACKING HARDWARE
SEE INDIVIDUAL STACKING COMBINATION SPECIFICATION SHEETS
STAND, STAINLESS STEEL
■■Mobile, with Cooling Racks & Casters, 38" H (965mm) 5003786
■■Stationary, with Cooling Racks & Bullet Feet 5003489
■■Stationary, with Cooling Racks & Seismic Feet 5003787
34-1/4" (870mm) min. • 35-1/2" (902mm) max. H (FEET ARE AD USTABLE)
M I N I M U M C L E A R A N C E R E Q U I R E M E N T S
SIDE S 2" (51mm)
BAC K SI DE 0" (0mm)
FROM GREASE PRODUCING EQUIPMENT 6" (152mm)
RECOMMENDED SERVICE ACCESS 20" (508mm)
RIGHT SIDE
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AWG AMPS kW
208 (AGCY)1 60 6 50.0 10.4
240 (AGCY)1 60 6 43.3 10.4
208 (AGCY)3 60 8 28.8 10.4
240 (AGCY)3 60 8 25.0 10.4
480 (AGCY)3 60 8 12.5 10.4
N O C O R D A N D P L U G
