Alto-Shaam 1000-MR2 User manual

The Alto-Shaam Mobile refrigerated Cart is not just a refrigerator
on wheels, but a well-designed and efficient system for storing and
transferring refrigerated food products.
Adjustable shelves allow for the storage of plated items,
pans or other items.
Full perimeter stainless steel bumper, transport handles,
heavy duty casters along with the cart's reduced height
provide easy mobility.
Electronic thermostat has digital display to view inside
set air temperature.
Non-magnetic stainless steel surface resists corrosion.
Environmentally safe refrigerant.
All mechanical equipment is easily accessible, without
the use of tools, for ease in servicing.
Center mounted cooling coil balances and distributes
air evenly.
Condensate from the cooling coil is used to cool the compressor, therefore, it is
unnecessary to have an alternate means of water disposal.
1000-MR2
DOUBLE CAVITY
#411
Mobile Refrigerated Cart
®

MODEL 1000-MR2
INTERIOR
IN IDE
DIMEN ION
(W x D x H)
PAN
CAPACITY
ELECTRICAL
NET WEIGHT
HIP WEIGHT
OPTION &
ACCE ORIE
izes and pecifications
56-5/8" (1438mm)
27-1/2"
(699mm)
29-1/2" (749mm)
68" (1727mm)
54-1/4" (1378mm)
67-1/2" (1714mm)
64-1/2" (1638mm)
on l
off o
POWER
2°
C
1-1/2" (35mm)
29-3/4" (749mm) 24-1/2" (622mm)
FULL
PERIMETER
BUMPER
27-1/2"
(699mm)
WITH BUMPER
PUSH
HANDLE
24-1/4" (617mm)
length
22 gauge non-magnetic (non-corrosive) stainless steel
— Four (4) removable stainless steel side racks
with 50 shelf positions spaced on
1-1/4" (32mm) centers
— Six (6) powder coated shelves (SH-25676)
26-1/2" x 21-3/4" (673mm x 552mm)
21-1/4" x 27-1/4" x 55-1/2" each cavity
(540mm x 692mm x 1410mm)
FULL-SIZE PANS GASTRONORM 1/1
—Forty-two (42) . . 12" x 20" x 2-1/2" . . . (530mm x 325mm x 65mm)
FULL-SIZE SHEET PANS
—Twenty-six (26)*. 18" x 26" x 1" . . on wire shelves only.
*Additional shelves required.
115V —60 Hz, 1 ph.
10.8 Amps
220-240V —50/60 Hz, 1 ph.
6.3 Amps
800 lb (363 kg)
1210 lb (549 kg)
NEMA 5-15P
15A, 125V Plug
NEMA 6-15P
15A, 250V Plug
Model 1000-MR2 Mobile Refrigerator
Double cavity model with 20 gauge, non-magnetic stainless steel
exterior and door, fully insulated with high density foamed-in-place
polyurethane. Doors include two (2) positive door latches with
magnetic-mechanical closing and cylinder door lock. The mobile
refrigerator is controlled by one (1) ON/OFF switch, with a factory set
temperature of 36°F (2°C). A LED display monitors the inside
temperature. Unit includes one (1) transport handle on each end of
the cart, and a full-perimeter stainless steel bumper guard. Cart is
furnished with removable side racks, six (6) powder coated shelves,
six (6) 5" (127mm) heavy duty casters —two (2) rigid and four (4)
swivel with brake and rear power cord storage during transport.
One (1) 1/3 horsepower compressor system utilizes 134a refrigerant,
generating 2560 BTU per hour.
PRINTED IN U.S.A.
COOK/HOLD/ ERVE Y TEM
W164 N9221 Water Street •P.O. Box 450 •Menomonee Falls, Wisconsin 53052-0450 •U.S.A.
PHONE: [phone] FAX: [phone].329.8744 U.S.A. ONLY WEBSITE:
800.558.8744 U.S.A./CANADA 262.251.1907 INTERNATIONAL DIVISION www.alto-shaam.com
®
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
#411 - 06/03
ORDERING INFORMATION:
Specify Fahrenheit or Celsius at time of order.
Specify voltage requirements.
Plate Carriers . . . . . . . . . . .Contact Factory for Capacity
—Covered "C" Carriers . . . . . . . . . . . . . . . . . .DC-2869
—Covered "EC" Carriers . . . . . . . . . . . . . . . .DC-23676
—Uncovered "P" Carriers . . . . . . . . . . . . . . . . .DC-2868
—Uncovered "EP" Carriers . . . . . . . . . . . . . . .DC-23580
Shelf, 26-1/2" x 21-3/4" (673mm x 552mm)
—Powder Coated . . . . . . . . . . . . . . . . . . . . .SH-25676
—Stainless Steel Wire . . . . . . . . . . . . . . . . . .SH-25677
