QC-50 R E M O T E
W I T H ROLL-IN CART
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T,S P E C I F I C AT I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E .PRINTED IN U.S.A. #403A- 04/07
●Enhanced food safety and production efficiency in a flexible
processing system designed to improve work flow and reduce
labor requirements.
●Features include a Quick-Freeze mode, Soft-Chill mode for less
dense items such as individual portions, ard-Chill mode for
products with more density, a olding mode for both chilled or
frozen items, and an automatic defrost.
●Programmable preset capability for up to 20 menu items.
●Safely and rapidly chills or freezes hot foods to proper holding
temperatures well within the ACCP/FDA food code guidelines.
●The Quickchiller process allows chilled foods to be stored for
5 days, including the day of preparation and the day of service.
●Reduces food preparation from a daily schedule to once or twice
a week to provide easier, more cost effective labor scheduling.
●The roll-in pan cart mobilizes chilled product production and is
interchangeable with specified Combitherm®ovens and alo eat®
Combimate®holding cabinets to add to the efficiency of product
movement with effective rack management.
eavy duty stainless steel construction, fully insulated with high density polyurethane foam. The insulated stainless
steel door is hinged left as standard and includes one (1) self-adjusting, rotary door latch. An enclosed mullion heater
is located around the full perimeter of the door to eliminate condensation. The unit includes three (3) internal product
temperature probes, and one (1) fan generating air circulation of 2,200 c.f.m. (62,3m3).
The Quickchiller features an electronic micro processor control with a vacuum florescent display. The control function
includes twenty (20) programmable presets; a display in English, Spanish, or French, and communication capability.
■■MODE QC-50 Remote
ADDITIONA FEATURES & OPTIONS
●The Quickchiller can be connected to a remote refrigeration system utilizing R-404A
refrigerant; a single, 2-1/2 hp compressor developing a total of 9,030 BTU's per hour at
-5°F (-21°C) in the freeze mode and 16,400 BTU's per hour at +20°F (-7°C) in the chill mode.
●Roll-In cart includes twelve (12) non-tilt pans support rails spaced at 2-5/8" (65mm),
six (6) stainless steel wire shelves, removable drip tray, and removable handle.
●Coved inside corners.
●Optional ACCP Documentation software provides the ability to monitor, store,
and print all relevant time and temperature data through a Windows®based PC.
●Optional ACCP with Kitchen Management web-based software provides the ability to
program, control, monitor, and store all relevant data.
PROCESSING FREEZER\CHILLER\REFRIGERATION SYSTEM
ITEM NO. _______________________
ANSI/NSF 7
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./ CANADA FAX: [phone].329.8744 U.S.A. ON Y
WEBSITE: www.alto-shaam.com
®

77-1/4" (1962mm)
53-1/2 (1359mm)*
74-3/4" (1899mm)
38-1/4"
(972mm)*
40-1/2"(1029mm)
35-1/2"
(902mm)
ELECTRICAL CONNECTION
9" (229mm) ADJUSTABLE
31-15/16" (811mm)
50-1/2"(1282mm)
30-1/2"
(775mm)
9"
(229mm)
51" (1295mm)
* Door opening
QC-50 R E M O T E
WITH ROLL-IN CART
O P T I O N S & A C C E S S O R I E S
■■Weather Protective Enclosure S-27871
ACCP Network Software Options
■■ACCP Documentation
■■ACCP with Kitchen Management
REFER TO HACCP SPECIFICATION #9015 FOR APP ICAB E PART NUMBERS.
■■Prechill Sealing Strip 1004781
■■Remote Condenser Package RE-27870
Roll-In Pan Cart (Trolley)
■■12•20 Combitherm and 12•20W Combimate®5814
■■10•20 Gas Combitherm and 12•20W Combimate®55619
■■Wire Shelves, Stainless Steel S -22473
D I M E N S I O N S ( x W x D)
EXTERIOR:77-1/4" x 51" x 35-1/2"
(1962mm x 1295mm x 902mm)
INTERIOR: 59-1/2" x 38-1/4" x 30-1/2"
(1511mm x 972mm x 775mm)
WEIGHT
REMOTE RO -IN
CABINET CONDENSER PAN CART
NET 870 lb (395 kg) 202 lb (92 kg) 120 lb (54 kg)
SHIPPING 1170 lb (531 kg) 302 lb (137 kg) 150 lb (68 kg)
CRATED 55" X48" X88"
DIMENSIONS:(1397mm x 1219mm x 2235mm)
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T, S P E C I F I C A T I O N S A R E S U B J E C T T O C A N G E W I T O U T N O T I C E .P R I N T E D I N U .S.A.#403A- 04/07
I N S TA L L AT I O N R E Q U I R E M E N T S
One (1) Floor Drain: 1/2" (12,7mm) diameter
Unit must be installed level. Unit must not be installed in
any area where it may be affected by steam, grease,
dripping water, high temperatures, or any other severely
adverse conditions.
P R O D U C T \ PA N C A PA C I T Y
Approximately 144 lb (65kg) MAXIMUM C ILLING CAPACITY — 90 quarts (114 liters)
RO -IN PAN CART STANDARD 5814 ❑OPTION 55619
FITS 12•20 ELECTRIC COMBIT ERM FITS 10•20 GAS COMBIT ERM
12•20 COMBIMATE OLDING CABINET 12•20 COMBIMATE OLDING CABINET
FU -SIZE PANS: 20" x 12" x 2-1/2" (GN1/1) 12 12
FU -SIZE SHEET PANS: 18" x 26" x 1" 12* 12*
STAIN ESS STEE WIRE SHE VES: 6 INCLUDED SH-22473 SH-22473
*ON WIRE SHE VES ON Y. EXTRA OPTIONA WIRE SHE VES REQUIRED FOR MAXIMUM CAPACITY.
N.T.S.
C L E A R A N C E R E Q U I R E M E N T S
BACK: 6" (152mm) TOP: 6" (152mm)
SIDES: 4" (102mm) minimum at both sides.
18" (457mm) MIN. FROM EAT PRODUCING EQUIPMENT.
R E F R I G E R AT I O N (OPTIONAL REMOTE CONDENSER PKG.)
R404a Refrigerant
One (1) 2-1/2 hp Condensing Unit:
FREEZE MODE: 9,030 BTU's per hour at -5°F (-21°C)
C ILL MODE: 16,400 BTU's per hour at +20°F (-7°C)
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./ CANADA FAX: [phone].329.8744 U.S.A. ON Y
WEBSITE: www.alto-shaam.com
®
E L E C T R I C A L
CABINET
RECOMMENDED
VO TAGE PHASE CYC E/HZ CIRCUIT AMPERAGE
208-240 1 60 20
RECOMMENDED WIRE SIZE #12/2 w.g.
REMOTE CONDENSER PACKAGE (OPTIONAL)
208-240 1 60 25 AMP LINE
MAX FUSE SIZE: 25 AMP
RECOMMENDED WIRE SIZE #8/2 w.g.
REQUIRES TWO (2) #12 WIRES FROM
QUICKCHI ER TO CONDENSER
