AltRider Hemisphere ALTR-9-4700 Installation guide

INSTALLATION & CARE INSTRUCTIONS
AltRider Hemisphere Heat Shield
Dear Rider,
Thank you for choosing AltRider! Whether a seasoned world adventurer or a
first time ADV-Newbie, we welcome you to the AltRider experience. You can
install your new product with the utmost confidence. AltRider designs, tests,
and manufactures all of its products here in the United States. We are
proud to do what we do, and honored to present to you the product of our
labors.
Enjoy it, show it off, and most of all, RIDE IT!
Venture On,
Jeremy LeBreton
AltRider LLC
mailing: 4000 Aurora Ave N Ste 100
Seattle, WA 98103 USA
phone: [phone]
email: [e-mail]
web: www.altrider.com
Global
Europe
mailing: Oude Middenweg 231-M
2491 AG DEN HAAG
Netherlands
email: [e-mail]
web: www.altrider.eu
AltRider Hemisphere
Heat Shield
Package Contents:
- Heat shield
- Hose clamp
MADE IN THE USA
Rev 0
The most up to date instructions can be downloaded from the product page at altrider.com, under the instructions tab.
made in
USA

2
1
1
1
2
Kit:
Heat shield
Hose clamp
Hemisphere Heat Shield // Installation & Care Instructions
1
2
Tools Needed:
1/4 driver & extension
8mm socket
1
2

2
Apply the (2) red adhesive foam pads as shown on the back side of the heat
shield.
Open up the stainless steel hose clamp all the way and then feed it through the
two slots of the heat shield with the natural bend of the clamp following that
of the heat shield. Keep in mind that when you tighten the hose clamp it will
naturally pull on the slotted end. If you have a very narrow diameter exhaust,
leave lots of room on the slotted side when feeding the hose clamp into the
heat shield.
Fit up to your bike and tighten the hose clamp with a 8mm socket. You will need
to test t your luggage to make sure that the luggage is only touching the heat
shield and not some part of the hot exhaust pipe. Try to position the clamp so
that the fastener is hidden behind the exhaust when fully tightened. Adjust as
needed.
If you are installing this heat guard on a DIRT BIKE, or in between the ex-
haust and a fairing, see step #3.
1
2
Hemisphere Heat Shield // Installation & Care Instructions

3
If you are installing on a dirt bike or between the fairing and the exhaust, it is
much easier to dry t the shield before adding the hose clamp.
IMPORTANT - Test your setup with fully loaded luggage and make sure that the
bike is up to full temp as well. During rst o-road ride inspect at the 50 mile
mark to ensure all plastics and luggage are protected.
3
Hemisphere Heat Shield // Installation & Care Instructions

4
CONGRATULATIONS!
You’ve completed your installation.
If at any point you have questions
about your installation or have any
feed back for us, we’d love to hear it.
A downloadable version of these
instructions can be found at our web
site. www.AltRider.com
After a short test ride, conrm
that your straps are secure and the
Tank Bag is not interfering with the
controls of the motorcycle.
email: [e-mail]
phone: [phone]
address: 4000 Aurora Ave N
Ste 100
Seattle, WA 98103
email: [e-mail]
address: Oude Middenweg 231-M
2491 AG DEN HAAG
Netherlands
