Cateye RAPID X2 User manual

Always charge the product before use.
Attach securely in the mounting position.
USB cable
To PC or USB battery charger
When the remaining battery
power is low, the lighting
mode switch starts flashing
and the lighting mode
changes to flash. Charge the
light as soon as possible.
TL-LD710-R / TL-LD710-F
Manual
RAPID X2
Click
Lighting mode switch
Press
and hold ON OFF
Before using the light, please read this
manual and the included separate sheet
“LITHIUM-ION / LITHIUM-ION POLYMER
BATTERIES” thoroughly, and keep them
for future reference.
ENG
Design Pat. Pending
Copyright© 2014 CATEYE Co., Ltd.
TLLD710R/F-141201 2
HOW TO CHARGE
HOW TO USE
1
HOW TO MOUNT
2
3
or
(MICRO USB)
Light unit USB cable
Rubber band
(Large/Small)
Shade the light with the sticker if you are dazzled.
*Clear lens only (Front model)
1
2
1
2
1
2
OPTION :
2
1
3
Rubber band
Rubber band
Spacer X
Bracket
44
or Clip
Automatic battery-saving function :
Shade sticker
*Clear lens only
(Front model)
PRECAUTIONS ON USE
• Check periodically to ensure that the light
unit is attached securely.
Do not use a damaged rubber band.
• Stop your bicycle to operate the switch.
• Keep the light away from children.
• This unit is not totally waterproof. Please
wipe and dry it completely after using in
rain. Otherwise, it may cause failure.
• If the light unit or parts become dirty with
mud, etc., clean with a soft cloth which is
moistened with mild soap. Never apply
paint thinner, benzine or alcohol; damage
will result.
PRECAUTIONS ON CHARGING
• We recommend using 500+mA (USB2.0)
USB battery charger.
• Charging and lighting times are approxi-
mate values, and will vary by environmen-
tal and user conditions.
HOW TO REPLACE THE BATTERY
When the operating time decreases signifi-
cantly, the battery life is close to an end.
Please contact CatEye local distributor listed
on our website www.cateye.com or CatEye
for replacing battery.
PRECAUTIONS ON DISPOSAL
When disposing of the light unit, remove the
internal rechargeable battery and dispose of
it according to local regulations.
Charging Charging is completed
Standard
charging time Approx. 2 h
(USB 2.0)
Switch (Indicator)
Hi
Approx. 1 h
Low
Approx. 5 h
Vibration
Approx. 8 h
Flash
Approx. 30 h
Pulse
Approx. 16 h
Rapid
Approx. 16 h
ø12 – 32 mm

2-8-25, Kuwazu, Higashi
Sumiyoshi-ku, Osaka 546-0041 Japan
Attn : CATEYE Customer Service
Section
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.cateye.com
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200,
Boulder CO 80301-5494 USA
Phone : [phone]
Toll Free : 800.5.CATEYE
Fax : [phone]
E-mail : [email protected]
CO., LTD.
SPARE / OPTIONAL PARTS
Battery : Rechargeable lithium-ion polymer battery
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times :
About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight: 2-59/64” x 1-13/64” x 1-19/64” (74.4 x 30.5
x 32.9 mm) / 1.08 oz (30.5 g)
* The specifications and design are subject to change without notice.
5447010
Rubber band
5342730
USB cable
(MICRO USB)
SPECIFICATIONS
LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materi-
als and workmanship for a period of 2 years from original
purchase. If the product fails to work during normal use, CatEye
will repair or replace the defect at no charge. Service must be
performed by CatEye or an authorized retailer. To return the
product, pack it carefully and enclose the warranty certificate
(proof of purchase) with instruction for repair. Please write or
type your name and address clearly on the warranty certificate.
Insurance, handling and transportation charges to CatEye shall be
borne by person desiring service. For UK and REPUBLIC OF
IRELAND consumers, please return to the place of purchase.
This does not affect your statutory rights.
5342470
Spacer X
5342460
Clip
(C-2)
Please register your CatEye product on the website.
http://www.cateye.com/en/support/regist/
