Overview:
The Altronix ALTV244-300/220 CCTV Power Supply is designed with four (4) individually fused outputs for powering CCTV
Cameras, environmental housings and other video accessories. It will provide 24VAC distributed via four (4) fused outputs with a
total of 12.5 amps continuous supply current.
Specifications:
• Input 220AC 50/60 Hz, 1.35 amps.
• 24VAC output.
• Four (4) 24VAC individual fuse protected outputs.
• 12.5 amps (300VA) supply current.
• Output fuses are rated at 3.5 amps / 250VAC.
• Surge protection.
• AC power LED indicator.
• Power ON/OFF switch.
• Spare fuse included.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
Enclosure dimensions: 12.25"H x 7.25"W x 4.5"D
Installation Instructions:
1. Mount ALTV244-300/220 in desired location
2. Slide switch SW1 (Fig. 1) to OFF position.
3. Connect the AC (220VAC 50/60 Hz) to the black and
white flying leads of the transformer (Fig. 1) .
4. Connect each camera to terminal pairs 1 to 4,
marked [1P-1N thru 4P - 4N] (Fig. 1) .
Note: Is good operating practice to measure output
voltage before connecting devices. All terminals with
common suffix P 1P, 2P...” are same polarity.
5. Slide switch SW1 (Fig. 1) to ON position.
6. Green LED will illuminate when AC power is present
7. Upon completion of wiring, secure enclosure door
with screws (supplied).
WARNING: To reduce the risk of fire or electric shock, do not
expose the unit to rain or moisture. This installation should be made by
qualified service personnel and should conform to all local codes and in
accordance with the National Electrical Codes.
ALTV244-300/220 - High Current
CCTV Camera & Accessory Power Supply
XFMR
Black Lead
White Lead
220VAC input
50/60 Hz,
1.35 amps
24 VAC fused output 1
(Follow same procedure
using terminals 2P & N
thru 4P & N fused
outputs 2 thru 4)
F1 F2 F3 F4
ON
INPUT
OFF
1P 1N 2P 2N 3P 3N 4P 4N
LED
SW1
MAIN FUSE
NP
PD4A
POWER DISTRIBUTING UNIT
ALTRONIX CORP.
BROOKLYN, NY 11220
MADE IN USA
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
Fig. 1
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
Altronix Corp.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: [email protected], Made in U.S.A.
IIALTV244-300/220 - Rev. 072400
MEMBER
1.25"
1.25"
4.875"
4.875"
1"
.875" 5.5"
1.25"
.875"
7.25"
Enclosure dimensions:
12.25"H x 7.25"W x 4.5"D
