Altronix T28140WP User manual

Overview:
The Altronix T28140WP Outdoor CCTV Camera Power Supply provides 28VAC with a total of 6.25 amp
continuous supply current. The NEMA 4 rated Outdoor enclosure permits installation close to the outdoor
CCTV equipment which reduces the need for long wire runs, which eliminates voltage drop.
Specifications:
Input:
• Input 115VAC 50/60 Hz, 1.5 amp.
Output:
• 28VAC output.
• 6.25 amp (175VA) total supply current.
• Secondary fuse rated @ 3.5 amp/250V.
Additional Features:
• NEMA 4 rated outdoor enclosure.
• Ease of installation saves time and
eliminates costly labor.
Enclosure Dimensions:
12"H x 8"W x 6"D
Installation Instructions:
1. Mount T28140WP in desired location
2. Connect AC power (115VAC 50/60 Hz) to the
black and white flying leads of the transformer
(Fig. 1).
3. Measure output voltage before connecting device.
This helps avoid potential damage.
4. Connect devices to terminal block on the inside
back of the enclosure.
5. Upon completion of wiring, secure enclosure door.
WARNING: This installation should be made by qualified service personnel and should conform to all
local codes and in accordance with the National Electrical Codes.
T28140WP - Outdoor CCTV Power Supply
XFMR
Output
28 VAC 
6.25 amp
Input
115 VAC 
50/60 HZ
1.5 amp
Fig. 1

Altronix Corp.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
web site: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIT28140WP - Rev. 020405 B04E
MEMBER Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
.5" 7.4" 8.77"
2"
0
0
10"
6"
0
0
.75"
.75"
11.25"
12"
8".77"
Enclosure Dimensions:
12"H x 8"W x 6"D
