Alula RE926S-SimonXT WiFi IGM User manual

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
RE926S-SimonXT WiFi IGM
Features
•Connects panels to local WiFi Network
•Compatible with:
oGE Simon XT
oGE Simon XTi
•Enables:
oAlarm Reporting
oInteractive Control Functions
oEthernet data reliability
oZ-Wave Communicator included
Key Instructions
•The same unit works for GE Simon XT & GE Simon XTi.
•RE926S mounts inside the GE Simon XT panel and communicates with the
GE Simon XT and GE Simon XTi via the Expansion Connector.
•Contains RF Module label –must be affixed to exterior of panel enclosure.
Operation
Event Reporting:
Events are reported to both the monitoring receiver and the interactive
server. All events use Contact ID reporting codes. The following events are
reported by default:
Alarms
Alarm cancels
Openings
Closings
System Low Battery
System Low Battery Restoral
AC Power Fail
AC Power Restoral
Interactive Control:
The system may be controlled remotely through the interactive platform.
Z-Wave
Z-Wave devices can be controlled via the Interactive function.
Revert to Factory Default Button
Press and hold for 5 seconds: Resets the board and keeps all settings
Press and hold for 10 seconds: Reverts board back to the factory default settings

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
LEDs
Ethernet LEDs
Indication
Power
(Green)
ON and Flashing once per second when the board is powered and
running
WiFi
(Red)
ON when the unit is registered with the local WiFi router
CS
(Red)
ON when the connection to the central station is established
Platform
(Amber)
ON when the connection to the Panel, and connection to the
interactive server is established
Z-Wave
Module
WPS
Button
Revert to
Factory
Default Button
Wi-Fi
Card
Status LEDs
Z-Wave
Antenna

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
Programming:
1) Refer to server setup instructions and set up the account on the Dealer Portal.
2) Disarm the system.
3) Power down the GE Simon XT system.
4) Plug RE926S into the back of the GE Simon XT control panel. (Picture below)
board communicates via the Expansion Connector.
5) Apply power to the GE Simon XT system.
6) WiFi Protected Setup Connection to Router:
a) Connection to Primary router:
◦Press & release Communicator's WPS button: WiFi LED flashes slowly
◦Press & release Primary Router's WPS button.
◦WiFi LED is steady when fully connected to Primary Router.
b) Connection to Backup router:
◦Press & hold Communicator's WPS button: WiFi LED flashes rapidly
◦Press & release Primary Router's WPS button.
◦WiFi LED is steady when fully connected to Backup Router
7) The keypad should display “Resolution WiFi Module”.
8) Installation is complete.
WiFi Communicator
in the
Expansion Connector

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
WiFi Not connecting
•Verify you have a router that is compatible with the communication board
•Is the router you are using a modem/router combo?
-Get a known compatible WiFi router
-Consult the IT administrator, home owner, or your routers
manual for configuring the router for this application
Specifications
Current Draw: 120 mA Nominal
Temperature Range: 0F to 120F
Housing dimensions: 2x4x1/2 inches
Specifications subject to change without notice.
GE Simon XT Firmware Version Compatibility
1.3 (minimum)

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
THIS PAGE INTENTIONALLY LEFT BLANK

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
THIS PAGE INTENTIONALLY LEFT BLANK

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
Notices
“GE”, “Honeywell”, “DSC”, “2GIG” and “Napco” are trademarks owned by General Electric
Company, Honeywell International Inc., Tyco Safety Products Canada LTD, 2GIG Technologies Inc.,
and NAPCO Security Systems, Inc., respectively.
Alula products will function with one of either GE, Honeywell, DSC or Napco systems. However,
no Alula product is produced by, endorsed by, nor is officially associated with GE, Honeywell, DSC
or Napco. Alula recommends verifying proper enrollment and operation, per control panel
installation instructions, at installation.
Warranty
Alula will replace products that are defective in their first five (5) years.
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference that may be received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by Alula could void the user's authority
to operate this equipment.
FCC ID: U5X-RE926
This device contains FCC ID: W7OMRF24WG0MAMB
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
(1)Reorient or relocate the receiving antenna.
(2)Increase the separation between the equipment and receiver.
(3)Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
(4)Consult the dealer or an experienced radio/TV technician for help.
RF Exposure:
To satisfy FCC RF Exposure requirements for mobile and base station transmission devices,
a separation distance of 20 cm or more should be maintained between the antenna of this
device and persons during operation. To ensure compliance, operation at closer than this
distance is not recommended.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

RE926S_47-0055-00_RevA 19-Apr-18
Tech Support Line: (888)88-ALULA [phone]
alula.net
IC Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1)This device may not cause interference, and
(2)This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1)l'appareil ne doit pas produire de brouillage, et
(2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Model: RE926S
IC: 8310A-RE926
This device contains IC: 7693A-24WG0MAMB
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante.
