Alula RE614-Au User manual

I
N
S
T
A
L
L
G
U
I
D
E
I
Smoke Alarm is a supervised single
station fire-protection device that
alarms when it detects smoke.
Features
• Complies with AS 3786-2014+A1:
• Encrypted wireless transmissions
• Sealed 10 year battery
• 5 year warranty
Quick Start Guide
1. Remove the cardboard piece
between the mounting plate and
smoke alarm.
2. Restore the mounting plate and
twist it fully onto the smoke alarm.
Note: Enrollment is possible only
if the mounting plate is twisted
onto the smoke alarm.
3. Enroll the smoke alarm by placing
the panel into wireless enrollment
mode and then holding down the
smoke’s test button until the smoke
alarm beeps.
4. Remove the mounting plate and
refer to Sections 2 and 6 for
positioning and installation.
5. After mounting plate is installed
restore the smoke alarm onto the
mounting plate and fully test the
smoke alarm per Section 7.
Alternate Enrollment Methods
• Scan the smoke alarm’s bar code
using the Connect+ Installer
App, OR
• Enter the 8-character serial
number on the interactive service
provider’s web portal.
Read and retain carefully for as long as the product is being used. It contains
vital information on the operation and installation of your Alarm. The leaflet
should be regarded as part of the product. If you are just installing the unit,
the leaflet must be given to the householder. The leaflet is to be given to
any subsequent user.
Use the Panel’s installation guide to verify proper system setup.
Test Smoke Alarm
Position Smoke Alarm
300 mm
minimum
300 mm
minimum
2015
RE614-Au Smoke Alarm
Connect+™Encrypted

is responding to a recurring nuisance alarm it
is very important that the offending Alarm is
identifiedsotheproblemcanbeeliminatedby
cleaningorreplacingthisAlarm.Theoffending
Alarm can be identified by a rapidly flashing
red LED. Once the offending Alarm has been
located follow 1.1.5 above.
1.2. Fault Conditions
1.2.1. Low battery
The Alarm will emit a short beep and flash the
YellowLEDwhenitbecomespartiallydepleted.
Check the date when the Alarm should be
replaced which is given on the sidewall of the
Alarm. When electronic self testing indicates
thatthe battery is becominglow the Alarm will
beep and the yellow LED will flash at the same
time (about every 48 seconds) to warn the
user.Thisindicatesthatthebatteryorbatteries
must be replaced.
1.2.2. Contaminated chamber
If the Alarm sounds without any apparent
smoke being present, press the test button to
silence the Alarm for 10 minutes (as described
in 1.1.5 above). If the Alarm sounds again
it may be contaminated. Pressing the test
button again, within 4 minutes of the Alarm
re-sounding,willgetthe Alarm to compensate
for chamber contamination. This will normally
resolve the problem.
If the Alarm re-sounds for a third time, the
Alarm is excessively contaminated and must
be replaced. If it is not convenient to replace
itimmediately, pressing the test buttonwithin
4 minutes of it going into alarm (for the third
RE614-Au Indicator Summary
Normal Operation Action Red LED Yellow LED Sounder
Power Up Twist on Base 1 Flash 1 Flash O
Standby O O O
Sensing Fire Rapid Flashing O Full Sound
Fault Mode Action Red LED Yellow LED Sounder
Low Battery O 1 Flash every 48 sec 1 Beep
Faulty Smoke Sensor O 2 Flashes every 48 sec 2 Beeps
End of Life O 3 Flashes every 48 sec 3 Beeps
Silence Sounding
Alarm
Press & Release Button 1 Flash every 8 sec O O for 10 mins
Silence “End of Life”
indication (up to
30 days)
Press & Release Button O O for 72 hours O for 72 hours
Test Mode Action Red LED Yellow LED Sounder
Test Smoke Alarm Press Button Rapid Flashing O Full Sound
Alarm Memory Action Red Led Yellow LED Sounder
24 Hour Memory 2 Flashes every 48
sec for 24 hours
O O
Long Term Memory Press & Hold Button Rapid Flashing O Rapid Chirping
1.1. Normal Operation
1.1.1. Power Up
Twist off the Alarm from the mounting plate.
TheredLEDwillflashoncefollowedby oneflash
of the yellow LED to indicate that the Alarm
has been powered successfully and is now in
standby mode.
1.1.2. Standby
In standby mode there are no active visible or
audible indications which can be intrusive to
the householder. To confirm that the Alarm is
operational perform a weekly button test.
1.1.3. Weekly button test
Press and hold the test button and verify that
the red LED flashes rapidly and the Alarm
ramps up to full sound.
1.1.4. Sensing Fire
As soon as the Alarm senses smoke it will
go into Alarm. The red LED on the Alarm
sensing smoke flashes rapidly to indicate this
is the Alarm sensing smoke / fire. Follow the
instruction in section 3 and evacuate the
building.
1.1.5. Silence False / Nuisance alarm
Occasionally Smoke Alarms can be activated
by phenomena other than fire, e.g. dust,
insects, cooking fumes. Once you are sure it is
a nuisance alarm press the large test button to
silence the Alarm for 10 minutes – the red LED
will then flash every 8 seconds for 10 minutes.
1.1.6. Nuisance alarm
In the case of a real fire, the occupiers of the
dwelling should proceed to evacuate as per
instructionsinsection3.Howeverifthesystem
2

time) will silence the Alarm for 8 hours –
however it will give two short beeps (second
apart) every 10 minutes to remind the user it
has been disabled. If the contamination clears
the Alarm will return to normal operation.
(Note: this does not reduce the users fire
protection, as a Smoke Alarm in continuous
alarm due to a fault, is useless and must be
silenced – by taking the Alarm down or as
described here. This procedure has the added
benefits that the user is reminded every 10
minutes by two short beeps that the Alarm
needs to be replaced and that if the problem
clears the Alarm will return to detecting fire).
1.2.3. Faulty smoke chamber
In the unlikely event of the smoke sensing
chamber becoming defective, the Alarm will
give 2 short beeps with 2 yellow LED flashes
every 48 seconds. The Alarm must then be
replaced.
Ifit is not convenientto replace it immediately,
pressing the test button will silence the beeps
and stop the yellow LED flashing for 12 hours.
This can be repeated as required.
2. Location and Positioning
Introduction
Congratulations on purchasing a Smoke
Alarm. You can easily install these Alarms
throughout the property on escape routes, on
eachstorey,incorridorsandinclosedroomsto
give warning of fire.
Heat Alarms can be installed in kitchens
and other areas where Smoke Alarms are
unsuitable.
IMPORTANT!
Specific requirements for Smoke Alarm
installation vary from state to state and from
region to region. Check with your local Fire
Department for current requirements in your
area.
SMOKE ALARMS
SufficientsmokemustenteryourSmokeAlarm
beforeitwillrespond.YourSmokeAlarmneeds
to be within 7.5 metres of the fire to respond
quickly. Smoke Alarms also need to be in
positionswheretheycanbeheardthroughout
the property, so they can wake you and your
family in time for everyone to escape. A single
Smoke Alarm will give some protection if it is
properlyinstalled,butmosthomeswillrequire
two or more (preferably interconnected) to
ensure that a reliable early warning is given.
For recommended protection you should put
individual Smoke Alarms in all rooms where
fire is most likely to break out (apart from the
kitchen and bathroom).
Your first Smoke Alarm should be located
between the sleeping area and the most likely
sources of fire (living room for example), but it
should not be more than 7.5 metres from the
door to any room where a fire may start and
block your escape from the house.
Multi-Storey Dwellings
If your home has more than one floor, at least
one Alarm should be fitted on each level (see
Figure 1). Preferably the Alarms should be
interconnected (if feature is present on unit)
so as to give sufficient warning throughout
the property.
Figure 1 illustrates where Smoke and Heat
Alarms should be located in a typical two
storey house. Note the spacings in “Protection
Levels”which ensure the earlydetection of fire
and that the warning will be heard.
Locate Heat Alarms in rooms adjoining escape
routes - kitchens, garages, boiler houses etc.
where Smoke Alarms are unsuitable.
Figure 1
For minimum protection
- Smoke Alarm on each storey
- in each sleeping area
- every 7.5 metres of hallways and rooms
- within 3 metres of all bedroom doors
- all units interconnected (where feature is
present)
For recommended protection
(in addition to the above):
- Smoke Alarms in every room (except
kitchens and bathrooms)
- Heat Alarms located in kitchens, garages
etc. within 5.3m of potential fire sources
Single Storey Dwelling
If the premises is one storey you should put
your first Smoke Alarm in a corridor or hallway
between the sleeping and living areas. Place it
as near to the living area as possible, but make
sure that it can be heard loudly enough in the
bedroom to wake someone. See Figure 2 for
placement example.
In houses with more than one sleeping area,
SmokeAlarmsshouldbeplacedbetweeneach
sleeping area and the living area and it is
recommended that Heat Alarms should be
placed in the kitchen and garage.
3

Figure 3
PLACE IN CENTRAL
LOCATION AND
NOT WITHIN
305mm (12”)
OF ANY CORNER
SMOKE ALARMS
<610mm (24”) FROM
APEX
DEAD
AIR
SPACE
Wall Mounting
Ifceilingmountingisimpractical,SmokeAlarms
may be mounted on a wall, provided that:
a) the top of the detection element is between
150mm(6”)and305mm(12”)belowtheceiling;
b) the bottom of the detection element is
above the level of any door openings;
Wallmountingshouldonlybeconsideredwhere
closespacedbeamsorsimilarobstructionsmay
preclude ceiling mounting. It is considered to
be the responsibility of the installer/client to
determine if the presence of asbestos in the
ceiling material would make ceiling mounting
‘impractical’.
On a Sloping Ceiling
With a sloping or peaked ceiling install a
Smoke Alarm within 610mm (24”) of the peak
(measured vertically). If this height is less than
610mm (24”) the ceiling is regarded as being
flat (see Figure 4).
Figure 4
SMOKE ALARMS
<610mm (24”)
APEX
xx
Locations to avoid
DON’T place Smoke Alarms in any of the
following areas:
• Bathrooms, kitchens, shower rooms, garages
or other rooms where the Smoke Alarm may
betriggeredbysteam,condensation,normal
smoke or fumes. Keep at least 6 metres (20ft)
away from sources of normal smoke/fumes.
• Locate away from very dusty or dirty areas
as dust build-up in the chamber can impair
performance.Itcanalsoblocktheinsectscreen
mesh and prevent smoke from entering the
smoke detector chamber.
Figure 2
Bedroom
Bedroom
Bedroom
Bathroom
Bath
Dining Room
Laundry
Room
Living Room
Kitchen
Recommended Protection
Fireauthoritiesrecommendyouputindividual
Smoke Alarms in or near all rooms where fire
is most likely to break out (apart from the
locations to avoid e.g bathrooms). The living
room is the most likely place for a fire to start
at night, followed by the kitchen (where a
Heat Alarm is recommended) and then the
diningroom.Considerationshouldbegivento
installingSmokeAlarmsinanybedroomswhere
fires might occur, for instance, where there is
an electrical appliance such as an electric
blanket or heater, or where the occupant is
a smoker. In addition, consideration should
be also given to installing Smoke Alarms in
any rooms where the occupant is unable to
respond very well to a fire starting in that
room, such as an elderly or sick person or a
very young child.
Checking Alarms Can Be Heard
With the Alarms sounding in their intended
locations check that the alarm can be heard
in each bedroom with the door closed, above
the sound of any TV/audio systems. The TV/
audio systems should be set to a reasonably
loud conversation level. If you cannot hear
the alarm over the sound of the TV/audio
system, the chances are it would not wake
you.InterconnectingtheAlarms(whenfeature
present) will help to ensure that the alarm will
be heard throughout the property.
Positioning
Ceiling Mounting
Hot smoke rises and spreads out, so a central
ceiling position is the recommended location.
The air is “dead” and does not move in corners,
therefore Smoke Alarms must be mounted
away from corners. Keep at least 300mm from
walls and corners (see Figure 3). Additionally,
mount the unit at least 300mm from any
light fitting or decorative object which might
prevent smoke entering the Smoke Alarm.
4

for separate disposal, handle carefully to
avoid possible eye damage or skin irritation if
battery has leaked or corroded.
• To maintain sensitivity to smoke, do not
paint or cover the Alarm in any manner; do
notpermitanyaccumulationofcobwebs,dust
or grease.
• If Alarm has been damaged in any way or
does not function properly, do not attempt
a repair - see section 5 ‘Getting Your Alarm
Serviced’.
•This appliance isintended ONLY forpremises
having a residential type environment.
• This is not a portable product. It must be
mounted following the instructions in this
instruction leaflet.
• SmokeAlarmsarenot asubstitutefor insurance.
The supplier or manufacturer is not your insurer.
Fire Safety Hints
Store petrol and other flammable materials in
proper containers.
Discard oily or flammable rags.
Always use a metal fireplace screen and have
chimneys cleaned regularly.
Replace worn or damaged sockets, switches,
home wiring and cracked or frayed electrical
cords and plugs.
Do not overload electrical circuits.
Keep matches away from children.
Never smoke in bed. In rooms where you
do smoke, always check under cushions for
smouldering cigarettes and ashes.
Be sure all electrical appliances and tools have
a recognised approval label.
Smokealarmsarenottobe used with detector
guards unless the combination has been
evaluatedandfoundsuitableforthatpurpose.
This device cannot protect all persons at all
times. It may not protect against the three
most common causes of fatal fires:
1. Smoking in bed.
2. Leaving children at home alone.
3. Cleaning with flammable liquids, such as
petrol.
Further information can be obtained from the
Fire Department.
• Do not locate in insect infested areas.
Smallinsectsgettingintothe smokedetector
chamber can cause intermittent alarms.
• Places where the normal temperature can
exceed 100°F (38.7°C) or be below 40°F
(4.4°C) (e.g. attics, furnace rooms, directly
above ovens or kettles etc.) as the steam
could cause nuisance alarms.
• Near a decorative object, door, light fitting,
window moulding etc., that may prevent
smoke from entering the Alarm.
• Surfaces that are normally warmer or colder
than the rest of the room (e.g. attic hatches).
Temperature differences might stop smoke
from reaching the Alarm.
• Next to or directly above heaters or air
conditioning vents, windows, wall vents etc.
that can change the direction of airflow.
• In very high or awkward areas (e.g. over
stairwells) where it may be difficult to reach
the Alarm (for testing, hushing or battery
replacement).
• Locate the Alarm at least 1m (39”) from
dimmer controlled lights and wiring as some
dimmers can cause interference.
• Locate Alarm at least 1.5m (59”) and route
wiring at least 1m away from fluorescent
light fittings as electrical “noise” and/or
flickering may affect the unit.
3. Fire Safety Advice
Whenusinghouseholdprotectivedevices,basic
safety precautions should always be followed,
including those listed below
• Please read all instructions.
•Rehearseemergencyescapeplanssoeveryone
at home knows what to do in case the alarm
sounds.
• Use the Alarm Test Button to familiarise your
family with the Alarm sound and to practice fire
drillsregularlywithallfamilymembers.Drawup
a floor plan that will show each member at least
2 escape routes from each room in the house.
Children tend to hide when they don’t know
what to do. Teach children how to escape, open
windows, and use roll up fire ladders and stools
without adult help. Make sure they know what
to do if the alarm goes off.
• Constant exposures to high or low
temperatures or high humidity may reduce
battery life.
• Nuisance alarms can be quickly silenced by
fanningvigorouslywith a newspaperorsimilar
to remove the smoke or press the test / hush
button.
• Do not attempt to remove, recharge or burn
the battery, as it may explode.
• If it is necessary to remove the battery
5

4. Alarm Limitations
Limitations of Smoke Alarms
While Smoke Alarms are extremely effective,
independentauthorities havestated that they
may be ineffective in some circumstances.
There are a number of reasons for this:
• Smoke Alarms will not work if the batteries
are depleted or if they are not connected.
Replace the batteries if necessary. Also check
the replace by date on the side of the Alarm.
• Smoke Alarms will not detect fire if sufficient
smoke does not reach the Alarm. Smoke may
be prevented from reaching the Alarm if the
fire is too far away, for example, if the fire is
on another floor, behind a closed door, in a
chimney, in a wall cavity, or if the prevailing
air draughts carry the smoke or heat away.
Installing Smoke Alarms on both sides ofclosed
doors and installing more than one Alarm as
recommended in this leaflet very significantly
improve the probability of early detection.
• The Smoke Alarms may not be heard.
• A Smoke Alarm may not wake a person who
has taken drugs or alcohol.
• The Alarms may not detect every type of
fire to give sufficient early warning. They
are particularly ineffective with: fires caused
by smoking in bed, escaping gas, violent
explosions, poor storage of flammable rags
and/or liquids, (for example petrol, paint,
spiritsetc),overloadedelectricalcircuits,arson,
children playing with matches.
• Current studies have shown smoke alarms
may not awaken all sleeping individuals, and
that it is the responsibility of individuals in the
household that are capable of assisting others
to provide assistance to those who may not
be awakened by the alarm sound, or to those
whomaybeincapableofsafelyevacuatingthe
area unassisted
Limitations of Heat Alarms
There are various situations where a Heat
Alarm may not be effective:
• Fires where the victim is intimate with a
flaming initiated fire; for example, when a
person’s clothes catch fire while cooking.
• Fires where the heat is prevented from
reaching the Heat Alarm due to a closed door
or other obstruction.
• Incendiary fires where the fire grows so
rapidly that an occupant’s egress is blocked
even with properly located Heat Alarms
5. Getting Your Alarm Serviced
If your Alarm fails to work after you have
read the sections on “Installation”, “Testing,
Planning Your Escape Route For When The
Alarms Sound
1. Check room doors for heat or smoke. Do not
openahotdoor. Useanalternateescaperoute.
Close doors behind you as you leave.
2. If smoke is heavy, crawl out, staying close to
floor. Take short breaths, if possible, through a
wet cloth or hold your breath. More people die
from smoke inhalation than from flames.
3. Get out as fast as you can. Do not stop
for packing. Have a prearranged meeting
place outside for all family members. Check
everybody is there.
4. Call the Fire Brigade from a neighbour’s
houseormobilephone.Remembertogiveyour
name and address.
5. NEVER re-enter a burning house.
6

Maintenance and Power Supply Monitoring”,
then contactCustomer Assistanceatthe nearest
address given at the end of this leaflet. If it needs
to be returned for repair or replacement put it
in a padded box with the battery disconnected.
Send it to “Customer Assistance” at the nearest
address givenontheAlarmor in this leaflet.State
the nature of the fault, where the Alarm was
purchased and the date of purchase.
6. Installation
Installation Procedure
1. Select a location complying with the advice
in Section 2.
2. Lift off the mounting plate from the Smoke
Alarm.
3. Place the mounting plate on the ceiling
exactly where you want to mount the Alarm.
With a pencil, mark the location of the two
screw holes.
4. Takingcare toavoidanyelectrical wiringinthe
ceiling, drillholes usinga5.0mm drillbitthrough
the centre of the marked locations. Push the
plastic screw anchors provided into the drilled
holes. Screw the mounting plate to the ceiling.
Figure 5
ROTATE UNIT ANTI-CLOCKWISE
UNIT WILL NOT TWIST OFF - IT MAY BE
TAMPERPROOFED - SEE FIGURE 8
5. Insert the battery or batteries as per the
Quick Start Guide, ensuring the orientation
is correct. If the battery is already installed in
your Alarm just pull the battery tab to power
the Alarm.
6. Carefully line up the Alarm on to the
mounting plate, gentle press home and twist
clockwise.
Install all the other Alarms similarly.
7.PresstheTestbuttononeachAlarmtoensure
that the Alarm works (see Figure 6).
Figure 6
Smoke Alarm
Tamperproofing the Alarm
TheAlarmcanbemadetamperprooftoprevent
unauthorised removal of the Alarm.
Break off the small pillar on the base as shown
in Figure 7a.
To remove the Alarm from the ceiling it is now
necessarytousea small screwdriver, to release
the catch (push catch towards the ceiling) and
then twist off the Alarm (see Figure 7b).
Figure 7a - How to Tamperproof
BREAK OFF
SMALL PILLAR
Figure 7b - How to Remove
PUSH UP CATCH & TWIST
ALARM ANTI-CLOCKWISE TO REMOVE
If necessary it is possible to further secure
the Alarm by using a No.2 or No.4 (2 to 3mm)
(1/8”) diameter - not supplied) self tapping
screw 6 to 8mm (1/4”) long (see Figure 7d), to
firmly lock the Alarm and its mounting plate
together (see Figure 7c).
7

Figure 7c
TAMPERPROOF SCREW
Figure 7d
6 to 8 mm
2 to 3 mm
SELF TAPPING
SCREW
Attach the Alarm to the mounting plate.
Line up the screw (not supplied) on the “U”
shaped recessed area shown in Figure 7c and
screw firmly home.
To remove the Alarm from the ceiling,
remove the screw first, and then twist off
anti-clockwise.
7. Testing, Maintenance and
Power Supply Monitoring
YourAlarmisalifesavingdeviceandshouldbe
checked periodically.
7.1 Manually Testing your Alarms
It is recommended that you test your Alarms
after installation and then at least weekly to
ensure the units are working. It will also help
you and your family to become familiar with
the sound of the Alarms.
- Press and hold the Test Button until the
Alarm sounds and the red light flashes (see
Figure7). TheAlarm will stop soundingshortly
after the button is released.
- Repeat this procedure for all other Alarms in
the system.
WARNING: Do not test with flame.
This can set fire to the Alarm and damage the
house. We do not recommend testing with
smoke as the results can be misleading unless
special apparatus is used.
When you press the Test button it simulates
the effect of smoke in a Smoke Alarm which it
could experience in a real fire.
7.2 Test/Silence Button to Control Nuisance
Alarms
The Smoke Alarms have a combined Test/
Silence button to help you control nuisance/
false alarms.
If, when the Alarm sounds, there is no sign of
smoke or noise to indicate that there is a fire,
it should be assumed that it is due to an actual
fire and the dwelling should be evacuated
immediately.
Check the house carefully in case there is a
small fire smouldering somewhere.
Check whether there is some source of smoke
or fumes, for example cooking fumes being
drawn past the Alarm by an extractor.
If there are frequent nuisance/false alarms
it may be necessary to re-locate the Smoke
Alarm away from the source of the fumes.
1. To cancel a false alarm from a Smoke Alarm
(which has its red light flashing rapidly), press
the Test/Silence button (the Smoke Alarm will
automatically switch to a reduced sensitivity
condition).
The Smoke Alarms will be silenced for a period
of approximately 10 minutes. The red light on
the cover of the Smoke Alarm will flash every
8 seconds to indicate that the unit has been
silenced.
2. The Smoke Alarm will reset to normal
sensitivity at the end of the silenced period
(10 minutes). If additional silenced time is
required, simply push the Test/Silence button
again.
3. If kitchen usage/layout is such that there
are an unacceptable level of nuisance alarms,
re-locatetheSmokeAlarmfurtherawaywhere
it will be less affected by cooking fumes etc.
We recommend the use of a Heat Alarm in the
Kitchen area to avoid such nuisance alarms.
7.3 Power Supply Monitoring
7.3.1 What to do when an Alarm is beeping:
A Smoke Alarm is beeping about every 48
seconds with the yellow light flashing at the
same time:
- The battery contained in the smoke alarm is
low. Replace the entire smoke alarm.
Dispose of used smoke alarm promptly. Keep
away from children. Do not disassemble and
do not dispose of in fire
7.4 Cleaning your Alarm
Clean your Alarm regularly. Use a soft bristle
brushorthebrushattachmentofyourvacuum
cleaner to remove dust and cobwebs from the
side slots where the smoke enters. To clean
the cover, wipe with a damp cloth and dry
thoroughly.
WARNING: Do not paint your Alarm.
Other than the maintenance and cleaning
described in this leaflet, no other customer
servicing of this product is required. Repairs,
8

automatically tests itself every 16 seconds.
If the chamber is degraded it will beep twice
every 48 seconds with 2 yellow LED flashes at
the same time. If this happens clean the unit.
If the beeping persists and the beep does not
coincide with a yellow light flash, return the
unit for service (see Section 5 - Getting Your
Alarm Serviced).
8.7 Dust and Insect Contamination
All Smoke Alarms and particularly the optical
(photoelectric) type are prone to dust and
insect ingress which can cause false alarms.
The latest design, materials and
manufacturing techniques have been
used in the construction of Alula Holdings
LLC’s Alarms to minimise the effects of
contamination. However it is impossible
to completely eliminate the effect of dust
and insect contamination, and therefore, to
prolong the life of the Alarm you must ensure
that it is kept clean so that excess dust does
not build up. Any insects or cobwebs in
the vicinity of the Smoke Alarm should be
promptly removed.
In certain circumstances even with regular
cleaning, contamination can build up in the
smoke sensing chamber causing the Alarm
to sound. If this happens the Smoke Alarm
mustbereturnedforservicingorreplacement.
Contamination is beyond our control, it is
totallyunpredictableandisconsiderednormal
wear and tear. For this reason, contamination
is not covered by the guarantee and a charge
is made for all such servicing work.
8.8 End of life
The entire Alarm must be replaced if:-
• The unit is installed for over 10 years (check the
“replace by” date marked on the side of the unit).
Do not put the Alarm into a fire.
The Alarm should be disposed in a safe and
environmentally sound manner at your local
recycle centre. Contact your local authority for
further advise.
8. Troubleshooting
Alarms sound for no apparent reason
• Check for fumes, steam, etc. from the kitchen
or bathroom. Paint and other fumes can cause
nuisance alarms.
• Check for any sign of contamination such as
cobwebsor dust. CleantheAlarm as described
in Section 8 if necessary.
• Press the Test/Silence button on the Smoke
AlarmcausingtheAlarm(thiscan be identified
as the Alarm with the red light flashing
when needed, must be performed by the
manufacturer.
7.5 Chamber Cleaning
Cleaning or replacing of the chamber cover
should only be carried out by suitably trained
personal.
1.Remove the Alarm from themounting plate.
2. Remove the battery or batteries.
3. With a flat screwdriver unclip the three
cover clip points (see figure 8a).
4. Remove the cover (see figure 8b).
5. To remove the chamber top turn the
chamberanti-clockwiseapprox.15degrees
(see figure 8d).
6. Blow out or use a soft bristled brush to
remove dust and dirt form the chamber
base.
7. Fit a new chamber top and clip in place by
turning clock-wise 15 degrees.
8. Place the cover back on the Alarm.
9. Press the test button to ensure the Alarm is
working correctly.
Figure 8a
Figure 8b
Figure 8d
8.6 Smoke Alarm Automatic Self-Test
The smoke chamber in the Smoke Alarms
9

rapidly) – this will silence the Smoke Alarm
for 10 minutes (and also silence all other
interconnected Alarms in the system).
The Alarm fails to sound when the Test
button is pressed
• Check the age of the unit - see the “replace
by” label on side of unit.
10

11
This Page Intentional Left Blank

Pro Tip
Pressing the test button on the smoke alarm will beep both the panel
and smoke alarm.
Specications
Physical
Housing Dimensions
Weight with Batteries
Mounting Fastener
115 mm (diameter) x 45 mm (height)
200 grams
#6 screws and anchors (provided)
Environmental
Operating Temperature
Maximum Humidity
0°C to 40°C
15% to 95% non-condensing relative humidity
Sensor Specications
Frequency
Battery Life
Transmitted Indications
Loudness
Smoke Sensitivity
Smoke Sensor Type
433.92 MHz
10 Years
Low Battery, Supervision
85 dBA at 3 metres minimum
Complies with EN 14604:2005
Photoelectric
Certication
RE614-Au AS/NZS 4268:2017, AS 3786:2014+A:2015,
VdS approved to: BS EN14604:2005,
ActivFire Product Listing
Specications subject to change without notice.
WARRANTY
Alula will replace all non-portable products that are
defective in their rst ve (5) years and all defective
portable products in their rst two (2) years.
The Smoke Alarms comply with AS 3786-2014
The crossed out wheelie bin symbol that is on your
product indicates that this product should not be
disposed of via the normal household waste stream.
Proper disposal will prevent possible harm to the
environment or to human health. When disposing
of this product please separate it from other waste
streams to ensure that it can be recycled in an
environmentally sound manner. For more details on
collection and proper disposal, please contact your
local government ofce or the retailer where you
purchased this product
47-0032-08 • RevB • 2018-03-09
Tech Support Line • (888) 88-ALULA • [phone]
alula.net
