Aluratek ABH05F User manual

Package Contents
Product Highlights Button Operation
Device Operation
Device Operation
qsg Q10546 Copyright © 2020 Aluratek, Inc. All Rights Reserved.
model ABH05F
Quick Start Guide
Bluetooth Wireless Stereo
Headphones
Charging the battery
The battery is not fully charged and it is highly recommended that you charge
ABH05F before you begin using it.
Note: Using ABH05F “out of the box” will not harm the device. You will experience reduced battery life
as the unit will not be fully charged.
Connect the larger USB end of the provided cable to your computer / power
adapter (not included). Connect the smaller micro USB end tothe USB port of
ABH05F. Please charge the battery for a minimum of 3 hours. The red LED will be
on while charging. When charging is complete, the blue LED will turn ON.
Device Operation
3.5mm music line-in function
Connect the audio line-in 3.5mm cable to 3.5 audio jack for wired music.
1. Connect the 3.5 audio wire to the headphone and audio player.
2. You can adjust the volume from the connected audio player or mobile phone.
Note: Phone function cannot be used in this mode
Button Operation
Note: The pairing mode will last 10 minutes. ABH05F will power off automatically if no devices can be
connected within 10 minutes.
Pairing with an iPhone, smartphone or tablet:
The pairing procedure will vary depending on the actual device. Please refer tothe
user guide of your device for detail instruction. The pairing procedures are as follows:
1. Make sure ABH05F is powered OFF.
2. To activate the headphone pairing mode, power on ABH05F, it will enter pairing
mode automatically. (Red and Blue LED will flash rapidly)
3. Activate your device’s Bluetooth function and set your device to search for
Bluetooth devices. Select ABCTVKITH when it is found.
4. For transmitter with Bluetooth version 2.1, you will not need to input a code.
If you are prompted for PIN, please enter “0000”.
5. If prompted by your device to connect, please select “Yes”.
6. After connecting successfully, the blue LED will flash once every 10 seconds.
Note: Please make sure the audio output is set to Bluetooth for audio streaming from the device.
USB Cable 3.5 mm Cable
Your order has been carefully packaged and inspected. The following accessories should be included in your package. Please
inspect the contents of the package to ensure that you have received all items and that nothing has been damaged. If you
discover a problem, please contact us immediately for assistance.
Microphone
Answer Call / End Call /
Play / Pause
Multifunction Button
Micro USB
Charging Port
3.5mm (AUX)
LINE IN Port
Bluetooth
Status LED
ON / OFF
Volume Control
Volume Adjust: Press the or buttons to adjust the volume.
Play/Pause: Short press the button to play and pause music.
Previous: Long press the button for 2 seconds to return to
the previous music track.
Next: Long press the button for 2 seconds to advance to the
next music track.
Answer Call: Short press the button to answer phone calls.
End call: Short press the button to end the phone call.
Reject call: Press and hold the button for 2 seconds to reject a call.
Last number redial: In standby status, press the button twice to redial the
last number.
Battery Capacity status: When the headphones are connected to an iOS
device, the headphone battery power status is visible in the upper right corner.

Warranty
Aluratek warrants this product against defect in material or workmanship for
1 YEAR from the date of purchase.
This warranty becomes invalid if the factory-supplied serial number or "warranty
void" sticker has been removed or altered on the product.
This warranty does not cover:
A) Cosmetic damage or damage due to acts of God
B) Accident, misuse, abuse, negligence or modification of any part of the product.
C) Damage due to improper operation or maintenance, connection to improper
equipment, or attempted repair by anyone other than Aluratek.
D) Products sold AS IS or WITH FAULTS.
IN NO EVENT SHALL ALURATEK'S LIABILITY EXCEED THE PRICE PAID FOR
THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE
PRODUCT, IT'S ACCOMPANYING SOFTWARE, OR IT'S DOCUMENTATION.
Aluratek makes no warranty or representation, expressed, implied, or statutory,
with respect to it's products, contents or use of this documentation and all
accompanying software, and specifically disclaims it's quality, performance,
merchantability, or fitness for any particular purpose. Aluratek reserves the right to
revise or update it's product, software or documentation without obligation to notify
any individual or entity.
If you need further assistance, please contact the Aluratek support department
for troubleshooting prior to returning this device.
E-mail: [email protected]
Web: www.aluratek.com/helpdesk
Local (Irvine, CA): 714-586-8730
Toll free: 1-866-580-1978
Radio and TV Interference Statement
WARNING!!! This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by whatever measures may be required to correct the interference.
