Alutech 500 Series User manual

Alutech 500 Standard
High quality construction
ensures a robust and stable
chair that can be mounted
to the deck, or Alutechs
range of deck rails.
Design and features
• Height adjustable
armrests
• Flip backarmrests
• Easily removable
armrest top
• Armrests accommodate
attachments for control
equipment and cup
holders etc
• Sitting height adjusted with
gas-struts
• Easy removable seat
cushion
• Backrest angle andjusted
with gas-struts
• Adjustable lumbar support
as standard
• Chair rotates 350°
and locks in any position
• Shock absorbing column
• Cable routing through the
chair and center column
• Footrest height adjusted
with gas-struts
• Fold up footrest
• Footrest rotates with chair
and is supported by the
column for stability
• No direct metal to metal
contact
• Constructed with
pressure die cast and
injection molded parts,
and extruded profiles.
No welded parts
• Power coat colour:
Metal Grey A1012724
ALUTECH
500 STANDARD
In-Mar Solutions, LLC
Ph: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.inmarsolutions.com

Seat
Alutech 520
Alutech 525
Alutech 530
Alutech 540
Alutech 550
Sitting Height
420 - 490 mm
550 - 750 mm
630 - 880 mm
730 - 980 mm
830 - 1030 mm
Minimum
Chair Height
1260 mm
1390 mm
1470 mm
1570 mm
1670 mm
Maximum
Chair Height
1330 mm
1590 mm
1720 mm
1820 mm
1870 mm
Chair
Weight
41 kg
50 kg
51 kg
52 kg
53 kg
HSC
Code
12 g
12 g
12 g
12 g
12 g
Footrest
No
Yes
Yes
Yes
Yes
Ø10 mm
360 mm
176 mm 300 mm
Ø10 mm
360 mm
176 mm 300 mm
Ø10 mm
360 mm
176 mm 300 mm
Chair rotation.
Position of
limitation can
be adjusted for
every 90º and
can be fixed in
any position.
Minimum
Chair Swing
Diamater 870 mm
Maximum Recline
Maximum
Chair Swing
Diamater 1290 mm
Sitting
Height
Footrest
Height
Adjustment
520 mm 980 mm
500 mm
705 mm
10º
Maximum
Recline
Armrest
Rotation
Min / Max Chair Height
Chairs - 500 series - Standard
In-Mar Solutions, LLC
Ph: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.inmarsolutions.com

FOOTPLATE ADJUSTMENT
The footrest folds back easily if space is
needed either for rotation of the seat or
simply to change working position.
CHAIR ROTATION
Push lever forward to enable rotation of
the seat. It is recommended to lock the seat
in desired position by firmly pulling the lever
backwards until the chair is fixed.
CHAIR HEIGHT ADJUSTMENT
To adjust sitting height, gently lift the lever
until desired position. As the function is
operated by gas struts, please leave the seat
to lift the height, but/or remain in the seat to
lower the height.
FOOTREST HEIGHT
ADJUSTMENT
Lift the lever gently and press footrest down
to extend space for legs or let the gas strut lift
to desired position.
USER MANUAL
500 / 600 SERIES
MANUALS / TOOLKIT
Toolkit, installation- and user manuals are
inserted under the footrest and included for
each chair delivered.
For more detailed information please refer to
intallation- og user manual which follows every chair delivered.
Please maintain the seat upholstery with mild detergents or as recommended.
BACKREST ADJUSTMENT
Lift the lever gently to recline the seat
back to desired position. The max reclining
is limited depending on the type of Alutech
500 delivered.
DECK RAIL MOVEMENT
Lift the lever fully to release the brake from
the deck rail. Please assure to push the lever
fully down to lock the chair in the desired
location. The chair should always be locked
on the deck rail to avoid personal damage.
LUMBAR SUPORT
Use the pump mechanism to adjust the
lumbar support. The pump can be easily
reached when user is seated.
ARMREST
HEIGHT
ADJUSTMENT
(500 and 600 series only)
To adjust the height of
the armrest loosen the
adjustment wheel/clip.
Hold firmly under the
armrest base and lift up
or press down to
desired position. There is
an indicator on the base to
assure correct height on
both sides.
ARMREST
ROTATION
Flip armrest backwards
at convenience if easier
access or more space is
required.
LOGO
Customer logo
stitched on the back
(or front) of seats
is available.
User Manuals - 500 / 600 Series
