OPS-AC Release Note
Mar 2006

Alvarion Ltd
Page 2 of 3
Introduction
The OPS-AC is a member of the OPS family of Outdoor Power Supply units that are
intended to be used with different Alvarion radio units in applications where there is
a need to install the power supply unit outdoors. Video surveillance and Homeland
security are two such applications that will require the use of the OPS-AC.
Note that while the OPS-AC is designed for extended temperatures, it is not
waterproof and should not be exposed to direct outdoor humidity. It is therefore
required to always install the OPS-AC inside an outdoor box that protects it from the
outdoor humidity.
The OPS-AC, an Extended Range Outdoor Power Supply Unit is:
o A compact unit, fully operational in temperature range of -40 to 55°C
o Functionally (but not physically) similar to the existing IDU
The OPS unit can replace the regular Alvarion indoor power supply unit (IDU) in the
Following product lines:
o BreezeMAX: CPE and PRO CPE
o BreezeACCESS VL: SU and Stand-Alone AU (AU-SA)
o BreezeNET B: BU and RB
o BreezeNET DS11: BU and RB (version 4.0 and higher)
The table below lists the specifications of the main parameters of the OPS-AC:
OPS-AC Specification
Input voltage 100 – 240 VAC
Input Frequency 47 – 63 Hz
Electrical
Input Current 1.5 A
Output Voltage 55 VDCOutput
Output Current 1.0 A
Environmental Operating Temperature -40 to 55
o
C (-40 – 131
o
F)
Humidity 5%-95% non condensing
Mechanical Dimensions 14 x 6.6 x 3.5 Cm (5.5x2.6x1.4 inch)

Alvarion Ltd
Page 3 of 3
OPS-AC Specification
Weight 0.3 Kg (0.7 lb)
Safety TUV / UL 60950-1
EN 60950-1
CE
EMC FCC Part 15 (Emission)
Standard and
Regulations
RoHS Compatible
Version Compatibility and Interoperability
The OPS-AC is fully compatible to the IDU that is used with the BreezeACCESS VL,
BreezeNET B and DS11 (Rev 4.0 and above).
The OPS-AC is compatible to the BreezeMAX product line and can replace the
BreezeMAX CPE-IDU-DATA with one limitation that the Wireless Link LED
functionality of the BreezeMAX IDU is not supported in the OPS-AC (in fact the
Wireless Link LED is not active). This should not interfere with the proper operation
of the OPS-AC with the BreezeMAX CPE-ODU.
Documentation
OPS-AC is shipped with a short installation guide inside the package.
When lightning protection is an issue, please refer also to the Lightning Protection
document, available in the Alvarion web site.
Known Limitations
None.
How to order
New
Part Number
Description
858553 OPS-AC
