ALVEO3D V2 User manual

ALVEO3D
INSTRUCTION
MANUAL
v1.1 EN
Electronic controller board V2
for filtering system ALVEO3D
Find all our tutorials and tips
www.alveo3d.com/en/board-v2-assembly/

ELEMENTS PROVIDED
Elements included in the board v2 package
Hexagonal nut M3 x4
Cylindrical screw M3 20mm x4
Electronic board v2
Power supply wire from v1 to v2 length 90 cm
Temperature probe length 90 cm
Tool needed
Hexagonal key 2.5 mm

STEP 5 - AUTOMATIC MODE p. 10
CONNECT V2 TO V1 p. 3
STEP 5 - AUTOMATIC MODE p. 11
ACTIVATION : START SCREEN p. 4
STEP 5 - AUTOMATIC MODE p. 12
STEP 2 - MODES p. 6
STEP 6 - EDIT PROFILES p. 13
STEP 3 - FAST CLEAN MODE p. 7
STEP 6 - EDIT PROFILES p. 14
STEP 4 - MANUAL MODE p. 8
STEP 7 - FILTER INITIALIZATION PROCESS p. 15
STEP 4 - MANUAL MODE p. 9
STEP 1 - MAIN INFORMATION p. 5
STEP 8 - END OF FILTER INITIALIZATION PROCESS p. 16
SECURITY p. 1
COMPOSITION BOARD V2 p. 2
STEP 9 - FILTER INFO & PROFILES REINITIALIZATION p. 17
STEP 10 - OPTIONS V2 p. 18
STEP 11 - LEDS & ERRORS p. 19
STEP 11 - LEDS & ERRORS p. 20
SUMMARY

Read the conditions of use :
The electronic board v2 is designed to work with alveoONE
filtering kits. If you used the board v2 with other devices than
recommended, no responsibility can be accepted in case of
system malfunction.
The electronic board v2 (version 2.1 or more) is powered by the
alveoONE filtering electronic board v1 (version 1.3 or more). You
must switch on the filtering box to run the electronic board v2.
1
The board v2 is delivered printed and assembled. In the case of
opening by the user, all damage will be under his responsibility.
The recommended operating temperatures of the board v2 are
from 0°C to 50 °C in an enclosure. Beyond this temperature, we
recommend using the electronic board v2 outside of the
enclosure.
While the fan is running always make sure the grid is on the
filtering box to avoid danger from the blades.
SECURITY ( Please refer to instruction before use )

2
Validation
Menu
Back
+
-
The board v2 is provided and assembled with the power wire and temperature
probe.
Power wire V1
(to alveoONE & alveoONE-R)
Temperature
probe
LED
Green
LED
Orange
COMPOSITION BOARD V2
find board V2 tutorials on :
www.alveo3d.com/en/tutorial-v2/
Connector
Temperature probe
Connector V1 RS 232
VCC / DQ / GND
Red / Yellow / Black
GND / VCC / PWM / Tin TX_v2 / RX_v2 / GND

3
Connect the 4 pins cable provided on the v1 connector called BOARD V2.
The electrical supply comes from the v1 board, you shall turn it on to feed the
v2.
From Board-v2
Board-v2
Board-v1
From FAN
CONNECT V2 TO V1 ON THE ALVEOONE

FIRST LAUNCH
After this step, the board v2 is ready to use, you can start to use it now.
At the first use, select the language with OK. English and French are available, if
you choose the wrong language you can change in the option (p.18).
At the first launch, the board v2 will require an initialization process. (see page 15
for the initialization process)
4
To turn on the board v2, the filtering box switcher must be turned on as well.
The loading screen appears while all sensors and systems are initiating.
ACTIVATION : START SCREEN

Temperature
operating time
of the filter
Find the board v2 tutorial video on :
www.alveo3d.com/en/board-v2-assembly/
5
When the device is turned on, the screen displays the main information and it
waits for mode selection before to start.
Main information
Filter saturation
in percent
Running mode
TimerFan rotation speed
Fan power
(PWM signal
power in
percent)
Main information
STEP 1 - MAIN INFORMATION

6
Main menu: all modes
To access to the modes in the main menu, press OK on the main screen
#1 Fast clean mode
«Fast clean mode» is designed to clean up your enclosure air as fast as possible.
With the enclosure air volume that you defined during the initialization step, the
board v2 calculates the best timing to renew the air. The fan speed is running at 100
% power in this mode.
#2 Start auto profile
«Start auto profile» for automatic speed fan profiles with unique features that you
can edit to create your own profiles.
#3 Start manual mode
«Start manual mode» is the manual mode to let you control the fan speed.
#4 Settings
«Settings» to access the board v2 parameters :
- Edit or reinitialize profiles
- New filter initialization
- Check filter and board details
STEP2 - MODES

7
The button «BACK»
can pause the mode
whereas «OK» can
stop it or to access
the parameters
The fast clean mode
is active during a
short calculated to
ensure optimum
air renewal.
Select the mode with
the button OK
Main menu : Select fast clean mode
The fast clean mode turns on the fan at 100% speed during the time determined
by the volume of your enclosure : this mode is designed to clean the air as fast as
possible before an operation inside the enclosure.
STEP 3 - FAST CLEAN MODE

8
Main menu : select the manual mode
Control the fan speed and duration with the manual mode
Mode selection
with « OK »
Choose filtration
time needed
with buttons
- and +
To reset the tiemr to zero faster, press buttons
- and + together in the same time.
STEP 4 - MANUAL MODE

Manual mode setting
After the setting time, the manual mode main menu appears : the bar graph
shows the fan speed.
Power settings
with - and + buttons
in real-time
Modify the remaining
fan operating time
with Set timer
Click on Back
to stop the mode
or on OK to access
to parameters
STEP 4 - MANUAL MODE
9

10
Main Menu : selection automatic mode
Profiles can adjust the speed of the fan automatically. That can help to change the
temperature in the enclosure or reduce the fan noise.
Automatic mode
profiles can be edited
Select automatic
mode with + and -
Start the profile
with OK, this arrow
shows the current
selected profile
STEP 5 - AUTOMATIC MODE

11
Automatic mode settings
After the profile selection, duration should be defined if you wish an automatic
fan stop.
We recommend to
define the profile
duration on the
printing time.
Change duration
with + and -.
The interval
is the time of each
profile sections.
Press Ok to start
profile
STEP 5 - AUTOMATIC MODE

12
Automatic mode : details
3 automatic modes are available.
Profil #1 : standard
Fan speed
(PWM signal
power)
Time
100
80
60
40
20
00
Profil #3 : first 10 minutes 100% speed before profile start then
automatic Fast clean mode at the end
Fan speed
(PWM signal
power)
Time
100
80
60
40
20
00
10 minutes
Fast clean mode
Profil #2 : free profile
Fan speed
(PWM signal
power)
Time
100
80
60
40
20
00
STEP 5 - AUTOMATIC MODE

13
To edit profiles go to the main menu / «Settings» / «Edit profiles». You can add
new profiles, but you can modify the 3 existing profiles.
Select the profile to modify with
the cursor and press OK
There are 12 intervals show the
total amount of running time.
The cursor indicates the
interval to modify.
Edit profiles
STEP 6 - EDIT PROFILES

14
Custom profiles can be created to suit your filtration needs.
When you have done, press BACK
then OK to validate and save the
modification.
Press - and + to move the cursor
to select the interval to modify
Edit profiles
Press OK to select the interval and
the cursor change to
With this cursor, you can modify
the power of the interval with
- and +
STEP 6 - EDIT PROFILES

15
Go to the main menu / «Settings». We always recommend doing the initialization
process with a new filter.
If you select «Reset filter» by
mistake you can go back to the
previous menu with BACK.
To access the initialization process,
go to «Settings» / «Reset option»
/ «Reset filter»
Filter initialization
If you think to access the
initialization process is not easy to
find. It is to avoid mistakes.
After the double confirmation,
reboot the board V2, by pressing
ON/OFF on the filter box alveo3D
STEP 7 - FILTER INITIALIZATION PROCESS
Enable it only if your printer has 2 Hotends or if you have 2 printers in

Caution do not touch
the fan during the
procedure.
16
The process is automatic, just follow the instructions displayed on the screen. Be
very careful the fan will run at 100% speed during the process.
Always place the fan grid in position before to run the fan.
The first step will take 20 seconds.
Then press «Ok».
The second step will start.
Follow the instructions then press
«Ok».
With - and + set the size of your
enclosure in dm3. After the filter
initialization process, you will be
redirected to the main screen.
Choose «YES» if you use a new
filter.
Choose «No» if your filter is not
new.
If you use a new filter.
Filter initialization
Remove the old filter, take
precautions with gloves and put
the old filter in a sealed plastic
bag.
The fan will start.
STEP 8 - END OF FILTER INITIALIZATION PROCESS
Remettre la grille de protection

17
If you want to get the default settings, go to «Settings» / «Reset option» / «Reset
profile»
Restore the default settings
See the filter information
Go to «Settings» / «Filter
manager» to see all filter
information
«confirm» then «validate»
to save the settings. All profiles
will be reset to default
Time : cumulated time of the use
of filter
Filter : filter saturation
Time left : time remaining before
saturation
STEP 9 - FILTER INFO & PROFILES REINITIALIZATION
