AlzaPower APW-DS18B User manual

Docking station
APW-DS18B
User Manual

ENGLISH 4
DEUTSCH 10
ČESKY 16
SLOVENSKY 22
MAGYAR 28
WARRANTY & SUPPORT 34
GARANTIE & BETREUUNG 34
ZÁRUKA & PODPORA 34
ZÁRUKA & PODPORA 34
GARANCIA & TÁMOGATÁS 34

4ENGLISH
We value your trust. We hope that you will be happy with our product, and as excited about it as we
are. We try to offer products of the highest quality that satisfy even the most demanding require-
ments. If you are satisfied, it would make us very happy if you chose us again the next time you make
a purchase.
We are environmentally conscious, therefore we use special eco-friendly packaging. Please recycle!
Recycling and Environmental Protection
We try to avoid using plastic packaging and film and only use them when they are absolutely neces-
sary to protect the product. So how are we different?
Packaging you can eat… Well, almost. :-)
We use ink made from soybeans as opposed to classic petroleum-based ink.
The majority of our packaging is made from 100% recyclable paper.
We limit the use of adhesives. If absolutely necessary, we make sure to choose only water-soluble
ones.
We think globally, which means that we actively search for eco-friendly solutions. We keep an eye on
trending technology and place findings of the scientific community into practice.
We don‘t just try to meet quotas and mandates, we aim to exceed them.
THANK YOU FOR CHOOSING US!

5ENGLISH
Input USB-C
Outputs 2× HDMI
1× VGA
1× DP
1× USB-C Gen 2 10G
2× USB-A Gen 2 10G
2× USB 2.0
1× 3.5mm audio
1× Toslink SPDIF
1× Coaxial SPDIF
1× RJ45
1× Micro SD
1× SD/MMC
1× USB Quick Charging
1× PD Charging
1× DC Jack
USB-C input parameters DP1.4 Alt mode support
USB-A output parameters
(Gen 2 10G)
Max. 10 GB/s per port
2 ports share max. 10 GB/s with the USB-C port
Maximum charging 900 mA per port
USB-C output parameters
(Gen 2 10G)
Data transfer max. 10 GB/s; shares max. 10 GB/s with 2
USB-A ports (Bluecore)
Max. 1.5 A when charging
USB-A 2.0 output parameters 2 ports share a maximum data transfer rate of 480 MB/s
2 ports share max. 900 mA while charging
USB-A Quick Charging Output
Parameters
This port only works when a PD power adapter or 20.5 V=
power adapter is connected. This port does not work without
an external power adapter.
This port is for smart charging, not for data transfer.
Support for the following charging protocols:
• QC3.0 and QC2.0 support; 5 V/9 V/12 V
• Apple 5 V/2.4 A support
• Samsung AFC 5 V/9 V support
• Hi Silicon FCP 5 V/9 V support
RJ45 output parameters Gigabit Ethernet support; 10M/100M/1000M
Wake-On-LAN support
Full duplex flow control support
A light indicator shows the current status. When it's not lit,
it's not connected to the internet. When it is orange, a net-
work connection is established. When it flashes green, data
transfer is in progress.
SD/TF 4.0 output parameters UHS-II support up 312 MB/s
Support for 2 card slots simultaneously
TECHNICAL SPECIFICATIONS

6ENGLISH
3.5 mm audio output parame-
ters
Support for telephone output with digital audio with a maxi-
mum sampling rate of 96 kHz/24 bits
Support for microphone input with digital audio with a maxi-
mum sampling rate of 96 kHz/24 bits
Support for automatic CTIA & OMTP detection
The sound graphics card can be switched between the PC,
the display connected to the DP Alt port and the docking sta-
tion. If the sound graphics card is switched to the docking
station, no sound will come out of the display when head-
phones are connected.
Toslink SPDIF output parame-
ters
Supports digital audio with a maximum sampling rate of 96
kHz/24 bits
Coaxial SPDIF output parame-
ters
Supports digital audio with a maximum sampling rate of 96
kHz/24 bits
PD Charging output parameters Support max. 100 W (PD charging)
PD3.0 Fast Role Swap support; the connected device will not
disconnect when plugging and unplugging the PD adapter.
Support for smart power supply, which allows you to distrib-
ute power according to the actual consumption of connect-
ed devices, making full use of the supplied energy.
DC Jack output parameters Maximum input power 120 W support (20.5 V / 5.85 A).
Support intelligent power supply, which can distribute pow-
er according to the actual power consumption of connected
devices, the host device can get power from 60W to 100W.
TECHNICAL SPECIFICATIONS

7ENGLISH
TECHNICAL SPECIFICATIONS
Parameters of HDMI, DP, VGA
outputs
Support 3 video devices (2× HDMI+VGA or 2× HDMI+DP)
simultaneously in SST and MST mode, where DP and VGA
are alternate (DP is before VGA when 2 ports are connected
simultaneously).
The 3 videos share a maximum bandwidth of 16.2 Gbps.
DP and HDMI support RGB 4:4:4/YCbCr 4:4:4/YCbCr 4:2:2
DP and HDMI support color depth 8 bit, 10 bit
DP and HDMI HDR support
DP and HDMI HDCP2.2 a 1.4 support
DP support DP++, which allows you to connect a passive DP
to the HDMI port to connect an HDMI display.
When one video port is connected, HDMI support is max.
4K/60 Hz, DP max. 4K/60 Hz, VGA max. 1920 x 1200/60 Hz.
Windows OS:
Supports two video devices (max 2× 4K/30 Hz) or three video
devices (max 4K/30 Hz + 2× 1080P/60 Hz) simultaneously in
MST mode (output different images).
Mac OS:
Support for two video devices (max. 4K/60 Hz) or three video
devices (max. 4K/60 Hz) in SST (Same Picture Output) mode.
Note:
• To achieve the above maximum resolution of each port,
the connected device should support DP1.4 Alt mode.
The above resolution will be reduced if the connected
device only supports DP1.2 (due to bandwidth limita-
tions).
• The above resolution combination is only a guide, the ac-
tual resolution of the video output depends on the con-
nected devices and displays.
• The ports for image transmission must be connected se-
quentially. First the HDMI port labeled "Stream 1", then
"Stream 2", etc.
Compatibility Android, Windows 7, Windows 8, Windows 10
Dimensions 185 × 80 × 30 mm
Weight 342 g
Operating temperature range 0–45 °C
Storage temperature -10–70 °C
Operating humidity 10 – 85 %
Storage humidity 10 – 90 %
Standby power consumption ≤ 3 W
PD Charging Up to 100 W
DC Jack Max. 120 W (60 to 100 W per connected device)

8ENGLISH
1 3.5 mm audio output jack for headphone connection
2 Memory card output slots to insert memory cards
3 USB-A (Gen 2 10G) output connectors for connecting external devices
4 USB-C (Gen 2 10G) output connector for connecting external devices
5 QC output connector for connecting peripheral devices and for charging.
6 S/PDIF output connector to connect external equipment (e.g. amplifier)
7 Connector to connect the mains adapter (max. 120 W)
8 USB-C output connector to connect a PD adapter
9 Input USB-C connector for connecting to a computer.
10 HDMI output connectors for connecting to a monitor or TV
11 DP output connector for connecting to a monitor with DP support
12 VGA output connector for connecting to a monitor with VGA support
13 Ethernet output connector for connecting to a LAN
14 USB-A output connectors for connecting external devices
OVERVIEW
1 2 3 4 5
6
7 8 9 10 11 12 13 14

9ENGLISH
INSTRUCTIONS
The docking station allows you to expand significantly the connectivity of your laptop or desktop
computer.
Plug the power adapter connector into the docking station and plug the power plug into a power
outlet.
Connect the USB input connector to the computer. Connect external devices to the other connectors
as required.
The docking station does not require installation of any drivers or other software.
Important notice: The ports for image transmission must be connected sequentially. First the
HDMI port labeled “Stream 1”, then “Stream 2”, etc.
SAFETY INFORMATION
• The product is intended for domestic use only.
• Unplug the product from power sources when not in use.
• Only use the product for its intended purpose.
• Incorrect use of the product can lead to a risk of fire, explosion or other hazard and can result in
a voided warranty.
• This product is not a toy. It may contain small components. Keep out of the reach of children.
• Do not use or leave the product in dusty or otherwise contaminated environments.
• Do not place any objects filled with water, such as vases, on the product.
• Do not place naked flame sources, such as lighted candles, on or near the product. Use the prod-
uct away from heat sources.
• Do not expose the product to high temperatures or low temperatures. Keep the product in a dry
environment.
• Do not disassemble the product. Attempting to modify the product may damage it and result in
serious injury.
• Use a soft, clean, dry towel for cleaning the surface of the product.
