Amada ML-73 EL Series User manual

Z11OM1209102-02
Fiber Laser Marker
ML-73□□EL
OPERATION MANUAL
Original instructions

Thank you for purchasing our Fiber Laser Marker ML-73□□EL.
Please read this manual carefully to ensure correct use of the product. Store the manual in a
convenient place for future reference.
This documentation for the fiber laser marker covers installation, operation, maintenance, and
specifications.
For marking in LMDraw6 using a computer, refer to the manual for LMDraw6.
■Notes
•This documentation is intended for ML-7320EL/7350EL/7323EL/7353EL. Figures and
screenshots are based on ML-7320EL, unless information for other laser markers is significantly
different.
•Unauthorized reproduction of this manual in whole or in part is prohibited.
•The contents of this manual are subject to change without notice.
•Every effort has been made to ensure the accuracy of this manual, but if you notice oversights or
errors, please notify your dealer.
•Be sure to read the user's manuals for any equipment used in conjunction with the system (e.g.,
documentation for computer systems).
•This system incorporates a QR code engine developed by Denso Wave Inc.
•Graphics rendering support in LMDraw (for importing DXF data) is provided by CADBuilderOCX,
developed by Knack SoftWare Inc.
■Trademarks
•Microsoft, Windows, and OpenType are trademarks or registered trademarks of Microsoft
Corporation in the United States and other countries.
•AutoCAD is a trademark or registered trademark of Autodesk Incorporated in the United States
and other countries.
•TrueType is a trademark or registered trademark of Apple Incorporated in the United States and
other countries.
•Intel and Celeron are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries.
•Other company and product names in this manual are trademarks or registered trademarks of
their respective owners.
■Symbols Used in This Manual
•Menus, icons, buttons, windows, tabs, and keys are indicated in brackets ([ ]).
Example: Click the [OK] button.
•Cross-references are enclosed in quotations.
Example: See 3.2.1 "Marking Condition Settings" (p. 5).
Indicates instructions that must be followed to prevent hardware or software damage or
operating errors.
Indicates that incorrect operation may pose a risk of injury or damage.
Indicates additional information on a particular topic.

Chapter Overview
Chapter 1 Safety Precautions
Precautions for safe use of the marker
Chapter 2 Overview of the ML-73□□EL
Summary of fiber laser marker features
Chapter 3 Part Names and Functions
Marker part names and functions
Chapter 4 System Configuration
System configuration, constituent parts, and included accessories
Chapter 5 Unpacking
Size and mass of the marker packaging, as well as lists of package contents
Chapter 6 Installation
Marker installation requirements and instructions
Chapter 7 Starting/Stopping the Equipment
Part names, starting and stopping the equipment, and general safety precautions
Chapter 8 Marker Specifications
Detailed marker specifications
Chapter 9 Serial Interface Specifications
RS-232C communication specifications for the marker
Chapter 10 QR Code and DataMatrix Specifications
QR code and DataMatrix specifications and instructions for preparing data elements
Chapter 11 Interface Specifications
General marker interface specifications
Chapter 12 Maintenance
Marker maintenance information and instructions
Chapter
6
Chapter
1
Chapter
2
Chapter
3
Chapter
4
Chapter
5
Chapter
7
Chapter
8
Chapter
9
Chapter
10
Chapter
11
Chapter
12
A
Appendix

1
ML-73 □□ EL
Contents
■Notes
■Trademarks
■Symbols Used in This Manual
Chapter Overview
Chapter 1 Safety Precautions ............................................................... 5
1.1 Meaning of Symbols.......................................................................6
1.2 Danger, Warning, and Caution Items.............................................7
1.3 Guidelines for Normal Use...........................................................10
1.4 For Disposal.................................................................................12
1.5 Compliance (ML-73□0EL Only)....................................................12
1.6 Warning/Explanation Labels for Safety........................................13
Chapter 2 Overview of the ML-73□□EL ..............................................14
2.1 Features.......................................................................................14
■Fiber Laser Marking .....................................................................................14
■ML-73□□EL...................................................................................................14
Chapter 3 Part Names and Functions................................................16
3.1 Control Unit ..................................................................................16
■Front.............................................................................................................16
■Back .............................................................................................................18
3.2 Head Unit .....................................................................................20
■Front and Side..............................................................................................20
■Back .............................................................................................................22
Chapter 4 System Configuration ........................................................ 24
4.1 System Configuration Schematic.................................................24
4.2 Components.................................................................................25
4.3 Accessories..................................................................................25
4.4 Options.........................................................................................26
Chapter 5 Unpacking ........................................................................... 27
5.1 Moving the Container...................................................................27
■Container Size and Mass .............................................................................27
5.2 Checking the Container Contents ................................................28
■Containers....................................................................................................28

2ML-73 □□ EL
Contents
■Options.........................................................................................................28
Chapter 6 Installation .......................................................................... 29
6.1 Installation Requirements.............................................................29
■Control Unit ..................................................................................................29
■ML-73□0EL, Standard Head Unit .................................................................30
■ML-73□0EL, Water and Oil Proof Head Unit (Option)..................................31
■ML-73□3EL, Head Unit.................................................................................32
6.2 Connections .................................................................................34
Chapter 7 Starting/Stopping the Equipment ..................................... 35
7.1 Turning the Hardware On and Off................................................35
■Starting the Marker.......................................................................................35
■Stopping the Marker.....................................................................................39
7.2 Adjusting the Work Distance........................................................40
Chapter 8 Marker Specifications ........................................................ 42
8.1 Basic Specifications .....................................................................42
8.2 Marking Area Specifications.........................................................44
■ML-73□0EL................................................................................................... 44
■ML-73□3EL................................................................................................... 44
8.3 External Specifications.................................................................45
■Control Unit ..................................................................................................45
■ML-73□0EL, Standard Head Unit ................................................................. 46
■ML-73□0EL, Standard Head Unit (With the Fixing Base (Option))...............47
■ML-73□0EL, Water and Oil Proof Head Unit (Option) ..................................48
■ML-73□3EL, Head Unit.................................................................................49
■ML-73□3EL, Head Unit (With the Fixing Base (Option)) ..............................50
Chapter 9 Serial Interface Specifications ..........................................51
9.1 Cable Specifications.....................................................................51
■Pin assignments (unit side) ..........................................................................51
■Connection example: Connected to a computer ..........................................52
9.2 Communication Settings ..............................................................53
9.3 Communication Codes.................................................................54
9.4 Communications Protocol ............................................................55
■Transmission control code ...........................................................................55
■Checksum ....................................................................................................55
■Numerical notation .......................................................................................56
■String notation ..............................................................................................56
9.5 Commands...................................................................................57
■Command Details.........................................................................................58
9.6 Communication Period.................................................................72

3
Contents
ML-73 □□ EL
Chapter 10 QR Code and DataMatrix Specifications..........................73
10.1 QR Code Specifications...............................................................73
10.1.1 QR Code Symbol Specifications.......................................73
■Detailed Specifications.................................................................................74
10.1.2 Preparing Data..................................................................75
■Overview of Sample Data............................................................................. 75
■Examples of Preparing Data Elements ........................................................76
10.2 DataMatrix Specifications.............................................................79
10.2.1 DataMatrix Symbol Specifications.....................................79
■Detailed Specifications.................................................................................79
10.2.2 Preparing Data..................................................................80
■Overview of Sample Data............................................................................. 80
■Examples of Preparing Data Elements ........................................................81
Chapter 11 Interface Specifications.....................................................84
11.1 External Input and Output (EXT. I/O)...........................................85
11.1.1 Input and Output Signals...................................................85
■Input Signals.................................................................................................85
■Output Signals..............................................................................................86
11.1.2 Connection Examples .......................................................87
■When connected to an output PLC with a 24 V DC source..........................87
■When using a contact signal ........................................................................ 88
■When using an open-collector signal ...........................................................89
11.1.3 Time Chart ........................................................................90
■If the power is turned ON and OFF ..............................................................90
■During normal operations (no EEXT. I/O) ....................................................91
■If laser errors occur ......................................................................................92
■If data errors occur .......................................................................................93
■When marking is stopped............................................................................. 93
■If the counter is used (Count reset and count up enabled) ..........................94
■When counter stop is used (increment of 1).................................................95
11.2 Extended External Input and Output (EEXT. I/O) ........................96
11.2.1 Input and Output Signals...................................................96
■Input Signals.................................................................................................96
■Output Signals..............................................................................................97
11.2.2 Connection Examples .......................................................98
■When connected to an output PLC with a 24 V DC source..........................98
■When using a contact signal ........................................................................ 99
■When using an open-collector signal .........................................................100
11.2.3 Time Chart ......................................................................101
■During normal operations...........................................................................101
■During data errors (errors from unregistered layouts)................................102
11.3 Carriage Control Input and Output (AXIS. I/O)...........................103
11.3.1 Input and Output Signals.................................................104
■Input Signals............................................................................................... 104
■Output Signals............................................................................................104

4ML-73 □□ EL
Contents
11.3.2 Connection Examples .....................................................107
11.3.3 Time Chart ......................................................................108
■During 2-axis control (when using EX2).....................................................108
■During 4-axis control (when using EX4).....................................................109
■If a transfer unit error occurs (after ACK timeout)....................................... 110
■When NAK (awaiting transfer unit operation) is used.................................111
11.4 Emergency Stop (E-STOP)/Remote Interlock (REMOTE I/L)....112
11.4.1 Pin Layout .......................................................................113
■Input Signals............................................................................................... 113
■Output Signals............................................................................................113
11.4.2 Connection Examples .....................................................114
■Remote Interlock ........................................................................................114
■Emergency Stop.........................................................................................115
11.4.3 Time Chart ......................................................................117
■Remote Interlock ........................................................................................117
■Emergency Stop.........................................................................................118
Chapter 12 Maintenance...................................................................... 119
12.1 Maintenance Tasks....................................................................119
12.2 Part Replacement Schedule ......................................................120
12.3 Air Filter Inspection and Replacement .......................................122
12.3.1 Control Unit .....................................................................122
12.4 Protective Glass Inspection and Replacement ..........................123
12.4.1 Cleaning the Protective Glass.........................................123
12.4.2 Replacing the Protective Glass.......................................123
12.5 Fiber Laser Module Warranty Period .........................................125
12.6 Backup Lithium Battery Replacement........................................126
12.7 Memory Card Management .......................................................128
■Memory Card Backup.................................................................................128
■Restoring Backup Data ..............................................................................128
Appendix A Troubleshooting...............................................................130
A.1 Error Messages on the Control Unit...........................................130
A.2 Problems in Marking Results .....................................................131
A.3 If No Laser Beam Is Projected ................................................... 132
Index ...............................................................................................................133

5
ML-73 □□ EL
Safety Precautions
Before using the Laser Marker, carefully read these safety precautions to ensure correct use.
•These precautions are intended to ensure safe use of the unit and to prevent damage or personal
injury to the user and other individuals. Be sure to read all precautions; they are critical for ensuring
safe use.
•The warning symbols are defined as follows:
Incorrect operation poses imminent risk of serious injury or fatality.
Incorrect operation may pose risk of serious injury or fatality
Incorrect operation may pose risk of injury or damage.
DANGER
WARNING
CAUTION
Chapter
1

Chapter
1
6ML-73 □□ EL
Chapter 1Safety Precautions
1.1 Meaning of Symbols
These symbols indicate prohibited actions.
The symbols warn against actions that will void the terms of the warranty.
The prohibited action is depicted in a circle or illustrated in a figure or described in a statement nearby.
These symbols indicate actions users must take.
The prohibited action is depicted in a circle or illustrated in a figure or described in a statement nearby.
The symbol indicates caution for electrical shock.
The symbols indicate danger, warning, or caution items.
The prohibited action is depicted in a circle or illustrated in a figure or described in a statement nearby.

Chapter
1
7
ML-73 □□ EL
1.2 Danger, Warning, and Caution Items
1.2 Danger, Warning, and Caution Items
Do not touch inside the Laser Marker when it is switched on
Doing so may result in electric shock.
Never attempt to disassemble, repair, or modify the Laser
Marker
Doing so may result in electric shock or fire.
Refrain from any mechanical adjustment other, than maintenance
specifically described in the operation manual.
Never expose eyes or skin to laser irradiation
Exposure to direct or scattered laser light is extremely hazardous.
Direct exposure of the eye to laser beams may result in blindness.
Never burn, destroy, cut, crush or chemically decompose
the Laser Marker
This product incorporates parts containing gallium arsenide
(GaAs).
DANGER

Chapter
1
8ML-73 □□ EL
Chapter 1Safety Precautions
Wear protective eyewear
Always wear protective eyewear having an optical density of at
least 7 when using the Laser Marker.
Keep in mind that exposure of the eyes to direct laser irradiation
through protective eyewear may result in blindness, even when
wearing protective eyewear. Protective eyewear attenuates the
laser beam, but does not block it.
Never aim the laser at any parts of your own body or those
of other individuals
Exposure to laser beams will cause severe burns.
Never aim the laser at yourself or at anyone else.
Do not touch workpieces during or just after marking
Workpieces may still be very hot.
Use only the specified cables. Make sure they are firmly
connected
Using cables of inadequate current capacity or connecting cables
loosely may result in fire or electric shock.
Avoid damaging power or connecting cables
Do not step on, twist, or pull cables.
Damaged cables may result in electric shock, short circuits, or
fires.
To repair or replace cables, contact your dealer or us.
Stop using the Laser Marker if any problems arise
Continuing to use the Laser Marker in the presence of
abnormalities (fumes, unusual sounds, excessive heat, smoke,
and so forth) may result in electric shock or fire.
In this case, immediately turn OFF the Laser Marker and contact
your dealer or us.
Ground the Laser Marker
Failure to ground the Laser Marker may result in electric shock if
the Laser Marker is damaged or if electrical leaks occur.
Pacemaker users must not approach the Laser Marker
Unless a physician has consented, pacemaker users must not
approach the Laser Marker in use, or even approach the working
area.
The Laser Marker generates electromagnetic fields that may affect
pacemaker function.
WARNING

Chapter
1
9
ML-73 □□ EL
1.2 Danger, Warning, and Caution Items
Avoid spilling or splashing water on the Laser Marker
The presence of water on electrical parts may result in electric
shock or short circuits.
Use the appropriate tools to terminate the power cable (wire
strippers, crimp tools, etc.)
Failure to use the appropriate tools may result in damage to the
wire core, resulting in fire or electric shock.
Install the Laser Marker on a solid, level surface
Should the Laser Marker tip over or fall, injury or damage to the
unit may result.
Never place liquid containers on the Laser Marker
Liquid spills may degrade the unit's insulation, resulting in electric
leaks or fire.
Keep combustible materials away from the Laser Marker
Sparks or spattering material may ignite combustible matter.
Do not apply the laser beam to combustible materials
To avoid risk of fire, never apply the laser beam to flammable or
combustible materials.
During use, do not cover the Laser Marker with a blanket,
cloth, or similar articles
When using the Laser Marker, do not cover with a blanket, cloth, or
similar articles.
The Laser Marker may become extremely hot, resulting in fire.
Do not use the Laser Marker for any purpose other than
laser marking
Using the unit for nonspecified applications may result in electric
shock or fire.
Wear protective gear
Use protective gloves, long-sleeve garments, leather aprons, or
other appropriate protective gear.
Sparks or spattering material may burn the skin on contact.
Keep a fire extinguisher nearby
Keep a fire extinguisher in the marking area in case of fire.
Maintain and inspect the unit at periodic intervals
Maintain and inspect the unit at periodic intervals. Repair any
damage before resuming use.
CAUTION

Chapter
1
10 ML-73 □□ EL
Chapter 1Safety Precautions
•Appoint a safety supervisor with as much expertise and experience with lasers and laser equipment
as possible. The supervisor, who will be in charge of the laser key switch, should familiarize users
with safety issues and coordinate laser marking.
•Partition off the area which might be exposed to the laser beam. A supervisor should control this work
area and post signs to keep out unauthorized personnel.
•Install the Laser Marker on a solid, level surface. Using the unit (other than the Head Unit) at an angle
or on its side may damage it.
- To prevent distorted marking, put workpieces on the same stand as the Head Unit so that
the workpieces do not vibrate during marking.
- The power supply must be single-phase 100 V AC to 240 V AC, with capacity of at least 10
A.
- Be sure to ground the unit with a Class D ground.
•To ensure optimal marking quality, use the Laser Marker in a place where the ambient temperature is
5 to 35 °C, where the relative humidity is 40 to 80%, and where it is not subject to sudden
temperature fluctuations. In addition, do not use the marker in the following places:
- Where there is excessive dirt, dust, or oil mist
- Where the unit is subject to vibration or impact
- Where the unit is exposed to chemicals
- Where there is a nearby source of high noise
- Where moisture may condense on the unit
•If the room temperature changes quickly (as when a heater is turned on in cold weather), moisture
may condense on the optical elements. Dust may adhere or the elements may become fogged up
with condensation. Thus, avoid sudden temperature changes. If condensation may have occurred,
wait for a while after turning the unit on before starting operation.
•The exterior of the system should be wiped clean using a soft or moist cloth. If the exterior is
particularly dirty, wipe it clean using diluted detergent or alcohol.
Do not use paint thinner, benzine, or similar chemicals, which may discolor the unit or deform parts.
•Do not place screws or other foreign objects inside the marker. This may damage the unit.
•Operate the switches and buttons gently by hand. Applying excessive force or using the tip of a
screwdriver, a pen, or other instrument may damage or break the switches or buttons.
•Operate only one switch or button at a time. Operating several switches or buttons at a time may
damage or break the unit.
•Do not turn off the power switch while a computer is connected to the Control Unit.
•If a computer is connected, it will continue to access the memory card for about 15 seconds after
going offline. During this time, do not turn off the power switch of the Control Unit.
1.3 Guidelines for Normal Use

Chapter
1
11
ML-73 □□ EL
1.3 Guidelines for Normal Use
•If a computer is connected, never disconnect the USB cable before turning off the power switch.
•For more consistent marking, allow the unit to warm up for about 10 to 30 minutes after turning on the
LD. The warmup time varies depending on the temperature and workpiece material.
•Use only memory cards purchased from us. If commercial cards are used, the unit may not function
normally.
•Before inserting or removing memory cards, always turn off the power switch. If the power switch is
on when cards are inserted or removed, data may be lost or the memory card may become unusable.
•Back up memory card data regularly.
If the memory card data becomes corrupted, it may prevent normal marking or the marker may not
start.
•The memory card connector can withstand 10,000 insertion/removal cycles, according to values
published by the connector manufacturer.
•When a supervisor or operator enters the area where the laser is used, protective measures not to
exceed the MPE* level must be taken.
* MPE: The maximum level of permissible exposure of the eyes or skin to laser beams. Abbreviation
of Maximum Permissible Exposure.
•Since the surge absorber is built in, do not perform the insulation resistance test and the withstand
voltage test. If the surge absorber fails, the marker may become unusable.
•The ML-73□3EL head unit has IP64 dust- and splash-proof performance. The performance can be
provided only by installing the control cable, fθ lens (f420, f508, f100 (telecentric), and f163
(telecentric) are not compatible) and protective glass properly.
•The water and oil proof head unit (option) has IP67 dust- and water-proof performance and IPXXG (in
the JIS standard) oil-proof performance. The performance can be provided only by installing the
control cable, fθ lens and protective glass properly. The head has a protective structure, but it cannot
be used in water or oil.
•Capable of corresponding to the fully closed locker to enhance the environment resistance of the
control unit. (This is not compatible with IP67G.) For details, contact us.
For other information on managing laser equipment or the MPE level, refer to the
following standards.
ML-7320EL and ML-7350EL
•CDRH Standards Part 1040 Sec. 1040.10 “Radiation safety standards for laser
equipment”
•IEC Standards IEC60825-1 "Safety of laser products Part1: Equipment
Classifications, requirements and use’s guide"
ML-7323EL and ML-7353EL
•JIS C 6802 "Safety of laser products"
•Ministry of Health, Labour and Welfare Notification No. 0325002 "Prevention
measures against laser injuries" (in Japanese)

Chapter
1
12 ML-73 □□ EL
Chapter 1Safety Precautions
This product incorporates parts containing gallium arsenide (GaAs). At the time of disposal, separate it
from general industrial waste or domestic waste and carry out the disposal in accordance with
applicable laws and regulations.
Please refer to the Declarations of Incorporation for the laser marker for compliance details.
The end user and integrator are responsible for integration of the laser according to the information in
this manual. With correct installation of the laser marker in an appropriate enclosure the laser marker
will comply with IEC13849-1 category 4. The PL of this system is e. Incorrect installation can defeat
safety features, cause hazards to personnel, and invalidate compliance or cause compliance to be to a
lesser category.
Compliance with IEC13849-1 achieved using the installation instructions in this manual affects only the
laser marker. Any additional equipment including the laser enclosure, automation controller, motion
hardware, or other must be separately developed to be compliant with this specification or laser marker
compliance will be invalidated.
If compliance with IEC13849-1 is a concern the end user must validate their complete machine against
the specification.
If there is any doubt about implementation, installation, or construction of the safety features of a
machine at large including a laser marker do not proceed without appropriate guidance.
1.4 For Disposal
1.5 Compliance (ML-73□0EL Only)

Chapter
1
13
ML-73 □□ EL
1.6 Warning/Explanation Labels for Safety
The following labels are applied to the marker. Read and follow the instructions on the labels to ensure
correct use.
1.6 Warning/Explanation Labels for Safety
ޟ࡟࡯ࠩ᡼኿ߩ಴ญޠ෶ߪ
ޟⵍ῜࿁ㆱߩߎߣ㧙ߎߩ㐿ญ߆ࠄ
࡟࡯ࠩ᡼኿߇಴ࠆޠ
ࠢ࡜ࠬ࡟࡯ࠩ⵾ຠ
࡟࡯ࠩ᡼኿
.#5'4#2'4674'14#81+&
':21574'.#5'44#&+#6+10+5
'/+66'&(41/6*+5#2'4674'
%.#55.#5'4241&7%6
.#5'44#&+#6+10
ߎߎࠍ㐿߈ޔ
ࠗࡦ࠲ࡠ࠶ࠢࠍ⸃㒰ߔࠆߣ
ࠢ࡜ࠬߩ࡟࡯ࠩ᡼኿߇಴ࠆ
ࡆ࡯ࡓ߿ᢔశߩ⋡෶ߪ
⊹⤏߳ߩⵍ῜ߪෂ㒾
⷗ߚࠅ⸅ࠇߚࠅߒߥ޿ߎߣ
㧨ᵈᗧ㧪
%.#55.#5'44#&+#6+10
9*'012'0#0&+06'4.1%-5
&'('#6'&#81+&';'
145-+0':21574'61&+4'%6
145%#66'4'&4#&+#6+10
%#76+10
㔚Ḯࠍ౉ࠇߚ߹߹ࠤ࡯ࡉ࡞ࠍᛮ߈Ꮕߒߒߥ޿ߢߊߛߐ޿ޕ
&10162.7)14702.7)%#$.'59*'0#%219'4+56740'&10
⼊๔
9#40+0)
଻⼔ࠟ࡜ࠬߪᲤᣣ󰶂᝹ߒߡ
ߊߛߐ޿ޕ
%.'#06*'2416'%6+8').#55
10%'#&#;
ᵈᗧ
%#76+10
ࡈࠔࠗࡃߩᦛߍඨᓘߪOO
એ⏕଻ߒߡߊߛߐ޿ޕ
-''26*'$'0&4#&+751(
(+$'4OO14/14'
ᵈᗧ
%#76+10
ࠢ࡜ࠬ࡟࡯ࠩ⵾ຠ
นⷞ෸߮นⷞ࡟࡯ࠩ᡼኿
ࡆ࡯ࡓ߿ᢔశߩ⋡෶ߪ⊹⤏߳ߩⵍ῜ߪ
ෂ㒾⷗ߚࠅ⸅ࠇߚࠅߒߥ޿ߎߣ
#81+&';'145-+0':21574'61&+4'%6
145%#66'4'&4#&+#6+10
8+5+$.'#0&+08+5+$.'
.#5'44#&+#6+10
%.#55.#5'4241&7%6
;Dࡈࠔࠗࡃ࡟࡯ࠩ;D(+$'4.#5'4
%927.5'PO/#:9
ඨዉ૕࡟࡯ࠩ.&
%9PO/#:O9

14 ML-73 □□ EL
Overview of the
ML-73□□EL
The ML-73□□EL is a scanning fiber laser marker. This marker offers the following features:
■Fiber Laser Marking
•Permanent marking
In contrast to ink-based printing, laser marking is permanent, since the laser beam changes the
material itself.
•Environmentally friendly
No solvent is needed, since no ink is used. Use of recycling marked materials is easier because
they contain no ink.
•Supports fine letters and detailed pictures
Laser marking makes it easy to make even highly detailed markings. Perfect for marking on tiny
electronic components.
•Non-contact marking
Permits marking on curved and concave surfaces.
■ML-73□□EL
•Compact and lightweight
Ideal for production lines where space is limited.
•Energy efficient
Low power consumption, thanks to a highly efficient diode laser.
•Fully air-cooled
Easy maintenance. Fully air-cooled-no coolant or coolant filters needed.
•Compatible with PCs running Windows operating systems (when a computer is connected)
The product is bundled with the LMDraw6 Windows-based marking application. Figures created
with commercial CAD software are easily registered as marking data.
The basic screen for normal use consists of just two main screens for drawing and marker
operations for a simple working environment.
•High-speed marking (ML-73□0EL)
Engraves 550 characters per second.
•Built-in guide beam
A red guide beam for positioning makes it easy to align marking positions.
•Full-featured drawing functions
- Able to import files in the AutoCAD 2009 DXF format
- Able to handle high-capacity marking data with compact flash card
- More powerful hatching functions for easier creation of figures with hatching
- Versatile drawing functions for more efficient production of marking data
Standard functions: Move, rotate, copy, enlarge, reduce, compress, mirror text, reverse
marking, undo, redo, grid, ruler, and rectangular DataMatrix marking data
2.1 Features
Chapter
2

Chapter
2
15
ML-73 □□ EL
2.1 Features
•Supports registration of multiple marking conditions
Up to 1,023 conditions may be specified.
•Auto backup
Specify an interval (in time or number of operations) for automatic data backup.
•Dust-proof head
The ML-73□0EL standard head is IP5X compatible. The ML-73□3EL standard head is IP64
compatible.
•Water and oil proof head (ML-73□0EL option)
The optional head is IP67 and IPXXG (the JIS standard) compatible.
•Fully closed locker for control unit (option)
Capable of corresponding to the fully closed locker to enhance the environment resistance of the
control unit. (This is not compatible with IP67G.)
•High-repetition frequency
High-speed, contrasty, and clear marking can be achieved with 20 k to 200 kHz (ML-732□EL) of
repetition frequency.
•Built-in power monitor (ML-73□3EL)
- Controlling the laser power of each workpiece prevents the outflow of defective. (RS-232C
communication)
- Power values can be logged at the set time. (RS-232C communication)
- Variation from device to device can be corrected by calibration by external power meter.
・Coaxial camera mountable (ML-73□3EL)
Since the C-mount camera can be mounted coaxially with the laser beam, it can be used for
positioning a small workpiece. By combining the coaxial camera and image processing, auto-
matic position correction can be achieved.
・Fully digital scanner equipped (ML-73□3EL)
High-repetition position accuracy and low drift are achieved, which are difficult to be achieved by
an analog scanner.
・Various optical composition (ML-73□3EL)
The most suitable optical composition for your purpose can be selected from among 8-type fθ
lens and 3-type expander lens.

16 ML-73 □□ EL
Part Names and
Functions
Incorporates the controller, fiber laser module and power supply unit.
You can monitor operating status from a computer.
■Front
①Emergency Stop Button
Press to halt the unit immediately during emergencies. This will immediately suspend marking and
turn OFF the LD.
Once pressed, the button will remain depressed. To reset this button, turn in the direction indicated
by the arrows.
②Liquid Crystal Display
Describes various messages on the status of the Marker and any system faults or errors that may
occur during marking.
3.1 Control Unit
Frequent use of the emergency stop button will significantly affect the LD service life.
Use this button to stop the device only in emergency situations.
⑦
②
④
①
⑥
⑤
③
Chapter
3
