3(}ww INSTALLATIONINSTRUCTIONS
(76.2CM)FREESTANDINGGASRANGE
with standard clean oven
Table of Contents .................................................. 2
Tothe installer: Please leave this instruction book with the unit.
Tothe consumer: Please read and keep this book for future reference.
W10130752A
TABLEOF CONTENTS
RANGE SAFETY .......................................................................... 2
iNSTALLATiON REQUIREMENTS .............................................. 4
Tools and Parts .......................................................................... 4
Location Requirements .............................................................. 4
Electrical Requirements ............................................................ 6
Gas Supply Requirements ........................................................ 6
iNSTALLATiON iNSTRUCTiONS ............................................ 8
Unpack Range ............................................................................ 8
Install Anti-Tip Bracket .............................................................. 8
Verify Anti-Tip Bracket Location ................................................ 9
Level Range ................................................................................ 9
Make Gas Connection ................................................................ 9
Check Operation ...................................................................... 10
Complete Installation .............................................................. 11
GAS CONVERSIONS ............................................................... 12
LP Gas Conversion .................................................................. 12
Complete Conversion .............................................................. 13
Natural Gas Conversion ........................................................... 14
Complete Conversion .............................................................. 15
RANGESAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
|
WARNING: If the information in this manual is not followed exactly, afire or explosion
may result causing property damage, personal injury or death. J
=Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
=WHAT TO DO iF YOU SMELL GAS:
•Do not try to light any appliance.
=Do not touch any electrical switch.
•Do not use any phone in your building.
=Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•if you cannot reach your gas supplier, call the fire department.
=Installation and service must be performed by aqualified installer, service agency, or
the gas supplier.
In the State of Massachusetts, the following installation instructions apply:
[] Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
[] If using a ball valve, it shall be a T-handle type.
[] A flexible gas connector, when used, must not exceed 3 feet.
Tip Over Hazard
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti-tip bracket, if the range is moved.
Failure to follow these instructions can result in death or serious burns to children and adults.
INSTALLATIONREQUIREMENTS
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
,. Level
[] 3/8"drive ratchet
[] Tape measure
[] Flat-blade screwdriver
[] Phillips screwdriver
[] Hand or electric drill
[] Slip-joint pliers
[] 7 mm combination wrench
[] Pipe wrench
[] 1/_,,(3.2 mm) drill bit (for wood floors)
[] 3A8"(4.8 mm) carbide-tipped masonry drill bit
(for concrete/ceramic floors)
[] Pipe joint compound resistant to LP gas
[] Non-corrosive leak-detection solution
Parts supplied
Check that all parts are included.
A
B
J
A. Anti-tip bracket
B. Plastic anchors (2)
C. #10x 1 1/2" screws (2)
[] Anti-tip brackets must be securely mounted to subfloor.
Thickness of flooring may require longer screws to anchor
bracket to subfloor. Longer screws are available from your
local hardware store.
Parts needed
Check local codes and consult gas supplier. Check existing gas
supply and electrical supply. See "Electrical Requirements" and
"Gas Supply Requirements" sections.
IMPORTANT." Observe all governing codes and ordinances. Do
not obstruct flow of combustion and ventilation air.
[] It is the installer's responsibility to comply with installation
clearances specified on the model/serial rating plate. The
model/serial rating plate is located on the oven frame behind
the left side of the broiler door.
Model/serial
rating plate
location
[] The range should be located for convenient use in the
kitchen.
[] Recessed installations must provide complete enclosure of
the sides and rear of the range.
[] To eliminate the risk of burns or fire by reaching over heated
surface units, cabinet storage space located above the sur-
face units should be avoided. If cabinet storage is to be pro-
vided, the risk can be reduced by installing a range hood that
projects horizontally a minimum of 5" (12.7 cm) beyond the
bottom of the cabinets.
[] All openings in the wall or floor where range is to be installed
must be sealed.
[] Do not seal the range to the side cabinets.
[] Cabinet opening dimensions that are shown must be used.
Given dimensions are minimum clearances.
[] The floor anti-tip bracket must be installed. To install the anti-
tip bracket shipped with the range, see "Install Anti-Tip
Bracket" section.
[] Grounded electrical supply is required. See "Electrical
Requirements" section.
Proper gas supply connection must be available. See "Gas
Supply Requirements" section.
[] Contact a qualified floor covering installer to check that the
floor covering can withstand at least 200°F (93°C).
[] Use an insulated pad or 1/4"(0.64 cm) plywood under range if
installing range over carpeting.
iMPORTANT." Some cabinet and building materials are not
designed to withstand the heat produced by the oven for baking
and self-cleaning. Check with your builder or cabinet supplier to
make sure that the materials used will not discolor, delaminate or
sustain other damage.
Mobile Home -Additional installation Requirements
The installation of this range must conform to the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280
(formerly the Federal Standard for Mobile Home Construction and
Safety, Title 24, HUD Part 280). When such standard is not appli-
cable, use the Standard for Manufactured Home Installations,
ANSI A225.1/NFPA 501A or with local codes.
Mobile home installations require:
[] When this range is installed in a mobile home, it must be
secured to the floor during transit. Any method of securing the
range is adequate as long as it conforms to the standards list-
ed above.
ProductDimensions
26-3/4"
(67.9 cm)
depth with
handle
24-1/4" 29-7/8" (75.9 cm)
(61.6 cm) _._" width
42"
(106.7 cm)
overall
height
installation Clearances
Cabinet opening dimensions shown are for 25" (64 cm) counter-
top depth, 24" (61 cm) base cabinet depth and
36" (91.4 cm) countertop height.
If the cabinet depth is greater than 24" (61 cm), the oven frame
must extend beyond cabinet fronts by 1/=,,(13 mm) minimum.
upperside
cabinetto
countertop I
,
Thisshaded area I
recommendedfor
wall or other com-
bustible material This shaded area
recommended for
installation
of gas pipe.
10" (25.4 cm)
3" (5.1 cm)
(7.6 cm)---__
NOT_:: 24" (61 cm) minimum when bottom of wood or metal cab-
inet is protected by not less than 1/4"(0.64 cm) flame retardant
millboard covered with not less than No. 28 MSG sheet steel,
0.015" (0.4 mm) stainless steel, 0.024" (0.6 mm) aluminum or
0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance between the top of the cooking
platform and the bottom of an unprotected wood or metal cabi-
net.
If installing a range hood or microwave hood combination above
the range, follow the range hood or microwave hood combination
installation instructions for dimensional clearances above the
cooktop surface.
ii!!!ili_!_,0ii:i_:_!iiii !!_i!!_qil_i:i_:__ii_i!_!!!%i:_!ii_¸
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
IMPORTANT." The range must be electrically grounded in accor-
dance with local codes and ordinances, or in the absence
of local codes, with the National Electrical Code, ANSI/NFPA 70,
latest edition.
If codes permit and a separate ground wire is used, it is recom-
mended that a qualified electrical installer determine that the
ground path is adequate.
A copy of the above code standards can be obtained from:
National Fire Protection Association
One Batterymarch Park, Quincy, MA 02269
CSA international
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
[] A 120-volt, 60-Hz, AC-only, 15-amp, fused electrical circuit
is required. A time-delay fuse or circuit breaker is also recom-
mended, it is recommended that a separate circuit serving
only this range be provided.
[] This range is equipped with a power supply cord having a 3
prong ground plug. To minimize possible shock hazard, the
cord must be plugged into a mating 3 prong, grounded outlet.
[] Electronic ignition systems operate within wide voltage limits,
but proper grounding and polarity are necessary. Check that
the outlet provides 120-volt power and is correctly grounded.
This range is equipped with an electronic ignition system that
will not operate if plugged into an outlet that is not properly
polarized.
[] The wiring diagram is located on the back of the range.
NOTE: The metal chassis of the range must be grounded in order
for the control panel to work. If the metal chassis of the range is
not grounded, no keypads will operate. Check with a qualified
electrician if you are in doubt as to whether the metal chassis of
the range is grounded.
Explosion Hazard
Use a new CSA International approved gas supply line.
install a shut=off valve.
Securely tighten all gas connections.
if connected to LP, have a qualified person make sure
gas pressure does not exceed 14" (36 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
Observe all governing codes and ordinances.
IMPORTANT." This installation must conform with all local codes
and ordinances. In the absence of local codes, installation must
conform with American National Standard, National Fuel Gas
Code ANSI Z223.1 - latest edition.
Type of Gas
Natural Gas:
This range is design-certified by the CSA international for use
with natural gas or, after proper conversion, for use with LP gas.
[] This range is factory set for use with natural gas. See "Gas
Conversions" section. The model/serial rating plate located on
the frame behind the broiler door has information on the types
of gas that can be used. Ifthe types of gas listed do not
include the type of gas available, check with the local gas
supplier.
LP Gas conversion:
Conversion must be done by a qualified service technician.
No attempt shall be made to convert the appliance from the gas
specified on the model/serial rating plate for use with a different
gas without consulting the serving gas supplier. See "Gas
Conversions" section.
Gas Supply Line
[] Provide a gas supply line of 3/4"rigid pipe to the range loca-
tion. A smaller size pipe on longer runs may result in insuffi-
cient gas supply. Pipe joint compounds that resist the action
of LP gas must be used. Do not use TEFLON ®ttape. With LP
gas, piping or tubing size can be 1/2"minimum. Usually, LP
gas suppliers determine the size and materials used in the
system.
Flexiblemetalapplianceconnector:
[] Iflocalcodespermit,anewCSAdesign-certified,4-5ft
(122-152.4cm)long,1/2"(1.3cm)or3/4"(1.9cm)I.D.,flexible
metalapplianceconnectormaybeusedforconnectingrange
tothegassupplyline.
[] A1/2"(1.3cm)malepipethreadisneededforconnectionto
thefemalepipethreadsoftheinlettotheappliancegaspres-
sureregulator.
[] Donotkinkordamagetheflexiblemetaltubingwhenmoving
therange.
Rigid pipe connection:
The rigid pipe connection requires a combination of pipe fittings
to obtain an in-line connection to the range. The rigid pipe must
be level with the range connection. All strains must be removed
from the supply and fuel lines so range will be level and in line.
[] Must include a shutoff valve:
The supply line must be equipped with a manual shutoff
valve. This valve should be located in the same room but
external to the range. It should be in a location that allows
ease of opening and closing. Do not block access to shutoff
valve. The valve is for turning on or shutting off gas to the
range.
A4
B..................
C
A.Shutoffvalvein "open"position
B.Gassupplyline
C.Torange
Burner input Requirements
Input ratings shown on the model/serial rating plate are for eleva-
tions up to 2,000 ft (609.6 m).
For elevations above 2,000 ft (609.6 m), ratings are reduced at a
rate of 4% for each 1,000 ft (304.8 m) above sea level.
Gas Supply Pressure Testing
Line pressure testing above r/2psi gauge (14" WCP}
The range and its individual manual shutoff valve must be discon-
nected from the gas supply piping system during any pressure
testing of that system at test pressures greater than
rA psi (3.5 kPa).
Line pressure testing at r/2psi gauge (t4" WCP) or lower
The range must be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any pressure
testing of that system at test pressures equal to or less than
rA psi (3.5 kPa).
Gas Pressure Regulator
The gas pressure regulator supplied with this range must be
used. The inlet pressure to the regulator should be as follows for
proper operation:
Natural Gas:
Minimum pressure: 5" WCP
Maximum pressure: 14" WCP
LP Gas:
Minimum pressure: 11" WCP
Maximum pressure: 14" WCP
Contact local gas supplier if you are not sure about the inlet pres-
sure.
1-(¢TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
INSTALLATIONINSTRUCTIONS
Excessive Weight Hazard
Use two or more people to move and install range.
Failure to do so can result in back or other injury.
f. Do not use oven door handle to lift or move the range.
2. Remove shipping materials, tape and protective film from
range. Keep cardboard bottom under range. Remove oven
racks and parts package from inside oven.
3. Take 4 cardboard corners from the carton. Stack one card-
board corner on top of another. Repeat with the other 2 cor-
ners. Place them lengthwise on the floor behind the range to
support the range when it is laid on its back. Using 2 or more
people, firmly grasp the range and gently lay it on its back on
the cardboard corners.
4. Pull cardboard bottom firmly to remove.
5. Use an adjustable wrench to loosen the leveling legs. Adjust
the leveling legs to the correct height. Leveling legs can be
loosened to add up to a maximum of 1" (2.5 cm). A maximum
of 3/16" (5 mm) is needed to engage the anti-tip bracket.
NOTE: If height adjustment is made when range is standing, tilt
the range back to adjust the front legs, then tilt forward to adjust
the rear legs.
6. Place cardboard or hardboard in front of range.Using 2 or more
people, stand range back up onto cardboard or hardboard.
A_
A.Cardboardshippingbase
Tip Over Hazard
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti=tip bracket, if the range is moved.
Failure to follow these instructions can result in death
or serious burns to children and adults.
Contact a qualified floor covering installer for the best procedure
for drilling mounting holes through your type floor covering.
Before moving range, slide range onto shipping base, cardboard
or hardboard.
f. Remove template from the anti-tip bracket kit (found inside
the oven cavity).
2. Place template on the floor in the cabinet opening so that the
left edge is against the cabinet and the top edge is against
the rear wall, molding or cabinet.
3. Tape template in place.
4. If the countertop is not flush with the cabinet opening edge,
align the template with the overhang.
i
If the cabinet opening is wider than specified in the "Location
Requirements" section, adjust the template so the range will be
centered in the cabinet opening.
5. To mount the anti-tip bracket to a wood floor, drill two 1/8"
(3.2 mm) holes at the positions marked on the bracket tem-
plate. Remove the template from the floor.
To mount the anti-tip bracket to a concrete or ceramic floor, use
a 3/16" (4.8 mm) masonry drill bit to drill 2 holes at the positions
marked on the bracket template. Remove the template from the
floor.
6. Tap plastic anchors into holes with a hammer.
7. Align the anti-tip bracket holes with the holes in the floor.
Fasten the anti-tip bracket with the screws provided.
Depending on the thickness of your flooring, longer screws may
be necessary to anchor the bracket to the subfloor. Longer
screws are available from your local hardware store.
8. Movetherangeclosetotheopening.Removetheshipping
base,cardboardorhardboardfromundertherange.
9.Openthebroilerdoor.Usea3/8"driveratchettolowerthe
rearlevelinglegsone-halfturn.Useflip-jointplierstolower
thefrontlevelinglegsone-halfturn.
10.Adjusttheleveling
legstothecorrect
height.Levelinglegscanbeloosenedtoadduptoamaxi-
mumof1"(2.5cm).Aminimumof3/16"(5mm)isneededto
engagetheanti-tipbracket.
11.Movetherangeintofinalpositionmakingsuretherearlevel-
inglegslidesintotheanti-tipbracket.
12.Ifinstallingtherangeinamobilehome,youmustsecurethe
rangetothefloor.Anymethodofsecuringtherangeisade-
quateaslongasitconformstothestandardsinthe
"LocationRequirements"section.
13.Continueinstallingyourrangeusingthefollowinginstallation
instructions.
1.Makesuretheanti-tipbracketisinstalled:
[] Lookfortheanti-tipbracketsecurelyattachedtothefloor.
[] Slidetherangebacksotherearrangefootisundertheanti-tip
bracket.
2.Ifinstallingtherangeinamobilehome,youmustsecurethe
rangetothefloor.Anymethodofsecuringtherangeisade-
quateaslongasitconformstothestandardsinthe"Location
Requirements"section.
3.Ifrangeisnotlevel,pullrangeforwarduntilrearlevelinglegis
removedfromtheanti-tipbracket.Uses/8"driveratchetand
slip-jointplierstoadjustlevelinglegsupordownuntilrangeis
level.
4.Pushrangebackintoposition.
5.Checkthatrearlevelinglegisengagedinanti-tipbracket.
NOTE:Rangemustbelevelforsatisfactorybakingperformance.
Typicalrigidpipeconnection
Acombinationofpipefittingsmustbeusedtoconnecttherange
totheexistinggasline.Yourconnectionmaybedifferent;accord-
ingtothesupplylinetype,size,andlocation.
t. ApplypipejointcompoundmadeforusewithLPgastoall
pipethreadconnections.
2. Usingapipewrenchtotighten,connectthegassupplytothe
range.
_ _ ....................S
H
G.....................
F
L,J
A. Pressure regulator con- D. Union
nection tiffing E.Nipple
B. 90°elbow EManual shutoff valve
C. Black iron pipe G. V2"to 3A"gas pipe
Typical flexible connection
t. Use a combination wrench to attach the flexible connector to
the adapters. Check that connector is not kinked.
A
A.Anti-tipbracket
B.Rangefoot
3. Continue installing your range using the following installation
instructions.
1. Place rack in oven.
2. Place level on rack and check levelness of range, first side to
side; then front to back.
E.............. _ .........................F
G
b.J
A. Pressure regulator con-
nection tiffing
B. Use pipe joint compound
C. Adapter
D. Flexible connector
E.Adapter
EUse pipe joint compound
G. Manual shutoff valve
H. V2"to 3/4'_gas pipe
Complete Connection
1. Locate gas pressureregulator in the broiler.
A.Gaspressure regu lator
iMPORTANT: Do not remove the gas pressure regulator.
2. Check that the gas pressure regulator shutoff valve is in the
"ON" position. GasPressureRegulator
f
3=
Front View /Front Side View//
Shutoff valve "ON" Position
Open the manual shutoff valve in the gas supply line. The
valve is "open" when the handle is parallel to the gas pipe.
Electronic ignition System
Cooktop and oven burners use electronic ignitors in place of
standing pilots. When a cooktop control knob is turned to the
"LITE" position, the system creates a spark to light the burner.
This sparking continues until the control knob is turned to the
desired setting.
When the oven control is turned to the desired setting, a hot sur-
face ignitor heats to a bright orange and ignites the gas. No
sparking occurs. The glow bar remains on while the burner oper-
ates.
Check Operation of Cooktop Burners
1. If control panel and knobs were oo OFF
removed earlier, reinstall knobs, oo
2. Push in and turn each surface
unit control knob to "LITE" posi-
tion. The flame should light with- _0
in 4 seconds.
3. Turn control knob to "HI" posi-
tion after burner lights.
4. Check each cooktop burner for
proper flame. The small inner ME_
cone should have a very distinct blue
flame 1/4"(6.4 mm) to 1A"(13 mm) long. cone
The outer cone is not as distinct as the
inner cone. inner
cone
A. Closed valve
B. Open valve
4. Test all connections by brushing on an approved noncorrosive
leak-detection solution. Bubbles will show a leak. Correct any
leak found.
5. Close the broiler door.
6. Place burners, burner caps and grates on the cooktop.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
7. Plug into a grounded 3-prong outlet.
5. Turn the control knob quickly to the "LO"
position after the burner lights. If the
flame goes out, turn the control knob to the "OFF" position.
6. Check each cooktop burner for proper low flame. The low
flame should be a minimum, steady blue flame. The flame size
should be 1/4"to _/8"(6.4 mm to 9.5 mm) high.
if the low flame needs adjusting:
f. Turn control knob to the "LO" setting and remove control
knob.
2. Insert a small flat-blade screwdriver into the valve stem. Turn
the valve adjusting screw to obtain the smallest flame that will
not go out when the control of a cold burner is quickly turned
from "HI" to "LO". Turn right to decrease flame height. Turn
left to increase flame height. Repeat for other cooktop burners
as needed.
A. Valve stem
3. Replace control knob.
10
