1
CABINET PARTS
For Models: NED4800VQ1
(White)
3−09 Litho in U.S.A. (LT)(bay) Part No. W10260028 Rev. A
29" ELECTRIC DRYER

CABINET PARTS
2
For Models: NED4800VQ1
(White)
W10260028
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10150612 Instructions,
Installation
W10232964 Use & Care Guide
W10185985 Wiring Diagram
W10089178 Sheet,
Cycle Feature
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, 8−18 x 3/8
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3403630 Screw, 10−32 x 3/8
7 3396805 Panel, Rear
8 3400500 Bolt,
5/16−18 x 3/4
9 348780 Base, Motor
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 3404413 Plug−Hole
13 3393008 Screw, 10−16 x 1/2
14
W10131364 Belt, Drive
15 3394083 Clip,
Front Panel (2)
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length
Package of 2)
(Not Included)
17 279318 Terminal, Tinned
& Brass (3)
(Includes
Illus. 39)
18 8530603 Cabinet
(Includes
Illus. 4)
19 98234 Clip, Ground
20 690363 Lock, Front Top (2)
21
W10224853 Panel, Front
22 691366 Idler & Pulley
Assembly
23 685203 Clip, Felt Pad (3)
24 3389441 Catch, Door
Assembly
25 3405246 Seal−Door
26 8066217 Hinge, Top (2)
27 342055 Screw, 8−18 x 3/8
28 3405514 Hinge, Door
29 3397659 Block, Terminal
30 3404162 Clamp, Motor
(W/Shield)
31
W10121316 Clamp, Motor
32
W10194250 Motor Assembly,
60 HZ.
33 3403431 Strike, Door
34 8066184 Pulley, 60 HZ.
35 3402341 Door, Rear
36 3402335 Door, Front
37 3405184 Handle, Door
38 3406129 Seal & Bearing
Assembly
39 279393 Terminal Block
Kit (For
Terminal Block)
40 697776 Screw, 10−32 x 5/8

TOP AND CONSOLE PARTS
3
For Models: NED4800VQ1
(White)
W10260028

TOP AND CONSOLE PARTS
4
For Models: NED4800VQ1
(White)
W10260028
Illus. Part
No. No. DESCRIPTION
1 8274261 Panel, Rear
Console
2 3397269 Connector
(Timer)
3 693995 Screw, Hex Head
4 8271365 Cap, End (L.H.)
5
W10186092 Harness, Wiring
6 388326 Screw, Console
7 694419 Buzzer, Mini
8 8271359 Cap, End (R.H.)
9 3405156 Switch,
Wrinkle Gaurd
10 8558463 Screen, Lint
11 8536939 Clip, Spring
12 8533971 Screw, 8−18 x 5/16
13 688983 Screw, 8−18 x 5/8
14 8533951 Screw, Grounding
15 3395683 Connector
(Motor)
16 8557930 Top
17
W10196503 Knob, Control (2)
18 3394427 Clip−Harness
19 94614 Terminal
20 3401144 Connector,
(PTS Relay)
21
W10185982 Timer, 60 Hz.
22
W10196507 Timer Knob,
Assembly
23 357213 Nut, Push−In (2)
24 3936144 Connector
25 3347243 Connector,
6−Circuit
26 3399639 Switch,
Temperature
27 8271418 Bracket, Control
28 3398095 Switch,
Push−To−Start
29
W10086735 Panel Control

BULKHEAD PARTS
5
For Models: NED4800VQ1
(White)
W10260028

BULKHEAD PARTS
6
For Models: NED4800VQ1
(White)
W10260028
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 487909 Screw, 8−15 x 1/2
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 696302 Shield, Exhaust
7 3392519 Thermal Fuse
8 3387134 Thermostat,
Internal−Bias
9 3977393 Thermal, Cut−Off
(Includes
Illus. 15)
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 8066155 Clip
13 343641 Screw, 10−16 x 1/2
14 8541818 Box, Heater
15 3977767 Thermostat,
221 F
(105 C)
16 3977373 Bracket, Drum
Light
17 3403585 Element, Heater
18 8066086 Drum Hole
Plug
19 279457 Wire Kit, Terminal
(For Heater
Element Wiring
Harness Repair)
20 489463 Screw, 8−18 x 5/8
21 3390647 Screw, 8−18 x 1/2
22 3406124 Bulb
23 3402841 Lens, Drum Light
24 690997 Ring, Tri
25 3399506 Shaft, L.H.
26 3399507 Shaft, R.H.
27 3397590 Roller, Support
28 348197 Washer, Support
29 3359452 Nut, 3/8−16
30 3403493 Bulkhead
31
W10136369 Socket Assembly
32 692526 Ring, Bearing (2)
33
W10219342 Screw, 8−16 x 1/2
34 3406130 Seal, Rear Drum
35 695587 Drum Assembly
36 692490 Baffle, Drum (2)
37 3976434 Bracket, Support
38 90296 Clip
39 3403636 Baffle, Drum (1)
40 339956 Seal

OPTIONAL PARTS (NOT INCLUDED)
7
For Models: NED4800VQ1
(White)
W10260028
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
3406839 Dry Rack
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
