Amana NGD5800DW User manual

W10573715B
W10573716B - SP
If you have any problems or questions, visit us at www.amana.com
Pour tout problème ou question, consulter www.amana.com
Use & Care Guide
Guide d’utilisation et d’entretien
Electronic Dryer
Sécheuse électronique
Para obtener acceso
al Manual de uso y
cuidado en español, o para
obtener información adicional
acerca de su producto, visite:
www.amana.com.

2
Dryer Safety
Table of Contents
DRYER SAFETY .......................................................................2
ACCESSORIES ........................................................................4
CHECK YOUR VENT SYSTEM FOR GOOD AIRFLOW............5
CONTROL PANEL AND FEATURES.........................................6
CYCLE GUIDE..........................................................................7
USING YOUR DRYER ..............................................................8
CYCLE STATUS INDICATORS................................................10
ADDITIONAL FEATURES .......................................................10
DRYER CARE .........................................................................11
TROUBLESHOOTING ............................................................13
WARRANTY............................................................................16
ASSISTANCE OR SERVICE..................................... Back Cover
Table de matières
SÉCURITÉ DE LA SÉCHEUSE ...............................................17
ACCESSOIRES ......................................................................19
VÉRIFICATION D’UNE CIRCULATION D’AIR ADÉQUATE
POUR LE SYSTÈME D’ÉVACUATION ....................................20
TABLEAU DE COMMANDE ET CARACTÉRISTIQUES ..........21
GUIDE DES PROGRAMMES..................................................22
UTILISATION DE LA SÉCHEUSE ...........................................23
TÉMOINS LUMINEUX DE PROGRAMME ..............................25
CARACTÉRISTIQUES SUPPLÉMENTAIRES..........................26
ENTRETIEN DE LA SÉCHEUSE .............................................27
DÉPANNAGE..........................................................................29
GARANTIE..............................................................................35
ASSISTANCE OU SERVICE...........................Couverture arrière

3
IMPORTANT: When discarding or storing your old clothes dryer, remove the door.

4
Accessories
Enhance your new washer and dryer with the following
genuine Whirlpool accessories. For more information on
options and ordering, call 1-800-442-9991, or visit us at:
www.amana.com/help. In Canada, call 1-800-807-6777
or visit us at www.amana.com/help
15" Pedestal
Color-matched pedestals raise the washer
and dryer to a more comfortable working
height. The large drawer provides convenient
storage.
Stack Kit
If space is at a premium, the stack kit
allows the dryer to be installed on top
of the washer.

5
Check Your Vent System for Good Airow
Good airow
Along with heat, dryers require good airow to efciently dry
laundry. Proper venting will reduce your drying times and
improve your energy savings. See Installation Instructions.
The venting system attached to the dryer plays a big role
in good airow.
Service calls caused by improper venting are not covered
by the warranty and will be paid by the customer, regardless
of who installed the dryer.
Maintain good airow by:
n Cleaning your lint screen before each load.
n Replace plastic or foil vent material
with 4" (102 mm) diameter heavy, rigid
vent material.
Good Better
n Use the shortest length of vent possible.
n Use no more than four 90° elbows in a vent system;
each bend and curve reduces airow.
n Remove lint and debris from the exhaust hood.
n Remove lint from the entire length of the vent system
at least every 2 years. When cleaning is complete, be
sure to follow the Installation Instructions supplied with
your dryer for nal product check.
n Clear away items from the front of the dryer.
Use Automatic Cycles for better fabric care and energy savings
Use the Automatic Cycles to provide the most energy savings and enhanced fabric care from the dryer. During Automatic Cycles,
drying air temperature and moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the dryer
shuts off when the load reaches the selected dryness. Use the NORMAL dryness level to provide optimal energy savings.
With Manual Cycles, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to
over-drying. Use Manual Cycles for the occasional damp load that needs a little more drying time or when using the drying rack.

6
Control panel and features
NOTE: The control panel features a sensitive surface that responds
to a light touch of your nger. To ensure your selections are registered,
touch the control panel with your nger tip, not your ngernail. When
selecting a setting or option, simply touch its name.
OPTIONS
Use to select available options for your dryer.
Control Lock
Use to lock the controls of the dryer and avoid
an accidental change in cycle options or preferences
during a drying cycle.
Touch and hold CONTROL LOCK for 3 seconds
to lock or unlock the controls of the dryer. During
this time, the LED Display will count down 3-2-1.
Once the controls are locked, the LED Display will
display “Lc.”
NOTE: The Control Lock function may be enabled
when recovering from a power failure. To unlock the
control, touch and hold CONTROL LOCK for at least
3 seconds.
5
3
2
1
5
4
1
2
3
POWER
Touch to turn the dryer on and off. Touch to stop/cancel
a cycle at any time.
CYCLE CONTROL KNOB
Turn the knob to select a cycle for your laundry load.
Automatic Cycles are Heavy Duty, Normal, and Delicates.
Manual Cycles are Quick Dry and Time Dry. See “Cycle
Guide” for detailed descriptions of cycles.
START/PAUSE
Touch and hold until the LED comes on to start a cycle,
or touch once while a cycle is in process to pause it.
LED DISPLAY AND SETTINGS
When you select a cycle, its default settings will light up
and the Estimated Time Remaining (for Automatic Cycles)
or actual time remaining (for Manual Cycles) will be
displayed. For times longer than 99 minutes, hours
will be displayed followed by minutes.
Touch TEMP or DRYNESS LEVEL to adjust cycle settings.
See “Cycle Guide” for available settings on each cycle.
Not all settings are available with all cycles.
–/+ (Adjust Drying Time)
Touch “+” or “–” with Manual Cycles to increase or
decrease the length of a Time Dry or Quick Dry cycle.
Temp
When using Manual Cycles, you may select a dry
temperature based on the type of load you are drying.
Use the warmest setting safe for the garments in the
load. Follow garment label instructions.
NOTE: Automatic Cycles use a preset temperature that
is not adjustable.
Dryness Level
When using Automatic Cycles, you may select a
Dryness Level based on the type of load you are drying.
NOTE: Dryness Level is for use with Automatic Cycles
only.
Cycle Status Lights
The indicator lights on the display will let you know
cycle and dryer status. For more information, see
“Cycle Status Indicators.”
4

7
Cycle Guide – Automatic Cycles
Settings and options shown in bold are default settings for that cycle.
If settings are changed, the new settings will be remembered. If there is a power failure, settings will return to the default.
Not all settings and options are available on each cycle.
Load Size Recommendations
For best results, follow the wet load size recommendations
noted for each cycle.
Small load: Fill the dryer drum with 3–4 items, not more
than 1/4 full.
Medium load: Fill the dryer drum up to about 1/2 full.
Large load: Fill the dryer drum up to about 3/4 full.
Do not pack tightly. Items need to tumble freely.
Use Automatic Cycles for better fabric care and energy savings
The dryer senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness level. Use the
NORMAL dryness level to provide optimal energy savings.
Cycle Guide – Manual Cycles
Settings and options shown in bold are default settings for that cycle.
If settings are changed, the new settings will be remembered (except on Quick Dry). If there is a power failure, settings will return to
the default.
Not all settings and options are available on each cycle.
Selecting the Drying Temperature
A High heat setting may be used for drying heavyweight items such as towels and work clothes.
A Low to Medium heat setting may be used for drying medium-weight items such as sheets, blouses, dresses, underwear, permanent
press fabrics, and some knits.
Use a no heat (air dry) setting for foam, rubber, plastic, or heat-sensitive fabrics.
Line dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures for various loads, refer to the care label directions.
Items to dry: Cycle:
Drying
Temperature:
Dryness
Level:
Default
Time: Cycle Details:
Heavyweight items
such as towels or
heavy work clothes
Heavy
Duty High More Normal
Less
45 Offers stepped drying starting with High heat followed
by Medium heat for enhanced fabric care and energy
savings.
Work clothes, casual
wear, mixed cottons,
sheets, corduroys
Normal Medium More
Normal
Less
38 Uses Medium heat to dry large loads of mixed fabrics
and items. Normal is the preferred energy cycle.
Undergarments,
blouses, lingerie,
performance wear
Delicates Low More
Normal
Less
28 Uses Low heat to gently dry delicate items.
Items to dry: Cycle:
Drying
Temperature:
Default
Time: Cycle Details:
Small loads and
sportswear Quick Dry High Medium
Low
Air Only
26 For small loads of 3–4 items.
Any load
NOTE: Select Air
Only to dry foam,
rubber, plastic,
or heat-sensitive
fabrics.
Time Dry High
Medium
Low
Air Only
40 Use to dry items to a damp level for items that do not require an entire
drying cycle. Select a drying temperature based on the type of fabrics in
your load. If you are unsure of the temperature to select for a load, select
the lower setting rather than the higher setting.

8
3. Touch POWER
Touch POWER to turn on the dryer.
4. Select the desired cycle
Select the desired cycle for your load. See the “Cycle Guide”
for more information about each cycle. Not all cycles are
on all models.
Using Your Dryer
1. Clean the lint screen
Clean the lint screen before each load. Pull the lint screen
straight up. Roll lint off the screen with your ngers. Do not rinse
or wash screen to remove lint. Wet lint is hard to remove. Push
the lint screen rmly back into place.
For additional cleaning information, see “Dryer Care.”
2. Load the dryer
Open the door by pulling on the handle. Place laundry in the
dryer. Add a dryer sheet to wet load, if desired. Close the door.
IMPORTANT: Do not tightly pack the dryer. Items need
to tumble freely. Tightly packing can lead to poor drying
performance and may increase wrinkling and tangling.
WARNING: To reduce the risk of re, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.

9
7. Remove garments promptly after
cycle is nished
Promptly remove garments after cycle has completed
to reduce wrinkling.
5. Adjust cycle settings, if desired
You may adjust different settings, depending on whether you
have selected an Automatic Cycle or Manual Cycle. See the
“Cycle Guide” for detailed information.
NOTE: Not all options and settings are available with all cycles.
Not all cycles are on all models.
Automatic Cycles:
You can select a different dryness level, depending on your
load. Touch DRYNESS LEVEL to scroll to More, Normal, or
Less. Selecting More, Normal, or Less automatically adjusts
the dryness level at which the dryer will shut off. Once a
dryness level is set, it cannot be changed without stopping
the cycle.
Automatic Cycles give the best drying in the shortest time.
Drying time varies based on fabric type, load size, and
dryness setting. Drying time is estimated and may change
throughout the cycle. Drying time can not be changed on
Automatic Cycles.
NOTE: Automatic cycles use a preset temperature that is not
adjustable.
Manual Cycles:
When you select a Manual Cycle, the default
time appears in the display. Touch +and –
to increase or decrease the time in 1-minute
increments. Touch and hold to change the
time in 5-minute increments.
The default temperature may be changed by
pressing Temp until the desired dry temperature is lit. Once a
cycle has started, the temperature can be changed after rst
pausing the cycle.
Changing the Automatic Cycle settings
to increase or decrease drying time
If all your loads on all Automatic Cycles are consistently
less dry or more dry than you would like, you may change
the default settings to increase or decrease the default
dryness level.
Your automatic drying settings can be adjusted to adapt to
different installations, environmental conditions, or personal
preference. This change is retained and will affect all of your
Automatic Cycles, not just the current cycle/load. There are
5 drying settings, which are displayed using the time
display:
F1 Factory preset dryness level.
F2 Slightly drier clothes, 15% more drying time.
F3 Much drier clothes, 30% more drying time.
F4 Slightly wetter clothes, 15% less drying time.
F5 Much wetter clothes, 30% less drying time.
To change the drying settings:
NOTE: The settings cannot be changed while the dryer
is running or paused. The dryer must be in standby mode
(power is off) to adjust the default settings.
1. Before starting a cycle, touch and hold DRYNESS
LEVEL for 6 seconds.
2. Touch DRYNESS LEVEL to select the dryness level
shown in the time display: F1, F2, F3, F4, or F5.
3. Touch START/PAUSE to save the new dryness level
setting.
6. Touch and hold START/PAUSE
to begin cycle
Touch and hold START/PAUSE to begin the cycle.

10
Additional Features
2. Align the two hooks on the front of the drying rack with
the holes in the dryer door opening and press down fully
into holes. Rest the rear support on the dryer back ledge.
USING THE DRYING RACK
To obtain a drying rack for your dryer, order by calling
1-877-944-7566. You will need your model and serial
number and the purchase date. Remove and discard
any packing material before use.
Use the Drying Rack for items that you do not want to
tumble dry, such as sweaters and tennis shoes. When you
use the drying rack, the drum continues to turn, but the rack
remains stationary.
The drying rack is intended for use with the Manual Dry/
Time Dry cycles only. The drying rack cannot be used with
Automatic cycles.
To use the drying rack:
IMPORTANT: Do not remove the lint screen.
1. Open dryer door.
3. Place wet items on top of the drying rack. Allow space
around items for air to circulate. The drying rack does
not move, but the drum will rotate; be sure to leave
adequate clearance between items and the inside of
the dryer drum. Make sure items do not hang over the
edges or between drying rack grille.
4. Close the door.
5. Select a Time Dry/Air Only, or Low Temperature cycle.
Items containing foam, rubber, or plastic must be dried
on a clothesline or by using the Air Only setting.
6. When the cycle is selected, the Estimated Time
Remaining display shows the default time. You can
change the actual time in the cycle by increasing or
decreasing the cycle time.
7. Start the dryer.
NOTE: Check the lint screen and remove any lint
accumulated from items dried on the drying rack
after the cycle is nished.
Cycle Status Indicators
The Cycle Status Indicators show the progress of a cycle.
Check Vent
This indicator will show the status of airow through the
dryer and dryer vent system for the dryer’s life. During the
sensing phase at the beginning of the cycle, the Check Vent
light will come on if a blocked vent or low airow issue is
detected. This light will stay on for the entire cycle. The
light will be cleared when selecting a new cycle, touching
POWER, or opening the door after the cycle has completed.
This feature is available during Automatic cycles only. For
more information on maintaining good airow, see “Check
Your Vent System for Good Airow.”
NOTE: If there are other error issues during a cycle, the
Check Vent indicator will not light up. See “Troubleshooting”
section.
Efciency Monitor
The Efciency Monitor allows you to see how the settings
you select affect your energy usage within the cycle chosen.
The Efciency Monitor indicator may change, depending on
the options and modiers selected.
Wet
The load is still wet and/or the cycle just started.
Cool Down
The dryer has nished drying with heat, and is now tumbling
the load without heat to cool it down and reduce wrinkling.
Done
This will indicate that the selected cycle has ended and
the load may be removed from the dryer.
