Standard Features
• Bi-Flow Liquid Line Filter Drier (Factory Installed)
• Back Seating Service Valves
• Scroll Compressor
• Manual Reset High Pressure Switch
• Automatic Reset Loss Of Charge Switch
• Time/Temperature Defrost
• Heating Mode Thermostatic Expansion Valve (TXV)
with Internal Check Valve
• Eight-Pole Condenser Fan Motor
• Compressor Sound Blanket
Accessories
• Fossil Fuel Kit (FFK03A)
• Hard Start Kit (HSK10A)
• Freeze Protection Kit (FSK01A)
(Installed On Indoor Coil)
• Anti Short Cycle Protection
Heat Pump Performance Data
For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
Above information is for nominal CFM and 70° F indoor dry bulb.
All pressures are PSIG.
All temperatures are °F.
NOTE: It is important to electrically connect the unit and
properly size fuses/circuit breakers and wires in accor-
dance with all national and/or local electrical codes. Use
copper wire only.
SPECIFICATION SHEET
R EMOTE H EAT P UMP
Due to policy of continual product
improvement, the right is reserved to
change specifications and design
without notice.
20451313 (1)
RHE48C2A
RHE48C2A / CHA60TCC / BBC60A2A@TAP B
48,500
27.2
137
1/3
2.3
3.6
3/8
7/8
242
208/230-60-1
36.2
50.0
1/2 or 3/4
1/2
281
Low Voltage
Power Supply (volts)
Min. Circuit Ampacity
Max. Overcurrent Device (amps)
Electric Conduit Size (in.)
Liquid Line, Inches O.D.
Suction Line, Inches O.D.
Refrigerant Charge (oz.)
Power Supply
Specifications
Approximate Shipping Weight (lbs.)
Cooling Capacity, BTUH (Nominal)
Compressor
R.L. Amps
L.R. Amps
Condenser Fan Motor
Horsepower
R.L. Amps
L.R. Amps
Outdoor Ambient Temperature (° F)
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
∆T34 32 30 28 27 26 24 22 20 19 17 16 16 14 13 11 9 8
Amps 20.6 19.1 17.9 16.9 16.3 16.0 15.1 14.4 13.8 13.2 12.6 12.3 12.2 11.6 10.9 10.3 9.5 8.6
HI PR 263 252 242 231 226 222 213 205 196 187 180 175 172 166 159 153 147 142
LO PR 73 68 64 59 55 53 49 44 39 35 31 29 28 23 20 17 15 12
When mix-matching with restrictor orifice
indoor coil, use Chatleff .092 diameter
restrictor orifice 11076314.

2
Typical Cooling Performance Data
CAUTION
The installation must be adjusted to obtain a temperature rise within the range listed on the
unit nameplate.
*Entering Dry Bulb Temperature. NOTE: Darker shaded area with white lettering is ARI rating conditions, (95° ambient, 80° IDB + 67° IWB).
Lighter shaded area with black lettering is ACCA rating conditions, (95° ambient, 75° IDB + 63° IWB). All Pressures are PSIG. All temperatures are in °F. Low and high pressure are measured at gauge port. Amps are total unit amps at a rated voltage of 230 VAC.
®
is a trademark of Maytag World-
wide N.V. and is used under license to Goodman Company, L.P. All rights reserved.
Effectivity Date: May 2003
RHE48C2A / CHA60TCC / BBC60A2A@TAP B
Outdoor Ambient Tem
p
erature
(
°F
)
65 75 85 95 105 115
Enterin
g
Indoor Wet Bulb Tem
p
erature
(
°F
)
IDB*
A
irflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
∆ T17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
1800 AMPS 12.4 12.7 13.1 - 13.4 13.7 14.1 - 14.5 14.8 15.3 - 15.4 15.8 16.3 - 16.3 16.7 17.3 - 17.3 17.7 18.2 -
HI PR 129 138 146 - 144 155 164 - 164 177 186 - 187 201 212 - 210 226 239 - 232 250 264 -
LO PR 58 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 70 75 82 - 73 77 84 -
∆ T19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
70 1640 AMPS 12.4 12.7 13.1 - 13.3 13.6 14.1 - 14.4 14.8 15.2 - 15.4 15.7 16.2 - 16.3 16.7 17.2 - 17.2 17.6 18.2 -
HI PR 128 138 146 - 144 155 163 - 164 176 186 - 186 200 212 - 210 226 238 - 232 249 263 -
LO PR 58 62 67 - 61 65 71 - 64 68 74 - 67 71 78 - 70 75 81 - 73 77 84 -
∆ T19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
1400 AMPS 12.1 12.4 12.7 - 13.0 13.3 13.7 - 14.0 14.4 14.8 - 15.0 15.3 15.8 - 15.9 16.2 16.7 - 16.8 17.2 17.7 -
HI PR 124 134 141 - 139 150 159 - 159 171 180 - 181 194 205 - 203 219 231 - 225 242 255 -
LO PR 56 60 65 - 59 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 70 75 82 -
∆ T20 19 15 10 20 19 15 11 20 19 15 11 21 19 16 11 20 19 15 11 19 17 14 10
1800 AMPS 12.5 12.8 13.2 13.7 13.5 13.8 14.2 14.7 14.6 14.9 15.4 15.9 15.5 15.9 16.4 17.0 16.5 16.9 17.4 18.0 17.4 17.8 18.4 19.1
HI PR 130 140 148 154 146 157 166 173 166 178 188 196 189 203 214 224 212 229 241 252 235 252 267 278
LO PR 59 63 68 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 73 78 85 91
∆ T21 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 11
75 1640
A
MPS 12.5 12.8 13.2 13.6 13.5 13.8 14.2 14.7 14.5 14.9 15.4 15.9 15.5 15.9 16.4 16.9 16.4 16.8 17.4 18.0 17.4 17.8 18.4 19.0
HI PR 129 139 147 153 145 156 165 172 165 178 188 196 188 203 214 223 212 228 241 251 234 252 266 277
LO PR 59 62 68 72 62 66 72 77 64 68 75 80 68 72 79 84 71 75 82 88 73 78 85 91
∆ T22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11
1400
A
MPS 12.2 12.5 12.8 13.3 13.1 13.4 13.8 14.3 14.2 14.5 14.9 15.5 15.1 15.4 15.9 16.5 16.0 16.4 16.9 17.5 16.9 17.3 17.9 18.5
HI PR 126 135 143 149 141 152 160 167 160 172 182 190 183 196 207 216 205 221 233 243 227 244 258 269
LO PR 57 60 66 70 60 64 70 74 62 66 72 77 66 70 76 81 69 73 80 85 71 76 83 88
∆ T22 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14
1800
A
MPS 12.6 12.9 13.3 13.8 13.6 13.9 14.3 14.9 14.7 15.1 15.5 16.1 15.7 16.0 16.5 17.1 16.6 17.0 17.6 18.2 17.6 18.0 18.6 19.2
HI PR 131 141 149 155 147 158 167 174 167 180 190 198 191 205 217 226 214 231 244 254 237 255 269 281
LO PR 59 63 69 73 63 67 73 78 65 69 76 81 68 73 80 85 72 76 83 89 74 79 86 92
∆ T24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 22 19 15
80 1640
A
MPS 12.6 12.9 13.3 13.8 13.6 13.9 14.3 14.8 14.7 15.0 15.5 16.0 15.6 16.0 16.5 17.1 16.6 17.0 17.5 18.2 17.5 17.9 18.5 19.2
HI PR 131 141 149 155 147 158 167 174 167 180 190 198 190 205 216 225 214 230 243 253 236 254 268 280
LO PR 59 63 69 73 63 67 73 77 65 69 75 80 68 73 79 84 72 76 83 89 74 79 86 92
∆ T25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 23 20 16
1400
A
MPS 12.3 12.6 13.0 13.4 13.2 13.5 13.9 14.4 14.3 14.6 15.1 15.6 15.2 15.6 16.1 16.6 16.1 16.5 17.0 17.7 17.1 17.5 18.0 18.7
HI PR 127 137 144 150 142 153 162 169 162 174 184 192 184 198 210 219 207 223 236 246 229 247 260 272
LO PR 57 61 67 71 61 65 70 75 63 67 73 78 66 70 77 82 69 74 81 86 72 76 83 89
