Amana Asure ASH13 Installation instructions

SS-ASH13 www.amana-hac.com 2/06
Supersedes 12/05
PRODUCT SPECIFICATIONS
13 SEER
ASH13
Split System Heat Pump
TheAmana
®
brandASH13 13 SEER Heat Pump
features operating sound levels that are among
the best in the heating and cooling industry. With
its13SEERrating—upto14SEERwithproperly
matchedAmana
®
brandcomponents— and up to
8.3 HSPF heating efficiency ratings, the ASH13
will help reduce energy consumption throughout
the life of the system. Other features include an
energy-efficient scroll compressor with overload
protection, a sound blanket for quiet operation,
and refrigeration-grade copper tube/enhanced
aluminum fin coils.
Nominal Cooling Capacity:
18,000 - 55,500 BTU/h
Nominal Heating Capacity:
18,000 - 55,500 BTU/h
Standard Features
• Energy-efficient Copeland®scroll compressor
• R-22 refrigerant
• High-density foam compressor sound blanket
• Copeland®ComfortAlert diagnostics
• Low-pressure switch
• Fully charged for 15’ of tubing length
• Factory-installed bi-flow liquid line filter dryer
• Liquid refrigerant return protection
• Two-speed condenser fan motor
• Copper tube/enhanced aluminum fin coil
• Sweat connection service valves with
easy access to gauge ports
• 13 SEER performance with flowrater
expansion device
• ARI Certified
• ETL Certified
Cabinet Features
• Unique Amana®brand sound control top design
• Wire fan discharge grille
• Steel louver coil guard
• Baked-on powder-paint finish
• Rust-resistant coated screws
• Compact footprint
• Top and side maintenance access
• Single-panel access to controls with space
provided for field-installed accessories
• When properly anchored, meets the 2001 Florida
Building Code unit integrity requirements for
hurricane-type winds

Specification Sheet
2www.amana-hac.com SS-ASH13
H
WD
NOMENCLATURE
ASH130361AA
Minor Revision
Product or inventory management)
Category 018 = 1.5 tons 048 = 4 tons
S = Split 024 = 2 tons 060 = 5 tons Major Revision
Unit Type 036 = 3 tons A = Initial Release
C = Condenser R-22 042 = 3.5 tons
X = Condenser R-410A
H = Heat Pump R-22
Z = Heat Pump R-410A Electrical
1 = 208/230 V, 1 Phase, 60 Hz
Brand Name
A = Amana
14 = 14 SEER
16 = 16 SEER
18 = 18 SEER
(not used for order entry
Nominal Capacity
SEER
13 = 13 SEER
DIMENSIONS
Model Dimensions
W x D x H
ASH130181A 29 x 29 x 32¼
ASH130241A 29 x 29 x 32¼
ASH130301A 29 x 29 x 34¼
ASH130361A 29 x 29 x 34¾
ASH130421A 29 x 29 x 32¼
ASH130481A 29 x 29 x 34¼
ASH130601A 35½ x 35½ x 34¼

Specification Sheet
SS-ASH13 www.amana-hac.com 3
SPECIFICATIONS
ASH13-
0181A ASH13- 0241A ASH13- 0301A ASH13- 0361A ASH13- 0421A ASH13- 0481A ASH13- 0601A
Capacities and Ratings
Nominal Cooling (BTU/h) 18,000 23,600 28,000 35,000 40,000 45,000 55,500
Nominal Heating (BTU/h) 17,400 23,000 27,000 34,000 39,500 43,000 55,500
Compressor
RLA 9 10.9 12.2 13.4 16.5 17.9 24.3
LRA 41 54 63 73 95 104 148
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/4 1/4 1/4 1/6
FLA 0.9 0.9 0.9 1.5 1.5 1.5 1.1
Refrigerant Lines
Liquid Valve Size (“O.D.)* 3/8” 3/8” 3/8” 3/8” 3/8” 3/8” 3/8”
Suction Valve Size (“O.D.)* 3/4” 3/4” 3/4” 7/8” 7/8” 7/8” 7/8”
Valve Connection Type Sweat Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 115 117 153 188 213 223 233
Shipped with Orifice Size 0.052 0.062 0.065 0.073 0.082 0.084 0.093
Electrical Data
Voltage 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Hz/Phase 60/1 60/1 60/1 60/1 60/1 60/1 60/1
Minimum Circuit Ampacity112.1 14.5 16.1 18.3 22.2 23.9 31.5
Maximum Overcurrent Device220 20 20 30 30 40 50
Min / Max Volts 197/253 197/253 197/253 197/253 197/253 197/253 197/253
Power Supply Conduit Size 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4”
Ship Weight (lbs) 175 190 240 260 260 275 325
* Line size up to 35’ in equivalent line length
1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes
2) May use fuses or HACR-type circuit breakers of the same size as noted

Specification Sheet
4www.amana-hac.com SS-ASH13
PERFORMANCE RATINGS
Heat
Pump Coil / Air Handler Total BTU/h Sensible BTU/h SEER EER Heating Capacity dBs
47° F
(Btuh) 47°F (COP) HSPF 17°F (Btuh) 17°F (COP)
ASH130181A*
AEPT030-00*-1* /AEPF18301A* 18,000 13,200 14.0 12 17,400 3.60 8.0 8,600 2.00
TBD
ARPF036-00B-1* /ADPF18241A* 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
ARPT032-00*-1* /ARPF18241A* 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
ARUF032-00*-1* /ARUF18241A* 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
CA*F030*2* / CA*F1824*6A*+ EEP 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
CA*F030*2* 18,000 13,200 14.0 12 16,800 3.50 8.0 8,600 2.00
CA*F1824*6A* +A*V80704B** 18,000 13,200 14.0 12 16,800 3.50 8.0 8,600 2.00
CA*F030*2* 18,000 13,200 13.5 12 16,800 3.50 7.7 8,600 2.00
CA*F1824*6A* +A*V90453B** 18,000 13,200 13.5 12 16,800 3.50 7.7 8,600 2.00
CHPF030B2* / CHPF1824A6A* + EEP 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
CHPF042B2* 18,000 13,200 14.0 12 16,800 3.50 8.0 8,600 2.00
CHPF2430B6A* +A*V80704B** 18,000 13,200 14.0 12 16,800 3.50 8.0 8,600 2.00
CHPF042B2* 18,000 13,200 13.5 12 16,800 3.50 7.7 8,600 2.00
CHPF2430B6A* +A*V90453B** 18,000 13,200 13.5 12 16,800 3.50 7.7 8,600 2.00
H36F / CSCF1824N6A* +EEP 18,000 13,200 13.0 12 16,800 3.50 7.7 8,600 2.00
H36F / CSCF1824N6A* + A*V80704B** 18,000 13,200 14.0 12 16,800 3.50 8.0 8,600 2.00
H36F / CSCF1824N6A* + A*V90453B** 18,000 13,200 13.5 12 16,800 3.50 7.7 8,600 2.00
CA*F030*2* / CA*F1824*6A* + MBE1200 18,000 13,200 14.0 12 16,800 3.60 8.0 8,600 2.00
ASH130241A*
AEPT030-00*-1* /AEPF18301A* 23,600 17,000 14.0 12 23,000 3.40 8.2 14,000 2.30
TBD
ARPF036-00B-1* /ADPF18241A* 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
ARPT032-00*-1* /ARPF18241A* 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
ARUF032-00*-1* /ARUF18241A* 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
CA*F037*2* / CA*F3030*6A* +EEP 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
CA*F037*2* 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20
CA*F3030*6A* +A*V80704B** 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20
CA*F037*2* 23,600 17,000 13.5 12 23,000 3.30 8.0 14,000 2.20
CA*F3030*6A* +A*V90453B** 23,600 17,000 13.5 12 23,000 3.30 8.0 14,000 2.20
CHPF030A2* / CHPF1824A6A* + EEP 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
CHPF042B2* 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20
CHPF2430B6A* +A*V80704B** 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20
CHPF042B2* 23,600 17,000 13.5 12 23,000 3.30 8.0 14,000 2.20
CHPF2430B6A* +A*V90453B** 23,600 17,000 13.5 12 23,000 3.30 8.0 14,000 2.20
H36F / CSCF1824N6A* +EEP 23,600 17,000 13.0 12 23,000 3.30 8.0 14,000 2.20
H36F / CSCF1824N6A* + A*V80704B** 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20
H36F / CSCF1824N6A* + A*V90453B** 23,600 17,000 13.5 12 23,000 3.30 8.0 14,000 2.20
CA*F030*2* / CA*F1824*6A* + MBE1200 23,600 17,000 14.0 12 23,000 3.30 8.0 14,000 2.20

Specification Sheet
SS-ASH13 www.amana-hac.com 5
PERFORMANCE RATINGS (CONT.)
Heat
Pump Coil / Air Handler Total BTU/h Sensible BTU/h SEER EER Heating Capacity dBs
47° F
(Btuh) 47°F (COP) HSPF 17°F (Btuh) 17°F (COP)
ASH130301A*
AEPT030-00*-1* /AEPF18301A* 28,000 21,000 14.0 12.2 27,000 3.40 8.0 15,000 2.30
78
ARPF048-00B-1* /ADPF30421A* 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
ARPT042-00*-1* /ARPF30301A* 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
ARUF042-00*-1* /ARUF30361A* 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
CA*F042*2* / CA*F3131*6A* +EEP 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
CA*F042B2*+A*V80704B** 28,000 21,000 14.0 12 27,000 3.40 8.0 15,000 2.30
CA*F042B2*+ A*V90453B** 28,000 21,000 13.5 12 27,000 3.40 8.0 15,000 2.30
CHPF042B2* / CHPF2430B6A* +EEP 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
CHPF042B2* 28,000 21,000 14.0 12 27,000 3.40 8.0 15,000 2.30
CHPF2430B6A* +A*V80704B** 28,000 21,000 14.0 12 27,000 3.40 8.0 15,000 2.30
CHPF042B2* 28,000 21,000 13.5 12 27,000 3.40 8.0 15,000 2.30
CHPF2430B6A* +A*V90704C** 28,000 21,000 13.5 12 27,000 3.40 8.0 15,000 2.30
H49F / CSCF3036N6A*+EEP 28,000 21,000 13.0 12 27,000 3.30 7.8 15,000 2.20
H49F / CSCF3036N6A* + G*V80704B** 28,000 21,000 14.0 12 27,000 3.40 8.0 15,000 2.30
H49F / CSCF3036N6A* + A*V90704C** 28,000 21,000 13.5 12 27,000 3.40 8.0 15,000 2.30
CA*F042*2* / CA*F3131*6A* + MBE1200 28,000 21,000 14.0 12 27,000 3.40 8.0 15,000 2.30
ASH130361A*
AEPT036-00*-1* /AEPF30361A* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
80
ARPF048-00B-1* /ADPF30421A* 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
ARPT049-00*-1* /ARPF36421A* 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
ARUF049-00*-1* /ARUF36421A* 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
CA*F060*2* / CA*F3642 *6A*+EEP 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
CA*F060*2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F3642 *6A* + A*V80905C** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F060*2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F3642 *6A* + A*V81155C** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F060*2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F3642 *6A* + A*V90905D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F060*2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F3642 *6A* + A*V91155D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CHPF3636B6A* + EEP 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
CHPF3642C6A* + EEP 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
CHPF048D2* / CHPF3642D6A* + EEP 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
CHPF3642C6A* +A*V80905C** 35,000 26,500 14.0 12 34,000 3.30 7.7 19,400 2.30
CHPF3642C6A* +A*V81155C** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CHPF048D2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CHPF3642D6A*+ A*V90905D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CHPF048D2* 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CHPF3642D6A* +A*V91155D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
H60F / CSCF3642N6A* +EEP 35,000 26,500 13.0 12 34,000 3.30 7.7 19,400 2.30
H60F / CSCF3642N6A* + A*V80905C** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
H60F / CSCF3642N6A* + A*V81155C** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
H60F / CSCF3642N6A* + A*V90905D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
H60F / CSCF3642N6A* + A*V9115D** 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30
CA*F060*2* / CA*F3642 *6A* + MBE1600 35,000 26,500 14.0 12 34,000 3.50 8.0 19,400 2.30

Specification Sheet
6www.amana-hac.com SS-ASH13
PERFORMANCE RATINGS (CONT.)
Heat
Pump Coil / Air Handler Total BTU/h Sensible BTU/h SEER EER Heating Capacity dBs
47° F
(Btuh) 47°F (COP) HSPF 17°F (Btuh) 17°F (COP)
ASH130421A*
AEPT060-00*-1* /AEPF42601A* 41,000 30,500 14.0 12 39,500 3.50 8.2 23,000 2.30
76
ARPF048-00B-1* /ADPF30421A* 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
ARPT049-00*-1* /ARPF36421A* 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
ARUF049-00*-1* /ARUF36421A* 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
CA*F060*2* / CA*F3642*6* + EEP 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
CA*F061*2* / CA*F4860*6* + A*V80905C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CA*F061*2* / CA*F4860*6* +A*V81155C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CA*F061*2* / CA*F4860*6* +A*V90905D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CA*F061*2* / CA*F4860*6* + A*V9115D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CHPF3636B6A* + EEP 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
CHPF3642C6A* + EEP 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
CHPF048D2* / CHPF3642D6A* + EEP 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
CHPF060D2* 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CHPF4860D6A* +A*V80905C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CHPF060D2* 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CHPF4860D6A* +A*V81155C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
CHPF060D2* 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CHPF4860D6A* +A*V90905D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CHPF060D2* 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CHPF4860D6A* +A*V91155D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
H60F / CSCF3642N6A* + EEP 40,000 30,500 13.0 12 39,000 3.40 8.0 23,000 2.20
H61F / CSCF4860N6A* + A*V80905C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
H61F / CSCF4860N6A* + A*V81155C** 41,000 31,300 14.0 12 39,000 3.40 8.2 23,000 2.20
H61F / CSCF4860N6A* + A*V90905D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
H61F / CSCF4860N6A* +A*V91155D** 41,000 31,300 13.5 12 39,000 3.40 8.0 23,000 2.20
CA*F060*2* / CA*F3642*6A* + MBE1600 40,000 30,500 14.0 12 39,000 3.50 8.2 23,000 2.30
ASH130481A*
AEPT060-00*-1* /AEPF42601A* 45,000 34,000 14.0 12.2 43,000 3.60 8.4 27,000 2.50
76
ARPF060-00B-1* /ADPF48601A* 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
ARPT061-00*-1* /ARPF48601A* 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
ARUF061-00*-1* /ARUF48601A* 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
CA*F061*2* / CA*F4860 *6A* + EEP 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
CA*F061*2* / CA*F4860*6* + A*V80905C** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CA*F061*2* / CA*F4860*6* + A*V81155C** 45,000 34,000 14.0 12 43,000 3.50 8.4 27,000 2.40
CA*F061*2* / CA*F4860*6* + A*V90905D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CA*F061*2* / CA*F4860*6* + A*V9115D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40

Specification Sheet
SS-ASH13 www.amana-hac.com 7
PERFORMANCE RATINGS (CONT.)
Heat
Pump Coil / Air Handler Total BTU/h Sensible BTU/h SEER EER Heating Capacity dBs
47° F
(Btuh) 47°F (COP) HSPF 17°F (Btuh) 17°F (COP)
ASH130481A* (cont.)
CHPF060D2* / CHPF4860D6A*+EEP 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
76
CHPF060D2* 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF4860D6A* +A*V80905C** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF060D2* 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF4860D6A* +A*V81155C** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF060D2* 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF4860D6A* +A*V90905D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF060D2* 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CHPF4860D6A* +A*V91155D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
H61F / CSCF4860N6A* + EEP 45,000 34,000 13.0 12 43,000 3.50 8.2 27,000 2.40
H61F / CSCF4860N6A* + A*V80905C** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
H61F / CSCF4860N6A* + A*V81155C** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
H61F / CSCF4860N6A* + A*V90905D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
H61F / CSCF4860N6A* + A*V91155D** 45,000 34,000 13.5 12 43,000 3.50 8.3 27,000 2.40
CA*F061*2* / CA*F4860 *6A* + MBE2000 45,000 34,000 14.0 12 43,000 3.60 8.4 27,000 2.50
ASH130601A*
AEPT060-00*-1* /AEPF42601A* 55,500 40,000 13.3 12 55,500 3.60 8.6 35,000 2.60
77
ARPF060-00B-1* /ADPF48601A* 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
ARPT061-00*-1* /ARPF48601A* 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
ARUF061-00*-1* /ARUF48601A* 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
CA*F061*2* / CA*F4860 *6A* + EEP 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
CA*F061*2* / CA*F4860*6* + A*V80905C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CA*F061*2* / CA*F4860*6* + A*V81155C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CA*F061*2* / CA*F4860*6* + A*V9115D** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF060D2* / CHPF4860D6A* + EEP 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
CHPF060D2* 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF4860D6A* +A*V80905C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF060D2* 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF4860D6A* +A*V81155C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF060D2* 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
CHPF4860D6A*+ A*V9115D** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
H61F / CSCF4860N6A* + EEP 55,500 40,000 13.0 12 55,500 3.50 8.5 35,000 2.50
H61F / CSCF4860N6A* + A*V8090C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
H61F / CSCF4860N6A* + A*V81155C** 55,500 40,000 13.3 12 55,500 3.50 8.5 35,000 2.50
H61F / CSCF4860N6A* + A*V91155D** 55,500 40,000 13.2 12 55,500 3.50 8.5 35,000 2.50
CA*F061*2* / CA*F4860 *6A* + MBE2000 55,500 40,000 13.5 12 55,500 3.60 8.6 35,000 2.60
NOTES:
1) Certified per ARI 210/240 @ 80 °F/67 °F/95 °F
2) Seasonal Energy Efficiency Ratio
3) Energy Efficiency Ratio @ 80 °F/67 °F/95 °F
4) HSPF = Heating Seasonal Performance Factor
5) Order the EEP from the Service Department using Part No. B13707-38 or new Solid State Board B13707-35S. Part No. B13707-38 is not
interchangeable with B13707-35S.
When mix-matching outdoor and indoor units, the indoor unit check-flowrator must match the outdoor unit size.

Specification Sheet
8www.amana-hac.com SS-ASH13
Amana®is a trademark of Maytag Corporation and used
under license to Goodman Company, L.P. All rights reserved.
Our continuing commitment to quality products may mean a change in
specifications without notice. Copyright © 2006 • Goodman Company,
L.P. • Houston, Texas • Printed in the USA.
THERMOSTATS
1213403 1213404 1213406 1213407 1213410
Changeover Manual Manual Manual or Auto Manual Manual
Programmable No No 5+2 5+2 5+2
Cool 11221
Heat 22322
Shape Rectangular Rectangular Rectangular Rectangular Rectangular
Battery Powered No No No Yes No
Analog/Digital Analog Digital Digital Digital Digital
EM Heat Yes Yes Yes No Yes
Color White White Beige White White
ACCESSORIES
Model Description ASH13-
018 ASH13- 024 ASH13- 030 ASH13- 036 ASH13- 042 ASH13- 048 ASH13- 060
AFE18-60A All-fuel Kit XXXXXXX
OT18-60A² Outdoor Thermostat XXXXXXX
FSK01A¹ Freeze Protection Kit XXXXXXX
ASC01 Anti-Short Cycle Kit XXXXXXX
TX3N2 TXV Kit XXXX
TX5N2 TXV Kit X X X
OT/EHR18-60 Emergency Heat Relay kit XXXXXXX
CSR-U-1 Hard-start Kit XXXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit X X
1) Installed on indoor coil
2) Required for heat pump applications where ambient temperatures fall below 0 °F with 50% or higher relative humidity.
