Amana PTAC 24" Operating instructions

RS4200005r11
September 2017
Service Instructions
isa registeredtrademark of MaytagCorporation oritsrelated companiesand isusedunder licenseto Goodman Company,L.P., Houston,TX, USA. Allrightsreserved.
PACKAGE TERMINAL
AIR CONDITIONER/HEAT PUMP
Standard and Remote Applications
with LED M70 Control Board
andR-410A
This manual is to be used by qualified, professionally trained HVAC technicians only.
Goodman does not assume any responsibility for property damage or personal injury
due to improper service procedures or services performed by an unqualified person.
©2014 - 2017 Goodman Company, L.P.

2
Prideandworkmanshipgointoeveryproducttoprovideourcustomerswithqualityproducts. Itispossible,however,
that during its lifetime a product may require service. Products should be serviced only by a qualified service
technicianwhoisfamiliarwiththesafetyproceduresrequiredintherepairandwhoisequippedwiththeproper tools,
parts, testing instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE
APPROPRIATE SERVICE MANUAL BEFORE BEGINNING REPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
IMPORTANT INFORMATION
INDEX
PRODUCT IDENTIFICATION ..................................................................................4
IMPORTANT INFORMATION...................................................................................2
SPECIFICATIONS ...............................................................................................5
PROPER INSTALLATION.......................................................................................9
MAINTENANCE ............................................................................................... 32
OPERATIONS.................................................................................................. 34
SERVICING .................................................................................................... 38
WIRING DIAGRAMS .......................................................................................... 61
O NLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL , ADJUST , SERVICE OR
REPAIR ( HEREINAFTER , “ SERVICE ”) THE EQUIPMENT SPECIFIED IN THIS
MANUAL SHOULD SERVICE THE EQUIPMENT . I N ADDITION , IN JURISDICTIONS
THAT REQUIRE ONE OR MORE LICENSES TO SERVICE THE EQUIPMENT SPECIFIED
IN THIS MANUAL , ONLY LICENSED PERSONNEL SHOULD SERVICE THE
EQUIPMENT . I MPROPER INSTALLATION , ADJUSTMENT , SERVICING OR REPAIR
OF THE EQUIPMENT SPECIFIED IN THIS MANUAL , OR ATTEMPTING TO INSTALL ,
ADJUST , SERVICE OR REPAIR THE EQUIPMENT SPECIFIED IN THIS MANUAL
WITHOUT PROPER TRAINING MAY RESULT IN PRODUCT DAMAGE , PROPERTY
DAMAGE , PERSONAL INJURY OR DEATH .

3
Tolocateanauthorizedservicer,pleaseconsultyourtelephonebookorthedealer
fromwhom you purchasedthis product. Forfurther assistance,pleasecontact:
CONSUMER INFORMATION LINE -
AMANA®BRAND PRODUCTS TOLL FREE
1-877-254-4729 (U.S. only)
email us at: [email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
WARNING
THIS AIR CONDITIONER IS NOT MEANT TO PROVIDE
UNATTENDED COOLING OR LIFE SUPPORT FOR
PERSONS OR ANIMALS WHO ARE UNABLE TO
REACT TO THE FAILURE OF THIS PRODUCT.
THE FAILURE OF AN UNATTENDED AIR CONDITION-
ER MAY RESULT IN EXTREME HEAT IN THE COND-
ITIONED SPACE CAUSING OVERHEATING OR
DEATH OF PERSONS OR ANIMALS.
PRECAUTIONS MUST BE TAKEN TO WARN OF OR
GUARD AGAINST SUCH AN OCCURENCE.
WARNING
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SERVICE OR SERVICE PROCEDURES. IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT,
YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH MAY
RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR
CONDITIONING EQUIPMENT.
isa registered trademarkof MaytagCorporationor itsrelated companies andis usedunderlicense toGoodmanCompany, L.P.,Houston, TX. Allrights reserved.

4
PRODUCT IDENTIFICATION
PTC 07 3 G 35 A X X X A A
BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.
PTC = Standard Cooler PTAC
PTH = Standard Heat Pump PTHP
DRY = Dehumid Cooler PTAC
PMC = Cooler w/ Makeup Air Kit
PMH = Heat Pump w/ Makeup Air Kit
HEH = High Efficiency Heat Pump HEHP
HEC = High Efficiency Cooler
COOLING CAPACITY
07 = 7000 BTUH (60 Hz)
09 = 9000 BTUH (60 Hz)
10 = 10000 BTUH (50 Hz)
12 = 12000 BTUH (50 or 60 Hz)
15 = 15000 BTUH (60 Hz)
17 = 16500 BTUH (60 Hz)
RATED VOLTAGE
2 = 115V 60Hz 1Ph
3 = 230/208V 60Hz 1Ph FEATURE CODE Examples
4 = 265V 60Hz 1Ph A = Standard Model PTC073E35AXXX
5 = 240/220V 50Hz 1Ph C = Corrosion Protection (Seacoast) PTC073E50CXXX
D = Power Door PTC073E35CDXX
E = Makeup Air Electric Heate
r
PTC073E35CQVX
DESIGN SERIES F = Fuse Holder PTC073E35CDQR
E = R-410A 2010 Ratings H = Hydronic
F = R-410A California Model H1 = McQuay Hydronic Replacment
G = R-410A 2012 Ratings K = Added Drain Valve (PTC only)
H = R-410A High EER 2012 L = Lighting Control
J = R-32 N = Non-Branded Front
P = Condensate Pump
Q = Quiet STC Kit
HEATER SIZE R = RF Antenna
00 = no electric heat V = Power Vent
15 = 1.5 kW W = Hard Wired
25 = 2.5 kW X= place holder
35 = 3.5 kw (230/208V) Y = High VA Transformer
= 3.7kW (265V) Use up to 4 as needed
50 = 5.0 kW In Alphabetical order

5
SPECIFICATIONS
* Actual vent CFM performance w ill vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-w ire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; how ever, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation w ithout condensate pump; unit automatically sw itches to electric heat at approximately 24°F outdoo
6Specify tw o-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems. R-134A used in Kit Fresh Air.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) pow er cord and meet UL 484 standards.
10 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers to compressor only.
4Overcurrent protection for all units w ithout electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
PMC/PMH SERIES
Model ¹, 6, 8, 9PMC073G** PMC093G** PMC123G** PMC153G**
230 / 208 230 / 208 230 / 208 230 / 208
Capacity (BTU/h) 7,700 / 7,700 9,000 / 9,000 12,000 / 11,700 15,000 / 14,700
3.5 / 3.5 4.1 / 4.1 5.6 / 5.6 7.0 / 7.0
655 / 655 795 / 795 1,150 / 1,110 1,575 / 1,530
EER 11.7/ 11.7 11.3/ 11.3 10.4/ 10.5 9.5/ 9.6
Kit Fresh Air, CFM 25-35 25-35 25-35 25-35
Kit Dehumidification (Oz/Hr) 5555
Voltage ¹, ³
Amps10
Watts10
Model ¹, 6, 8, 9PMH073G** PMH093G** PMH123G** PMH153G**
230 / 208 230 / 208 230 / 208 230 / 208
Capacity (BTU/h) 7,600 / 7,600 9,000 / 9,000 12,000 / 12,000 14,700 / 14,700
3.6/3.6 4.1/4.1 5.7/5.7 7.0/7.0
640 / 640 795 / 795 1150 / 1150 1,530 / 1,530
EER 11.8 / 11.8 11.3 /11.3 10.4 / 10.4 9.6 / 9.6
Kit Fresh Air, CFM 25-35 25-35 25-35 25-35
Kit Dehumidification (Oz/Hr) 5555
Voltage ¹, ³
Amps10
Watts10
Model ¹, 6, 8, 9PMH074G** PMH094G** PMH124G**
265 265 265
Capacity (BTU/h) 7,700 9,000 12,000
3.2 4.3 5.1
655 795 1150
EER 11.7 11.3 10.4
Kit Fresh Air, CFM 25-35 25-35 25-35
Kit Dehumidification (Oz/Hr) 555
Voltage ¹, ³
Amps10
Watts10

6
SPECIFICATIONS PTC G SERIES
COOLING - PTC
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
* Information in this manual applies only to the BA revision of 092G*** model.
** Actual vent CFMperformance w ill vary due to application and installation conditions.
No t e s :
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² MinimumCircuit Ampacity (MCA) ratings conformto the National Electric Code; however, local codes should apply.
Minimumvoltage on 230/208-volt models is 197 volts; maximumis 253 volts.
3Minimumvoltage on 265-volt models is 239 volts; maximumis 292 volts.
4Minimumvoltage on 115-volt models is 104 volts; maximumis 127 volts.
6Heatin
g
capacit
y
and efficienc
y
based on unit operation without condensate pump; unit automaticall
y
switches to electric heat at approximatel
y
24°F outdoor
a
7Specify two-digit heater kW size to complete model number.
8R-410A refrigerant used in allsystems.
9All units meet or exceed ASHRAE90.1 standards.
10 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
11 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers to compressor only.
5Overcurrent protection for allunits without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
PTC PTC PTC PTC PTC PTC PTC PTC
073G** 074G** 092G***BA* 093G*** 094G*** 123G** 153G*** 154G***
230/208 265 115 230 / 208 265 230/208 230 / 208 265
Capacity (BTU/h) 7700/7700 7,700 9,000 9,000 / 9,000 9,000 1200/11700 15,000 / 14,700 14,800
3.5/3.5 3.0 8.3 4.1 / 4.1 3.6 5.6/5.6 7.0 / 7.0 6.1
655/655 655 795 805 / 785 795 1150/1110 1,500 / 1,470 1,480
EER 11.7/11.7 11.7 11.3 11.2 / 11.5 11.3 10.4/10.5 10.0 / 10.0 10.0
Unit without Electric Heater
4.33.68.34.94.46.88.57.4
High 330 340 290 290 290 340 340 340
Low 245 245 264 264 264 245 314 314
High 360 370 310 310 310 370 360 360
Low 270 270 282 282 282 270 332 332
40* 65* 65** 65** 65** 40* 65** 65**
1.71.72.22.22.21.74.44.4
106 103 102 102 102 108 113 113
115 115 117 117 117 125 130 130
Model 1, 7, 9, 10
Voltage ¹, ³
Amps11
Watts11
Min. Circuit Amps 2, 5, 11
Ship Weight (lbs.)
CFM (Cool/Wet Coil)
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)**
Dehumidification (Pints/Hr.)
Net Weight (lbs.)

7
SPECIFICATIONS PTC G SERIES
COOLING - PTC
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
** Actual vent CFMperformance will vary due to application and installation conditions.
No t e s :
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² MinimumCircuit Ampacity (MCA) ratings conformto the National Electric Code; however, local codes should apply.
Minimumvoltage on 230/208-volt models is 197 volts; maximumis 253 volts.
3Minimumvoltage on 265-volt models is 239 volts; maximumis 292 volts.
4Minimumvoltage on 115-volt models is 104 volts; maximumis 127 volts.
6Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°Foutdoor
a
7Specify two-digit heater kWsize to complete modelnumber.
8R-410A refrigerant used in all systems.
9All units meet or exceed ASHRAE90.1 standards.
10 All units less than 250 volts have a LeakCurrent Detector Interrupter (LCDI) power cord and meet UL 484 standards.
11 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers tocompressor only.
5Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
PTC PTC PTC
073G**DA 093G***DA 123G**DA
230/208 230 / 208 230/208
Capacity (BTU/h) 7000/7000 9,200 / 9,000 11500/11400
3.1/3.1 4.1 / 4.1 5.0/5.0
580/560 790/765 1045/1015
EER 12/12.5 11.6 / 11.7 11.0/11.0
Unit without Electric Heater
3.7 5.0 6.2
High 330 290 340
Low 245 264 245
High 360 310 370
Low 270 282 270
40* 65** 40*
1.7 2.2 1.7
106 108 110
115 119 126
Model 1, 7, 9, 10
Voltage ¹, ³
Amps11
Watts11
Min. Circuit Amps 2, 5, 11
Ship Weight (lbs.)
CFM (Cool/Wet Coil)
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)**
Dehumidification (Pints/Hr.)
Net Weight (lbs.)

8
SPECIFICATIONS
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
** Actual vent CFMperformance will vary due to application and installation conditions.
No t e s :
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² MinimumCircuit Ampacity (MCA) ratings conformto the National Electric Code; however, local codes should apply.
Minimumvoltage on 230/208-volt models is 197 volts; maximumis 253 volts.
3Minimumvoltage on 265-volt models is 239 volts; maximumis 292 volts.
4Minimumvoltage on 115-volt models is 104 volts; maximumis 127 volts.
6Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°Foutdoor
a
7Specify two-digit heater kWsize to complete modelnumber.
8R-410A refrigerant used in all systems.
9All units meet or exceed ASHRAE90.1 standards.
10 All units less than 250 volts have a LeakCurrent Detector Interrupter (LCDI) power cord and meet UL 484 standards.
11 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers tocompressor only.
5Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
HEC HEC HEC
073H** 093H*** 123H**
230/208 230 / 208 230/208
Capacity (BTU/h) 7000/7000 9,200 / 9,000 11600/11400
3.5/3.5 4.5 / 4.5 5.4/5.4
555/535 770/750 1025/990
EER 12.6/13 11.9 / 12 11.3/11.5
Unit w ithout Electric Heater
4.2 5.4 6.6
High 330 290 340
Low 245 264 245
High 360 310 370
Low 270 282 270
40* 65** 40*
1.7 2.2 1.7
106 108 110
115 119 126
CFM (Cool/Wet Coil)
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)**
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
Model 1, 7, 9, 10
Voltage ¹, ³
Amps11
Watts11
Min. Circuit Amps 2, 5, 11
Ship Weight (lbs.)
COOLING - HEC HEC H SERIES

9
SPECIFICATIONS
HEAT PUMP - PTH
* Actual vent CFM performance w ill vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-w ire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; how ever, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation w ithout condensate pump; unit automatically sw itches to electric heat at approximately 24°Foutdoo
6Specify tw o-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) pow er cord and meet UL 484 standards.
10 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers to compressor only.
4Overcurrent protection for all units w ithout electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
PTH G SERIES
Model ¹, 6, 8, 9PTH
073G**
PTH
093G**
PTH
123G**
PTH
153G**
PTH
074G**
PTH
094G**
PTH
124G**
PTH
154G**
230 / 208 230 / 208 230/208 230 / 208 265 265 265 265
Capacity (BTU/h) 7600/7600 9,000 / 9,000 12,000 / 12,000 14,200 / 14,200 7,600 9,100 12,000 14,200
3.6/3.6 4.2 / 4.2 5.7/5.7 7.0 / 7.0 33.7 4.9 6.1
645/630 785 / 785 1,090 / 1,090 1,465 / 1,465 645 790 1090 1,465
EER 11.7/12.0 11.5 / 11.5 11.0/11.0 9.7 / 9.7 11.7 11.5 11 9.7
Unit without Electric Heater
5.4 5.1 6.9 8.5 3.6 4.5 6.0 7.4
High 330 330 330 390 330 330 390 390
Low 245 245 245 340 245 245 340 340
High 360 360 360 410 360 360 410 410
Low 270 270 270 370 270 270 370 370
40* 65* 65* 65* 65* 65* 65* 65*
1.7 2.2 2.2 4.4 2.2 2.2 4.4 4.4
111 112 123 126 108 112 124 125
131 127 141 143 123 127 142 142
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)*
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
Ship Weight (lbs.)
Voltage ¹, ³
Amps10
Watts10
Min. Circuit Amps ², 4, 10
CFM (Cool/Wet Coil)

10
SPECIFICATIONS
HEAT PUMP - HEH
EER - Energy Efficiency Ratio per The Air-
Conditioning, Heating, and Refrigeration
Institute (AHRI) Test Procedures and Canadian
Standards Association (CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
HEH H SERIES
HEH073H
**AXXX HEH093H **AXXX HEH123H **AXXX HEH074H **AXXX HEH094H **AXXX HEH124H **AXXX
230 / 208 230 / 208 230 / 208 265 265 265
7,700/7,700 9,000 / 9,000 12,000 / 12,000 7,700 9,100 12,000
4.1 / 4.1 4.7 / 4.7 6.2 / 6.2 3.6 4.2 5.4
595 / 595 720 / 720 1,040 / 1,040 595 730 1,040
12.9 / 12.9 12.5/12.5 11.5/11.5 12.9 12.4 11.5
5.4 5.4 5.4 3.6 3.6 3.6
High 340 330 340 340 330 340
Low 245 245 245 245 245 245
High 370 360 370 370 360 370
Low 270 270 270 270 270 270
65* 65* 65* 65* 65* 65*
1.7 2.2 3.6 1.7 2.2 3.6
107 111 114 107 111 114
122 126 131 122 126 131
*Actual vent CFM performancewill vary due to application and installation conditions.
Model ¹, 6, 8, 9
Voltage ¹, ³
Capacity (BTU/h)
Amps10
Watts10
EER
Net Weight (lbs.)
Ship Weight (lbs.)
Unit without Electric Heater
Min. Circuit Amps ², 4, 10
CFM (Cool/Wet Coil)
CFM(Dry Coil)
Ventilated Air, CFM (Fan Only)*
Dehumidification (Pints/Hr.)
Notes
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Mi nimum vol ta ge on 230/208-vol t model s is 197 vol ts; maxi mum i s 253 vol ts.
³ Minimumvoltage on 265-volt models is 239 volts;maximum is 292 volts.
⁴Overcurrent protecti on for al l units wi thout el ectri c hea ters is 15 amps.
Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses (included and factory-installed on all Amana® brand 265-volt chassis).
⁵Heati ng capa ci ty and effici ency based on uni t operation wi thout condensa te pump; uni t a utoma ti call y s wi tches to el ectri c heat at approximately 24°F outdoor ambient.
⁶Specify two-digit heater kW size to complete model number.
⁷R-410A refrigerant used in all systems.
⁸All units meet or exceed ASHRAE 90.1 standards.
⁹All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
¹⁰Refer to electri c heat performance da ta for tota l MCA and recommended overcurrent protecti on. Amps and Watts notati on refers to compressor only.

11
SPECIFICATIONS
HEAT PUMP HEATING DATA
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-w ire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; how ever, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation w ithout condensate pump; unit automatically sw itches to electric heat at approximately 24°F outdoor
6Specify tw o-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) pow er cord and meet UL 484 standards.
10 Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and Watts notation refers to compressor only.
4Overcurrent protection for all units w ithout electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater perform
PTH G SERIES
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
PTH
093G**
PTH
123G**
PTH
153G**
PTH
094G**
PTH
124G**
PTH
154G**
230 / 208 230/208 230 / 208 265 265 265
BTU/h58,300 / 8,100 12,000 /12,000 13,800 / 13,600 8,300 12,000 13,700
4.2 / 4.2 5.7 / 5.7 7.0 / 7.0 3.7 4.9 6.1
715 / 700 1090 / 1090 1350 / 1330 715 1090 1340
COP53.4 / 3.4 3.1 / 3.2 3.0 / 3.0 3.4 3.1 3.0
CFM (Dry) 360 360 410 360 410 410
COP= Coefficiency of Performance; per AHRI Test Procedures, units are rated for capacities and efficiencies.
Model
Voltage ¹, ³
Amps10
Watts10
Notes
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum branch circuit ampacity ratings conform to the National Electric Code; however, local codes should apply.
³ Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts. Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
⁴Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be
cartridge-style time-delay fuses (included and factory-installed on all Amana® brand 265-volt chassis).
5
Total watts for 15,000 BTU/h models; subtract 20 watts for HEH07/09/12
6
Speci fy two-digi t hea ter kW si ze to compl ete model number.
7
R-410A refrigerant used in all systems.
8
All units meet or exceed ASHRAE 90.1 standards.
9
All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
10
Refer to electri c heat performance data for total MCA and recommended overcurrent protecti on. Amps and Watts notation refers to compressor only.
EER - EnergyEfficiency RatioperTheAir-Conditioning,
Heating,and RefrigerationInstitute(AHRI) Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - Coefficient of PerformanceperAHRI Test
Procedures
Voltage
1, 3
230/208 230/208 230/208 265 265 265
BTU/h
5
6,800/6,800 8,300/8,100 11,500/11,300 6,800 8,300 11,400
Amps
10
4.1/4.1 4.7/4.7 6.2/6.2 3.6 4.2 5.4
Watts
10
600/600 735/715 1,085/1,065 600 735 1,075
COP
5
3.3/3.3 3.3/3.3 3.1/3.2 3.3 3.3 3.1
CFM (Dry) 360 370 370 360 370 370
HEH124H**AXXX
Heating Capacity
1
HEH073H**AXXX HEH093H**AXXX HEH123H**AXXX HEH074H**AXXX HEH094H**AXXX
HEH H SERIES

12
SPECIFICATIONS
ELECTRIC HEAT PERFORMANCE
PTH G SERIES
HEH H SERIES
PMH & PMC SERIES
EER - Energy Efficiency Ratio per The Air-
Conditioning,Heating, and Refrigeration
Institute(AHRI) Test Procedures and
CanadianStandards Association(CSA)
TestProcedures.
COP - Coefficientof PerformanceperAHRI
TestProcedures
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum branch circuit ampacity ratings conform to the National Electric Code; however, local codes should apply.
³ Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5
Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
7
Specify two-digit heater kW size to complete model number.
8
R-410A refrigerant used in all systems.
9
All units meet or exceed ASHRAE 90.1 standards.
10
All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
4
Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis).
6
Total watts for 15,000 BTU/h models; subtract 20 watts for PT07/09/12 & HEH07/09/12
@ 230V @ 208V @ 265V
230/208V 2.5 1 8,500 6,800 - - 2,545 / 2,090 11.2 / 10.2 14.1 15 6-15 P
230/208V 3.5 1 12,000 9,900 - - 3,545 / 2,905 15.6 / 14.1 19.5 20 6-20 P
230/208V 5 1 17,100 14,000 - - 5,045 / 4,130 22.0 / 20.0 27.6 30 6-30 P
265V 2.5 1 - - - - 8,500 2,550 9.6 12.0 15 7-20 P
265V 3.7 1 - - - - 12,600 3,750 14.2 17.7 20 7-20 P
265V 5 1 - - - - 17,100 5,050 19.1 23.8 25 7-30 P
Min. Circuit
Ampacity² MOD
4
(amps) Power CordVoltage Electric
Heater Size
(kW)
No. of
Stages
Nominal Heating (BTU/h) Total
Watts
6
Total
Amps

13
PROPER INSTALLATION
OPERATINGVOLTAGES
WARNING
USE EXTREME CAUTION WHEN CHECKING HIGH VOLTAGE.
Use a voltmeter, check the voltage at the outlet.
The reading must be within the minimums and maximums shown below for the operating voltage.
Unit Voltage
Rating Minimum Voltage Maximum Voltage
115 104 127
230/208 197 253
265 238 292
Operating Voltages
Voltage Utilization Range
•LCDI or AFCI Power Cords - Underwrites Laboratories and the National Electric Code (NEC) now require power cords that
sense current leakage and can open the electrical circuit to the unit on units rated at 250 volts or less. In the event that
unit does not operate, check the reset button located on or near the head of the power cord as part of the normal
troubleshooting procedure.
LCDI Power Cord

14
PROPER INSTALLATION
WALL SLEEVE INSTALLATION
The wall sleeve must be installed before the air conditioner
or heat pump chassis can be set in place. Read the instruc-
tions thoroughly before proceeding.
Pre-installation Considerations
Before proceeding with the sleeve installation, ensure
the following guidelines for locating the wall opening and
sleeve are met:
• The wall opening must be the correct size. See the
figures below for wall sleeve Dimensions and mini-
mum wall opening size.
161/16"
410mm
133/4"
350mm
Wall Receptacle Within 58"
From Bottom Right Side Corner
on 115 VAC and
208/230 VAC Units Only
Wall Sleeve Dimensions
Internal
Adjacent
Wall
Internal
A
djacent
Wall
Outside
Wall
Allow Front Clearance (See Table 1)
Minimum Unit Clearances
• The wall sleeve will need to be installed with mini-
mum clearances to the floor and adjacent walls. Mini-
mum projections of the sleeve into and out of the
room will also have to be met. See Minimum Unit
Clearances and Minimum Interior and Exterior Pro-
jections Figures as well as Minimum Clearances and
Projections table for details.
• If installed in a concrete or masonry wall, a lintel
must be provided in the wall opening for support. Do
not use the wall sleeve as a lintel. See Framing
with Lintel Figure for a typical lintel construction.
Framing with Lintel
• When installed in the opening, the wall sleeve must
be horizontally level from side to side and pitched
(one quarter bubble in the sight glass) to the out-
side. DO NOT INSTALL LEVEL (FRONT TO BACK) OR
SLOPE THE WALL SLEEVE TOWARD THE ROOM.
• The installer must determine and supply the mount-
ing bolts and/or screws to attach the wall sleeve to
the sides of the wall opening. Make sure the wall
opening is adequate for strong support.
• The installer must provide adequate sealing and in-
sulation around the sleeve after it is installed (air
and water tight). See Block and Brick Veneer Instal-
lation Figure for one of many types of constructions.
Steel
Lintel
Caulk Top,
Bottom, and
Both Sides
13 1/2" (340 mm)
Maximum
(No Accessories)
Block and Brick Veneer Installation

15
PROPER INSTALLATION
Minimum Interior and Exterior Projections
in. mm in. mm in. mm
Wall Sleeve Only 3 75 0 0 0 0
Subbase Kit 3 75 3 1/4 85 2 3/4 70
Leveling Legs Kit 3 75 3 75 2 50
Duct Kit 3 75 0 0 1 3/8 35
Drain Kit 3 75 010100
Hard Wire Kit 3 75 1 1/4 30 0 0
Hydronic Heat Kit
"A" Series 9 230 0 to 3 1/430 to 85332 752
Hydronic Heat Kit
"J" Series 6 150 0 0 2 1/2 65
Option
MINIMUM CLEARANCES AND PROJECTIONS
ABC
Minimum
Clearances
Minimum
Projection
1If inside mounted then B = 1 1/2 inches (40 mm).
2To achieve a flush fit between the hydronic front and the finished wall,
Dimension “C” must be between 3” and 3 1/8”. If this dimension is
more than 3 1/8” there will be a gap between the front and the wall.
This gap could permit occupant access to hydronic lines or other danger-
ous parts.
3This dimension can be from 0” to 3-1/4”, but cannot exceed 3-1/4”.
If this dimension exceeds 3-1/4”, the skirt around the front will not
reach the floor.
• For installations in walls deeper than 13-1/2 inches,
special care is necessary to prevent problems with
rain water, condensate drainage and intake/discharge
air. Under these circumstances, careful job site analy-
sis and precautions are required. You must consult
with your Sales Representative and receive approval
before attempting such installations.
• If used, a 115 volt or 230/208 volt wall receptacle
must be located within 58 inches of the lower right
sleeve corner. Extension cords must not be used with
the unit. See the note on Wall Sleeve Dimensions Fig-
ure.
421/4"
1075mm
Minimum
161/4"
415mm
Minimum
Dimension "B"
in Table 1
Minimum Wall Opening Dimensions
When 115 volt or 230/208 volt units are to be installed,
the power supply may be either cord connected or per-
manent wiring. Permanent wiring may be done through
the accessory hard wire junction box, or the accessory
subbase.
When 265 volt units are to be installed, the power supply
must be permanent wiring. Permanent wiring may be done
through the accessory hard wire junction box, or the ac-
cessory subbase. An exposed cord connection on 265
volt units is not permitted.
The subbase accessory includes leveling legs. If added
wall sleeve support is required and the subbase is not to
be used as an accessory, leveling leg kit may be installed.
Drain Kit
An indoor/outdoor drain kit is available as an accessory
item. When a drain kit is to be installed, do so before in-
stalling the wall sleeve in the wall. See the drain kit for
actual installation instructions.
Subbase, Leveling Legs, Main Duct, and Hydronic Heat
Kits
Installation of these kits requires drilling of mounting holes
on both sides of the wall sleeve. The minimum required
clearancedistance betweenthe wallsleeveandwallis shown
in Minimum Clearances and Projections Table. If the dis-
tance between wall sleeve and wall will be at or near the
minimumclearance distance, mountthese kitsonthe sleeve
before installing the sleeve in the wall. The kit installation
instructions are included with the accessory kits.

16
161/16"
410mm
133/4"
350mm
Wall Receptacle Within 58"
From Bottom Right Side Corner
on 115 VAC and
208/230 VAC Units Only
Wall Sleeve Dimensions
Outside Enclosure Panel Removal
The sleeve stiffener must be taken out before the enclo-
sure panel can be removed from the sleeve.
The enclosure panel can be removed by folding the four
flaps up and downward and manipulating the front ends of
the top plus bottom towards the center. The entire panel
can be pulled out diagonally from one side.
Installthe wallsleeve condenserair grillebyusingthescrews
and holes provided.
Installation (WS900B or WS900D)
After the wall opening is checked and approved for loca-
tion, size, and clearances, complete the following to install
the wall sleeve.
NOTE: Check with Amana®Brand Technical Service when a
chassis is installed in any wall sleeve not supplied by
Goodman.
1. Removethe outsideenclosurepanelfromthewallsleeve.
2. Slide the wall sleeve into the wall opening. Do not dis-
tort the cabinet shape to fit the wall opening. The unit
chassis must fit snugly and uniformly into the wall
sleeve.
3. Locate the sleeve within the range of minimum projec-
tions, as shown in Minimum Wall Opening Dimensions
and Minimum Interior and Exterior Projections Figures,
so both sides are at least the minimum projection from
thewall.
4. Check the level of the wall sleeve. For proper drainage,
the sleeve should be level from side to side and one-
quarter bubble in the sight glass sloping to the outside.
5. Two holes will need to be drilled in both sides of the
wall sleeve for mounting into the wall. Drill holes of
proper size and in the proper location so the screws will
engage into strong supporting members of the wall. DO
NOT DRILL THROUGH BOTTOM OF SLEEVE. The fol-
lowing figure shows possible fastening methods.
Plastic
Anchor
Expansion
Anchor Bolt
Attaching Wall Sleeve to Opening
6. Check the level of the wall sleeve and adjust if neces-
sary.
7. Caulk or seal around the outside of the entire sleeve.
8. If the unit chassis will not be installed immediately,
replace the enclosure panel on the outside opening of
the sleeve. This will prevent weather damage to the
building interior.
9. Recycle or dispose of packaging materials per local
codes.
OUTDOOR GRILLE
Anoutside grillemustbeinstalledto directair flowforproper
unit operation and also protect the outdoor coil. The grille
must be installed before installing the chassis. Refer to the
Installation Instructions supplied with the outdoor grille kit
for a complete description of the installation procedure.
This model requires either a Stamped Grille Kit (Model SGK-
-B) or an Architectural Grille Kit (Model AGK--B). When re-
placing an old chassis with an existing grille, please check
withyoursales representativetodetermine if thenew chas-
sis should be used with the old outdoor grille. An improper
outdoor grille can decrease cooling or heating capacity, in-
crease energy usage and shorten compressor life.
FRONT REMOVAL
1. Grasp the cabinet front as shown.
2. Pullthe bottomofthe cabinetfront away fromthe chas-
sis until the retaining clips disengage.
PROPER INSTALLATION

17
3. Lift the cabinet front off the chassis. Reverse this pro-
cedure to reinstall the cabinet front.
CHASSIS INSTALLATION
1. Remove the cabinet front from the chassis as described
in Front Removal.
2. Insert the chassis into the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
Slide Chassis In
3. Slide the chassis into the wall sleeve until the chassis
flanges contact the front edge of the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
4. Secure the chassis to the wall sleeve using three screws
on each side of the chassis to ensure a proper seal be-
tween the chassis and the wall sleeve. The screws are
supplied in a plastic bag which is attached to the power
cord.
IMPORTANT NOTES:
1. The unit is equipped with a rubber grommet mounted
compressor. These grommets are factory set and re-
quire no adjustment.
2. If a standard subbase is used, be sure the right hand
subbase cover is removed before the chassis is installed
in the sleeve.
3. On 230V, 30A units installed with an existing subbase,
use the subbase cover extension kit.
4. Check the indoor and outdoor grilles for obstructions to
air flow. The unit must be located where curtains, fur-
niture, trees, shrubs or other objects do not block the
air flow to and from the unit. If air is obstructed and/or
deflected back into the unit, the air conditioner’s com-
pressor may cycle on and off rapidly. This could dam-
age the compressor and void the warranty.
Front Mounting Holes - Two mounting holes are provided to
give the owner the option of securing the front to the chas-
sis. The mounting holes are located behind the intake grille.
The owner must supply two 1/2 inch long #8 sheet metal
screws per unit. The two screws must be removed before
the front can be removed.
Front Mounting Screw
accessed
through louvers.
Front Mounting Screws
PROPER INSTALLATION

18
SPECIFICATIONS
WIRING Cord connection to a wall socket is not permitted for 265-
volt units. All 265-volt units must be hard wired using the
hard wire kit or make use of the plug-in receptacle in the
standard subbase.
Heaterless Units
Ifaheaterless unit isordered, field provisionsmust be made
for supplemental heat if desired. All 208/230 volt heater-
less units are shipped with a 15 Amp power cord and all
heaterless 265 volt units are shipped with a 20 Amp power
cord.
OPERATING CONTROLS
Users Controls
A 7 button touch key pad, located behind the control door,
controls both temperature and operation mode. The key
pads can be used alone or in combination.
Mode
Switches
Master Switch
The master switch disconnects power to all of the system
components. When this switch is in the off position, the
compressor, fan motor, reversing valve, and electric resis-
tance heater will all be de-energized.
REMOTE/STANDARD
The remote/standard configuration is used to change the
control of the unit from the standard on board controls in
the standard mode, to a remote wall mounted thermostat
in the remote mode. For remote control configuration set-
tings, refer to Configuration Settings.
Fan Cycle Configuration
The fan cycle configuration sets the operational mode of
the fan. In the ON position, the fan will run continuously
whenever the unit is in the heat or cool mode. In the AU
position, the fan will cycle on and off with the compressor
or electric heater when the unit is in the cool or heat mode.
PROPER INSTALLATION

19
PROPER INSTALLATION
Remote Control Inputs
The C, R, G, (GL for low fan speed or GH for high speed fan
on W2, Y/W1 and B terminals provide control inputs for a
remote wall mounted thermostat. See following illustra-
tion.
IN1 COM IN2
AUXILIARY
CRGLW2
Y/W1 B GH
REMOTE THERMOSTAT
Control Board
Connections
Thermostat Connections
R
G*
W2
W1
Y
C
*NOTE: For high speed fan operation, connect “G” to “GH”.
IMPORTANT NOTE: Disconnect power to the unit and/or
turn the Master Switch on the control board to OFF when
connecting or altering wiring to any terminal. Failure to do
so may result in shorting the fuse or damaging the control
board.
Front Desk Control (IN1, IN2, COM)
The COM and (IN2 or IN1) terminals provide control inputs
for a front desk switch. Shorting across the terminals will
disable unit operation. The only control function which will
remain active when these terminals are shorted is freeze
protection. Any switch which will produce a short circuit
across these two terminals can be used as a front desk
switch. The contact resistance of the switch, when closed,
must be less than 200 ohms for the front desk feature to
operate properly. Table 3 shows the maximum wire length
and corresponding gage size for installation of a front desk
switch. The following figure shows a wiring schematic for
connecting the front desk switch to the unit.
If the unit is configured for wired unrented setback energy
management(see Configuration Settings sectionu8 andu9).
If IN* and COM are shorted, the unit will go into setback
temperatures for cooling and heating as configured in c3
and c4 (see Configuration Settings). Unit operation will be
disabled. “Fd” (see Diagnostic Codes) will appear on the
display. This allows the room to quickly recover to a com-
fortable temperature when the room is occupied.
Wire Size
(AWG)
Maximum
Length Allowed
(ft)
#24 400
#22 600
#20 900
#18 1500
#16 2000
MAXIMUM WIRE LENGTH
FOR FRONT DESK SWITCH
The following figure shows a wiring schematic for connect-
ing the front desk switch to the unit.
IN1 COM IN2
AUXILIARY
CRGL
W2 Y/W1 B GH
REMOTE THERMOSTAT
IAT
BLACK
FRONT
DESK
SWITCH
Front Desk Switch Wiring Schematic
IMPORTANT NOTE: Do not apply 24VAC across these ter-
minals. Applying 24VAC to these terminals will result in fail-
ure of the control board. Shorting these terminals to any
other terminals may also result in control board failure.
Temperature Limiter
The temperature limiting feature can reduce energy costs
by controlling the maximum temperature available in heat-
ingand theminimum temperatureavailable incooling. While
approximate temperature settings are shown below, actual
room temperature will vary slightly.

20
PROPER INSTALLATION
Users Controls "Digital Touch Pad"
A seven button touch key pad located behind the control
door controls both temperature and operation mode. The
key pads can be used alone or in combination.
Touch Pad With Display User Controls
ThermostatSetting
7 BUTTON TOUCH PAD WITH DISPLAY
Pressing the COOL thermostat control and the up or down
arrowswill providea coolerroom temperature,respectively.
Pressing the HEAT thermostat control and the up or down
arrow keys will provide a warmer room temperature.
Fan Speed
The fan speed touch key will deliver high, low or auto fan
speed to circulate room air. NOTE: The AUTO selection will
not be available if a fan speed is selected without COOL or
Heat selection.
Fan Operation HIGH or LOW with HEAT or COOL mode se-
lected - The selected fan speed shall run in the selected
speed.
Fan Operation AUTO with HEAT or COOL mode selected -
The fan will run in low and high speed. The changes in fan
speed are automatic. See "Configuration Settings" section
for further details.
Diagnostic Light
The green diagnostic light located in the lower left hand
corner of the touchpad and indicates operation warnings.
Thislightusually indicatesthateither thefilter or coilsneed
cleaning. Please refer to the Maintenance and Cleaning
section for the proper cleaning procedure. If this light is
still on after cleaning, please refer to the Diagnostic & Sta-
tus Report section for assistance.
ON OFF
MASTER SWITCH
IN1 COM IN2
A
UXILIARY
CRGLW2
Y/W1 B GH
REMOTE THERMOSTAT
IAT
BLACK
Control Board User Inputs*
*NOTE: The PTAC Wire Harness Kit (PWHK01G70) is
required for the auxiliary or remote thermostat options.
Additional Control Inputs
The control inputs provide additional unit control and fea-
tures. To access these control inputs, the cabinet front
must be removed (see Front Removal).
Master Switch
The master switch disconnects power to all of the system
components. When this switch is in the off position, the
compressor, fan motor, reversing valve, and electric resis-
tance heater will all be de-energized.
Remote Control Inputs
The C, R, GL, W2, Y/W1, B/O, and GH terminals provide
control inputs for a “manufacturer-approved” remote wall
mounted thermostat. The “B” terminal can be configured
to become “O” if needed see Configuration Settings For
remote control thermostat operation, refer to the Remote
Thermostat Operation section.
Vent Control
NOTE: Vent control is only used on units with the power
vent or power vent door kit not installed.
The vent control allows fresh air to be drawn into the condi-
tioned area. This fresh air can provide ventilation when the
blower is operating, but it will increase the heating or cool-
ing load and operating costs.
