Amana ACF3315A User manual

Getting Ready
1. Remove storage drawer and verify that the anti tip bracket has been
installed and is engaged. Refer to Installation Instructions for details.
2. Read important safety instructions in Owner’s Manual.
3. Burner caps and grates must be placed correctly. Burner caps should match
the size of the burner base. Once caps are placed, grate needs to be placed
over the burners. Refer to Adjusting Burner Flame section in the Owner’s
Manual.
4. Remove all hanging tags and papers from the range. Check the inside oven
cavity for paper. Remove any residue with non abrasive cleanser. Do not
store paper in range, oven or storage drawer, or around range. For more
information, refer to Care and Cleaning section in the Owner’s Manual.
Operating Your New Range
It is normal for all four burner electrodes to spark when one
burner is turned on.
Burners should ignite within 4 seconds. If not, refer to
Adjusting Burner Flame section in Owner’s Manual.
Oven may make noise during a heating or cooling cycle,
especially during a self-clean. This is normal. It is the sound of the oven cavity
expanding and contracting.
Do not allow flames to extend up the sides of the cooking utensil. This may
cause burns or damage.
Oven may generate smoke the first few times operated, especially during a self-
clean cycle. This is normal. If possible, ventilate odors.
Remove birds and animals from area when using the self-clean cycle. Refer
to Self-cleaning section in the Owner’s Manual for more information.
Surface burners should not be used during a self-clean cycle. A self-clean cycle
can be set for times when the oven is not in use. Refer to Self-cleaning section in
the Owner’s Manual for more information.
Setting the
Clock
To set the clock, press
Recall Clock pad. The light above the
button will glow, indicating the clock
can be adjusted. Use the arrow keys to
set the clock to the correct time of day.
The clock is a twelve hour clock and
does not display AM, PM, or military
time. To set time, press RECALL
CLOCK pad again open.
Using the
Minute Timer
The minute timer is a timer only, and
does not control baking, broiling or
cleaning functions of the oven. To set
timer, press TIMER ON/OFF. The light
above the button will glow, indicating
the timer can be set. Use arrow keys
to set the timer. Timer can be set up to
11 hours and 59 minutes. Timer begins
after 5 seconds of no further time
adjustment. To cancel the timer, press
and hold the TIMER ON/OFF pad for
five seconds. Timer signals once at the
end of the countdown.
Questions?
Refer to Owners Manual or
call Amana Consumer Affairs Department
1-800-843-0304
¸
:
Quick Start Reference Guide
Refer to Installation Instructions and Owners Manual for safety statements.
Covering Amana®Distinctions ACF3315A
and The Big Oven ACF3335A

Bake
To bake in your new oven:
1. Arrange racks to desired position.
2. Push and turn temperature knob. Temperature will be displayed in clock area.
• Display reverts to time of day. Press RECALL OVEN TEMP/CLOCK pad to
view cooking temperature.
3. Preheat light will glow during preheat cycle. Once oven has reached selected
temperature, a signal will sound and preheat light will shut off.
4. To shut off oven, turn temperature knob to OFF position.
Timed Bake
To set the oven to perform a timed bake:
1. Arrange racks to desired position.
2. Press COOK/CLEAN TIME pad.
3. Use arrow keys to enter the selected amount of time.
4. Push and turn the oven temperature control knob to desired temperature.
• Temperature will be displayed in clock area.
5. Oven will begin to heat.
6. When cooking time has elapsed, END displays and a signal will sound four times
and then once approximately every 10 seconds until oven temperature knob is
turned to OFF.
Delayed Bake
NOTE: Do not use delayed bake with any dairy, meat, or egg products:
1. Arrange racks to desired position.
2. Press START COOK/CLEAN pad.
3. Use arrow keys to select the time of day to begin cooking.
4. Press COOK/CLEAN TIME pad.
5. Use the arrow keys to enter the desired amount of time.
6. Push and turn the oven temperature control knob to desired temperature.
Temperature will be displayed in clock area.
7. Oven will begin to heat at selected start time.
8. When cooking time has elapsed, END displays and a signal will sound four times
and then once approximately every 10 seconds until oven temperature knob is
turned to OFF.
Self-Clean
To set a self-clean cycle in your
oven:
1. Prepare the oven and surrounding
area for self-clean (refer to Self-clean
section in Owner’s Manual).
2. Remove all animals from area and, if
possible, open a window the first few
self-clean cycles.
3. Remove all pans, broiler pans, oven
racks and accessories from inside
oven, rangetop, backguard and
storage drawer.
4. Push and turn oven control knob to
CLEAN. CLN will display.
5. Default cycle time of 3 hours will
display. Cycle can be set from 2 to 4
hours by adjusting time with arrow
buttons.
6. Self-clean will begin. Oven door will
automatically lock during the cycle.
•Surface burners SHOULD NOT
be used during a self-clean cycle.
7. When complete, oven will beep and
LOCKED light will shut off. Oven may
still be warm to touch. DO NOT force
oven door open. Wait for the LOCKED
light to turn off to open door.
Broil
NOTE: Oven door MUST be closed during broiling.
1. Arrange racks to desired position.
2. Place food in oven. Preheating is not required.
3. Close door.
4. Push and turn temperature knob to BROIL.
5. BRL will display in clock area.
6. When finished cooking, turn temperature knob to OFF position.
 2000 Amana Appliances
Amana, Iowa 52204
Part No.36-32033801-0
Printed in U.S.A.11/00
Amana Appliances Online • http://www.amana.com
B
Your oven temperatures are factory
set for the best performance. However,
to provide the flexibility to change
these settings, a temperature
adjustment feature has been added
for your convenience. Refer to your
Owner’s Manual for instructions.
Quick Start Reference Guide
