Amana A4TCNWFB User instructions

90˚
F
Top Mount Refrigerator
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
LOCATION REQUIREMENTS
A4TCNWFB
A8TCNWFA
Electrical: A 115-volt, 60-Hz, AC-
only, 15- or 20-amp fused, grounded
electrical supply is required. It is
recommended that a separate circuit
serving only your refrigerator be
provided. Use an outlet that cannot be
turned off by a switch. Do not use an
extension cord.
Water: A cold water supply with
water pressure between 30 and
120 psi (207 and 827 kPa) is required
to operate ice maker and water
dispenser. If you have questions about
your water pressure, call a licensed,
qualified plumber.
IMPORTANT: The pressure of the
water coming out of a reverse
osmosis system going to the water
inlet valve of the refrigerator needs to
be between 30 and 120 psi (207 and
827 kPa).
Reverse Osmosis Water Supply: If a
reverse osmosis water filtration
system is connected to your cold
water supply, the water pressure to
the reverse osmosis system needs to
be a minimum of 40 to 60 psi (276 to
414 kPa).
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. W10214129A
1/31/13
1 / 2" (1.25 cm)
2" (5.08 cm)
" (7.5 cm)
3
To ensure proper ventilation for your refrigerator, allow for a 1⁄2" (1.25 cm) space on
each side. Allow 3" (7.5 cm) of space between overhead cabinets and refrigerator
top. Allow at least 1" (25.40 mm) between back of cabinet and the wall. If your
refrigerator has an ice maker, make sure you leave some extra space at the back for
the water line connections.
If you are installing your refrigerator next to a fixed wall, leave 2" (5.08 cm)
minimum on the hinge side (depending on your model) to allow for the door to
swing open.
NOTE: It is recommended that you do not install the refrigerator near an oven,
radiator, or other heat source, nor in a location where the temperature will fall below
55°F (13°C).
Model
Number Cubic Ft. Depth “A” Cab. Width “B” Door Width “C” Cab. Height “D”
Overall
Height
“E”
Depth Door
Open 90°
“F”
A4TCNWFB 14.4 29³⁄₄"
(75.6 cm)
28"
(71.1 cm) 28" (71.1 cm) 621⁄8" (157.8 cm) 62³⁄₄"
(159.4 cm)
57"
(144.8 cm)
A8TCNWFA 17.6 311⁄8"
(79.1 cm) 28" (71.1 cm) 28" (71.1 cm) 673⁄8" (171.0 cm) 677⁄8" (172.4 cm) 57" (144.8 cm)
E
overall
D
top of
cabinet
B
A
C
