CABINET PARTS
1
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
9−07 Litho In U.S.A. (cjj) Part No. W10164063 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10164064 Tech Sheet
W10164066 Use & Care Guide
W10164065 Tag, Energy
2 67006317 Tube, w/waterline
(fill IM)
3 67003405 Block, Pivot
4 B5759649 Gasket, MC Back
5 67005127 Roller
6 Cover, Fill Tube
67006320 Black
67006321 White
7 67006427 Cover, Control Box
8 M0108105 Clamp, Tube
9 67006521 Screw, Hinge Cover
10 12456801 Bracket, Roller
11 67006380 Screw, Center
Hinge
12 67006611 Bolt, Roller Adj.
13 Cover, Top Hinge
(Left)
67005951 Black
67005952 Bisque
67005953 White
14 67006303 Screw, Top Hinge
15 Hinge, Center (RT)
67006379 White
67006443 Black
16 67006390 Box, HV Control
17 Cover, Corner
67003484 White
67003485 Black
67003486 Bisque
18 67005950 Hinge, Top Left
19 67007174 Bracket, Foot
Cabinet (2)
20 67006564 Screw (8)
21 Shim, Top Hinge
67006308 Left
67006309 Right
22 Grille, Toe
67006375 Black
67006376 Bisque
67006377 White
23 67006428 Lid, HV Control
24 Hinge, Center (LT)
67006277 White
67006442 Black
25 67006425 Screw, Cover
26 67002227 Roller Bracket
27 67006426 Cover, Water Valve
28 67006626 Screw, Block
29 67006429 Gasket, HV Control
30 67006101 Cover,MC Back
31 M0286708 Nut, Speed
32 M1205302 Rivet
33 67003796 Fiber, Acoustic
34 67003868 Brake, Foot
35
W10162662 Board, HV Control
36 67001066 Tube, Drain
37 67001067 Clip, Drain Tube
38 Cabinet (Not a
Servicable Part)
39 67005955 Hinge, Top Right
40 Cover, Top Hinge
(Right)
67005956 Black
67005957 Bisque
67005958 White

REFRIGERATOR LINER PARTS
3
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

REFRIGERATOR LINER PARTS
4
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67006328 Module, Light
3 67006326 Foil, Light
4 67006327 Cover, Light
5 67006316 Grille, Air
6 12466103 Switch, Light
7 67006318 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light
10
Y12570701 Socket, Light
11 67006330 Cover, Water Tank
(Upper)
12 67006331 Lid, Water Filter
13 67006329 Cover, Water Tank
(Lower)
14
UKF8001AXX Filter, Water
15 67006325 Bracket, Filter
Base
16 12002355 Thermister
17 67006324 Bracket, Water
Tank & Valve
18 12956202 Water Tank &
Head Assembly
19 12664501 Plug, Bypass
20 67006322 Valve, Water Inlet
21 67006350 Cover, Ice Box
Harness
22 M0238642 Screw
23 67006319 Cover, Chiller
Vent
24 12962204 Waterline
25
W10118193 Enclosure, Valve
26
W10118194 Lid, Enclosure

SHELF PARTS
5
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

SHELF PARTS
6
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION
1 67002761 Glass, Pantry
2 67006287 Screw
3 67006412 Shelf, Mini
(Stationary)
4 67006010 Support, Pantry(2)
5 67002330 Brace, Pantry (2)
6 67001719 Track, Pantry
7 10423131 Bin, Utility
8 10436404 Lid, Utility
9 67002329 Gasket, Pantry
10 67005625 Housing, Control
11 67006411 Shelf, Glide (3)
12 67003793 Slide, Temperature
13 10436506 Tray, Egg
14 67007026 Glide, Drawer (2)
15 67006400 Screw
16 Track, Pantry
67005863 Left
67005858 Right
17 67005915 Pan, Crisper (2)
18 67002748 Support, Crisper
Cover
19 67004636 Trim, Crisper
20 67003854 Frame, Crisper
21 67006704 Glass, Crisper
Cover
22 67006358 Ladder, Center
23 67006354 Ladder, Side
24 67006400 Screw
25 67006360 Screw
26 67006415 Screw
27
Y67001287 Slide, Humidity
Control
28 67003795 Rod, Temperature
Control
29 67003531 Drawer, Pantry
30 67003791 Knob, Temperature
Control
31 67005900 Door,
Pantry Drawer
32 67004514 Support, Center
Crisper Frame
33 12603701 Stud,
Crisper Frame
34 67002759 Divider,
Pantry Drawer

MOTOR AND ICE CONTAINER PARTS
7
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

MOTOR AND ICE CONTAINER PARTS
8
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION
1 W10149456 Icemaker (Includes
Fill Tube Cup,
Wire Harness &
Sensor Arm
2 67006334 Impinger Assembly
3 67006335 Shroud, Ice
Box Fan
4
W10162697 Motor, Fan
5 67006337 Blade, Fan
6 67006338 Clip, Fan Motor
7 67006339 Grommet, Fan Motor
8
W10162707 Divider, Ice Box
9 67006341 Gasket, Damper
10 67006342 Motor, Auger
11
W10127427 Damper, Control
12 67006344 Solenoid
13 67007110 Screw, Impinger
14 67006425 Screw (3)
15 67007111 Bracket, Solenoid
16 67006346 Washer
17 63052−1 Yoke, Ice
Dispenser
18 67006347 Yoke, Solenoid
19 67006348 Spring, Solenoid
20 67006349 Ice Bin Assembly
(Includes Auger)

FREEZER LINER PARTS
9
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

FREEZER LINER PARTS
10
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 12002355 Thermistor Kit
3 67004430 Gear (Left)
4 67003924 Cover, Thermistor
5 67004017 Shaft, Rack
6
Y12570701 Socket, Light
7 67004429 Gear, (Right)
8 67006473 Screw, Bracket
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67006383 Cover, Evap
12 67006425 Screw
13 Bracket, Door
Slide
W10122147 Left
W10122148 Right
14 67006423 Module, Freezer
Light
15 67006338 Clip, Fan Motor
16 67006422 Switch, Rocker
17 67006287 Screw, Fan Shroud
18 67006769 Screw, Slide
To Basket
19
W10120018 Slide, Drawer (2)
20 67003731 Gasket, Foam
21 Adapter
W10120017 Left
W10120083 Right
22 67006382 Grille, Air
23 67006424 Shroud, Evap Fan
24 67006337 Blade, Fan
(Evaporator)
25 67006339 Grommet, Fan
Motor (2)
26
W10162809 Motor, Evaporator
Fan
27 D7753903 Funnel, Drain
28 M0500703 Seal, O Ring
29 B8381501 Gasket,
Drain Tube
30 67006406 Screw, Adapter

REFRIGERATOR DOOR PARTS
11
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

REFRIGERATOR DOOR PARTS
12
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Door, Left
67007124 White
67007078 Black
67007101 Bisque
W10162823 Stainless Steel
2 67006311 Dispenser, Can
3 67003819 Door, Dairy
4 67001279 Tray, Dairy
5 67006313 Bucket, Chiller
6 67006626 Screw
7 Screw, Handle
12992902 White, Black And
Bisque Models
8 Gasket, Door
W10162893 White
W10162891 Black
9 Door Handle
(Right Door)
W10119663 White
W10119665 Black
W10119664 Bisque
(Left Door)
W10119666 White
W10119668 Black
W10119667 Bisque
10 67006113 Mount, Handle
11 12962106 Waterline, Door
12 67006404 Bin, Shelf
(Large)
13 12665101 Seal, Ice Chute
14 Mullion, Door
67006402 White
67006401 Black
W10159432 Bisque
15 67006315 Frame, Chiller
(Rear)
16 Closure, Door
67003638 White
67003639 Black
17 Stop, Door
12968202W White
67007011 Black
12968202Q Bisque
18 67006314 Frame, Chiller
(Front)
19 67005954 Bushing, Door
(Left Door)
20 67006312 Door, Chiller
21 67006287 Screw
22 12528501 Nameplate
23 Door, Right
67007125 White
67007077 Black
67007100 Bisque
W10162843 Stainless Steel
24 Door Handle
(Right Door)
W10136873 Stainless Steel
24 Door Handle
(Left Door)
W10136873 Stainless Steel
25 67002935 Screw Handle
Stainless model

DISPENSER FRONT PARTS
13
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 Dispenser Keyboard
67006957 White
67006955 Black
67006956 Bisque
3 67006294 Board, L.V.
4 Sump, Dispenser
67006394 White
67006399 Black
67006440 Bisque
5 Chute, Ext/Yoke
(Includes Switch)
67006298 White
Y67006296 Black
67006297 Bisque
6 67006303 Screw (4)
7 67006295 Ring, Target
8 Facade, Dispenser
67006396 White
67006395 Black
W10164155 Bisque
9 M0108106 Clamp, Tube

FREEZER DOOR PARTS
14
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Freezer Door
W10164158 White
W10164157 Black
W10164156 Bisque
67006144 Stainless Steel
2 Handle
W10119669 White
W10119671 Black
W10119670 Bisque
67007070 Stainless Steel
3 67006408 Screw
4 Gasket, Door
W10162897 White
W10162895 Black
5 Screw, Handle
12992902 White, Black And
Bisque Models
67002935 Stainless Model
6 67006366 Bin, Lower
7 67006370 Adapter, Bin
(Outer)
8
W10164154 Bin, Upper
9 67006113 Stud, Handle
(Stainless Model)
10
W10163002 Adapter, Bin
(Inner)
11 67006372 Bracket/Glide
Assembly
12 67006369 Glide, Upper
13 Retainer, Glide
67006368 Right
67006367 Left
14 Bracket, Door
Slide
W10122147 Left
W10122148 Right

UNIT PARTS
15
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063

UNIT PARTS
16
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67005889 Base
4 67006425 Screw
5 67004954 Screw
6 67006737 Screw, Clip
7
W10119239 Harness, Evap
Heater
8 67007175 Pan, Drain
9 61004743 Grommet
10
W10162932 Evaporator Heater
11 Capacitor
67005562 Production
1118576 Service
12 Overload
67005561 Production
(Includes Relay)
2159596 Service
13 61003210 Seal, Condenser
Shroud
14 67006387 Thermostat,
Defrost
15 67005680 Grommet (7)
16 12820504 Pad, Acoustic
17 67007052 Clip, Capacitor
18 67006131 Condenser
19 2183454 Relay
(Service Only)
20 67002490 Tray, Drip
21 67007110 Screw
22
W10162998 Evaporator
23 Support−EV
W10162951 Right Side
W10162962 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060201 Harness, Unit
27 Drier
B2150504 Production
4387019 Service
28 8201555 Compressor
(Includes Items
11, 12, 17, 19,
27 & 35)
29
W10162963 Shroud
30 67004953 Bracket, Fan Motor
31 10547003 Clip, Drier
32 Grommet (4)
67003493 Production
4387558 Service
33 10623002 Clip, Evaporator
34 67006432 Screw
35 67006573 Screw
36 67004700 Tube, Discharge
37 67005149 Roller (2)
38 67006434 Axle
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)

OPTIONAL PARTS (NOT INCLUDED)
17
For Models: AFI2538AEW12, AFI2538AEB12, AFI2538AEQ12, AFI2538AES12
(White) (Black) (Bisque) (Stainless Steel)
W10164063
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−up kit
(Black)
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
Refinishing Material
799340 Enamel, Black
(1 Qt. Uncut)
799344 Enamel, White
(1 Qt. Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
876370 Kit, Insulation
(2 Pcs. x 3" x 24"
X 48")
876305 Kit, Insulation
(14 Pcs. x 3"
x 24" x 48")
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
X 2−5/8)
876029 Kit, Foam Slab
(30" x 32−1/2"
x 1−1/2")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
20000008 Cleaner,
Stainelss Steel
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
833938 Kit, Terminal
Connector
67006349 Ice Container
Assembly
20000008 Cleaner,Stainless
Steel Magic
TORX SCREW WRENCH
1117510 Torx Key
