Amana Bottom Freezer Refrigerator User manual

English........................................................................ 2
Dansk ....................................................................... 15
Deutsch .................................................................... 28
Åëëçíéêá ................................................................ 41
Españo ..................................................................... 54
Français.................................................................... 67
Italiano ...................................................................... 80
Nederlands ............................................................... 93
Norsk ...................................................................... 106
Português ................................................................119
Suomi ..................................................................... 132
Svenska .................................................................. 145
International
Bottom Freezer
Refrigerator
Owner's Manual
Keeptheseinstructionsforfuturereference.Besurethis
manalstays with refrigerator.

2
Electrical Requirements
Recognize this symbol as a safety
precaution.
WARNING
Refrigeratoris designed to operateona
separate 230 volt, 50 hertz., 10A circuit.
!
!
Contents
ElectricalRequirements .............................................. 2
InstallationInstructions................................................ 3
ModelIdentification ..................................................... 2
CutoutDimensions...................................................... 3
InstallationChecklist ................................................... 5
Controls
FreshFood andDeepfreeze®Controls...................... 6
Setting Controls ....................................................... 6
FreshFood Features
Spillsaver™Shelves .................................................. 6
Deli Port™................................................................ 7
Drawers ................................................................... 7
CrisperTote™........................................................... 7
CoveredStorageBucket .......................................... 8
DairyCenters........................................................... 8
DoorBuckets........................................................... 8
DoorShelf ................................................................ 8
AdjustableDividers .................................................. 9
TallPackage Retainer .............................................. 9
Deepfreeze®Features
Deepfreeze®Shelf .................................................... 9
Wire Basket............................................................. 9
WireDivider ............................................................. 9
PivotBin™................................................................ 9
CareandCleaning
General .................................................................. 10
OdorRemoval ........................................................ 10
Adhesives .............................................................. 10
DoorGaskets......................................................... 10
CondenserCoils .................................................... 10
GlassShelves........................................................ 10
Light Bulbs............................................................. 11
EnergyTips............................................................... 11
VacationTips ............................................................ 11
NormalOperating Sounds ......................................... 12
BeforeCalling ForService ......................................... 13
Warranty ................................................................... 14
Model Identification
Product information is on the serial plate, located on
ceilingof Fresh Food section. Record the following
information:
ModelNumber:
ManufacturingNumber:
S/Nor Serial Number:
Dateof purchase:
Dealer’sname and address:
Keep a copy of sales receiptfor future reference.
Enjoythis new Amana®refrigerator.

3
Installation Instructions
Introduction
Aqualified engineer must connectrefrigeratorin
accordancewiththeseinstallationinstructions.Measure
dooropening anddepth andwidth ofrefrigerator.Remove
handlesor doors as required. Engineer must follow local
electricalcompany connection regulations
Properinstallation will ensure that this refrigerator
operatesmost efficiently.Amana Refrigeration,Inc.
cannotbe responsible for improper installation.
• SeeHTK530 InternationalHandleand Trim Kitfor
installationofdoor handles and trim.
1. Remove doors if necessary.
H
D
W
Cutout Dimensions
Sin
g
le Installation Double
Installation
H 175.3 cm with 30.5 cm deep
cabinets above refri
g
erator.
177.8 cm with 61.0 cm deep
cabinets above refri
g
erator.
W 91.4 cm 184.8 cm
D 61.0 cm 61.0 cm
• See BID trim kit for specifications.
9 mm screws
8 mm screws
Top hinge
Center hinge
Phillips
screws
Door closure
Door
closure
Center hinge
pin
Plug
a. Removetophinge cover.Remove tophinge.
b. RemoveFreshFood door.
c. Lift doorclosureoff center hinge pin.Removecenter
hingepin.
d. RemoveDeepfreeze®door. Aninternalsupport rod
mayslideout.Replacerodpriortohangingdoor.
e. Removecenterhingebracket.
f. Removetoegrille. Removebottom hinge(s).
Caution
To avoid property damage, protectsoftvinyl or
otherflooring with cardboard, rugs,orother
protectivematerialwhen movingrefrigerator.
g. Slideappliance cartunderside of refrigerator.Wrap
refrigeratorwith blanket or pad.Threadcart strap
aroundrefrigerator andtighten. Donot overtighten
strap.Move refrigerator in frontoffinal location.
h. Reversedoorsifnecessary.
• Replaceinternal support rod in hinge side of
Deepfreeze®doorpriorto hangingdoor.
• Movebottom hinge pin anddoorclosure from
rightbottomhinge to left bottom hinge. Move
plastic plug from left bottom hinge to right
bottom hinge using a needle nose pliers. Pinch
tabsfrom underside ofhingeto remove.
Pin
!
Bottom
hinge

4
i. Rehangdoors by reversingstepsa-f.
• Spacedoor 18 mm from cabinet.
• Handleside of door should beapproximately
3 mm higher than hinge side.
2. Plug in power cord.
• Thisequipment, including power cord, must be
servicedonly by qualified servicepersonnel.Special
toolsare required to service equipment.Contact
nearestauthorized service facility for examination,
repairor adjustment.
3. Move refrigerator into final location.
18 mm
4. Level refrigerator.
a. Removetoegrille.
b. Turnroller adjustment screwtoraiseor lower rear of
refrigerator.
c. Turn stabilizing legs clockwise to raise or
counterclockwiseto lower frontof refrigerator.
Stabilizing legs must be firmly against floor.
Stabilizing leg
Rear roller adjustment
screw
!
Caution
Toavoid personalinjury or propertydamage
causedby refrigerator tipping, stabilizing legs
must be firmly against floor.
1/4" hex head

5
Installation Checklist
This checklist is for personal records only.
Consumer Installer Doors
Handlesideof door is 3 mm higher than hinge side of door.(Door lowers when
loadedwith food.)
Doorsseal completely to refrigerator cabinet.
Leveling
Refrigeratoristilted6mmfromfronttorear.
Stabilizinglegsare against floor.
Toe grille is properly attachedtorefrigerator.
Product Literature
Owner'smanual isreviewedincluding thefollowing information:
• FreshFood and Deepfreeze®controls
• humiditycontrolled crisper drawer
• temperaturecontrolleddrawer
• normaloperating sounds
Notes
Consumer's Signature DateInstaller's Company Name/Phone Number
Installer's Signature

6
Controls
Thisrefrigerator operates most efficientlyinnormal
householdtemperatures of 13°Cto 43°C.
Fresh Food and Deepfreeze®Controls
FreshFood control is located on upper rear wall ofFresh
Foodsection.
Deepfreeze®controlislocatedon right front ceiling of
Deepfreeze®section.
When Deepfreeze®control is set " ", neither Fresh Food
nor Deepfreeze®sections will cool. Initially, set both
controls to 4 . Wait 24 hours for Fresh Food and
Deepfreeze®sectionstoreachdesired temperatures.
After 24 hours, adjust controls, one number at a time, as
desired. 1 is warmest setting and 7 is coldest.
Setting Controls
Setcontrolspreciselyusingahouseholdthermometer
thatincludes temperatures between -21°C to10°C.
Putthermometer snugly between frozen packages in
Deepfreeze®section.Wait5-8hours. If Deepfreeze®
temperatureisnot-17°Cto-16°C,adjustcontrol,one
number at a time. Check again after 5-8 hours.
Put thermometer in a glass of water in middle of Fresh
Foodsection.Wait5-8hours.IfFreshFoodtemperature
is not 3°C to 4°C, adjust control, one number at a time.
Checkagain after 5-8 hours.
Fresh Food Features
Caution
Toavoid propertydamage, confirmshelf
is secure before placing items on shelf.
Spillsaver™Shelves
Spillsaver™shelvesadjustto meet individual storage
needs and hold simple spills for easier cleaning.
Caution
Toavoid personalinjuryor property
damage,handle temperedglassshelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperaturechange.
• Removeshelves by liftingfront,releasing hooks
from metal track then pulling out.
• Replace shelves by inserting hooks into metal track
andloweringfront.
!
!
EasyGlide™shelves pull forward for easy access of items
in back.

7
Deli Port™
DeliPort™providesspace savingstorageunderneath
Spillsaver™shelfand pulls forward for easy access.
• Removeshelf by pulling forward until shelf stops.
Push tabs on sides of shelf in and pull shelf forward.
• Replace shelf by inserting shelf into track and sliding
back.
Tab
Drawers
Humidity Controlled Crisper Drawer
Theright drawer is humidity controlled. This drawerkeeps
produce freshlonger. Wrapproduce tightly. Do notwash
producebefore placing in drawer.Excess moisture could
causeproduceto spoil prematurely. Do not line drawer
withpaper towels. Paper towels will retain moisture.
Humidity control is located below front shelf trim. Control
adjusts humidity in drawer. Slide control to right for
produce with leaves such as lettuce, spinach or cabbage.
Slide control to left for produce with skins such as
cauliflower,corn or tomatoes.
Temperature Controlled Drawer
Theleft drawer istemperature controlled. Thisdrawer
keepsfoodfresh longer and up to 3°C colder than Fresh
Foodtemperature. Use this drawer for deli storageor
additionalproduce storage.
Temperature control is located below front shelf trim.
Controladjusts amount of aircirculatingaround drawer.
Slidecontrol to left for normal Fresh Food temperature
and to right for colder temperature. Ice crystals may form
on drawer or food on coldest setting. Cold air can
decreaseFresh Food temperature. FreshFoodcontrol
may need to be adjusted.
Removeshelf and drawersby completing thefollowing
steps.
1. Openleft*drawer. *For doorshingedon left, open
rightdrawer.
Caution
Toavoid personalinjuryor property
damage,handle temperedglassshelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperaturechange.
2. Removeshelfbygently pushing up fromunderneath.
Tilt one end up then pull out.
3. Removeleft*drawerby liftingfrontwhile supporting
underneaththen pulling out. *For doors hinged onleft,
removerightdrawer.
4. Remove support post at recess in bottom center of
Fresh Food section by lifting.
5. Removeother crisper by sliding to opposite wall. Lift
frontwhile supporting underneath thenpullout.
6. Replacedrawers andshelfby reversing steps 1-5.
Crisper Tote™
CrisperTote™provideseasyaccess and protection for
small produce such as cherry tomatoes, lemons,
mushrooms, etc. in the humidity controlled crisper drawer.
!

8
Covered Storage Bucket
Storagebucket has a lid and removable egg tray. When
tray is removed, bucket will accept items such as a
standard egg carton, ice, etc.
Dairy Centers
Dairycenters provide convenient storageforitems such
as butter, cheese, etc.
• Removedairy centers by lifting door,pushing tabs
towardcenter and pulling out.
• Replace dairy centers by sliding in until tabs lock into
placeand loweringdoor.
Door Buckets
Doorbucketsadjust to meet individual storage needs.
• Removedoor buckets by pushing tabs towardcenter
andpulling out.
• Replace door buckets by sliding in until tabs lock
into place.
Door Shelf
• Removedoor shelf by lifting ends and pullingout.
• Replacedoorshelf by placing shelf on glides and
slidingdown.
Glide
Tab

9
Deepfreeze®Features
Caution
Toavoid propertydamage, confirm shelf
is secure before placing items on shelf.
!
This refrigerator features an ice bucket, ice cube trays,
ice service rack and slide out wire shelf.
• Remove ice service rack by lifting rack off plastic
washersthen pulling out.
• Replace ice service rack by placing rack on washer
andslidingdown until secure.
Washer
Deepfreeze®Shelf
• RemoveDeepfreeze®shelf by pulling out. A sharp tug
may be necessary.
• Replace Deepfreeze®shelf by sliding in until back
locks in place.
Wire Basket
Wire basket slides out for easy access of items in back.
• Removewire basket by lifting and pulling out.
• Replace wire basket by sliding in.
Wire Divider
Wiredivider organizes storage space.Dividercan be
movedleft or right.
Pivot Bin™
PivotBin™providesconvenient storage forfrozen food
itemsinDeepfreeze®door and tilts forward for easy
access of those items.
PivotBin™
Adjustable Dividers
Adjustable dividers keep items in place and adjust to
meetindividual storage needs. Divider fits in anyFresh
Fooddoor bucket or door shelf.
Tall Package Retainer
Tall package retainer keeps tall items secure. Retainer fits
in any Fresh Food door bucket or door shelf.

10
Care and Cleaning
WARNING
To avoid electrical shock which can cause
severepersonal injury or death, disconnect
powerto refrigeratorbefore cleaning.After
cleaning,connect power.
Caution
Toavoid personal injuryorproperty damage,
readand follow all cleaningproduct
manufacturer'sdirections.
General
1. Wash surfaces with 4 tablespoons baking soda
dissolved in 1 liter warm water and a soft, clean cloth.
2. Rinsesurfaces with warm water. Dry surfaces with a
soft, clean cloth.
• Do not use the following items:
- abrasiveor harsh cleaners,ammonia,chlorine
bleach, etc.
- concentrateddetergents or solvents
- metalscouringpads
These items can scratch, crack and discolor
surfaces.
• Do not place buckets, shelves, etc. in dishwasher.
Odor Removal
1. Removeallfood.
2. Cleanall interiorsurfacesincludingceiling, floor, and
walls according to “General” instructions. Pay special
attentionto corners, crevices, and grooves. Include all
drawers,shelves, and gaskets.
3. Wash and dry all bottles, containers and jars before
returning foodto refrigerator. Wrapfoods intightly
sealedcontainers to preventfurtherodor. After24
hours, check if odor was eliminated.
Completethefollowing steps if odor was not eliminated.
4. Completesteps 1-2.
5. Placegarden fresh crispers on top shelf of Fresh
Foodsection.Pack Fresh Food and Deepfreeze®
sections including doors with crumpled sheets of
blackand white newspaper.
6. Placecharcoalbriquettesrandomly throughout
newspaper.
7. Closedoors and let stand 24-48 hours.
8. Removecharcoalbriquettes and newspapers.
9. Completesteps 2-3.
!
!
Adhesives
1. Removeglueresidueby rubbing toothpaste into
adhesivewith fingers untiladhesive loosens.
2. Rinsesurface with warm water.Dry surface with a
soft, clean cloth.
Door Gaskets
1. Cleandoor gaskets every 3 monthsaccordingto
“General”instructions.
2. Apply a light film of petroleum jelly to keep gaskets
pliable.
Condenser Coils
Cleancondensercoil every 3 months to ensure maximum
performanceof refrigerator. Accumulateddustand lint
maycausethefollowing:
• reducedcoolingperformance
• increasedenergy usage
• prematurepartfailure
1. Removetoegrilleby holding ends andpulling forward.
2. Cleanfront surfaceofcondenser coil with a vacuum
cleanerhose nozzle.
3. Replace toe grille by inserting clips in holes and
snappingin.
Glass Shelves
Caution
Toavoid personalinjuryor property damage,
handletempered glass shelvescarefully.
Shelvesmaybreaksuddenlyifnicked,
scratched,or exposed to sudden temperature
change.
Removeshelf by lifting front, releasing hooks frommetal
track then pulling out. Place shelf on a towel. Allow shelf
toadjust to room temperature before cleaning.
Cleancrevices by completing the following steps:
1. Dilutemild detergentandbrush solution into crevices
using a plastic bristle brush. Let set for 5 minutes.
2. Spraywarm water into crevices usingfaucetspray
attachment.
3. Dryshelf thoroughly andreplaceshelfby inserting
hooks into metal track and lowering front.
!

11
Energy Tips
Thisrefrigeratorisdesignedtobeoneofthemostenergy
efficientrefrigerators available.Reduceenergy use by
observingthefollowing.
• Operatein normal household temperaturesof13°C to
43°Cawayfromheat sources and direct sunlight.
• SetFresh Food, Deepfreeze®,anddrawercontrolsno
colderthannecessary.
• KeepDeepfreeze®sectionfull.
• Keepdoorgasketscleanandpliable.Replace
gaskets if worn.
• Keep condenser coils clean.
Vacation Tips
Completethe following steps for short vacations.
1. Removeperishable foods.Warranty does not cover
food loss.Checkwarranty certificate for specific
coverage.
2. If an ice maker is installed, move ice maker arm to off
position.
Completethe following steps for longvacations.
1. EmptyFresh Food and Deepfreeze®sections.
2. Unplugrefrigerator.
3. Cleanrefrigerator anddoorgaskets according to
“General”instructions in “Care and Cleaning”section.
4. Prop doors open, so air can circulate inside.
5. If an ice maker is installed, turn water supply to
refrigeratoroff and moveice maker armtooff
position.
Light Bulbs
WARNING
To avoid electrical shock which can cause
severepersonal injury or death, disconnect
powerto refrigeratorbeforereplacing light bulb.
Afterreplacing light bulb, connect power.
Caution
Toavoid personalinjuryor property
damage,observethefollowing:
• Allow light bulb to cool.
• Weargloves when replacing lightbulb.
• Access light bulbs by removing 2 outside back
screws.Backof light bulb cover drops down. Replace
lightbulbswith25-wattappliancebulbs.
• Replacelight bulb cover byholdingcover against
ceiling. Insert and tighten screws.
!
!
6 mm screws

12
Normal Operating Sounds
Thisnew refrigerator maybe replacing adifferently
designed,less efficientor smaller refrigerator.Today’s
refrigeratorshave newfeatures andare moreenergy
efficient. As a result, certain sounds may be unfamiliar.
Thesesounds are normal and will soon becomefamiliar.
Thesesounds also indicate refrigeratorisoperating and
performingas designed.
•Deepfreeze®control clicks when starting or
stoppingcompressor.
•Deepfreeze®fan air rushes and whirs.
•Sealed system(evaporatorandheatexchanger)
refrigerantflow gurgles, pops or soundslikeboiling
water.
•Defrost heater sizzles, hisses or pops.
•Condenser fan air rushes and whirs.
•Compressorhas a high pitched hum orpulsating
sound.
•Ice cubes from ice maker (some models) drop into
ice bucket.
•Ice maker water valve hookup (some models)
buzzes when ice maker fills with water. This occurs
whetheror not refrigerator is connectedtowater
supply. If refrigerator is not connected to water supply,
stop sound by raising ice maker arm to off position.
• Foaminsulation is very energy efficient and has
excellentinsulating capabilities. However, foam
insulation is not as sound absorbent as
previouslyused fiberglass insulation.

13
Before Calling For Service
Refrigeratordoes notoperate.
• ConfirmDeepfreeze®controlis on.
• Confirmrefrigerator isplugged in.
• Check fuse or circuit breaker. Plug in another item at
that wall outlet.
• Wait 40 minutes to see if refrigerator restarts. If
Deepfreeze®control is on, lights work but 2 fans and
compressorare not operating, refrigerator maybein
defrost cycle.
Refrigeratorstill won’t operate.
• Unplugrefrigerator.Transfer foodto anotherunit
orplace dry ice in Deepfreeze®sectionto preserve
food.Warranty does not cover food loss. Check
warrantycertificate for specificcoverage.
Foodtemperature appears toowarm.
• Seeabove sections.
• Allowtime for recently added warm food to reach
FreshFood orDeepfreeze®temperature.
• Checkgaskets for proper seal.
• Cleancondenser coils.
• AdjustFresh Food and/or Deepfreeze®control.
Temperaturecontrolled drawer temperatureistoo warm.
• Slide control to colder setting.
• AdjustDeepfreeze®controlto colder setting.
Food temperature is too cold.
• Cleancondenser coils.
• Adjust Fresh Food control.
• AdjustDeepfreeze®control to warmer setting. Allow
severalhours for temperaturetoadjust.
Refrigeratorruns toofrequently.
• It may be normal to maintain constant temperature.
• Doorsmay havebeenopened frequentlyorfor an
extendedperiod of time.
• Allowtime for recently added warm food to reach
FreshFood orDeepfreeze®temperature.
• Cleancondenser coils.
• AdjustDeepfreeze®control.
• Checkgaskets for proper seal.
Waterdroplets form on inside of refrigerator.
• It is normal during high humidity periods or if doors
havebeenopened frequently.
Waterdroplets form on outside ofrefrigerator.
• Checkdoor gaskets for proper seal.
Drawersdo not close freely.
• Checkfor a package whichmayprevent drawer
fromclosing properly.
• Confirmdrawer is in properposition.
• Cleandrawer channels with warm,soapywater.
Rinseand dry thoroughly.
• Apply a thin layer of petroleum jelly to drawer
channels.
• Confirmrefrigeratorislevel.
Refrigeratorhas anodor.
• See“Odor Removal”instructionsin “Care and
Cleaning”section.

14
Warranty
Limited One Year Warranty
Limited Five Year Warranty on Compressor
First Year
RaytheonApplianceswill provide a free replacement part, f.o.b. Amana, Iowa, U.S.A., for any part which
isdefective due to workmanship or materials.
Second through Fifth Years
RaytheonAppliances will provide a free replacement part, f.o.b. Amana, Iowa, U.S.A.,foranycompressor
whichis defective due to workmanship or materials.
Warranty Limitations
• Beginsat date of original purchase.
• Servicemust be performed by anauthorized
Amanatechnician.
Warranty Is Void If
• Serialplate is defaced.
• Product is used on a commercial, rental or leased
basis.
• Producthasdefectordamageduetoproduct
accident,alteration, connection to an improper
electricalsupply, fire, flood, lightning, shipping and
handling,or other conditions beyond the control of
Amana.
• Product is improperly installed or used.
Owner'sResponsibilities
• Provideproof ofpurchase(sales receipt).
• Providenormal careand maintenance.
Replaceowner replaceableitemswhere
directionsappear in Owner'sManual.
• Makeproduct reasonably accessible for
service.
• Paypremium service costs for service outside
technician'snormal business hours.
• Pay for service calls related to product
installationorusage.
In no event shall Raytheon Appliances be
liable for incidental or consequential damages
including food loss*.
Anyquestions regarding the above or to locate an authorized servicer, contact appliance supplier or:
InternationalDivision
RaytheonAppliances
2800220thTrail
PO Box 8901
Amana,IA52204-0001
USA
Telephone[phone]
Facsimilie1-319-622-2180
