Amana ATB11ARW User manual

IMPORTANT
Do Not Return This Product To The Store
If you have a problem with this product, please contact the "Haier Customer Satisfaction
Center" at 1-877-337-3639.
DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE
IMPORTANT
Ne pas Réexpédier ce Produit au Magasin
Pour tout problème concernant ce produit, veuillez contacter le service des
consommateurs ‘Haier Customer Satisfaction Center’au 1-877-337-3639.
UNE PREUVE D’ACHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.
IMPORTANTE
No regrese este producto a la tienda
Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al
Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A).
NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA
115V,60 Hz
Made in China
Fabriqué en Chine
Hecho en China
Haier America Trading, L.L.C.
New York, NY 10018
Printed in China
ATB09ARW/ATB11ARW / ATB12ARW
Issued: December 05 Part# RF-9999-233
ROOM AIR CONDITIONING AND DEHUMIDIFIER PRODUCTS

ATB11ARW
ROOM AIR CONDITIONING AND DEHUMIDIFIER PRODUCTS
Two Door Auto Defrost Refrigerator
Deux Portes Dégivrent le Réfrigérateur
Dos Puertas Descongela el Refrigeradore
User Manual
Model # ATB09ARW, ATB11ARW, ATB12ARW
Guide de l’Utilisateur
Modéle # ATB09ARW,ATB11ARW, ATB12ARW
Manual del Usuario
Para Modelo de # ATB09ARW,ATB11ARW, ATB12ARW
Amana is a registered trademark of the Maytag Corporation and is used under license to Haier America.

1
English
Recognize Safety Symbols,
Words and Labels
What you need to know about Safety Instructions
Warning and mIportant Safety Instructions appearingin this manual are not meant
to cover all possible conditions and situations that may occur. Common sense,
caution and care must be exercised when operating, moving or cleaning this
product.
Always contact your dealer, distributor, service agent or manufacturer about
problems or conditions you do not understand.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious
injury.
WARNING indicates a potentially hazardous situation
which, if not aoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
CAUTION used without the safety alertsymbol
indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
DANGER
WARNING
CAUTION
CAUTION

2
SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When using
this appliance, always exercise basic safety precautions, including the
following:
1) Use this appliance only for its intended purpose as described in this use
and care guide.
2) This refrigerator must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in the
installation section.
3) Never unplug your refrigerator by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
4) Repair or replace immediately, all electric service cords that have become
frayed or otherwise damaged. Do not use a cord that shows cracks or
abrasion damage along its length, the plug or the connector end.
5) Unplug your refrigerator before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6) Do not use any electrical device or any sharp instrument in defrosting your
refrigerator.
7) If your old refrigerator is not being used, we recommend that you remove
the doors and leave the shelves in place. This will reduce the possibility of
danger to children.
8) After your refrigerator is in operation, do not touch the cold surfaces in
the freezer compartment, particularly when hands are damp or wet. Skin
may adhere to these extremely cold surfaces.
9) Do not refreeze foods, which have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: "…You may safely refreeze frozen foods that have thawed if they
still contain ice crystals or if they are still cold-below 40˚F".
"…Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat."
"…Even partial thawing and re-freezing reduce the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality
as you can."
English

3
English
10) This refrigerator should not be recessed or built-in an enclosed cabinet. It
is designed for freestanding installation only.
11) Do not operate your refrigerator in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
Staple your receipt to your manual.
You will need it to obtain warranty service.
Thank you for using our Amana
product. This easy-to-use manual will
guide you in getting the best use of
your refrigerator.
Remember to record the model and
serial number. They are on a label
inside of the refrigerator cabinet.
Model number
Serial number
Date of purchase
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves in place
so that children may not easily climb inside.
DANGER

4
English
Table Of Contents
PAGE
Section One
Recognize Safety Symbols, Words and Labels ..........................................1
Safety Precautions...............................................................................2-3
Section Two
Parts and Features..................................................................................5
Installing Your Refrigerator ......................................................................6
Unpacking Your Refrigerator ...................................................................6
Leveling Your Refrigerator........................................................................6
Proper Air Circulation ............................................................................6
Electrical Requirements............................................................................6
Installation Limitations ............................................................................7
Use of Extension Cord ............................................................................7
Door Alignment......................................................................................8
Reversing the Door Swing ......................................................................9
Section Three
Refrigerator Features and Use ..............................................................11
General Features..................................................................................11
Refrigerator Interior Shelves ..................................................................11
Crisper and Crisper Cover ....................................................................12
Food Storage Information......................................................................13
Normal Operating Sounds....................................................................14
Section Four
Proper Refrigerator Care and Cleaning..................................................15
Light Bulb Replacement ........................................................................16
Power Interruptions ..............................................................................16
Vacation and Moving Care ..................................................................16
Troubleshooting ....................................................................................17
Section Five
Warranty Information ..........................................................................18

5
English
Parts And Features
1
1. Ice Cube Trays (2)
2. Full-Width Freezer Door Shelves (2)
3. See Thru Gray Tint Covered Dairy
Compartment
4. Full-Width Door Shelves (2)
(Shelves May Vary per Model)
5. Adjustable Front Leveling Legs
(not shown)
6. See Thru Gray Tint Crispers (2)
7. Clear Glass Crisper Cover
8. Adjustable Full-Width Glass Spill
Proof Shelves (2)
9. Adjustable Temperature Control
(Location may vary per model
purchased)
10. Automatic Interior Light
11. Freezer Shelf (Style may varyper
model purchased)
2
3
4
5
6
7
8
9
10
11
ATB11ARW

6
English
Installing Your Refrigerator
Unpacking Your Refrigerator
1. Remove all packaging material. This includes the foam base and all adhesive
tape holding the refrigerator accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed materials before
connecting power to your refrigerator.
Leveling Your Refrigerator:
• Your refrigerator has two leveling legs which are located in the front corners of
your refrigerator. After properly placing your refrigerator in its final position,
you should level your refrigerator for horizontal standing.
• Leveling legs can be adjusted by turning them counterclockwise to raise your
refrigerator or by turning them clockwise to lower your refrigerator. The
refrigerator door will close easier when the leveling legs are raised.
Proper Air Circulation
• To assure your refrigerator works at the maximum efficiency it was designed
for, you should install it in a location where there is proper air circulation,
plumbing and electrical connections.
• The following are recommended clearances around the refrigerator:
Sides……………3/4" (19mm)
Top....................1" (25mm)
Back..................1" (25mm)
Electrical Requirement
•Make sure there is a suitable power outlet (115 volts, 15 amps outlet) with
proper grounding to power the refrigerator.
• Avoid the use of three plug adapters or cutting offthe thirdgrounding in order to
accommodate a two plug outlet. This is a dangerous practice since it provides no
effective grounding for the refrigerator and may result in shock hazard.
WARNING

7
English
Installation Limitations
• Do not install your refrigerator in any location not properly insulated or heated
e.g. garage etc. Your refrigerator was not designed to operate in temperature
settings below 55˚ Fahrenheit.
• Select a suitable location for the refrigerator on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness should be
corrected with the leveling legs located on the front bottom corners of the
refrigerator.
Use of Extension Cords
• Avoid the use of an extension cord because of potential safety hazards. If it is
necessary to use an extension cord, use only a 3-wire extension cord that has
a 3-blade grounding plug and a 3-slot outlet that will accept the plug. The
marked rating of the extension cord must be equal to or greater than the elec-
trical rating of the appliance.

Door Alignment
Freezer Door: (see fig. # 1)
1. Remove hinge cover screw.
2. Remove the top hinge cover.
3. Loosen the top hinge screws using a phillips head screwdriver.
4. Adjust the door or put a spacer in between and then tighten the screws.
5. Replace the top hinge cover.
Refrigerator Door: (see fig. # 2)
1. Loosen and remove the bottom hinge using a
phillips head screwdriver.
2. Adjust the door, or put a spacer in between and
then tighten the screws.
8
fig. # 1
Hinge box
cover
Top hinge
fig. # 2
lower bracket
lower pivot pin
lower pivot pin hole
bottom hinge pad
English

9
English
Reversing the Door Swing
Left/right door opening method:
This product provides the reversing of the left/right door opening. You can select
your preference of door opening by following the procedure to make the change.
Dismantling: (see fig. # 1 and fig. # 3)
1. Fix refrigerator and freezer door by sticking adhesive tape on both sides to hold
doors in place.
2. As shown in fig. 1, dismantle the hinge box cover on the upper part of freezer
door with a phillips head screwdriver. Then remove the three screws from the
hinge. Take out the hinge by pulling it vertically, and keep it in a safe place.
3. Remove the adhesive tape on freezer door, lift and take the door down, and
carefully put it aside.
4. Dismantle two screws of the central hinge, lift and take down the central hinge,
and keep them in a safe place. (see fig # 3)
5. Remove the adhesive tape on refrigerator door, lift and take down
refrigerator door, and carefully put it aside.
6. Remove the door stoppers from the freezer and refrigerator doors and install
them on the opposite side of the door.
fig. # 3
screw holes
stop of freezer door
middle pivot pin
stop of refrigerator door
middle bracket
(central hinge bracket)

10
Reinstallation: (see fig. # 4 and fig. # 5)
1. Remove the lower pivot pin from the bracket of the lower
hinge by turning counter clockwise. Move the pin to the
opposite hole and tighten.
2. Loosen the screws holding the lower hinge bracket
and remove the hinge.
3. Align the holes in the lower hinge bracket to the
corresponding holes in the opposite side of the cabinet.
Insert and tighten the screws.
4. To install refrigerator door: make the left bottom hole of the
refrigerator compartment door fall over the lower hinge axle, move door forward
to make it straight and in alignment with central hinge. Install the central hinge
again, turn the hinge axle until it
completely enters the door body, then fix it with screws.
5. To install freezer door: make the left bottom hole of freezer door fall over the cen-
tral hinge axle; raise upper hinge, so that hinge axle can be installed in the
upper hole of the upper part of the freezer door; adjust door to make it straight
and level.
6. As shown in Fig. 1, install the upper freezer hinge to the left
corresponding position. (tighten the screws of upper hinge)
7. Replace the hinge cover as shown in Fig. 1.
stop of freezer door
middle pivot pin
middle bracket
(central hinge bracket)
screw holes
stop of refrigerator door
lower bracket
lower pivot pin
bottom hinge pad
fig. # 4
English
lower pivot pin hole
fig. # 5

11
English
Refrigerator Features And Use
The refrigerator shelves of your refrigerator were designed with you in
mind. Their varied adjustability allows you to satisfy your
personal storage needs.
To remove or adjust a full-width
slide-out shelf: (see fig. # 6)
1. Gently tilt the shelf up and slide forward until the shelf has been
completely removed.
2. To replace the shelf, select the desired setting and gently slide the
shelf back until it rests in the locking position.
General Features
Adjustable temperature dial:
Your refrigerator will automatically
maintain the temperature level you
select. The temperature control dial has
7 settings plus off. 1 is the warmest. 7
is the coldest. Turning the dial to OFF
stops cooling in both the refrigeration
and freezer sections. At first, set the
dial to 4 and allow 24 hours to pass
before adjusting the temperature to your
needs.
(Note: If the refrigerator has
been placed in a horizontal or
tilted position for any period
of time wait 24 hours before
plugging the unit in.)
Refrigerator Section
Interior Light:
Your refrigerator is equipped with an
automatic interior light in the fresh
food section for you to easily locate
your food.
Refrigerator Interior Shelves
fig. # 6

12
To remove and install the crisper: (see fig. # 7)
1. Grip the crisper firmly and slide out completely.
2. Replace the crisper by placing the crisper properly in position and
gently sliding it back into place.
Removing or replacing the crisper cover: (see fig. # 8)
1. Carefully grasp the crisper cover and slide out to remove.
2. To replace, slide the rear of the crisper cover into the right and left slots
above the crisper area and gently slide back into place.
Crisper and Crisper Cover
fig. # 7
fig. # 8
English

13
English
Food Storage Information
Fresh Food
•When storing fresh food, which is not prepackaged, be sure to wrap or store food
in airtight and moisture proof material unless otherwise noted. This will ensure
proper shelf life and prevent the transfer of odors and tastes.
• Wipe containers before storing to avoid needless spills.
• Eggs should be stored in an upright position in their original carton to maximize
shelf life.
• Fruit should be washed and dried then stored in sealed plastic bags before storing
in the refrigerator.
• Vegetables with skins should be stored in plastic bags or containers.
• Leafy vegetables should be washed and drained and then stored in plastic bags
or containers.
• Hot food should be allowed to cool before storing in the refrigeration. This will
prevent unnecessary energy use.
• Fresh seafood should be used the same day as purchased.
• When storing meats in the fresh food section, keep in the original
packaging or rewrap as necessary. Follow the suggestions below for safe stor-
age:
•Chicken 1-2 Days
• Ground Beef 1-2 Days
• Cold Cuts 3-5 Days
• Steaks/Roasts 3-5 Days
• Smoked/Cured Meats 7-10 Days
• All others 1-2 Days
If longer periods of storage are required, store immediately in the freezer section.

14
Frozen Food
•Proper freezer storage requires correct packaging. All foods must be in
packages, which do not allow the flow of air or moisture in, or out.
Improper storage will result in odor and taste transfer and will result in
the drying out of the improperly packaged food.
• Follow package or container instructions for proper storage.
•Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
• Do not refreeze defrosted/thawed foods.
• It is recommended that the freezing date be marked on the
packaging.
•The fan circulating air inside the interior of your unit to maintain the
temperature you have selected.
• Boiling water, gurgling sounds or slight vibrations that are the result of
the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
Normal Operating Sounds You May Hear
English

15
English
Cleaning and Maintenance
To avoid electric shock always unplug your refrigerator before
cleaning. Ignoring this warning may result in death or injury.
Before using cleaning products, always read and follow
manufacturer’s instructions and warnings to avoid personal
injury or product damage.
General: • Prepare a cleaning solution of 3-4 tablespoons of baking
soda mixed with warm water. Use sponge or soft cloth,
dampened with the cleaning solution, to wipe down your
refrigerator.
•Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine
bleach,concentrated detergents, solvents or metal scouring
pads. SOME of these chemicals may dissolve, damage
and/or discolor your refrigerator.
Door Gaskets: •Clean door gaskets every three months according to general
instructions. Gaskets must be kept clean and pliable to
assure a proper seal.
•Petroleum jelly applied lightly on the hinge side of gaskets
will keep the gasket pliable and assure a good seal.
Proper Refrigerator Care and
Cleaning
Refrigerators:
We recommend that you clean the rear of the refrigerator at least twice a
year. Some operating environments may require more frequent cleaning.
• Slowly pull the refrigerator straight out away from the wall.
Note: Do not move the refrigerator sideways as this
may cause damage to the floor covering of your
refrigerator.
•Unplug the refrigerator.
•Use a vacuum or a brush to clean coils.
•When cleaning has been completed, plug the cord back into the outlet and slide
the refrigerator straight back to its original position.
Note: When pushing it back, be careful not to roll over
the power cord.
WARNING
CAUTION
WARNING
CAUTION

16
English
1. Switch off power to refrigerator.
2. Remove the highest shelf.
3. Allow light bulb to cool before removing.
4. Pinch the plastic cover between fingers and
thumb and gently pull to the left.
5. Remove the bulb by screwing it counter-clockwise.
6. Always replace with appliance type light bulb rated at 15 watts
or lesser wattage.
7. Do not exceed the 15 watts rating at any time.
8. To replace cover, insert rear clips in first and gently push front
clip in until the cover snaps into place.
• Occasionally there may be power interruptions due to thunderstorms or
other causes. Remove the power cord from AC outlet when a power out-
age occurs. When power has been restored, replug power cord to AC
outlet. If outage is for a prolonged period, inspect and discard spoiled
or thawed food in freezer and refrigerator. Clean
refrigerator before reusing.
• For long vacations or absences, empty food from refrigerator and
freezer, move the temperature DIAL to the OFF position and clean the
refrigerator and door gaskets according to "General cleaning" section.
Prop doors open, so air can circulate inside.When moving always move
the refrigerator vertically. Do not move with the unit lying down. Possible
damage to the sealed system could occur.
Light Bulb Replacement (Location may vary per model purchased)
Power Interruptions
Vacation and Moving Care
CAUTION

English
17
Refrigerator Does Not Operate
•Check if thermostat control is not in the “OFF” position.
• Check if refrigerator is plugged in.
• Check if there is power at the ac outlet, by checking the circuit breaker.
Food temperature appears too warm
•Frequent door openings.
• Allow time for recently added warm food to reach fresh food or freezer temperature.
• Check gaskets for proper seal.
• Adjust temperature control to colder setting.
Food temperature is too cold
• If temperature control setting is too cold, adjust to a warmer setting and allow several
hours for temperature to adjust.
Refrigerator runs too frequently
•This may be normal to maintain constant temperature during high temperature and
humid days.
• Doors may have been opened frequently or for an extended period of time.
• Check gasket for proper seal.
• Check to see if doors are completely closed.
Moisture build up on interior or exterior of the refrigerator:
•This is normal during high humidity periods.
• Prolonged or frequent door openings.
• Check door gaskets for proper seal.
Refrigerator has an odor:
•Interior needs cleaning.
• Foods improperly wrapped or sealed are giving off odors.
Refrigerator light does not work:
•Check power supply.
• Tighten bulb in socket.
• Replace burned out bulb.
Refrigerator/Freezer door does not shut properly:
•Level the refrigerator.
• Re align refrigerator/freezer door.
• Check for blockages e.g. food containers, crisper cover, shelves, bins etc.
TroubleShooting

18
English
Limited Warranty
What is covered and for how
long?
This warranty covers all defects in work-
manship or materials for a period of:
12 months labor (In-Home Service)
12 months parts
EXCEPTIONS: Commercial or
Rental Use warranty
90 days labor (carry-in only)
90 days parts
No other warranty applies
What is covered.
1. The mechanical and electrical parts,
which serve as a functional, purpose
of this appliance for a period of 12
months. This includes all parts except
finish, and trim.
2. The components of the sealed system
e.g. hermetic compressor, condenser
and evaporator from manufacturing
defects for a period of 1 years from
the date of purchase. Any damages
to such components caused by
mechanical abuse or improper han-
dling or shipping will not be covered.
What will be done?
1. We will repair or replace, at our dis-
cretion any mechanical or electrical
part which proves to be defective in
normal usage during the warranty
period so specified.
2. There will be no charge to the
purchaser for parts and labor on any
covered items during the initial 12
month period.
3. Contact your nearest authorized
service center. For the name of the
nearest service center please call
1-877-337-3639
THIS WARRANTY COVERS
APPLIANCES WITHIN THE
CONTINENTAL UNITED STATES,
PUERTO RICO AND CANADA.
IT DOES NOT COVER
THE FOLLOWING:
Damages from improper installation.
Damages in shipping.
Defects other than manufacturing.
Damage from misuse, abuse, accident,
alteration, lack of proper care and
maintenance or incorrect current or
voltage.
Damage from other than household use.
Damage from service by other than an
authorized dealer or service center.
Decorative trims or replaceable
light bulbs.
Transportation and shipping.
Labor (after the initial 12 months).
THIS LIMITED WARRANTY IS GIVEN IN
LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR, INCLUDING THE
WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR
PURPOSE
The remedy provided in this warranty is
exclusive and is granted in lieu of all
other remedies.
This warranty does not cover incidental
or consequential damages, so the above
limitations may not apply to you. Some
States do not allow limitations on how
long an implied warranty lasts, so the
above limitations may not apply to you.
This warranty gives you specific legal
rights, and you may have other rights,
which vary, from state to state.
Haier America
New York, NY 10018
