Amart Furniture QUINN 65500 User manual

Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
ASSEMBLY INSTRUCTION
QUINN CORNER DESK
ITEM CODE 65500
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
165500

PRE-ASSEMBLY PREPARATION
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product.
2. Take care when li ing. Product should be assembled as near as possible to
the point of use.
3. Ensure that you have all required contents for complete assembly.
4. Always read the assembly instruc ons carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over ghten the screws and bolts as this may damage the threads.
30
265500
2

PARTS LIST
365500
C1
C2
C3
C5
C6
C7
1
1
2
1
1
1
1182x550x18mm
832x550x18mm
750x550x18mm
732x550x18mm
18x18x1164mm
18x18x1164mm
A B C
21xA
C4
C8
118x18x1164mm
M6x30mm 4xB
M6x12mm M4x20x60mm
C9
C10
1
1
1
18x18x832mm
18x18x832mm
18x18x832mm

EXPLODED VIEW
465500
C1
C2
C3
C3
C4
C5
C6
C7 C8
C9
C10

STEP 1
STEP 2:
565500
Fix C5 to C3 and C4 using Bolt A and tighten using Allen key C.
Fix C6 and C7 to C3 using Bolt A and C4 using Bolt B then
tighten using Allen key C.
Fix C9 and C10 to C4 using Bolt B and C3 using Bolt A then
tighten using Allen key C.
Fix C8 to C7 and C3 using Bolt A then tighten using Allen key C.
C3
C7
C6
C5
C4
A
B
C8
C10
C9
C3
A
B
B
A
A
A
C4
A
A
B
A
C7

STEP 3
STEP 4:
665500
Fix C1 on C6 and C7 using Bolt A and tighten using Allen
key C.
C6
C3
C7
C1
C4
A
A
A
A
A
A
A
C8
C9
C2
A
A
AA
AA
Fix C2 on C9 and C8 using Bolt A and tighten using Allen
key C.

Step 5:Assembly Complete
765500

865500
SAFETY BRACKETS INSTRUCTIONS
1. A ach one Moun ng Plate to the wall with the Large Screws. Make sure to a ach the
Moun ng Plate into a stud. If moun ng into brick or masonry you will need to acquire
wall anchors. Please enquire with your local hardware supplier for appropriate fixings.
2. A ach the second Moun ng Plate to the furniture frame with the Short Screws.
3. Move the furniture to its final posi on. Thread a Wall Strap through the both Moun ng
Plates and ghten un l snug. Do not over ghten.
4. Make sure that the Moun ng Plates are firmly a ached to the wall and furniture and
that the Wall Strap is snug.
HARDWARE
Moun ng Plate x 2 Wall Strap x 1 Large Screw x2 Small Screw x2
This furniture poses a pping risk and as such must be secured to a wall using the provided
pping kit.

965500
CARE AND MAINTENANCE
PRODUCT CARE FOR HI-GLOSS ITEMS
•Hi-gloss lacquered furniture is more sensi ve to marks and scratching then some other
furniture products. It is important to exercise ca on and care to maximise the life and
beauty of this product
•Following the below simple guidelines when using your hi-gloss product will protect your
investment for years to come
•Dust frequently with a clean damp lint-free cloth. This will help remove abrasive build up
which can damage a finish over me
•Avoid using chemicals or solvents when cleaning the product
•Do not place hot objects on any furniture surface. Always use a hot plate or placemat.
Lacquer finishes provide added scratch and heat resistance to our furniture, but they can
sll be damaged without proper care
•Avoid exposing your furniture to strong sunlight, heat outlet, open windows or dampness.
Prolonged exposure to direct sunlight can fade the finish of your furniture, while extreme
temperature and humidity changes can cause cracking or spli ng
•Do not expose your furniture to any liquids. Never allow water to sit on your furniture.
Alcohol, nail polish and perfume are also dangerous as they will dissolve the lacquer
finish on contact and may require professional repairs
•Do not allow plas c to come in direct contact with your furniture. Chemicals in the plas c
of placemats etc. may so en and mark the finish if le in contact with the furniture for a
period of me
•Avoid placing sharp or rough objects on the surface of your furniture. These may scratch
the surface of the product
•When moving your furniture, do not drag it across the floor. This may damage the
product. Instead use two (2) people to li carefully from either end
