Amazon Fleet Edge Compute Module User manual

315.00 mm
148.00 mm
105.00 mm105.00 mm105.00 mmFleet Edge User Guide – Covered under NDA
Amazon.com Confidential
1
Fleet Edge Compute Module Description &
User Guide
Rivian Installations, V1.0, September 2021
Purpose
This document covers the Amazon Fleet Edge compute Module as installed in a Rivian vehicle.
Fleet Edge Overview
Fleet Edge is an edge compute system for deployment on Amazon delivery vehicles. It provides an
in-vehicle platform for video and position data acquisition and onboard analysis. The system is
designed as a flexible edge-compute platform, and can run various programs. The system has LTE
and Wi-Fi connections for over the air updates and data offload, Bluetooth for connection to local
mobile devices, and GPS for location measurement. 5 cameras are connected to the compute system:
a Forward facing camera, a driver facing camera, a cargo facing camera, and two exterior side
cameras.
This system is made of multiple hardware modules which are installed during the production of
the vehicle. It is not directly accessible by the vehicle operator, and has no direct user interface.
The primary function is on vehicle data acquisition, data processing for privacy and bandwidth
reduction and automated uploading of this data to cloud storage.
Hardware Overview
The installation consists of a compute module, a camera processor module, a Wi-Fi/LTE antenna, a
GPS splitter to share GPS signals with the host vehicle antenna, and at five cameras.
Fleet Edge User Guide – Covered under NDA
Amazon.com Confidential
2
Compute Module
The primary computer for the Fleet Edge system. Includes compute, disk storage, a GPS receiver,
LTE, WiFi, and Bluetooth modems, as well as Ethernet, CAN, USB and HDMI connections. Not all
interfaces are used in standard installations. In Rivian installations, data connection is made to the
vehicle via the dual wire automotive Ethernet connection.
Powered directly from the 12V vehicle system, this module is connected to both permanent power
and a switched ignition circuit. The device powers on with ignition, and remains on for some time
after ignition power is removed, in order to enable continuity between deliveries and for a
controlled shut down.
Includes a simple LED screen with two 7 segment displays to show high level status, which is used
for basic troubleshooting.
The system is mounted with the connectors down in order to limit liquids or other objects from
entering the enclosure. A plastic cap on the side opposite from connectors also limits intrusions
from above when installed.
This module is a component in the system, installed during the production of the vehicle. For
primary functionality, connections to other devices is required.
Approximate dimensions are 353mm x 273mm x 93mm and weight is 7kg.
Fleet Edge User Guide – Covered under NDA
Amazon.com Confidential
3
General Component Locations
ACIM
POWER (for ACIM)
Vehicle CAN
AI
BOX PCM
POWER
IGN
Veh Speed
ETH
CAMERA
GPS
Antenna
LTE
WiFI
Antenna
RF
RF
CAN
1934110024R_1100923.pdf 1 2021/9/23 上午 09:50:36

315.00 mm
148.00 mm
105.00 mm105.00 mm105.00 mmFleet Edge User Guide – Covered under NDA
Amazon.com Confidential
4
Built in Diagnostics
The Compute Module includes a built-in screen that indicates the state of the software and
hardware, and is the initial troubleshooting step. This is a 7-segment green LED display, with two
digits. It is important to read this in the correct orientation in order to not mistake the code being
displayed.
Early in boot immediately after power application, the display shows low level boot debugging
information. This is not covered here. Wait for a code to be stable before using the table below.
After the ignition signal is removed, the system begins a countdown timer. This is indicated on the
display as well, as a hex number that changes once a second and counts up.
As this device is installed an enclosed space in the Rivian vehicle, observing this display requires
removal of access panels, and a mirror or other observation techniques may be required.
Fleet Edge User Guide – Covered under NDA
Amazon.com Confidential
5
Code Table
Status
Code System(s) Description Troubleshooting Action(s)
P0
-
Success
–
No Failure.
None
L1 Camera Could not detect camera
system.
Check Ethernet connection to VPU-
L2 Camera Front view camera not found. Check camera coax connection.
L3
Camera
Camera 2 not functional.
System Mis
-
Configured.
L4
Camera
Camera 3 not functional.
System Mis
-
Configured.
L5 Camera Front view camera not
functional.
Replace camera.
L6 Camera Camera 2 not functional. System Mis-Configured.
L7
Camera
Camera 3 not functional.
System Mis
-
Configured.
H1 GNSS GNSS device not accessible. Replace Fleet Edge computer.
H2 GNSS GNSS hardware not present. Replace Fleet Edge computer.
H3 GNSS GNSS hardware read failure. Replace Fleet Edge computer.
H4
LTE
Modem device not accessible.
Replace Fleet Edge computer.
H5
LTE
SIM not found.
Add or replace with activated SIM.
H6 LTE SIM not activated. Add activated SIM.
H7 LTE No internet access. Check LTE antenna connection and
LTE coverage.
H8 LTE No SSH access (internal use). Check LTE antenna connection and
LTE coverage.
H9 Security TPM device not properly
configured.
Replace Fleet Edge computer.
HA Wi-Fi Wi-Fi component not detected. Replace Fleet Edge computer.
HB Wi-Fi Wi-Fi component not
functional.
Replace Fleet Edge computer.
HC
VPU
Vision Processor not detected.
Replace Fleet Edge computer.
HD Ignition Ignition signal not detected. Check ignition connection and
voltage.
U1
Provisioning
Software provisioning process
failures. Contact Fleet Edge
engineering for further details.
Reboot device. Check for stable LTE
access. Replace Fleet Edge computer.
U2
U3
U4
U5
U8
U9 Vehicle VIN acquisition failure. Check CAN connection to vehicle. –
UC
Activation
Software activation and cloud
registration failures. Contact
Fleet Edge engineering for
further details.
Reboot device. Check for stable LTE
access. Replace Fleet Edge computer.
UE
UF
BLANK
Power No power or ignition signal Check voltages on power, ignition,
and ground wires as well as main fuse
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
(If device is outdoor AP, please delete it. If device is indoor AP, need to add it.)
This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC
Rules.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
6
1934110024R_1100923.pdf 2 2021/9/23 上午 09:50:36

Professional installation instruction
1. Installation personal
This product is designed for specific application and needs to be installed by a
qualified personal who has RF and related rule knowledge. The general user shall
not attempt to install or change the setting.
2. Installation location
The product shall be installed at a location where the radiating antenna can be
kept 20cm from nearby person in normal operation condition to meet regulatory
RF exposure requirement.
3. External antenna
Use only the antennas which have been approved by the applicant. The
non-approved antenna(s) may produce unwanted spurious or excessive RF
transmitting power which may lead to the violation of FCC limit and is prohibited.
4. Installation procedure
Please refer to user’s manual for the detail.
5. Warning
Please carefully select the installation position and make sure that the final
output power does not exceed the limit set force in relevant rules. The violation
of the rule could lead to serious federal penalty.
