Package Contents..................................................................................................................................................................................................... 3

Assembling the Grill................................................................................................................................................................................................. 7

Feedback and Help.................................................................................................................................................................................................27

Contents

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 2PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 2 10/10/2022 3:44:19 PM10/10/2022 3:44:19 PM

Package Contents

Parts

Part Name Image Quantity

1 Front foot 1

2 Back foot 1

3 Front left support 1

4 Back left support 1

5 Tank shelf 1

6 Tank lock 1

7 Back right support 1

8 Front right support 1

9 Front panels 2

10 Axle 1

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 3PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 3 10/10/2022 3:44:20 PM10/10/2022 3:44:20 PM

Part Name Image Quantity

11 Wheels 2

12 Tank exclusion bar 1

13 Grill box 1

14 Side braces 2

15 Left side shelf 1

16 Left shelf cover 1

17 Shelf brackets 2

18 Right sideburner shelf 1

19 Right shelf cover 1

20 Side burner 1

21 AA battery 1

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 4PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 4 10/10/2022 3:44:20 PM10/10/2022 3:44:20 PM

Part Name Image Quantity

22 Grease tray 1

23 Grease pan holder 1

24 Grease pan 1

25 Control knobs 7

26 Heat plates 6

27 Side cooking grates 2

28 Middle cooking grate 1

29 Warming rack 1

30 Side burner grate 1

31 Hose bracket 1

32 Handle 1

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 5PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 5 10/10/2022 3:44:21 PM10/10/2022 3:44:21 PM

Hardware

Part Name Image Quanitity

A1/4-20x1/2” truss head

screws 31

B5/32-32x2/5” truss

head screws 35

C1/4” at washers 6

D5/16” at washers 2

E 5/16” nuts 2

F 5/32” nuts 4

G5/32” at washer 2

Tools Needed

Philips screwdriver Adjustable wrench

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 6PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 6 10/10/2022 3:44:21 PM10/10/2022 3:44:21 PM

Assembling the Grill

Step 1

1/4-20x1/2” truss head screws (x4)

1. Secure the front foot (1) to the front left support (3) with two 1/4-20x1/2” truss head screws (A).

2. Secure the back foot (2) to the back left support (4) with two 1/4-20x1/2” truss head screws (A).

Step 2

Remove the screw on the tank lock (6) and disassemble into four parts (screw, washer, bracket, and pin).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 7PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 7 10/10/2022 3:44:21 PM10/10/2022 3:44:21 PM

Step 3

1/4-20x1/2” truss head screws (x2)

Secure the bracket from the tank lock (disassembled in the previous step) to the tank shelf (5) with two 1/4-20x1/2” truss head

screws (A).

Step 4

Thread the pin through the hole in the end of the tank shelf (5), then secure with the screw and washer.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 8PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 8 10/10/2022 3:44:22 PM10/10/2022 3:44:22 PM

Step 5

1/4-20x1/2” truss head screws (x10) 5/32-32x2/5” truss head screws (x4)

1. Secure the back right support (7) to the tank shelf (5) with three 1/4-20x1/2” truss head screws (A).

2. Secure the back left support (4) to the tank shelf (5) with three 1/4-20x1/2” truss head screws (A).

3. Secure the front right support (8) to the tank shelf (5) with two 1/4-20x1/2” truss head screws (A) and two 5/32-32x2/5”

truss head screws (B).

4. Secure the front left support (3) to the tank shelf (5) with two 1/4-20x1/2” truss head screws (A) and two 5/32-32x2/5”

truss head screws (B).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 9PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 9 10/10/2022 3:44:22 PM10/10/2022 3:44:22 PM

Step 6

5/32-32x2/5” truss head screws (x8)

Secure the two front panels (9) to the front supports with eight 5/32-32x2/5” truss head screws (B).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 10PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 10 10/10/2022 3:44:22 PM10/10/2022 3:44:22 PM

Step 7

Thread the axle (10) through the holes at the bottom of the right supports.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 11PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 11 10/10/2022 3:44:22 PM10/10/2022 3:44:22 PM

Step 8

5/16” at washers (x2) 5/16” nuts (x2)

Slide the wheels (11) onto each end of the axle, insert a 5/16” at washer (D) onto each end, then secure each wheel with a

5/16” nut (E). Tighten each nut with a wrench.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 12PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 12 10/10/2022 3:44:22 PM10/10/2022 3:44:22 PM

Step 9

1/4-20x1/2” truss head screw (x1)

Insert the ends of the tank exclusion bar (12) into the left supports, then secure the bar to the tank shelf with a 1/4-20x1/2”

truss head screw (A).

Step 10

With a partner, lift the grill box (13) onto the supports.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 13PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 13 10/10/2022 3:44:23 PM10/10/2022 3:44:23 PM

Step 11

1/4-20x1/2” truss head screws (x4)

Secure the grill box with one 1/4-20x1/2” truss head screw (A) at each corner.

Step 12

1/4-20x1/2” truss head screws (x4) 5/32-32x2/5” truss head screws (x4)

Secure the grill box with four 1/4-20x1/2” truss head screws (A) and four 5/32-32x2/5” truss head screws (B).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 14PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 14 10/10/2022 3:44:23 PM10/10/2022 3:44:23 PM

Step 13

5/32-32x2/5” truss head screws (x4) 5/32” nuts (x4)

Align the two side braces (14) with the holes in the supports, then secure with four 5/32-32x2/5” truss head screws (B) and four

5/32” nuts (F).

Step 14

1. Remove the two screws from the ends of the handle (32).

2. Align the ends of the handle with the holes in the grill box, then secure with the two screws.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 15PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 15 10/10/2022 3:44:24 PM10/10/2022 3:44:24 PM

Step 15

5/32-32x2/5” truss head screws (x4)

1. Align a shelf bracket (17) with the left side shelf (15) and left shelf cover (16), then secure with two 5/32-32x2/5” truss

head screws (B). Do not fully tighten.

2. Secure the edge of the left side shelf and left shelf cover with two more 5/32-32x2/5” truss head screws (B).

3. Fully tighten the screws.

Step 16

Loosen the two upper screws on the left side of the grill box, then slide the left shelf assembly onto the grill box. The grill box

screws should t into the shelf’s keyhole slots.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 16PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 16 10/10/2022 3:44:24 PM10/10/2022 3:44:24 PM

Step 17

1/4-20x1/2” truss head screws (x3) 1/4” at washers (x3)

Secure the left side shelf with three 1/4” at washers (C) and three 1/4-20x1/2” truss head screws (A).

Step 18

5/32-32x2/5” truss head screws (x2)

1. Make sure that the shelf assembly is fully seated in the keyhole slot, then retighten the screw you loosened in step 16.

2. Secure the left shelf cover with two 5/32-32x2/5” truss head screws (B).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 17PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 17 10/10/2022 3:44:24 PM10/10/2022 3:44:24 PM

Step 19

5/32-32x2/5” truss head screws (x4)

1. Align a shelf bracket (17) with the right sideburner shelf (18) and right shelf cover (19), then secure with two 5/32-32x2/5”

truss head screws (B). Do not fully tighten.

2. Secure the edge of the right sideburner shelf and right shelf cover with two more 5/32-32x2/5” truss head screws (B).

3. Fully tighten the screws.

Step 20

Loosen the two upper screws on the right side of the grill box, then slide the right sideburner assembly onto the grill box. The

grill box screws should t into the shelf’s keyhole slots.

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 18PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 18 10/10/2022 3:44:25 PM10/10/2022 3:44:25 PM

Step 21

1/4-20x1/2” truss head screws (x3) 1/4” at washers (x3)

Secure the right sideburner shelf with three 1/4” at washers (C) and three 1/4-20x1/2” truss head screws (A).

Step 22

5/32-32x2/5” truss head screws (x2)

1. Make sure that the sideburner assembly is fully seated in the keyhole slot, then retighten the screws you loosened in step

20.

2. Secure the right shelf cover with two 5/32-32x2/5” truss head screws (B).

PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 19PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 19 10/10/2022 3:44:25 PM10/10/2022 3:44:25 PM

Step 23

1. Loosen the two sideburner control screws. Do not remove the screws.

2. Place the sideburner valve into the hole of the right sideburner shelf cover, then slide it down to lock in place.

3. Retighten the two sideburner control screws.

Step 24

Remove the two screws on the sideburner (20).
