AmbiCom PowerSaver AMB8010 User manual

PowerSaver™ 16-bit 10 Mbps Ethernet PC Card
for HandHeld PCs using Windows CE
Model: AMB8010
Specifications:
Standard Conformance IEEE 802.3 for 10 Base-T
Data Bus Width 16-bit
Transmission Speed 10Mbps
Interrupt Level 3,4,5,9,10,11,12, and 15
I/O Base Address 300h, 320h, 340h, 360h
On-board RAM 16K Buffer Memory
Socket Support Type II PC Card Slot
Cable 10Base-T unshielded twisted pair (UTP)
Connector Type RJ-45, male
Operating Distance 327feet (100 meter)
Hardware Standard Type II PC Card
Power Consumption 26mA max.
Network Operating Systems WindowsCE v.2.0 or higher, Windows
2000, Windows98/ME, Windows95/OSR2,
WindowsNT 4.0
Regulatory Approval FCC Code of Federal Regulations,
Part 15, Class B
CE Mark (EN 55022, Class B)
