AmbiCom WL22-PC Installation instructions

Product Specifications Rev. 0.1
Model Number WL22-PC
Description Wave2Net IEEE802.11b+ Wireless LAN PC Card
Interface Type II CardBus Card
Radio Specifications
Radio Type DSSS
Data Rate 22, 11, 5.5, 2, 1 Mbps
Antenna Internal Patch DiversityAntenna
Frequency Band ( ISM Band)
And Operating Channels
(802.11g compliant)
Japan-2471MHz–2497 MHz(14 Channels)
North America, Europe and Extended Japan -2400MHz –2483.5MHz(11 Channels)
Spain -2455MHz–2475MHz(13 channels)
France -2446.5MHz –2483.5MHz(13 channels)
Type of Modulation BPSK, QPSK, CCK, PBCC
Receiver Sensitivity -80 dBm (@25°C±5°C)
Operating Range
Open Environment 22Mbps –100M
11Mbps –150M
5.5Mbps –250M
2Mbps–300M
1Mbps–350M
Transmit Power 15 dBm (Maximum)
Operation Humidity 15% ~ 95% Non-condensing
Operation Temperature 32°F to 131°F ( 0°C to 55°C)
Storage Temperature -4°F to 176°F ( -20°C to 80°C)
Power Consumption TX:650mA (max)
RX: 350mA
Encryption 64 / 128/ 256bit WEP
Physical Specifications
Size 128mm x 54mm x 9.6mm (Non –detachable card)
Weight 1.75 oz. ( 50 g)
LED
Power Status
Unlighted: Power Off
Red color LED steady on: Power On
RF TX/RX Unlighted: No Activity
Green color LED blinking: TX/RX Activity
System Requirements Notebook with 32-bit CardBus Card
Operating System Support Windows XP / 2000 / ME / 98SE
Standard Conformance IEEE 802.11b+ USA: FCC
Europe: CE
Warranty 1 – Year Limited
22 Mbps Wireless LAN PC Card
Model: WL22-PC
