Ambient Weather WS-1172 User manual

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather WS-1172 Advanced Weather Station
User Manual
Table of Contents
1. Introduction.....................................................................................................................................2
2. Getting Started ................................................................................................................................2
2.1 Parts List .......................................................................................................................................2
2.2 Recommend Tools.........................................................................................................................2
2.3 Thermo-Hygrometer Sensor Set Up..............................................................................................2
2.4 Display Console Set Up................................................................................................................3
2.4.1 Radio Controlled Clock (RCC)..............................................................................................3
2.4.2 Display Console Layout.....................................................................................................4
2.4.3 Sensor Operation Verification............................................................................................5
3. Remote Sensor Installation .............................................................................................................5
4. Console Operation...........................................................................................................................5
4.1 Quick Display Mode.....................................................................................................................5
4.2 Set (Program) Mode......................................................................................................................6
4.2.1 Setting Barometric Pressure...................................................................................................8
4.2.2 Setting Calibrated Humidity...............................................................................................8
4.3 Alarm Mode ...........................................................................................................................9
4.3.1 Alarm Display ........................................................................................................................9
4.3.2 Alarm Programming...........................................................................................................9
4.3.3 Cancelling the Alarm........................................................................................................10
4.3.4 Outdoor Alarm –Temperature vs. Dew Point..................................................................10
4.4 Min/Max Mode ...........................................................................................................................10
4.5 Other Console Features ........................................................................................................ 11
4.5.1 Weather Forecasting......................................................................................................... 11
4.5.2 Weather Icons................................................................................................................... 11
4.5.3 Weather tendency indicator.............................................................................................. 11
4.5.4 Storm threshold indicator.................................................................................................12
4.5.5 Pressure threshold setting.................................................................................................12
4.5.6 Pressure Graph.................................................................................................................13
5. Glossary of Terms .........................................................................................................................13
6. Specifications................................................................................................................................13
6.1 Wireless Specifications ...............................................................................................................13
6.2 Measurement Specifications .......................................................................................................14
6.3 Power Consumption....................................................................................................................14
7. Troubleshooting Guide..................................................................................................................14
8. Accessories ...................................................................................................................................16
9. Liability Disclaimer ......................................................................................................................16
10. FCC Statement..........................................................................................................................16
11. Warranty Information ...............................................................................................................17

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 2
1. Introduction
Thank you for your purchase of the Ambient Weather WS-1172 Advanced Weather Station with
Temperature, Humidity, Barometer and Advanced Forecasting. The following user guide provides step
by step instructions for installation, operation and troubleshooting. To download the latest manual and
additional troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws1172
2. Getting Started
Note: The power up sequence must be performed in the order shown in this section (remote
transmitter first, Display Console second).
The WS-1172 weather station consists of a display console (receiver), and a thermo-hygrometer
(remote transmitter).
2.1 Parts List
QTY
Item
1
Display Console
Frame Dimensions (LxWxH): 7.25 x 4 x 1.25 in
LCD Dimensions (LxW): 4.25 x 2.50”
1
Thermo-hygrometer transmitter (WH2B) with mounting bracket
Dimensions (LxWxH): 3.5” x 2.5” x 0.9”
2.2 Recommend Tools
Philips precision screwdriver
Drill for mounting bracket
2.3 Thermo-Hygrometer Sensor Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Remove the battery door on the back of the sensor with a Philips screwdriver (there is only one screw,
at the bottom of the unit). Insert two AAA batteries as shown in Figure 1 (we recommend lithium
batteries for cold weather climates, but alkaline batteries are sufficient for most climates).
Replace the battery door and set screw. Note that the temperature and humidity will be displayed on
the LCD display. Looking at the back of the unit from left to right, the polarity is (-) (+) for the top
battery and (+) (-) for the bottom battery.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 3
Figure 1
2.4 Display Console Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Move the remote thermo-hygrometer at least 10’ away from the display console (if the sensor is too
close, it may not be received by the display console).
Remove the battery door on the back of the display. Insert three AA (alkaline or lithium, avoid
rechargeable) batteries in the back of the display console. Looking at the back of the unit (left to right),
the polarity is (+) (-) for the top battery, (-) (+) for the middle battery and (+) (-) for the bottom battery.
The display will beep once and all of the LCD segments will light up for a few seconds to verify all
segments are operating properly.
Replace the battery door, and fold out the desk stand and place the console in the upright position.
The console will instantly display indoor temperature, humidity, barometer, tendency, date and time.
The outdoor temperature and humidity will update on the display within a few minutes. Do not touch
any buttons until the remote sensor reports in, otherwise the remote sensor search mode will be
terminated. When the remote sensor data has been received, the console will automatically switch to
the normal mode, and all further settings can be performed.
If the remote does not update, please reference the troubleshooting guide in Section 7.
2.4.1 Radio Controlled Clock (RCC)
The RCC is received by the remote sensor and transmitted to the main console to improve reception.
After the remote sensor is powered up, the sensor will transmit weather data for 30 seconds, and then
the sensor will begin radio controlled clock (RCC) reception. During the RCC time reception period
(maximum 10 minutes), no weather data will be transmitted to avoid interference.
If the signal reception is not successful within 1 minute, the signal search will be cancelled and will
automatically resume every two hours until the signal is successfully captured. The regular RF link
will resume once RCC reception routine is finished. In some locations, it may take a couple of days to
receive the radio control signal.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 4
2.4.2 Display Console Layout
The following illustration shows a simple layout of the WS-1172 display screen.
Figure 2
1. Weather forecast icon
7. RCC icon (flashes on, then off when updating,
normally off)
2. Weather tendency indicator
8. Time (hour:minute:second)
3. Pressure with 24 hour history graph (3
hours per bar)
9. Date
4. Outdoor temperature (°F or °C)
10. Outdoor humidity (%)
5. Outdoor humidity (%)
11. Indoor temperature (°F or °C)
6. Day of week (MON-SUN)
12. Barometric Pressure (inHg or hpa)

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 5
2.4.3 Sensor Operation Verification
Verify the indoor and outdoor humidity match closely with the console and sensor array in the same
location (about 10’ apart). The sensors should be within 10% (the accuracy is ± 5%). Allow about 30
minutes for both sensors to stabilize.
Verify the indoor and outdoor temperature match closely with the console and sensor array in the same
location (about 10’ apart). The sensors should be within 4°F (the accuracy is ± 2°F). Allow about 30
minutes for both sensors to stabilize.
3. Remote Sensor Installation
It is recommended you mount the remote sensor on a north facing wall, in a shaded area. Direct
sunlight and radiant heat sources will result in inaccurate temperature readings. Although the sensor is
water resistant, it is best to mount in a well protected area, such as an eve.
Use 3 screws to affix the mounting bracket to the wall with a precision screwdriver. Connect the
remote sensor to the wall bracket by snapping into place.
Figure 3
4. Console Operation
Note: The console has four keys for easy operation: SET key, ALARM key, MIN/MAX key and
+key. There are four program modes: Quick Display Mode, Set Mode, Alarm Mode and Min/Max
Mode.
Any program mode can be exited at any time by either pressing the SNOOZE/LIGHT key (on the top
of the display console), or waiting for the 10-second time-out to take effect.
4.1 Quick Display Mode
While in Normal Mode, press the SET key to enter the Quick Display Mode as follows (once for
outdoor temperature and dew point and twice for absolute pressure and relative pressure):
1. Display Outdoor Temperature and Dew Point. Press the MIN/MAX or +key to toggle
between outdoor temperature and dew point.
2. Absolute Pressure and Relative Pressure. Press the MIN/MAX or +key to toggle between
absolute pressure and relative pressure.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 6
4.2 Set (Program) Mode
While in Normal Mode, press and hold the SET key for at least three seconds to enter the Set Mode.
The first setting will begin flashing. You can press the SET key again to skip any step, as defined
below.
Note: In the Set mode, press the +key or MIN/MAX key to change or scroll the value. Hold
the +key or MIN/MAX key for 3 seconds to increase/decrease rapidly.
Note: Press the SNOOZE key (or wait 10 seconds), and the Set Mode will return to Normal
Mode.
1. Daylight Savings Time (DST). The DST (ON or OFF) setting will begin flashing. Press the
+key to toggle between DST ON and DST OFF.
2. Time Zone Settings. Press the SET key again to adjust the Time Zone (TZ) setting.
Press the +key or MIN/MAX key to adjust the time zone from -12 to 12, based on the
number of hours from Coordinated Universal Time, or Greenwich Mean Time (GMT).
The following table provides times zones throughout the world. Locations in the eastern
hemisphere are positive, and locations in the western hemisphere are negative.
Hours from
GMT
Time Zone
Cities
-12
IDLW: International Date Line West
---
-11
NT: Nome
Nome, AK
-10
AHST: Alaska-Hawaii Standard
CAT: Central Alaska
HST: Hawaii Standard
Honolulu, HI
-9
YST: Yukon Standard
Yukon Territory
-8
PST: Pacific Standard
Los Angeles, CA, USA
-7
MST: Mountain Standard
Denver, CO, USA
-6
CST: Central Standard
Chicago, IL, USA
-5
EST: Eastern Standard
New York, NY, USA
-4
AST: Atlantic Standard
Caracas
-3
---
São Paulo, Brazil
-2
AT: Azores
Azores, Cape Verde Islands
-1
WAT: West Africa
---
0
GMT: Greenwich Mean
WET: Western European
London, England
1
CET: Central European
Paris, France
2
EET: Eastern European
Athens, Greece
3
BT: Baghdad
Moscow, Russia
4
---
Abu Dhabi, UAE
5
---
Tashkent
6
---
Astana
7
---
Bangkok
8
CCT: China Coast
Bejing
9
JST: Japan Standard
Tokyo

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 7
Hours from
GMT
Time Zone
Cities
10
GST: Guam Standard
Sydney
11
---
Magadan
12
IDLE: International Date Line East
NZST: New Zealand Standard
Wellington, New Zealand
3. 12/24 Hour Format. Press the SET key again to adjust the 12/24 hour format setting. Press
the +key to change between 12 hour and 24 hour format.
4. Change Hour. Press the SET key again to set the hour. Press the +key or MIN/MAX key to
adjust the hour up or down.
5. Change Minute. Press the SET key again to set the minute. Press the +key or MIN/MAX
key to adjust the minute.
6. Change Year. Press the SET key again to set the calendar year. Press the +key or
MIN/MAX key to adjust the calendar year.
7. Change Month. Press the SET key again to set the calendar month. Press the +key or
MIN/MAX key to adjust the calendar month.
8. Change Day. Press the SET key again to set the calendar day. Press the +key or MIN/MAX
key to adjust the calendar day.
9. Temperature Units (Celsius or Fahrenheit). Press the SET key again to toggle the
temperature units from Celsius to Fahrenheit.
10. Indoor Humidity Calibration (default is measured indoor humidity). Press the SET key to
adjust the indoor humidity. Press the +key or MIN/MAX key to adjust the relative humidity
up or down in 1% increments.
To view the uncalibrated value, press the ALARM key while the humidity is flashing.
Reference Section 4.2.2 Setting Calibrated Humidity for more details on this function.
11. Outdoor Humidity Calibration (default is measured outdoor humidity). Press the SET key
to adjust the outdoor humidity. Press the +key or MIN/MAX key to adjust the relative
humidity up or down in 1% increments.
To view the uncalibrated value, press the ALARM key while the humidity is flashing.
Reference Section 4.2.2 Setting Calibrated Humidity for more details on this function.
12. Barometric Pressure Display Units (hPa or inHg). Press the SET key again to toggle the
pressure units between hPa or inHg.
13. Relative Pressure Calibration (default is 29.92 inHg). Press the SET key to adjust the
relative barometric pressure. Press the +key or MIN/MAX key to adjust the relative
barometric pressure up or down. Reference Section Error! Reference source not found. for
more details on this function.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 8
14. Pressure Threshold Setting (default level 2). Press the SET key again to adjust the
pressure threshold setting. Press the +key or MIN/MAX key to adjust the pressure
threshold up or down. Reference Section Error! Reference source not found. for more details
on this function.
15. Storm Threshold Setting (default level 4). Press the SET key again to adjust the storm
threshold setting. Press the +key or MIN/MAX key to adjust the storm threshold up or
down. Reference Section Error! Reference source not found. for more details on this
function.
4.2.1 Setting Barometric Pressure
Note: This is a continuation of the previous section. To enter this mode, you must start at the
beginning of this section.
The display console displays two different pressures: absolute (measured) and relative (corrected to
sea-level).
To compare pressure conditions from one location to another, meteorologists correct pressure to
sea-level conditions. Because the air pressure decreases as you rise in altitude, the sea-level corrected
pressure (the pressure your location would be at if located at sea-level) is generally higher than your
measured pressure.
Thus, your absolute pressure may read 28.62 inHg (969 mb) at an altitude of 1000 feet (305 m), but
the relative pressure is 30.00 inHg (1016 mb).
The standard sea-level pressure is 29.92 in Hg (1013 mb). This is the average sea-level pressure
around the world. Relative pressure measurements greater than 29.92 inHg (1013 mb) are
considered high pressure and relative pressure measurements less than 29.92 inHg are considered low
pressure.
To determine the relative pressure for your location, locate an official reporting station near you (the
internet is the best source for real time barometer conditions, such as Weather.com or
Wunderground.com), and set your weather station to match the official reporting station.
To change the relative pressure in the SET mode, press the +key or MIN/MAX key to increase or
decrease the relative pressure setting to match the official reporting station.
4.2.2 Setting Calibrated Humidity
Note: This is a continuation of the previous section. To enter this mode, you must start at the
beginning of this section.
The display console allows you to calibrate both the indoor and outdoor humidity. Humidity is a
difficult parameter to measure accurately and drifts over time. The calibration feature allows you to
zero out this error. To calibrate humidity, you will need an accurate source, such as a sling
psychrometer or Humidipaks One Step Calibration kit, available from Ambient Weather, which uses a
salt bath.
To calibrate indoor humidity, in the Set Mode with indoor humidity flashing, press the +key or

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 9
MIN/MAX key to increase or decrease the humidity setting (in increments of 1%) to match the
calibrated or known humidity source. To return the indoor humidity to the measured value, press and
hold the SET key for 3 seconds and the humidity will return to the uncalibrated value.
Note: The remote (outdoor) thermo-hygrometer will always display the measured humidity level
and not the calibrated humidity level. Only the console will show the calibrated value.
Note: The dew point calculation is based on the calibrated humidity level.
4.3 Alarm Mode
4.3.1 Alarm Display
While in Normal Mode, press the ALARM key to enter the High Alarm Mode. HIAL will be
displayed. Press the ALARM key again to enter the Low Alarm Mode. LOAL will be displayed.
Press the ALARM key again to return to normal mode (or wait 10 seconds).
Note: After entering the ALARM mode, the console will display the high and low alarm
settings. If the value reads --.-- (dashes), the alarm is not active.
4.3.2 Alarm Programming
While in Alarm Mode, press the SET key to set the alarms. The following are high and low alarms:
High Alarm Limits:
Time alarm (hour/minute)
Indoor humidity high alarm
Indoor temperature high alarm
Outdoor humidity high alarm
Outdoor temperature / dew point high alarm
Pressure high alarm
Low Alarm Limits:
In the Low Alarm Mode press the SET key to select the following alarm modes:
Time alarm (hour/minute)
Indoor humidity low alarm
Indoor temperature low alarm
Outdoor humidity low alarm
Outdoor temperature / dew point low alarm
Pressure low alarm
In the alarm mode, Press the +key or MIN/MAX key to change or scroll the alarm value.
Hold the +key or MIN/MAX key for 3 seconds to change the number rapidly. Press the ALARM key
to select the alarm on or off (if alarm is enabled, the speaker icon on the LCD will be turned on
indicating the alarm function has been enabled).
Press the SET key to confirm the setting and continue pressing the SET key to toggle through each
alarm mode until it returns to the normal display mode.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 10
When an alarm has been set, the alarm icon will be displayed . When an alarm condition
sounds, the unit will beep and the alarm icon will flash.
Press the SNOOZE key, and the alarm will stop beeping and the alarm icon will continue to flash, and
sound again in 10 minutes.
4.3.3 Cancelling the Alarm
When an alarm condition has been activated, the specific alarm will sound and flash for 120 seconds.
Press any key (other than the SNOOZAE key) to cancel the alarm.
When an alarm condition is activated again within 10 minutes, the alarm will not sound but will
continue to flash until the weather condition is stable. This feature is useful to avoid repeated
triggering for the same alarm value.
The alarm will reset automatically once the value has fallen below the set value, or if a new value is
entered.
4.3.4 Outdoor Alarm –Temperature vs. Dew Point
When the outdoor weather alarm has been triggered, it will flash on the LCD display and the general
outdoor alarm icon and high/low alarm icon will flash. For example, in the outdoor temperature
display mode, when dew point high alarm is triggered the DEW POINT icon will flash along with
general outdoor alarm icon and high alarm icon, indicating that the current alarm source is from dew
point, as shown in Figure 4.
Figure 4
4.4 Min/Max Mode
While in Normal Mode, press the MIN/MAX key to enter the maximum mode, and the MAX icon
and maximum records will be displayed and begin flashing.
Press MIN/MAX key again to enter the minimum mode, and the MIN icon and minimum records will
be displayed and begin flashing.
Press MIN/MAX key again to return the Normal Mode.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 11
In the maximum (or minimum) reading Mode, press the +key to display the specific maximum (or
minimum) value you wish to reset. This value will begin flashing with the time and date time stamp at
which the maximum (or minimum) value occurred. Select the +key again to proceed to the next
parameter, in the following order:
1. Indoor humidity maximum (or minimum)
2. Indoor temperature maximum (or minimum)
3. Outdoor humidity maximum (or minimum)
4. Outdoor temperature maximum (or minimum)
5. Pressure maximum (or minimum)
Press the SET key for two seconds to reset the specific value (that is flashing) and associated date and
time to the current reading.
Press the SNOOZE key or wait 10 seconds, and the Min/Max mode will return to Normal Mode.
4.5 Other Console Features
The following section describes additional console features.
4.5.1 Weather Forecasting
Note: The weather forecast or pressure tendency is based on the rate of change of barometric
pressure. In general, when the pressure increases, the weather improves (sunny to partly cloudy) and
when the pressure decreases, the weather degrades (cloudy to rain).
The weather forecast is an estimation or generalization of weather changes in the next 24 to 48 hours,
and varies from location to location. The tendency is simply a tool for projecting weather conditions
and is never to be relied upon as an accurate method to predict the weather. ***
4.5.2 Weather Icons
Sunny
Partly Cloudy
Cloudy
Rainy
The four weather icons are Sunny, Partly Cloudy, Cloudy and Rainy. There are also two weather
tendency indicators to show the air pressure tendency between the weather icons.
4.5.3 Weather tendency indicator
The weather tendency arrow is located between the weather icons to show the air pressure tendency
and provide a forecast based on increasing or decreasing air pressure.
The arrow pointing to the right indicates that the air pressure is increasing and the weather is expected
to improve. The arrow pointing the left indicates that the air pressure is decreasing and the weather is
expected to deteriorate.
The weather tendency is based on the pressure change since last six hours. If the weather is changing,

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 12
the weather tendency indicator (animated arrows) will flash for three hours, indicating the weather is
expected to change. If the weather conditions become stable and no new weather change conditions
are met, then the arrows will be fixed.
Example 1: Pressure is decreasing, weather is deteriorating.
Example 2: Pressure is increasing, weather is improving.
4.5.4 Storm threshold indicator
The storm threshold (the negative rate of pressure change signifying a storm is expected) can be
adjusted by the user from level 3 to level 9 (the default level 4 mbar/hour).
When negative rate of change of pressure is exceeded for 3 hours, the storm warning indicator will be
activated, and the clouds with rain icon and tendency arrows will flash for 3 hours indicating the storm
warning feature has been activated.
4.5.5 Pressure threshold setting
The pressure threshold (the negative or positive rate of change of pressure signifying a change in the
weather) can be adjusted by the user from level 2 to level 4 (default level 2 mbar/hour).
The lower the level pressure threshold setting, the higher sensitivity for weather forecast changes.
Locations that experience frequent changes in air pressure require a higher setting compared to
locations where the air pressure is typically stagnant.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 13
4.5.6 Pressure Graph
Note: The weather station bar graph flashes from right to left to prevent screen burn in. This
feature cannot be turned off.
The pressure graph displays the barometric pressure for the last 24 hours. Each bar represents three
hours.
5. Glossary of Terms
Term
Definition
Absolute Barometric
Pressure
Relative barometric pressure, corrected to sea-level. To compare
pressure conditions from one location to another, meteorologists correct
pressure to sea-level conditions. Because the air pressure decreases as
you rise in altitude, the sea-level corrected pressure (the pressure your
location would be at if located at sea-level) is generally higher than your
measured pressure.
Accuracy
Accuracy is defined as the ability of a measurement to match the actual
value of the quantity being measured.
HectoPascals (hPa)
Pressure units in SI (international system) units of measurement. Same
as millibars (1 hPa = 1 mbar)
Hygrometer
A hygrometer is a device that measures relative humidity. Relative
humidity is a term used to describe the amount or percentage of water
vapor that exists in air.
Inches of Mercury (inHg)
Pressure in Imperial units of measure.
1 inch of mercury = 33.86 millibars
Range
Range is defined as the amount or extent a value can be measured.
Relative Barometric
Pressure
Measured barometric pressure relative to your location or ambient
conditions.
6. Specifications
6.1 Wireless Specifications
Line of sight wireless transmission (in open air): 300 feet
Frequency: 433 MHz
Update Rate: 48 seconds

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 14
6.2 Measurement Specifications
The following table provides specifications for the measured parameters.
Measurement
Range
Accuracy
Resolution
Indoor Temperature
32 to 140 °F
± 2 °F
0.1 °F
Outdoor Temperature
-40 to 149 °F
± 2 °F
0.1 °F
Indoor Humidity
1 to 99 %
± 5% (only guaranteed
between 20 to 90%)
1 %
Outdoor Humidity
1 to 99%
± 5% (only guaranteed
between 20 to 90%)
1 %
Barometric Pressure
8.85 to 32.50 inHg
± 0.08 inHg (within
range of 27.13 to 32.50
inHg)
0.01 inHg
6.3 Power Consumption
Base station : 3 x AA 1.5VAlkaline batteries
Remote sensor : 2 x AAA 1.5V Alkaline batteries
Battery life: Minimum 12 months for base station
Minimum 24 months for thermometer-hygrometer sensor (use lithium batteries in cold
weather climates)
7. Troubleshooting Guide
If your question is not answered here, you can contact us as follows:
1. Email Support: [e-mail]
2. Live Chat Support: www.ambientweather.com/chat.html (M-F 8am to 4pm Arizona Time)
3. Technical Support: 480-283-1644 (M-F 8am to 4pm Arizona Time)
Problem
Solution
Wireless remote (thermo-hygrometer) not
reporting in to console.
There are dashes on the display console.
The maximum line of sight communication range is
300’. Move the sensor assembly closer to the display
console.
If the sensor assembly is too close (less than 10’), move
the sensor assembly away from the display console.
Cycle power on the console. The console may have
exited the search mode.
Install a fresh set of batteries in the remote
thermo-hygrometer. For cold weather environments,
install lithium batteries.
Make sure the remote sensors are not transmitting
through solid metal (acts as an RF shield), or earth
barrier (down a hill).
Move the display console around electrical noise
generating devices, such as computers, TVs and other

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 15
wireless transmitters or receivers.
Move the remote sensor to a higher location. Move the
remote sensor to a closer location.
Radio Frequency (RF) Sensors cannot transmit through
metal barriers (example, aluminum siding) or multiple,
thick walls.
Temperature sensor reads too high in the
day time.
Make sure the thermo-hygrometer is mounted in a
shaded area on the north facing wall. Consider the
following radiation shield if this is not possible:
http://www.ambientweather.com/amwesrpatean.html
Indoor and Outdoor Temperature do not
agree
Allow up to one hour for the sensors to stabilize due to
signal filtering. The indoor and outdoor temperature
sensors should agree within 4 °F (the sensor accuracy is
± 2 °F).
Indoor and Outdoor Humidity do not
agree
Allow up to one hour for the sensors to stabilize due to
signal filtering. The indoor and outdoor humidity sensors
should agree within 10 % (the sensor accuracy is ± 5 %).
Use the calibration feature to match the indoor and
outdoor humidity to a known source.
Console outdoor humidity and remote
humidity do not agree.
The console displays the calibrated humidity. The remote
displays the measured humidity only. Refer to 4.2.2 to
set and reset the humidity calibration.
Relative pressure does not agree with
official reporting station
You may be viewing the absolute pressure, not the
relative pressure.
Select the relative pressure. Make sure you properly
calibrate the sensor to an official local weather station.
The barometer is only accurate to ± 0.08 inHg within the
following absolute pressure range: 27.13 to 32.50 inHg,
which corresponds to an altitude of -2,200 to 2,700 feet.
At higher altitudes, expect some non-linearity or error.
The forecast icon is not accurate
The weather station console must run for several days to
trend barometric pressure.
The weather forecast is an estimation or generalization of
weather changes in the next 24 to 48 hours, and varies
from location to location. The tendency is simply a tool
for projecting weather conditions and is never to be
relied upon as an accurate method to predict the weather.
Display console contrast is weak
Replace console batteries with a fresh set of batteries.

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 16
8. Accessories
The following software and hardware accessories are available for this weather station at
www.AmbientWeather.com .
Accessory
Description
Energizer AA Lithium
Battery (2-pack) - Batteries
for Long Life and Cold
Climates
AA lithium batteries for cold weather
climates.
Ambient Weather
SRS100LX Temperature
and Humidity Solar
Radiation Shield
Solar Radiation Shield improves temperature
accuracy for hot weather climates. Remove
the rain guard and install over
thermo-hygrometer.
Ambient Weather Humidity
Calibration Kits
One step calibration kits for digital
hygrometers use salt slurry formula to
accurately calibrate the indoor and outdoor
hygrometers.
9. Liability Disclaimer
Please help in the preservation of the environment and return used batteries to an authorized depot.
The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in
wild country and/or in unauthorized grounds strongly damages the environment.
Reading the “User manual” is highly recommended. The manufacturer and supplier cannot accept any
responsibility for any incorrect readings and any consequences that occur should an inaccurate reading
take place.
This product is designed for use in the home only as indication of weather conditions. This product is
not to be used for medical purposes or for public information.
The specifications of this product may change without prior notice.
This product is not a toy. Keep out of the reach of children.
No part of this manual may be reproduced without written authorization of the manufacturer.
Ambient, LLC WILL NOT ASSUME LIABILITY FOR INCIDENTAL, CONSEQUENTIAL,
PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE OPERATION OR
MALFUNCTION OF THIS PRODUCT.
10. FCC Statement
Statement according to FCC part 15.19:
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Statement according to FCC part 15.21:

Version 1.0 ©Copyright 2012, Ambient LLC. All Rights Reserved. Page 17
Modifications not expressly approved by this company could void the user's authority to operate the
equipment.
Statement according to FCC part 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
11. Warranty Information
Ambient, LLC provides a 1-year limited warranty on this product against manufacturing defects in
materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products purchased and
only to the original purchaser of this product. To receive warranty service, the purchaser must contact
Ambient, LLC for problem determination and service procedures.
Warranty service can only be performed by a Ambient, LLC. The original dated bill of sale must be
presented upon request as proof of purchase to Ambient, LLC.
Your Ambient, LLC warranty covers all defects in material and workmanship with the following
specified exceptions: (1) damage caused by accident, unreasonable use or neglect (lack of reasonable
and necessary maintenance); (2) damage resulting from failure to follow instructions contained in your
owner’s manual; (3) damage resulting from the performance of repairs or alterations by someone other
than an authorized Ambient, LLC authorized service center; (4) units used for other than home use (5)
applications and uses that this product was not intended (6) the products inability to receive a signal
due to any source of interference or metal obstructions and (7) extreme acts of nature, such as
lightning strikes or floods.
This warranty covers only actual defects within the product itself, and does not cover the cost of
installation or removal from a fixed installation, normal set-up or adjustments, claims based on
misrepresentation by the seller or performance variations resulting from installation-related
circumstances.
