AMC XIA30 User guide

IA
ON
OFF
PHONOCDTUNERAUX
iPod/DACVIDEO
1
4
7
2
5
8
0
3
6
9
VOLUME
CD
CDUSB24192
PLAY/PAUSE
STOP
TRK/TITLE
DIRECT
AM
FM
AUTO
MANUAL
PRESET
DAB+
SELECT
INFO
ENTER/M
RC-S8
XIA30
XIA50
STEREO INTEGRATED
AMPLIFIER

2
The AMC remote controllable integrated
amplifiers XIA30/XIA50 offer in an
innovative and elegant design, an
affordable combination of high quality
sound reproduction and comprehensive
facilities.
The integrated amplifier accepts five
inputs (Phono, CD, Tuner, Aux/USB and
Tape), is compatible with both moving
magnet and moving coil cartridges, has
full tape monitoring capabilities and also
both a direct switch, allowing the tone
control circuitry to be by-passed for
improved sound quality.
To get the best from your amplifier
please study this manual carefully.
Should you experience any problems,
please discuss them with your dealer
who has a full knowledge of AMC
products and their use in a variety of
systems.
If the mains plug is fused, fit a 3amp
fuse. Your AMC amplifier contains fuses
which are designed to protect the
amplifier and prevent the occurrence of
a dangerous fault condition. These
should only be inspected and replaced
by a conpetent engineer using the
correct replacement types.
*Unique phono stage design that employs
two audiophile grade op-amps per
channel that provide very low THD, TIM
and noise, together with switchable
MM/MC sensitivities.
*The high overload tone control stage can
be completely by-passed with the
DIRECT switch to give natural sound
quality.
*Special designed passive tone control
circuit to give natural sound quality.
*Uses audiophile grade components
throughout, providing exceptional
accuracy to phono and tone control
responses.
*High overload margin on tone control
circuit by virtue of its topologies.
*Power amplifiers with 30 Amp high peak
output current devices to offer
capabilities to drive almost all types of
speaker systems.
*Power amplifiers with special designed
perfect virtual image topology to make it
possible to be without output relays. The
topology connects amplifier outputs to
speaker systems without relay contacts
to offer best possible sound quality.
*Using high output current devices with
optimized power supply designs, the
power amplifiers can be only protected
with fuses on power supplier side in
order to delivery extremely high output
current in demand to give superb sound
quality.
*Heavy duty gold plated speaker binding
posts and phono connectors for ultra
reliable connections.
INSTALLATION
Your AMC amplifier is supplied set to
work on your local mains supply voltage.
Check that your local mains supply
voltage agrees with the voltage setting
indicated on the back panel of the
amplifier. If not, please set the AC
Select Switchon back panel to your
local mains supply voltage.
FUSES
*AMC XIA30/XIA50 is designed with
option of USB connector for networking
to other equipments, computer, LAN and
so the Internet.
*AMC XIA30/XIA50 creates CD quality
sound from computer and Internet
through the USB linking system
designed in AMC IA system.
*With universal power transformer passed
all international safety standards, end
users can use the unit in all countries by
re-setting the AC select to correct
voltage.
Note: All Connection must be completed
and AC Select Switch should be set to
correct voltagebefore plugging in powwr
cord and turning the power on.
INTRODUCTION FEATURE

AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
PHONO AUX TUNER CD IN TAPE OUT PRE OUT MAIN IN
RL
SPEAKERS
IMPEDANCE
SPEAKERS
R R
L L
GROUND
MC/MM
4W8W
WELTRONICS CORP.
LONDON/L.A.
180W 115V/60Hz 230V/50Hz
DESIGNED AND ENGINEERED IN LONDON/LOS ANGELES
PRODUCED TO IEEE GROUP QUALITY STD IN TAIWAN
POWER RATING
SERIAL NUMBER
AC
Select
AC115/230V 50/60Hz MAINS
SWITCHED 0.5A MAX
11R- 8466- 7
Stereo Integrated Amplifier
XIA30
XIA50
1.PHONO GROUND TERMINAL
2.PHONO MM/MC INPUT SELECTION SWITCH
3.PHONO INPUT
4.AUX INPUT
5.TUNER INPUT
6.CD INPUT
7.TAPE INPUT
8.TAPE OUTPUT
9.PRE OUT/MAIN IN
10.LOUDSPEAKER TERMINALS
11.SPEAKER IMPEDANCE SELECTION
SWITCH (XIA30 ONLY)
12.AC SELECT SWITCH
13.AC SWITCHED OUTLET
14.AC RECEPTACLE
15.USB (OPTION) (XIA50 ONLY)
3
REAR PANEL
1
2
5
34
6
7
8
9
10 1211 13 14
REAR PANEL CONNECTIONS/FRONT PANEL CONTROLS
15
2
1
5
34
6 7 8 9 10 12 13 14

1.POWER SWITCH
2.INFRARED RECEIVER
3.BALANCE CONTROL
4.PHONES
5.MUTE/NORMAL/DIRECT
SWITCH
6.BASS CONTROL
7.TREBLE CONTROL.
8.TAPE MONITOR SWITCH
9.INPUT SELECTION SWITCH
10.VOLUME CONTROL
FRONT PANEL
1 23 54678 9 10
1 23 54678 9 10
4

5
A/C OUTLET
INPUTS
The A/C convenience outlet is fitted so
that other components can be powered
when the AC line cord of your amplifier is
plugged into mains outlet.
You must fit an Standard 3 pin plug,
available from most specialist dealers.
All audio Inputs and tape outputs are via
gold plated RCA type phono connectors.
All the phono sockets on your AMC
amplifier are marked "L" for left and "R"
for right channels, with the left channels
nearer the top of the cabinet. Your
connection leads will have a white or
black plug for left, and a red plug for right.
Note: The A/C outlet is UNSWITCHED by
the power switch on your amplifier.
The maxinum output current rating
of A/C outlet is 1A.
UNDER NO CIRCUMSTANCES SHOULD
THE CASE OF THE AMPLIFIER BE
OPENED BY ANYONE OTHER THAN A
QUALIFIED ENGINEER, AS DANGEROUS
VOLTAGES ARE PRESENT INSIDE. ANY
UNAUTHORIZED REPAIR MAY INVALIDATE
YOUR WARRANTY.
USB CONNECTOR (XIA50 only)
PHONO INPUT (OPTION COAXIAL IN)
Note:
CD INPUT
TUNER INPUT
AUXILIARY INPUT
TAPE INPUT
The USB connector is for connecting to
computer, other equipments with USB,
LAN and so the Internet.
The analog output of the USB connector
is in parallel with auxiliary input.
This input is suitable for both moving
magnet and moving coil cartridges. For
either type of cartridge the plugs on your
turntable lead should be connected to the
phono input sockets on the rear panel of
your amplifier.
A switch adjacent to the disc input
sockets allows the selection of either MM
or MC input. Facing the back of the
amplifier, move the switch to the right for
use with MM or high output MC cartridges
and to the left for use with normal(low
output) MC cartridges.
Never operate the MM/MC selector
switch with the volume control turned up
as the resultant electrical surge may
damage your loudspeakers.
To minimize hum the turntable lead
should be kept away from the mains
wiring, and any separate turntable ground
lead should be attached firmly to the
earth terminal on the rear of the amplifier.
The PHONO can be replaced with AMC
proprietary designed DAC to convert the
PHONO INPUT into a COAXIAL INPUT.
The CD input is suitable for use with any
CD player. Connect your CD player to the
amplifier using the phono sockets marked
"CD".
The Tuner input is suitable for use with
most AM/FM tuners. Connect your tuner
to the amplifier using the phono sockets
marked "Tuner".
The Auxiliary input is suitable for use with
any extra source processing a line level
output, perhaps a second tuner or CD
player, or an additional tape or video
recorder wired for replay only.
The auxiliary input is in parallel with the
analog output of the USB connector.
This input is suitable for use with most
cassette, reel to reel or video recorders.
Connect the "record" leads of your tape
recorder to the phono sockets marked
"Tape out" on the rear of your amplifier
using phono/phono leads.

6
Connect the "playback" leads of your tape
recorder to the phono sockets marked
"Tape in" on the rear of your amplifier
using phono/phono leads. If your tape
machine processing DIN outputs, then
DIN/phono leads, or a DIN/phono adaptor
can be used. If you experience level
matching problems when using DIN
connectors, please consult your tape
machine manufacturer.
Normally the pre-amplifier and power
amplifier sections of this unit are
connected together via factory-installed
U-shaped metal jumpers that bridge the
PRE-OUT and MAIN-IN jacks. Check to
be sure that they are fully inserted into
the jacks and that nothing is touching
them.
By switching OFF the power and
removing the metal jumpers, you can
connect a signal processor such as a
surround-sound decoder or an electronic
crossover in the path between preamp
and power amp. Connect a cable from
PRE-OUT to the processor's input and a
second cable from the processor's output
to MAIN IN.
PRE OUT/MAIN IN
LOUDSPEAKERS
Your AMC amplifier is designed to drive
loudspeakers with a nominal impedance
of 4-8 ohms.
However,XIA30 can only drive 4 ohm
speakers by switching the impedance
selector on the rear panel of the unit to
the 4 ohm setting.
LOUDSPEAKER CONNECTIONS
AC Selector (115V or 230V)
The loudspeaker output terminals will
accept 4mm(banana)plugs, spade
connectors, pin connectors or bare wires.
Connect the negative side(usually black)
of your left hand loudspeaker lead to the
black terminal of the two terminals
marked "left" on the rear of your amplifier.
The other side of your left hand speaker
lead (the positive side or red) should be
connected to the red terminal marked
"left". Repeat this operation for the right
hand loudspeaker.
Your AMC amplifier is capable of
generating high peak currents, so all
connections must be checked to avoid
inadvertent short circuits and to ensure a
good clean contact.
The AC Selector will be set to the AC
power voltage of your country from
factory. But in case if your XIA30/XIA50 is
not received directly from factory or you
move from one country to the other, the
AC selector might be set at different
voltage. So, before plug power cord into
UNDER NO CIRCUMSTANCES SHOULD
THE OUTPUTS BE SHORTED TOGETHER.
Such action will damage output circuitry
and is not covered by guarantee.
The heat produced by your AMC amplifier
during normal operation is dissipated by
an during normal operation is dissipated
by an internal finned heatsink. It is
perfectly normal for your amplifier to
becomes quite warm and to radiate heat
when in use, especially if it is run near full
power. However, if it becomes too hot to
touch, switch off at once and contact your
dealer.
It is very important that there is adequate
ventilation for the whole of the amplifier.
Do not place the unit on a rug or other
soft surface that it could sink into,
obstructing the air inlets on its underside,
and take care not to obstruct the outlet
grille on the top cover.
HEATSINK/VENTILATION REQUIRE-
MENTS

your wall AC outlet, please always check
if the Voltage selector set to the voltage of
the country you will use XIA30/XIA50 or
not and set to correct voltage. When the
AC Selector is set to 115VAC, the
XIA30/XIA50 can be used in countries
with AC Power Voltage between 110V
and 120V. When the AC Selector is set to
230V, the XIA30/XIA50 can be used in
countries with AC Power Voltage between
220V and 240V.
AC RECEPTACLE
The AC RECEPTACLE is for you to plug
in with power cord attached in the
packing or you can plug in with other
power cord with your preferences.
7

POWER SWITCH
Note:
BALANCE CONTROL
INPUT SELECTION
TAPE MONITOR SWITCH
The amplifier is turned on by depressing
the power switch. The small indicator
above the switch will glow blue. Before
switching on, always set the volume
control to minimum to avoid damage to
your loudspeakers.
Your AMC amplifier will play music
almost immediately after being switched
on. However, in common with other
audiophile products, the internal circuits
take some time to stabilize fully, and the
best possible sound quality may not be
obtained until the amplifier has had some
time (possibly an hour or two) to warm
up.
The Balance Control adjusts the relative
levels of the left and right channels. It has
no effect on recordings being made. A
detent at the 12 o'clock position marks
the point of equal balance. Rotation of the
Balance Control to the right (clockwise)
decreases the level of the left channel so
that only the right channel is heard.
Rotation to the left shifts the sonic image
toward the left speaker.
Adjust the Balance Control to produce a
natural spread of sound across the space
between the speakers, with any
monophonic sound (such as a radio
announcer's voice) appearing as a
phantom image centered midway
between them. Recordings often contain
small errors in channel balance, typically
no more than 2dB; but this is enough to
degrade stereo imaging. Small
compensating changes in the setting of
the Balance Control can significantly
improve the depth and stability of the
stereo image.
The rotary input selector switch selects
which input signal(Phono, CD, Tuner or
Aux/USB)is fed to the power amplifier.
The selected signal is also fed to the
"Tape out" sockets for recording.
The Tape Monitor switch is generally left
in the "Source" position, so that the
program selected by the input switch is
routed to the loudspeakers/headphones.
If the Tape Monitor switch is turned to the
"Tape" position, the signal from the tape
INFRARED RECEIVER
The infrared receiver for receiving the
infra-red signals from your remote
handset.
Recorder is routed to the loudspeakers/
headphones.
If your tape machine is a three head type
suitable for A/B monitoring, then turning
the Tape Monitor switch to the "Tape"
position will allow full off-tape monitoring
of the recorded signal to be carried out
via the loudspeakers/headphones.
The volume control adjusts the overall
loudness level of the sound. It has no
effect on the level of the signals fed to the
TAPE OUT jacks for tape recording. The
Volume control is designed for accurate
tracking of its two channels, so that the
stereo balance will not shift noticeably as
the loudness of the sound is varied.
The tone controls on your AMC amplifier
use low colouration passive circuitry to
ensure the minimum degradation of the
music signal. They are designed to
gradually modify the tonal emphasis of
the music and to compensate for such
problems as difficult room acoustics.
If required, the tone controls can be
completely by-passed with a resultant
increase in sound quality. To do this
simply turn the Direct/Mute switch to the
"Direct" position.
VOLUME CONTROL
TONE CONTROLS
FRONT PANEL CONTROLS
8

With the Direct/Mute switch in the
"normal" position, the tone controls will
cut their respective frequencies when
turned anti-clockwise and boost them
when turned clockwise. The flattest
response is found when the controls are
in the "12 o'clock position.
PHONES
MUTING
TAPE RECORDING
PLAYBACK
The headphone socket will accept any
headphones fitted with a standard
1/4"(6.35mm) stereo jack plug. When
Headphones are in use, the output to
your loudspeakers will be cut and all the
amplifier's functions will operate as
normal.
By turning the Direct/Mute switch to
"Mute" it is possible to cut the output to
your loudspeakers, a feature which will
prove useful in situations where a lower
volume level may be required for short
periods (e.g. for a phone call ect.)
All sources, Phono, CD, Tuner and Aux
can be recorded via the tape connections.
To record an input, select the required
source and set your recorder to the
record mode.
To record from one tape recorder to
another, the palyback recorder should be
plugged into the Aux/USB socket, and the
recording machine into the Tape socket.
The input selector switch should be set to
"Aux". A recording can now be made in
the normal way.
Set the Tape Monitor switch to the "Tape"
position and set your recorder into the
playback mode.
9

AMC Amps Remote Code List
Customer Code: 07FC
Function
Tuner
CD
Video
Phono/Option
Aux
iPod/DAC
Master Volume Up >
Master Volume Dn <
Hex
C0
C1
C8
C9
CA
CB
D8
D9
Type
Input
General
Input
Input
Input
Input
Input
General
Product(s)
XIA30/XIA50,XIA100/XIA150
XIA30/XIA50,XIA100/XIA150
XIA100/XIA150
XIA30/XIA50,XIA100/XIA150
XIA30/XIA50,XIA100/XIA150
XIA100/XIA150
XIA30/XIA50,XIA100/XIA150
XIA30/XIA50,XIA100/XIA150
D0
0
1
0
1
0
1
0
1
D1
0
0
0
0
1
1
0
0
D2
0
0
0
0
0
0
0
0
D3
0
0
1
1
1
1
1
1
D4
0
0
0
0
0
0
1
1
D5
0
0
0
0
0
0
0
0
D6
1
1
1
1
1
1
1
1
D7
1
1
1
1
1
1
1
1
10

11
1
2
1
1.INPUT SOURCES 2.VOLUME CONTROL
PHONO, iPod/DAC, CD, TUNER,
VIDEO, AUX - 3100MKII, 3150MKII,
CVT3030MKII, CVT1030MKII
PHONO, CD, TUNER, AUX - XIA30,
XIA50, XIA, 306d
XT - Zone key is deleted in RC-S8.
: VOLUME UP
: VOLUME DOWN
ONOFF
PHONO CD TUNER AUX
iPod/DAC VIDEO
1
4
7
2
5
8
0
3
6
9
VOLUME
CD
CD USB 24192
PLAY/PAUSE
STOP
TRK/TITLE
DIRECT
AM
FM
AUTO
MANUAL
PRESET
DAB+
SELECT
INFO
ENTER/M
RC-S8

12
SPECIFICATIONS
Weltronics Corp. reserved the right to improve its products at any time. Specifications are
subject to change without notice.
Rated Power into 8/4 ohms .............................. 30/30W
With both channels driven
Rated T.H.D.20Hz-20KHz ..
1KHz clipping power into 8/4 ohms ..................... 36/36W
High level inputs ......................................... 23mV/150mV
Phono input MM ....................................... 0.5mV/2.7mV
MC
High level inputs ..................................... 20K ohms
Phono input MM/MC ................................. 47K ohms/100pF
Tone bypass 20Hz-20KHz ........................................ +/-0.5dB
Normal 20Hz-20KHz ................................................ +/-1.0dB
High level inputs -3dB ................................... 10Hz/60KHz
High level inputs "A" WTD .................................... 88dB
Phono inputs"A" WTD ................................................. 80dB
Separation 20Hz-20KHz ...................................... >65dB
Bass at 100Hz .......................................... +/-10dB
Treble at 10KHz .......................................... -8/+11dB
Overall feedback ....................................... 26/29dB
Dimensions (W x H x D) ......................... 430x82x288 mm
Net weight ......................................................... 8.2 Kgs
Shipping weight (4 pieces) ........................................ 34.3 Kgs
Finish .................................................. black or silver
.............................. 0.05%
................................. 0.05mV/0.27mV
Input Sensitivity for 1W/Rated Power into 8 ohms:
Input impedance:
Frequency response:
Signal to noise ratio(ref.1W/8 ohms):
Tone control range:
PHYSICAL:
45/60W
-8/+11dB
26/29dB
black or silver
0.05%
48/65W
23mV/150mV
0.5mV/2.7mV
0.05mV/0.27mV
20K ohms
47K ohms/100PF
+/-0.5dB
+/-1.0dB
10Hz/60KHz
88dB
80dB
>65dB
+/-10dB
430x182x288 mm
8.2Kg
34.3Kg
XIA50XIA30

All the safety and operating instructions should be read
before the appliance is operated.
The safety and operating instructions should be retained for
future reference.
All warnings on the appliance and in the operating instructions
should be adhered to.
All operating and use instructions should be followed.
The appliance should not be used near water - for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
The appliance should be used only with a cart or stand that is
recommended by the manufacturer.
An appliance and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance
and cart combination to overturn.
This equipment is not designed for use mounted on a wall or a
ceiling.
The appliance should be situated so that its location or position
does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings, or placed in a
built-in installation, such as bookcase or cabinet that may
impede the flow of air through the ventilation openings.
The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked
on the appliance.
Power-supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from
the appliance
The appliance should be cleaned only as recommended by
the manufacturer.
The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
Care should be taken so that objects do not fall and liquids are
not spilled into the enclosure through openings.
The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing
should be referred to qualified service personnel.
The appliance should be serviced by qualified service
personnel when:
a) The power-supply cord or the plug has been damaged; or
b) Objects have fallen, or liquid has been spilled into the
appliance; or
c) The appliance has been exposed to rain; or
d) The appliance does not appear to operate normally or
exhibits a marked change in performance; or
e) The appliance has been dropped, or the enclosure is
damaged.
(APPLIES TO TUNERAND RECEIVERS ONLY)
An outdoor antenna should be located away from power lines.
(APPLIES TO TUNERAND RECEIVERS ONLY)
If an outside antenna is connected to the receiver, be sure the
antenna system is grounded so as to provide some protection
against voltage surges and built up static charges.
Section 810 of the National Electrical Code,ANSI/NFPA No.
70-1984, provides information with respect to proper
grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode. See Figure.
a) Use No. 10 AWG (5.3 mm ) copper, No. 8 AWG (8.4 mm )
aluminum, No. 17 AWG (1.0 mm ) copper-clad steel or
bronze wire, or larger, as a ground wire.
b) Secure antenna lead-in and ground wires to house with
stand-off insulators spaced from 4-6 feet (1.22-1.83 m)
apart.
c) Mount antenna discharge unit as close as possible to where
lead-in enters house.
d) Use jumper wire not smaller than No.6 AWG (13.3 mm )
copper, or the equivalent, when a separate antenna-
grounding electrode is used. See NEC Section 810-21(j).
1. READ INSTRUCTIONS
2. RETAIN INSTRUCTIONS
3. HEED WARNINGS
4. FOLLOW INSTRUCTIONS
5. WATER AND MOISTURE
6. CARTS AND STANDS
6A.
7. WALL OR CEILING MOUNTING
8. VENTILATION
9. HEAT
10. POWER SOURCES
11. POWER-CORD PROTECTION
12. CLEANING
13. NON USE PERIODS
14. OBJECT AND LIQUID ENTRY
15. SERVICING
16. DAMAGE REQUIRING SERVICE
17. POWER LINES
18. OUTDOOR ANTENNA GROUNDING
22
2
2
SAFETY INSTRUCTION
S3125A
PORTABLE CART WARNING
Antenna Lead
In Wire
Ground
Clamp
Electric
Service
Equipment
Power Service Grounding
Electrode System
(NEC Art 250 Part H)
Ground Clamps
Antenna
Discharge
Unit (NEC
Section 810.20)
Grounding Conductors
(NEC Section 810.21)
Antenna Grounding According to
the National Electrical Code
National Electrical Code
Available from Library, book
stores, or National Fire Protection
Association (Batterymarch Park,
Quincy. MA 02269).
AMC 21-3004

PN: 21R-XIA30_S8
v04
21R- XI A30_S8
