AMC MP05 User manual

User
Manual
MP 05
Music player recorder

Safety instructions
USER MANUAL MP 05 Music player recorder
When using this electronic device, basic precautions
should always be taken, including the following:
1Read all instructions before using the product.
2Do not use this product near water (e.g., near a bathtub, washbowl,
kitchen sink, in a wet basement or near a swimming pool etc).
3 Use this device when you are sure that player has
a stable base and it is fixed securely.
4This product, in combination with amplifier and loudspeakers may be
capable of producing sound levels that could cause permanent hearing
loss. Do not operate for a long period of time at a high volume level or at
a level that is uncomfortable. If you experience any hearing loss or ringing
in the ears, you should consult with otorhinolaryngologists.
5The product should be located away from heat sources such as radiators,
heat vents, or other devices that produce heat.
6The product should be connected to a power supply that is described
in the operating instructions or are marked on the product.
7The power supply should be undamaged and never share an outlet
or extension cord with other devices. Never leave device plugged
into the outlet when it is not being used for a long period of time.
8Care should be taken that objects do not fall into liquids and liquids
would not be spilled on the device.
9The product should be serviced by qualified service personnel if:
– The power supply or the plug has been damaged.
– Objects have fallen into or liquid has been spilled on the product.
– The product has been exposed to rain.
– The product has been dropped or the enclosure damaged.
10 There are some areas with high voltage inside, to reduce the risk of electric
shock do not remove cover of the microphone receiver or power supply.
The cover should be removed by the qualified personnel only.

Table of contents
USER MANUAL MP 05 Music player recorder
Before you start
Introduction......................................................................................................................................................2
Features................................................................................................................................................................2
Operation
Front panel ........................................................................................................................................................3
Rear panel...........................................................................................................................................................4
IR remote control.........................................................................................................................................5
Front panel operation...........................................................................................................................6-8
Rear panel operation..................................................................................................................................9
Settings and functions
Remote control pinout ..........................................................................................................................10
RS 232 commands ....................................................................................................................................11
Specifications
General specifications.............................................................................................................................12
USER MANUAL MP 05 Music player recorder
Before you start
02
MP05 music player/recorder with integrated SD/MMC and USB flash drive readers and CD player. CD, USB
flash drive or SD/MMC card selectable for play back. Recording function is performed on memory cards or
USB Flash drive. MP 05 can be controlled by IR remote control, RS232 interface or by trigger inputs in remote
control connector.
FEATURES
• Compressedaudioplayback
• Audiorecording
• Supportsupto32GBUSBashandSDcards
• ID3informationsupport
• Serialinterface
• GPIOinputs
• IRremotecontrol
• Balancedaudioinputsandoutputs

USER MANUAL MP 05 Music player recorder
Front Panel
1. ON/OFF switch |2. SD MMC card’s slot |3. Track selection buttons |4. Display |5. USB flash’s slot |6. Find |7. Folder up/down |8. Repeat
9. Record/delete |10. Function |11. Input level indicator |12. Input level potentiometer |13. Eject |14. Play/Pause |15. Stop |16. Down/Rev
17. Prog |18. IR detector |19. CD slot
Operation
03 USER MANUAL MP 05 Music player recorder04
Operation
Rear Panel
1. Serial interface RS 232 |2. Remote control trigger |3. Stereo outputs 4. Stereo inputs for recording | 5. Mains power socket

USER MANUAL MP 05 Music player recorder
Operation
IR remote control
1. Play/Pause |2. Stop |3. Prog |4. Display | 5. ID3 | 6. Rev | 7. Cue | 8. Remain | 9. Function | 10. Rec | 11. Del | 12. Track selection buttons
13. Folder up |14. Folder down | 15. Repeat | 16. Find | 17. Eject | 18. Mutec
FOLDER
REV CUESKIP
PROG
56
4
DISPLAY
789
23
REPEAT FIND
ID3
0
MUTE
EJECT
STOP
1
PLAY
PAUSE
REC DEL
REMAIN FUNCT
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
17
18 11
Batteries changing
1. Open the battery cover
2.InserttwoAAAbatteriesin
accordance with marks in the remote
control battery compartment
3. Close the battery cover
05 USER MANUAL MP 05 Music player recorder
Front panel operation
ON/OFF SWITCH
Turns on and off the device.
SD MMC CARD’S SLOT
This slot is designed for SD and MMC cards. Please note that maximum support-
ed capacity of card is up to 32GB.
TRACK SELECTION BUTTONS
Allowsselectthesoundtracksdirectly.
DISPLAY
Displays the status of the device and main information about the files and
folders.
USB FLASH’S SLOT
This slot is designed for USB flash disc and it can support up to 32GB capacity.
FIND
By pressing this key once search mode is changed into FILE search. By pressing
this key twice search mode is changed into FOLDER search.
MUTE
enables or disables audio from CD/USB/SD.
06
Operation
FOLDER UP
In stop mode this key skips the starting play folder to next folder, and automat-
ically switches to first folder if current folder is last. In the program entry mode
this key switches to next folder’s first file, if the folder is last it switches to first
folder. In normal play mode this key skips the playing file and switches to next
folder’s first file.
FOLDER DOWN
In stop mode this key skips the starting play folder to next previous, and
automatically switches to last folder if current folder is first. In the program entry
mode this key switches to previous folder’s first file, if the folder is first it switch-
es to last folder. In normal play mode this key skips the playing file and switches
to previous folder’s first file.
REPEAT
Pressing this key allows to change sound tracks playing mode like in picture
below.

USER MANUAL MP 05 Music player recorder
07
Operation
RECORD/DELETE
RecordingfromAUXinput
REC button starts recording audio signal from REC input to USB or SD card, de-
pending with one is inserted. MP05 player will ask you to choose storage, if both
USB and SD card will be detected on player. Please use tracks selection button
tosetstorageyouwish.AUXinputmustbeselectedbyusing“FUNC”button
before the start of recording. The REC input level can be adjusted by using input
level potentiometer according to level indicator located in the front panel. To
stop recording, press REC button again. Successful recording will be indicated
by“RECOK”messageonthescreen.Recordswillbenamedautomaticallyand
placedinTMAUXfolder,likeinthepicturebelow:
Recording from CD
If CD player is selected, and CD with compressed audio files is inserted, after
pressing REC button CD audio signal will be recorded to SD MMC or USB flash.
Press REC button again to stop the recording and the confirmation of successful
ending“RECOK”appearsonthescreen.Allrecordswillbenamedautomatically
and placed in CDROM folder, like in the picture below.
If CD player is selected and audio CD is inserted, after pressing REC button CD
audio signal will be recorded to SD MMC or USB flash. Press REC button again to
stoptherecordingandtheconrmationofsuccessfulending“RECOK”appears
onthescreen.AllrecordswillbenamedautomaticallyandplacedinCD-DA
folder, like in the picture below.
Copying
If USB or SD/MMC source are selected you can copy files from one source to an-
other (from USB to SD/MMC and contrary). Press REC button and by using REV
antCUEkeysndthedesiredfolder.Afterthisyoumustselectthelefromthis
folder by pressing REV or CUE for the long time. Now you can press REC button
one more time and copying will be started. During the copy procedure display
willshow“COPY”.Ifcopyissuccessful“COPYOK”appearsonthescreen.
Delete
If USB or SD/MMC source are selected you can delete files from memory card
or flash. First of all you must press DEL button to turn on delete function. By
pressingREVorCUEkeysndthefolder.Afterthisyoumustselectthelefrom
thisfolderbypressingREVorCUEforthelongtime.Afterleselectionpress
DEL button one more time to delete file.
Folder Files
TM AUXTMAUX001.MP3
TMAUX002.MP3
TMAUX........MP3
Folder Files
CDROM001 File name 001.MP3
File name 002.MP3
File name 003.MP3
Folder Files
CD-DA TMCDA001.MP3
TMCDA002.MP3
TMCDA003.MP3
USER MANUAL MP 05 Music player recorder
08
Operation
FUNC
ThiskeyallowschangemusicscourgeandselectAUXinput.Whenthiskeyis
pressed device mode are changed cyclically as in picture below.
INPUT LEVEL INDICATOR
These LED’s indicates level of the recording signal from the REC input.
INPUT LEVEL POTENTIOMETER
This potentiometer is for adjusting the recording audio level from the REC input.
EJECT
By pushing this key CD is ejected.
PLAY/PAUSE
By pressing this key when device is stopped, play starts after track search. When
this key is pressed during playing the mode of the device is changed in to
pause. When this key is pressed during pause, it switches back to play mode.
DOWN/REV
In stop mode this key changes starting track (file) in descending order, and au-
tomatically goes to the last track if it is in first track. Single pressed in play mode
or program mode changes to previous track (file). By pressing longer than 0,7
sec switches to fast reverse mode.
STOP
When device is playing or is in pause mode, by pressing this you will stop it.
UP/CUE
In stop mode this key changes starting track (file) in ascending order, and auto-
matically goes to first track if it is in the last track. Single pressed in play mode or
program mode changes to next track, in random mode skips to random track.
By pressing longer than 0,7 sec. switches to fast forward mode.
PROG
This key is used for programming.
AllprogramsareclearedwhenSTOPkeyispushedintheprogrammingmode.
IR DETECTOR
Receive controls commands from remote control.
CD SLOT
This slot is designed for CD and it can support compressed audio files.
REMAIN ( function available only for CD)
allows to change time counter mode. Three options available, remaining time
until the end of audio track, remaining time until the end of CD tracks and time
from the beginning of track.
ID3
AllowtoshowdierentaudiotrackID3informationondisplay.
CD USB CARD AUX

USER MANUAL MP 05 Music player recorder09
Operation
Rear panel operation
SERIAL INTERFACE RS 232
D-Sub 9-pin connection for serial interface (RS232). This connector is designed
to control device functions by using external control unit, like Creston or PC etc.
REMOTE CONTROL TRIGGER
Because of this input the device can by controlled by using external push
buttons or relays. The maximum distance between the device and push buttons
should be up to 10m. if shielded cable are used.
STEREO OUTPUT
ThisislineleveloutputwithbalancedstereoXLRandstereoRCAconnectors.
STEREO INPUT FOR RECORDING
ThisislinelevelinputwithbalancedstereoXLRandstereoRCAconnectorsfor
the audio recording. Recording audio level can be adjusted by using poten-
tiometer located in the front panel. To prevent signal clipping please give
attentions to signal level indicator located in the front panel too.
USER MANUAL MP 05 Music player recorder10
Settings and functions
Remote control pinout
D-SUB 25 connector
Remote control connector. Pin’s description. Remote control wiring diagram (MP05 rear panel view)
Pin
number
Description
1 GND
2 Play/pause
3 Stop
4 Up
5 Down
6 Folder skip >>
7 Folder skip <<
8 Repeat
9 Eject
10 PROG
11 Find
12 Mute
13 Function
14 Record
15 Delete
16 0
17 1
18 2
19 3
20 4
21 5
22 6
23 7
24 8
25 9

USER MANUAL MP 05 Music player recorder11
Settings and functions
RS 232 commands
Baud rate 9600,
8 data bits,
no parity,
1 stop bit,
no flow control.
Please note: The partition between two orders must exceed 300ms.
Byte 12345
Functions
ASCII ASCII ASCII HEX HEX
Folder skip - E AA0d 0a
Folder skip + E AB 0d 0a
Down EAC 0d 0a
Up E AD 0d 0a
Stop E AE 0d 0a
Play / pause E AF 0d 0a
Eject E AG 0d 0a
Prog EAH 0d 0a
ID3 E AI 0d 0a
Find E AJ 0d 0a
Mute EA K 0d 0a
Repeat E AL 0d 0a
Func E AM 0d 0a
Display E AN 0d 0a
A-B EAO 0d 0a
Rec E AP 0d 0a
Del E AQ 0d 0a
Play 1 E AU 0d 0a
Remain E AV 0d 0a
0 E A0 0d 0a
1 E A1 0d 0a
2 E A2 0d 0a
3 E A3 0d 0a
4 E A4 0d 0a
5 E A5 0d 0a
6 E A6 0d 0a
7 E A7 0d 0a
8 E A8 0d 0a
9 E A9 0d 0a
Answer form device if OK + O K0d 0a
Answer form device if ERROR + E R 0d 0a
USER MANUAL MP 05 Music player recorder
General Specifications
MP 05
Availablesources USB flash, SD/MMC card and CD
Maximum compatible USB SD/
MMC size up to 32GB
Input StereoRCAandbalancedStereoXLR(RECinput)
Output StereoRCAandbalancedStereoXLR
Max REC input level +6 dBu
Output level 0 dBu
THD 0,1 % @ 1 kHz
Frequency response 20 Hz – 20 kHz
Signal to noise ratio 80 dB
Stereo separation 60 dB
Recording bit rate 128 kbps
Supported audio
formats Compressed audio
Power supply ~230 V 50 Hz
Power consumption 50VA
Weight 3,8 kg
Dimensions 482 mm x 44 mm x 250 mm
12
The specifications are correct at the time of printing this manual.
For improvement purposes, all specifications for this unit, including
design and appearance, are subject to change without prior notice.
