AMD ATI TV Wonder 650 User manual

ATI TV Wonder™ 650 PCI
User Guide
P/N 117-70420-00

© 2007 Advanced Micro Devices Inc. All rights reserved.
The contents of this document are provided in connection with Advanced Micro Devices, Inc. (“AMD”)
products. AMD makes no representations or warranties with respect to the accuracy or completeness of
the contents of this publication and reserves the right to make changes to specifications and product
descriptions at any time without notice. The information contained herein may be of a preliminary or
advance nature and is subject to change without notice. No license, whether express, implied, arising by
estoppel or otherwise, to any intellectual property rights is granted by this publication. Except as set forth
in AMD’s Standard Terms and Conditions of Sale, AMD assumes no liability whatsoever, and disclaims
any express or implied warranty, relating to its products including, but not limited to, the implied
warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual
property right. AMD’s products are not designed, intended, authorized or warranted for use as
components in systems intended for surgical implant into the body, or in other applications intended to
support or sustain life, or in any other application in which the failure of AMD’s product could create a
situation where personal injury, death, or severe property or environmental damage may occur. AMD
reserves the right to discontinue or make changes to its products at any time without notice.
AMD's products are not designed, intended, authorized or warranted for use as components in systems
intended for surgical implant into the body, or in other applications intended to support or sustain life,
or in any other application in which the failure of AMD's product could create a situation where personal
injury, death, or severe property or environmental damage may occur. AMD reserves the right to
discontinue or make changes to its products at any time without notice.
Trademarks
AMD, the AMD Arrow logo, AMD Athlon, AMD Opteron and combinations thereof, ATI and ATI product
and product-feature names are trademarks of Advanced Micro Devices, Inc.
HyperTransport is a licensed trademark of the HyperTransport Technology Consortium.
Microsoft is a registered trademark of Microsoft Corporation.
Other product names used in this publication are for identification purposes only and may be trademarks
of their respective companies.
Disclaimer
While every precaution has been taken in the preparation of this document, Advanced Micro Devices,
Inc. assumes no liability with respect to the operation or use of AMD hardware, software or other
products and documentation described herein, for any act or omission of AMD concerning such products
or this documentation, for any interruption of service, loss or interruption of business, loss of anticipatory
profits, or for punitive, incidental or consequential damages in connection with the furnishing,
performance, or use of the AMD hardware, software, or other products and documentation provided
herein.
Advanced Micro Devices, Inc. reserves the right to make changes without further notice to a product or
system described herein to improve reliability, function or design. With respect to AMD products which
this document relates, AMD disclaims all express or implied warranties regarding such products,
including but not limited to, the implied warranties of merchantability, fitness for a particular purpose,
and non-infringement.
Product Notices
Dolby® Laboratories, Inc.
Manufactured under license from Dolby® Laboratories. Dolby and the double-D symbol are trademarks
of Dolby Laboratories. Confidential Unpublished Works.
© 1992-1997 Dolby Laboratories, Inc. All rights reserved.
Macrovision
Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132. Licensed for
limited viewing uses only.
This product incorporates copyright protection technology that is protected by US patents and other
intellectual property rights. Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized
by Macrovision. Reverse engineering or disassembly is prohibited.
Documentation Updates
AMD is constantly improving its product and associated documentation. To maximize the value of your
AMD product, you should ensure that you have the latest documentation. AMD’s documentation contains
helpful installation/configuration tips and other valuable feature information.
ii
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Important Safety Instructions
Note: This product is for use only with compatible UL-listed personal computers
that have installation instructions detailing user installation of this class of product.
Read all instructions before beginning installation.
All safety and installation instructions should be read before the product is installed or
operated.
Retain all instructions.
Safety, installation, and operating instructions should be retained for future reference.
Heed all warnings.
All warnings regarding the product and its operating instructions should be adhered to.
Use appropriate grounding.
Caution:
For continued protection against the risk of electric shock and fire, install this accessory
only in products equipped with a three-wire grounding plug, a plug having a third
(grounding) pin. A three-pin plug will only fit into a grounding-type power outlet. This
is a safety feature. If you are unable to insert the plug into the desired outlet, contact an
electrician to replace the obsolete outlet. Do not remove the grounding pin of a three-
pin plug.
Attach product securely.
All product-securing screws or fasteners should be completely tightened in order to
provide continuous bonding between the product and the PC chassis, as appropriate.
For cards with TV tuners:
•Ground outdoor antenna appropriately.
Caution:
Since an outdoor antenna or cable system may be connected to the product, be sure
that the antenna or cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to
the antenna discharge unit, size of grounding conductors, location of antenna-
discharge unit, connection of grounding electrodes, and requirements for the
grounding electrode.
•Unplug system during storms or prolonged disuse.
Caution:
For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the product
from power-line surges.
•Install outdoor antenna system away from power lines.
Warning:
When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits, as contact with them may be fatal.
iii
© 2007 AMD ATI TV Wonder™ 650
P/N 117-70420-00

Caution:
An outside antenna system should not be located in the vicinity of overhead power
lines or other light or power circuits, or where it can fall into such power lines or
circuits.
Note to CATV System Installer
This reminder is provided to call the CATV systems installer’s attention to Section 820-40
of the NEC, which provides guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding system of the building as close
to the point of cable entry as is practical.
iv
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Contents
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Backplate Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using Your ATI TV Wonder™ 650 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using Your Multimedia Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting External Video and Audio Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Video is unstable or only black and white. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
No video or audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Recording stops unexpectedly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dropped frames during recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Poor TV reception. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Additional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
FCC Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Industry Canada Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

vi
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Chapter 1
Getting Started
Product Overview
Your ATI TV Wonder™ 650 is an advanced PCI TV tuner card that lets you enjoy
a superior home theater experience from your computer.
The ATI TV Wonder™ 650 includes the following features:
•ATSC digital TV tuner.
•NTSC analog TV tuner with motion-adaptive 3D comb filtering.
•FM radio tuner.
•Worldwide analog stereo audio decoding with digital output to the PC.
•Hardware noise reduction.
•Personal video recorder (PVR) to let you pause, rewind, or record live TV, or
schedule recordings.
Note: The digital TV tuner also allows you to receive unencrypted digital
cable channels (Clear QAM channels). Availability of Clear QAM channels
varies by area and by cable provider.
ATI TV Wonder™ 650 also includes ATI Catalyst™ Media Center (CMC)
multimedia software. CMC features include the following (available only when
using CMC):
•Electronic program guide.
•Video converter, with support for capturing or converting video in a
number of formats, including MPEG-1, MPEG-2, MPEG-4, DivX, WMV9, and
H.264.
•DVD decoder software.
•DVD authoring software.

System Requirements
Hardware •AMD Athlon™ or AMD Sempron™, Intel® Pentium® 4 or
Celeron®, (or compatible) CPU.
•Sound card and speakers.
•System memory:
•For Windows® XP: 256 MB required, 512 MB or more
recommended for better performance.
•For Windows Vista™: 1GB required, 2 GB or more
recommended for better performance.
•CD drive (for installation software).
•An ATI Radeon™ DirectX 9 compatible or higher graphics card
is recommended for optimal display output quality.
•Cable TV signal or amplified antenna.
•Free PCI slot on motherboard.
Operating
System
•Windows XP Media Center Edition 2005.
•Windows XP Home Edition, Service Pack 2.
•Windows XP Professional Edition, Service Pack 2.
•Windows Vista Home Premium or Ultimate Edition.
Decoder •An MPEG-2 decoder (a DVD player or multimedia application,
such as ATI Catalyst Media Center) must be installed to play
DVDs or MPEG-2 video files captured by the
ATI TV Wonder™ 650.
Monitor •High-resolution MultiSync or multi-frequency monitors or
any other type of VGA monitor.
•Digital flat-panel (DFP) displays or digital CRT display.
2Getting Started
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Chapter 2
Installation
Installation Diagram
Figure 2–1 Installing Your Tuner Card
1 PCI card.
2 PCI connection on motherboard.
3 Card insertion point.

Backplate Connections
Figure 2–2 ATI TV Wonder™ 650 Backplate
The following connections are available on the backplate of your tuner card:
1DTV/FM. FM Radio and Digital TV antenna coaxial connection
2TV. Cable TV Coaxial Connection
3AV IN. Audio/video connection (to purple adapter)
Hardware Installation
To install your hardware:
1. Turn off the computer, monitor, and other peripheral devices.
2. Unplug the computer's power cord, and disconnect all cables from the back
of your computer.
Caution:
Wait approximately 20 seconds after unplugging the power cord before
disconnecting a peripheral or removing a component from the
motherboard to avoid possible damage to the motherboard.
3. Remove the computer cover. If necessary, consult your computer's manual
for help in removing the cover.
Caution:
Remember to discharge your body's static electricity by touching the
power supply or the metal surface of the computer chassis before touching
the motherboard or components.
4. Locate an available PCI slot and, if necessary, remove the metal back-plate
cover.
5. Align your card with the slot, then press the card in firmly until it is fully
seated.
6. Screw in or fasten the card securely and replace your computer cover.
7. Reconnect any cables you have disconnected, and then plug in the
computer’s power cord.
8. Attach a TV antenna or coaxial cable to the TV connector on your
ATI TV Wonder™ 650.
4Installation
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

➭For over the air digital TV, connect a DTV antenna (if available) to the
DTV/FM connector.
➭For FM radio, attach an antenna to the DTV/FM connector.
➭If your cable service provides an FM signal, you can use a splitter to
connect the cable to the DTV/FM and TV connectors on your card.
9. Plug the purple input adapter provided with your ATI TV Wonder™ 650 into
the AV IN connection.
10. Attach your S-video source and/or composite source to the proper input on
the purple input adapter.
11. Turn on the monitor, and then your computer.
If you have properly installed your card, operating system messages will appear
once the boot procedure is finished. Proceed with the installation of drivers and
software.
Software Installation
Note:
•You must install or reinstall the drivers and software in the following
cases:
•After you have installed the card in your system.
•After you have reinstalled or upgraded your operating system.
•To install or remove the drivers, you must be logged on as a user with
administrator rights. We also recommend that you have the latest
Windows Service Pack installed.
•If a previous version of the product is installed on your machine,
uninstall the drivers and software for the previous version.
•The setup and install screens are displayed in English if your
operating system's language is not supported
To install your software:
1. After installing your tuner, start your system.
2. When the Found New Hardware Wizard appears, click Cancel. When the
System Settings Change window asks you to restart your computer, click
No.
3. Insert the installation CD into your CD drive. The installation screen appears.
If your CD autorun is not enabled or the ATISETUP utility does not start
automatically, follow these steps:
a. In the Windows task bar, click the Start button.
b. Click Run.
c. In the Run dialog, type X:\ATISETUP.EXE (where X: is your CD/DVD
drive).
4. Click Software Install. The Software Install screen appears.
5. Click Install CATALYST. The ATI Software screen and installation wizard
appear.
5
© 2007 AMD ATI TV Wonder™ 650
P/N 117-70420-00

6. Click Next and follow the instructions in the installation wizard to install your
drivers and configuration software.
Note: The Express installation option is recommended. Custom
installation allows you to select individual software components for
installation.
7. When the driver and software setup concludes, the wizard's Setup Complete
dialog box appears. To restart your computer and immediately enable the
installed software, click Finish.
Note: If you select "No, I will restart my computer later", click Finish
to close the wizard, then click Back to return to the main installation
screen, and Exit to close the installer.
You may be required to reboot your computer after installing the drivers and
software.
After the system reboots, the Found New Hardware message may display the
Digital Signature Not Found message. Click Yes or Continue to complete the driver
installation.
6Installation
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Chapter 3
Using Your ATI TV Wonder™ 650
Using Your Multimedia Software
The ATI TV Wonder™ 650 supports the following multimedia software:
•ATI Catalyst Media Center (CMC)
•Windows Media Center® with Windows Vista Home Premium or Ultimate
editions
•Windows Media Center® with Windows® XP Media Center Edition 2005
For details on how CMC or Windows Media Center® can help you get the most out
of your ATI TV Wonder™ 650, see the online Help files installed with those
applications.
To open Windows Media Center®:
1. In the Windows Start Menu, click Media Center.
or
From the Windows Start Menu, choose Programs > Accessories > Media
Center > Media Center.
2. Click the MY TV button, then click Live TV.
Connecting External Video and Audio Sources
Your ATI TV Wonder™ 650 lets you connect external devices such as DVD players,
camcorders, stereo systems, or TVs as input sources.
You can, for example, connect audio devices to the AUDIO input connector on the
backplate of your tuner (see the topic, "Backplate Connections" earlier in this
guide.)
You can also connect video devices using the S-VID connector on the backplate,
or use composite connections with a composite-to-S-Video adapter.

8Using Your ATI TV Wonder™ 650
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

Chapter 4
Reference
Troubleshooting
Video is unstable or only black and white.
•Check that you are using the correct broadcast standard format.
•Check the quality of the incoming TV signal on another receiver.
•Connect your tuner directly to the cable TV or antenna source. Splitters can
degrade the signal.
No video or audio.
•Check that the speakers are connected and turned on.
•Check that your system's sound device is working properly (Control Panel ▷
Sounds and Audio Devices).
•Make sure the monitor is plugged in, turned on, and connected to the
computer.
•Make sure the cable or antenna is connected.
•Check that all connectors are securely plugged in to the correct jacks.
•Check that the tuner is securely connected.
Recording stops unexpectedly.
•Make you have sufficient disk space to accommodate the recording.
•Make sure you are recording to the correct hard disk. Check your software
manual for instructions on determining the target drive and folder for your
recordings.
•The maximum file size for the FAT32 file system is 4 gigabytes.
•Disable screen savers while recording.
•Disable Power Management while recording.
Dropped frames during recording.
Dropped frames during video recording indicates that some part of the system is
not fast enough to keep up with the recording. Recording video is a very
demanding task for even the most powerful system.
•Defragment your hard drive.
•A large, dedicated disk is recommended if you plan to do a lot of video
recording.
•Close all other running tasks, including those in the System Tray (clock,
popup reminders, virus scanners, etc.)

•Close and exit from any Task Scheduler.
•Do not log on to your network.
•Do not connect new devices while recording.
•Do not open or close CD or DVD trays while recording.
•Do not move the mouse while recording.
Poor TV reception.
•If you use an indoor antenna, you will get the best results with an amplified
model. To avoid interference, place the antenna as far away from the PC
monitor as possible.
•Splitting the cable or antenna input can reduce signal quality. For the best
reception, connect the cable or antenna directly to your tuner.
Additional Accessories
Additional and replacement cables, installation CDs, manuals, and other
accessories for ATI products can be purchased from the online ATI store at
ati.amd.com/online/accessories
Compliance Information
This section details the compliance information for this product.
FCC Compliance Information
This product complies with FCC Rules Part 15. Operation is subject to the
following two conditions
•This device may not cause harmful interference.
•This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with manufacturer's
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Re-orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
10 Reference
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00

The use of shielded cables for connection of the monitor to the graphics card is
required to ensure compliance with FCC regulations. Changes or modifications
to this unit not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
Complies with FCC 15.107, 15.109, 15.111, and 15.117.
For further compliance information:
Advanced Micro Devices, Inc. 62 Forest Street Marlborough, MA 01752 USA Tel:
508-303-3900
Industry Canada Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003 and with BETS-7,
Section 3.6.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du
Canada, et NTMR-7, Section 3.6.
Electrical Safety
UL 60950-1:2003, 1st Edition, CAN/CSA C22.2 No. 60950-1:2003, 1st Edition
To meet UL safety requirements, the computer’s maximum room temperature
should not exceed 40º C.
Industry Canada Compliance Statement 11
© 2007 AMD ATI TV Wonder™ 650
P/N 117-70420-00

12 Reference
ATI TV Wonder™ 650 © 2007 AMD
P/N 117-70420-00
