American Audio Tri Pack System User manual

AMERICAN AUDIO
4295 Charter Street
Los Angeles, Ca. 90058
www.americanaudio.us
Rev. 7/05
TRI PACK

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 2
Tri Pack System Contents
Tri Pack System Unpacking
Tri Pack System Introduction
Every Tri Pack System has been thoroughly tested and has been shipped in perfect operating condi-
tion. Carefully check the shipping carton for damage that may have occurred during shipping. If the
carton appears to be damaged carefully inspect your units for any damage and be sure all accessories
necessary to operate the system have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for further instructions. Please do not
return the speaker to your dealer without first contacting customer support.
CUSTOMER SUPPORT..........................................................................................................................2
UNPACKING.............................................................................................................................2
HANDLING PRECAUTIONS...................................................................................................................3
FEATURES...........................................................................................................................................4
PRODUCT REGISTRATION....................................................................................................................5
AVAILABLE ACCESSORIES...................................................................................................................5
CONTROLS AND FEATURES................................................................................................................6
MOUNTING..................................................................................................................................11
SPEAKON ASSEMBLY.........................................................................................................................12
WARRANTY.......................................................................................................................................13
SPECIFICATIONS............................................................................................................................14
Introduction: Congratulations and thank you for purchasing the American Audio® Tri Pack System.
This system is a representation of American Audio’s continuing commitment to produce the best and
highest quality audio products possible at an affordable price. The Tri Pack System includes a sub-
woofer plus two satellite speakers. The speakers and subwoofer have been designed to be used as
both a portable and a permanently installed unit. The speakers include a poll mount slot and rubber feet
on the bottom of the unit for portable applications. Please read and understand this manual completely
before attempting to operate your new speaker system. This booklet contains important information
concerning the proper and safe operation of your new system.
Customer Support: American Audio® provides a toll free customer support line, to provide set up help
and answer any question should you encounter problems during your initial set up or operation. You
may also visit us on the web at www.americandj.com for any comments or suggestions. Service Hours
are Monday through Friday 9:00 a.m. to 5:30 p.m. Pacific Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Caution! There are no user serviceable parts inside the subowoofer or speakers. Do not attempt any
repairs, without being instructed to do so by an authorized American Audio technician. Doing so will
void your manufactures warranty. In the unlikely event your speaker may require service, please contact
American Audio®.

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 3
ELECTRICAL PRECAUTIONS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
READ INSTRUCTIONS — All the safety and operating
instructions should be read before the product is
operated.
RETAIN INSTRUCTIONS — The safety and operating
instructions should be retained for future reference.
HEED WARNINGS — All warnings on the product and
in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use
instructions should be followed.
CLEANING — The product should be cleaned only with
a polishing cloth or a soft dry cloth. Never clean with
furniture wax, benzine, insecticides or other volatile
liquids since they may corrode the cabinet.
ATTACHMENTS — Do not use attachments not
recommended by the product manufacturer as they
may cause hazards.
WATER AND MOISTURE — Do not use this product
near water — for example, near a bathtub, wash
bowl, kitchen sink, or laundry tub; in
a wet basement;
or near a swimming pool; and the like.
ACCESSORIES — Do not place this product on an
unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturerʼs instructions, and should
use a mounting accessory recommended by the
manufacturer.
CART — A product and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
VENTILATION — Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturerʼs instructions have been adhered to.
POWER SOURCES — This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company.
LOCATION – The appliance should be installed in a
stable location.
NONUSE PERIODS – The power cord of the appliance
should be unplugged from the outlet when left un-
used for a long period of time.
GROUNDING OR POLARIZATION
• If this product is equipped with a polarized alternating
current line plug (a plug having one blade wider than
the other), it will fit into the outlet only one way. This
is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
• If this product is equipped with a three-wire
grounding type plug,
a plug having a third (grounding)
pin,
it will only fit into a grounding type power outlet.
This
is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the grounding type plug.
POWER-CORD PROTECTION - Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the product.
OUTDOOR ANTENNA GROUNDING — If an outside
antenna or cable system is connected to the product,
be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode. See Figure
A.
LIGHTNING — For added protection for this product
during
a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product
due to lightning and power-line surges.
POWER LINES — An outside antenna system should
not be located
in the vicinity of overhead power lines
or other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installing an outside antenna system, extreme care
should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
OVERLOADING — Do not overload wall outlets,
extension cords, or integral convenience receptacles
as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY - Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
SERVICING — Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
- Unplug this product
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
• When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into
the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its
normal operation.
• If the product has been dropped or damaged in any
way.
• When the product exhibits a distinct change in
performance — this indicates a need for service.
REPLACEMENT PARTS -- W hen replacement parts
are required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, or other hazards.
SAFETY CHECK - Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks
to determine that the product
is in proper operating condition.
WALL OR CEILING MOUNTING — The product should
not be mounted to a wall or ceiling.
HEAT
— The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce
heat.
IMPORTANT SAFETY INSTRUCTIONS
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
Fig. A
NEC — NATIONAL ELECTRICAL CODE
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
THERE ARE NO USER SERVICEABLE PARTS
INSIDE REFER SERVICE TO YOUR AUTHORIZED
AMERICAN AUDIO® SERVICE TECHNICIAN.
Tri Pack System Handling Precautions

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 4
Tri Pack System Safety Precautions
• The Tri Pack System can easily reproduce sound pressure levels (SPL) sufficient enough to
cause sever and permanent hearing damage. A great degree of care should be taken to protect
your ears to prolong exposure to SPL in excess of 85dB.
• For adult use only - Keep out of the reach of children.
• Be sure all power is turned off before making subwoofer and speaker connections
• Do not remove the protective grills under any conditions
• Always use a power cord that meets the manufactures exact power specifications
• Disconnect from main power before making any type of connection
• To reduce the risk of electrical shock or fire, do not expose this unit rain or moisture
• Always mount the speakers in a safe and stable matter.
• Power Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where they exit from the mixer.
• Heat -The subwoofer and speakers should be situated away from heat sources such as radia-
tors, heat registers, stoves, or other mixers (including amplifiers) that produce heat
• Be sure to save the packing carton in the event the unit needs to be returned for service
• Read all documentation before attempting to operate your new system. Please save all your
docu mentation for future reference
• Do not spill water or other liquids in to or on to your subwoofer or speakers
• Be sure that the local power outlet matches that of the required voltage for your system.
• Do not attempt to operate this subwoofer if the power cord has been frayed or broken. Please
route your power cord out of the way of foot traffic
• Always have the gain controls set to their lowest level during initial power-up to prevent
subwoofer and speaker damage
• Servicing - The user should not attempt to service the subowoofer or speaker(s) beyond that
described in this manual. All other servicing should be referred to qualified service personnel.
The subwoofer and speakers should only be serviced by qualified personal when;
A. Objects have fallen, or liquid has been spilled into the subwoofer or speakers
B. The subwoofer or speakers has been exposed to rain or water
C. The subwoofer or speakers does not appear to operate normally or exhibits a change in
performance
D. The terminal/cross-over plate has been damaged
Tri Pack System Main Features
Tri Pack System:
• Powered Subwoofer
• Dual Speakon Type Connections
• LED Peak Indicator
• Built-in Pole Mount Socket
• In and Out Balanced XLR Jacks for Parallel Connections
• Adjustable Electronic Crossover
• Built-in Carrying Handles
• Attached Rubber Feet on the Satellite Speakers
• Attached Wheels on the Subwoofer

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 5
Tri Pack System™ Registration
Tri Pack System Accessories
Impact Bag - Subwoofer and Speaker Transport Case - A rugged gig bag with a heavy duty zip-
per and handle and rear and front trap doors. Designed to protect your subwoofer and speakers from
damage and the environment during transportation and storage.
SPS-1B - Speaker Stands - American Audio® carries a speaker stand
that may be used to raise the speakers during use. The SPS-1B is a stur-
dy aluminum tri-pod and includes a mounting socket bracket for added
security. The SPS-1B can raise the speaker to a maximum height of six
feet and has a maximum weight capacity of 80 pounds. SPS-1B; weight
= 6lbs, pipe diameter - 1 3/8”
The Tri Pack System carries a one year (365 days) limited warranty. Please fill out the enclosed war-
ranty card to validate your purchase. All returned service items whether under warranty or not, must
be freight pre-paid and accompany a return authorization (R.A.) number. The R.A. number must be
clearly written on the outside of the return package. A brief description of the problem as well as the
R.A. number must also be written down on a piece of paper and included in the shipping container.
If the unit is under warranty, you must provide a copy of your proof of purchase invoice. You may
obtain a R.A. number by contacting customer support at [phone]. All packages returned to
the service department not displaying a R.A. number on the outside of the shipping package will be
returned to the shipper unopened.
The serial and model number for this unit is located on the rear panel Please write down the num-
bers here and retain them for future reference.
Model No.________________________________ Date Purchased___________________________
Serial No.________________________________ Dealer Name______________________________

Subwoofer Rear Panel:
1. RIGHT SPEAKON CONNECTION – The subwoofer includes a pair of Speakon type connec-
tions. The Speakon connectors have a pin 1+ (hot) and 1- (ground) configuration, pins 2+ and
2- are not used. For more wiring information regarding the Speakon connectors see page 12.
2. RIGHT BALANCED XLR LINE INPUT – This connection is designed to accept a balanced line
input signal from a mixer or other line level device with a balanced output jack. Use a balanced
cable when the signal cable length exceeds 15 feet, this will reduce excessive signal loss. Be
sure to connect only line level input devices such as mixers and tape machines to this jack.
3. RIGHT XLR PARALLEL OUTPUT JACK – This jack is used to send the incoming line level
signal from either of the Line Level Inputs Jacks to another subwoofer, speaker or other line
level input jack such as a mixer or power amp.
4. RIGHT SPEAKER GAIN CONTROL – This knob is used to regulate the output level of the right
speaker.
5. SUBWOOFER GAIN CONTROL – This knob is used to regulate the output level of the sub-
Tri Pack System Controls and Features
©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 6
1 32
11
121314151617
10987654
1920
18

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 7
Tri Pack System Controls and Features
woofer.
6. CROSSOVER – This knob is used to adjust the crossover frequency of the subwoofer.
7. LEFT SPEAKER GAIN CONTROL – This knob is used to regulate the output level of the left
speaker.
8. LEFT XLR PARALLEL OUTPUT JACK – This jack is used to send the incoming line level signal
from either of the Line Level Inputs Jacks to another subwoofer, speaker or other line level input
jack such as a mixer or power amp.
9. LEFT BALANCED XLR INPUT – This connection is designed to accept a balanced line input
signal from a mixer or other line level device with a balanced output jack. Use a balanced cable
when the signal cable length exceeds 15 feet, this will reduce excessive signal loss. Be sure to
connect only line level input devices such as mixers and tape machines to this jack.
10. LEFT SPEAKON CONNECTION – The speaker includes a pair of Speakon type connections.
You may use both connections at once to loop speakers. The Speakon connectors have a pin
1+ (hot) and 1- (ground) configuration, pins 2+ and 2- are not used. For more wiring information
regarding the Speakon connectors see page 12.
11. POWER LED - This L.E.D. will be lit when you switch on the power.
12. MAIN POWER INLET – This connector is used to supply main power to the unit via the in-
cluded detachable power cord. The power connection uses an I.E.C. type connector, use only
the supplied polarized AC power cord. Use only a power cord that matches this type of con-
nection. Be sure to only connect this unit to a power outlet that matches the printed power
label on the unit. Never use a power when the ground prong has been removed or broken off.
The ground prong is used to reduce the risk of electrical shock in case of an electrical short.
This cord is designed to fit in one direction only. Do not attempt to force a cord if it does not
fit, be sure the cord is being inserted properly.
13. FUSE HOLDER – This housing stores the 10 amp GMA protective fuse. Always replace with
the exact same type fuse, unless otherwise instructed, by an authorized American Audio®
service technician. Replacing with any other type of fuse than that of the recommended fuse
will void your unit warranty.
14. PROTECT INDICATOR - The red Protect LED will begin to glow when the channel goes into
protect mode. When the channel goes into protect mode all output for that channel will turn
off. This is to protect any speakers connected to the channel.
15. MAIN POWER SWITCH – This is the main power ON/OFF button. A yellow LED directly above
the power switch will glow indicating power is ON. Before main power is applied, be sure you
have made all connections to the speaker. Remember to avoid damaging pops to the speakers,
the mixer is turned on first and turned off last.
16. VOLTAGE SELECTOR SWITCH - Because power supplies vary from location to location a
voltage selector switch has been incorporated in the unit's design. This switch can select a
voltage input of 120v or 230v to accommodate the two major power source. Always be sure
to disconnect the power plug before changing the voltage.
17. CLIP L.E.D. - When your Subwoofer or Speaker Levels are distorted or too loud this L.E.D.
will light letting you know to adjust your volume level to a lower setting.

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 8
Satellite Rear Panel:
18. TRANSPORT HANDLE – The Tri Pack System with built-in heavy- duty transportation han-
dle. Be sure to carry the speaker by the handle for secure and easy transportation.
19. SPEAKON CONNECTIONS – The speaker includes a pair of Speakon type connections. You
may use both connections at once to loop speakers. These Be sure to use either the Speakon
type input connector or the 1/4” Phono input connector, never use more than one input con-
nection at once. The Speakon connectors have a pin 1+ (hot) and 1- (ground) configuration,
pins 2+ and 2- are not used. For more wiring information regarding the Speakon connectors
see page 17.
20. RUBBER FEET – The speaker includes heavy-duty rubber feet on the bottom of the unit.
These feet are used to secure a speaker to another when stacking. They are also used to
secure the speaker to the ground to prevent it from shifting during heavy bass reproduction.
Tri Pack System Controls and Features

AUX 4
AUX / IN
MADE IN CHINA
MODEL NO.: Q-3433 MKII
POWER SOURCE:
115/230V~ 50/60Hz 20W
MIN MAX
TRIM OUTPUT
©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 9
Tri Pack System Set-Up
Tri Pack System Set-Up
XLR-XLR Balanced Cables
RIGHT SATELLITE
SPEAKER
LEFT SATELLITE
SPEAKER
SUBWOOFER

AUX 4
AUX / I N
MADE IN CHINA
MODEL NO.: Q-3433MKII
POWER SOURCE:
115/230V~ 50/60Hz 20W
MIN MAX
TRIM OUTPUT
Tri Pack System Set-Up
Tri Pack System Set-Up
©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 10
XLR-XLR Balanced Cables
RIGHT SATELLITE
SPEAKER
LEFT SATELLITE
SPEAKER
SUBWOOFER
DLS 15P DLS 15P

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 11
Tri Pack System Satellite Mounting
Pole Mounting – The Impact 3 satellite speakers include a pole mount
option. The pole mount socket located on the bottom of the speaker may
be used to secure the speaker to a speaker tri-pod, such as the American
Audio® SPS-1B as illustrated on the left. Always be sure to follow the
guidelines listed below when pole mounting your speaker;
• Always be sure the stand is designed to support the weight of
the speaker
• In outdoor situations that are prone to windy conditions and
strong wind gust, be sure to use sandbags as additional tri-pod
support, this will greatly reduce the risk of tipping
• Do not stack speakers on top of each other when mounting on
a tri-pod. Only one speaker should be mounted to a tri-pod at one
time.
• Always position the tri-pod legs away from foot traffic
• Extend the tri-pod legs to their fully extended position to avoid
accidental tipping
• Observe and follow all safety guidelines and regulations specified
by the tri-pod’s manufacturer
• Be sure the tri-pod is situated on a flat, level, and stable surface
• Always tighten all tri-pod locks

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 12
SPEAKON ASSEMBLY: You will need a pair of Neutrik Speakon® NL4FC connectors. You will also
need high-quality two or four conductor speaker cable, a pair of needle-nosed pliers and a 1.5-
mm Allen key to assemble the Speakon connectors to your speaker wire. To assemble the Neutrik
Speakon NL4FC connector, complete the following steps:
1. Strip back 3 /4-inch of the cable casing. Strip off 1
/4-inch from the end of each of the conductors down
to bare wire, and insert the brass fittings ( Figure
10).
2. Slide the cable tension clip (D) and the speakon
coupler (E) through the cable end. See figure 11.
3. Insert each wire with the brass fittings into the
top of appropriate slot of the connector insert (B) as
shown in figures 11 and 12. Use a 1.5-mm Allen key
to tighten the connection (Figure 12).
4. Be sure to properly match the positive (+) and
negative (–) leads of each wire (Figure 13).
5. Slide the connector insert (B) into the connector
housing (A), making sure that the large notch on the
outer edge of the insert lines up with the large groove
on the inside of the connector housing. The insert
should slide easily through the housing and out the
other side until it extends approximately 3 /4-inch
from the end of the housing.
6. Slide the cable tension clip (D) along the cable and
insert into the housing (A), making sure that the large
notch lines up with the large groove on the inside of
the connector housing (A). The cable tension clip (D)
should slide easily into the housing until only 3 /8-
inch of the cable tension clip (D) extends from the
back end of the connector.
7. Slide the coupler (E) along the cable and screw it
onto the end of the housing (A). Before tightening,
you may want to test the connector to make sure it
has been assembled properly.
Figure 10
C 1C 2
UTPUTS
CAUTION
MINIMUM LOAD IMPEDANCE 2 OHM PERCHANNEL 4 OHM BRIDGE
INPUT TU
INPUT BAANCE
120 60
4800 ATTS
SPEAKON 1+ HOT
1 COLD
C 1C 2
- + - +
N
- B ID E +
+
+1
-1
+2
+2
+
+1
-1
+2
+2
Figure 13
Figure 12
4-Conductor Speaker Cable
Brass Inserts
Figure 11
D EBA C
Tri Pack System Speakon Assembly

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 13
1-YEAR LIMITED WARRANTY
A. American Audio® hereby warrants, to the original purchaser, American Audio® products to be
free of manufacturing defects in material and workmanship for a period of 1 Year (365 days) from
the date of purchase. This warranty shall be valid only if the product is purchased within the
United States of America, including possessions and territories. It is the owner’s responsibility to
establish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service, send the product only to the American Audio® factory. All shipping charges
must be pre-paid. If the requested repairs or service (including parts replacement) are within the
terms of this warranty, American Audio® will pay return shipping charges only to a designated
point within the United States. If the entire instrument is sent, it must be shipped in its original
package. No accessories should be shipped with the product. If any accessories are shipped
with the product, American Audio® shall have no liability whatsoever for loss of or damage to
any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified
in any manner which American Audio® concludes, after inspection, affects the reliability of the
product; if the product has been repaired or serviced by anyone other than the American Audio®
factory unless prior written authorization was issued to purchaser by American Audio®; if the
product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning or peri-
odic check-up. During the period specified above, American Audio® will replace defective parts
at its expense, and will absorb all expenses for warranty service and repair labor by reason of
defects in material or workmanship. The sole responsibility of American Audio® under this war-
ranty shall be limited to the repair of the product, or replacement thereof, including parts, at the
sole discretion of American Audio®. All products covered by this warranty were manufactured
after January 1, 1990, and bear identifying marks to that effect.
E. American Audio® reserves the right to make changes in design and/or improvements upon its
products without any obligation to include these changes in any products theretofore manufac-
tured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory sup-
plied with products described above. Except to the extent prohibited by applicable law, all
implied warranties made by American Audio® in connection with this product, including warran-
ties of merchantability or fitness, are limited in duration to the warranty period set forth above.
And no warranties, whether expressed or implied, including warranties of merchantability or
fitness, shall apply to this product after said period has expired. The consumer’s and or Dealer’s
sole remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall American Audio® be liable for any loss or damage, direct or consequential,
arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to American Audio® Products and super-
sedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
Tri Pack System Warranty

©American Audio® - www.americanaudio.us - Tri Pack System - Instruction Manual Page 14
Model: American Audio® Tri Pack System - Professional
Powered Subwoofer and Satellite Speakers
Subwoofer Section:
Component: 15” Woofer (4 Ohm)
Dimensions: 27.9” x 21.4” x 23.03” / 710mm x 545mm x 585mm
Weight: 92.5 Lbs. / 42 kgs
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Power Handling: 300W RMS
Frequency Response: 40 ~ 500Hz
Crossover Frequency: 40 ~ 250Hz (Adjustable)
Satellite Speaker Section:
Component: 8” Woofer (4 Ohm) + 1” Tweeter
Dimensions: 23.6” x 15.3” x 23.03” / 600mm x 390mm x 585mm
Weight: 20.9 Lbs. / 9.5 kgs
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Power Handling: 180W RMS
Normal Impedance: 4 Ohm
Frequency Response: 80 ~ 19KHz
Crossover Frequency: 350Hz
Sensitivity: 96dB@1W/1M
NOTES:
The specifications are subject to change to any improvement by negotiations in advance.
The parts are subject to change to any improvement within the range of the specifications.
Tri Pack System™ Technical Specifications

©American Audio
A Division of the American DJ Group of Companies
4295 Charter Street
Los Angeles, CA 90058 USA
Tel: [phone] Fax: [phone]
Web: www.americanaudio.us E-mail: [email protected]
