SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 1 of 15
SpeedDome®Ultra VII EIS
Day/Night Camera Dome
Configuration Utility
Operator’s Manual Supplement
Contents
About this Supplement.......................................... 1
SpeedDome Ultra VII EIS Features...................... 1
Menu Programming Navigation............................. 2
Setting Up EIS....................................................... 2
Changing Camera Functions within Presets......... 3
Return to Auto After Calling a Preset.................... 4
Programming Sequences...................................... 4
Pattern Options: Fixed or Variable Speed............. 7
Recording Patterns When Configured for 16........ 7
DirectSet Menu......................................................8
SpeedDome VII with EIS Compatibility...............10
Specifications-Indoor Dome................................ 13
Specifications-23X Camera with EIS ..................14
Declarations ........................................................ 15
© 2005 Sensormatic Electronics Corp.
About this Supplement
This supplement provides detailed information
about SpeedDome Ultra VII with EIS (Electronic
Image Stabilization) camera dome features that are
not currently covered in your operator’s manual.
This supplement supports information found in the
Day/Night Camera Dome Configuration Utility
Operator’s Manual, 8200-0184-04.
NOTE: Keep this supplement with your operator’s
manual for reference purposes.
If you need assistance...
Contact your Sales Representative.
SpeedDome Ultra VII EIS
Features
EIS (Electronic Image Stabilization) technology
works to overcome unsteady or blurred video
images from camera movement caused by wind,
vibration, and similar conditions.
The SpeedDome Ultra VII with EIS provides the
following features with firmware version 0710-
0532-0202 and newer.
•Electronic Image Stabilization
•16 Sequences
•Up to 16 Patterns
•Ability to change camera functions for each
Preset.
Updated information is also provided for
SensorNet, RS-422, Manchester, and UTC matrix
switchers and controllers.

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 2 of 15
Menu Programming
Navigation
The SpeedDome Ultra VII with EIS is programmed
from on-screen menus that are accessible through
your controller (keyboard, virtual keyboard, or
Touch Tracker®).
The starting point for programming is the
Configuration Menu. To access the menu on
most controllers press and hold the following
buttons in sequence:
Iris Open > Focus Far > Zoom Out
(Consult your keyboard manual for instructions if
you are unable to access programming menu.)
When programming dome functions, the primary
methods of navigation, item selection, and value
increases or decreases are:
Joystick. The joystick allows you to move the
cursor—represented by highlighting—around the
menus. You can select a field when it is
highlighted.
Focus Far button. Pressing the Focus Far button
selects or enables a choice on a highlighted field.
Zoom In/Out button. Pressing the Zoom In/Out
button scrolls a pre-determined list of values either
up or down in a highlighted field.
Setting Up EIS
You can turn off EIS or adjust the EIS sensitivity
level for all SpeedDome VII EIS cameras on your
system through the Camera Functions screen.
Follow the steps below:
1. Access the Dome Configuration Menu
(Figure 1) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 1
2. Use the joystick to highlight Camera
Functions and press Focus Far to select. The
Camera Functions screen appears (Figure 2).
Figure 2
3. Make your desired changes. EIS settings
provide the following choices:
•10 Hz = Default setting designed to stabilize
the dome when unwanted dome movements
are at 10 Hz.
•5 Hz = Designed to stabilize the dome when
unwanted dome movements are at 5 Hz.
•Off = Turns off Electronic Image
Stabilization.
For further details on the Camera Functions
screen, consult Chapter 3 of the Day/Night
Camera Dome Configuration Utility Operator’s
Manual, 8200-0184-04.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
CAMERA FUNCTIONS
Auto White Bal ON
IR MODE Auto Low
EIS 10 Hz
AGC/Shutter Max Gain Limit
Open Shutter 28 dB 1/4 s
RESET TO FACTORY SETTINGS
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 3 of 15
Changing Camera Functions
within Presets
When Presets are created, they adopt the dome
parameters defined in the Camera Functions
screen. You can now customize camera functions
for each Preset by accessing the Camera
Functions screen from the Preset screen.
Note: If you change the parameters in the Camera
Functions Menu for an existing Preset, you will
need to reprogram the Preset to save the changes.
Follow the steps below to change camera functions
with Presets:
1. Access the Dome Configuration Menu
(Figure 3) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 3.
2. Use the joystick to highlight Alarms / Areas /
Home / Presets / PZ and Press Focus Far to
select. The Alarms / Areas / Home / Presets /
PZ screen appears (Figure 4).
Figure 4.
3. Use the joystick to highlight Presets and press
Focus Far to select. The Select Preset To
Program screen appears (Figure 5).
Figure 5.
4. Use the joystick to highlight the PRESET
NUMBER field and press the Zoom In/Out
button until your desired Preset number
appears.
5. Use the joystick to highlight Camera Functions
and press the Focus Far button. The Camera
Functions screen appears (Figure 6).
Figure 6.
6. Make your desired changes. EIS settings
provide the following choices:
•10 Hz = Default setting designed to stabilize
the dome when unwanted dome movements
are at 10 Hz.
•5 Hz = Designed to stabilize the dome when
unwanted dome movements are at 5 Hz.
•Off = Turns off Electronic Image
Stabilization.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
ALARMS/AREAS/HOME/PRESETS/PZ
SET ALARM ACTIONS
SET ALARM STATES
SET HOME POSITION
SET NORTH POSITION
AREA BOUNDARIES
PRIVACY ZONES
PRESETS
SCAN LIMITS
EXIT
SELECT PRESET TO PROGRAM
PRESET PRESET NAME
NUMBER
1-96 PRESET 1-96
SEQUENCE SETUP MENU
CAMERA FUNCTIONS
FOCUS FAR to program preset
EXIT
CAMERA FUNCTIONS
Auto White Bal ON
IR MODE Auto Low
EIS 10 Hz
AGC/Shutter Max Gain Limit
Open Shutter 28 dB 1/4 s
RESET TO FACTORY SETTINGS
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 4 of 15
7. Use the joystick to highlight EXIT and press
the Focus Far button to select. The Select
Preset to Program screen appears.
8. Program (or reprogram) the Preset by
selecting FOCUS FAR to program preset (see
Note above).
For further details on the Camera Functions
screen, consult Chapter 3 of the Day/Night
Camera Dome Configuration Utility Operator’s
Manual, 8200-0184-04.
Note: Camera Function settings carry forward
from the last Preset created to the next Preset
created. You can change these settings on the
next Preset when creating the next Preset.
Return to Auto After Calling a
Preset
When calling a Preset, the SpeedDome Ultra VII
EIS camera adopts the IR Mode and EIS setting
uniquely created for that Preset. When an operator
moves the dome from its Preset position, the dome
can return to global IR Mode and EIS settings only
if programmed to do so through the Return to
Auto screen.
Follow the steps below to program Return to Auto:
1. Access the Dome Configuration Menu
(Figure 7) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 7
2. Use the joystick to highlight Pan / Tilt / Zoom /
Sync Opts and Press Focus Far to select.
The Pan / Tilt / Zoom / Sync Opts screen
appears (Figure 8).
Figure 8
3. Use the joystick to highlight Return to Auto and
Press Focus Far to select. The Return to Auto
screen appears (Figure 9).
Figure 9
4. Use the joystick to highlight each field (Focus,
Iris, EIS, and IR Mode). Select either On of Off
as your global camera default setting for each
field.
5. Use the joystick to highlight EXIT and press
Focus Far to select. When you reach the Dome
Configuration Menu, highlight EXIT AND SAVE
CHANGES and press Focus Far.
Note: the Reset to Factory Settings field resets
only the fields on the Return To Auto screen.
Programming Sequences
A Sequence is a sequential display of multiple
camera Presets. Sequences provide a methodical
and effective way to monitor multiple areas of
interest by switching to different Presets
automatically. Sequences are programmed from
the Select Preset to Program screen.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
PAN / TILT / ZOOM / SYNC OPTS
PROPORTIONAL FLIP OFF
1ST ZOOM STOP X 35
MAX TOTAL ZOOM X 92
LINE LOCK ON
FREEZE-FRAME OFF
RETURN TO AUTO
RESET TO FACTORY SETTINGS
EXIT
RETURN TO AUTO
FOCUS ON/OFF
IRIS ON/OFF
EIS ON/OFF
IR MODE ON/OFF
RESET TO FACTORY SETTINGS
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 5 of 15
Sequences are created by identifying Preset views
to include in the Sequence and specifying a dwell
time that controls how long each Preset remains on
screen before switching to another Preset. You can
create up to 16 Sequences, each with 16 steps
(Presets).
Steps to Programming
Sequences
Follow the steps below to program Sequences.
1. Access the Dome Configuration Menu
(Figure 10.) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 10.
2. Use the joystick to highlight Alarms / Areas /
Home / Presets/PZ and Press Focus Far to
select. The Alarms / Areas / Home / Presets /
PZ screen appears (Figure 11.).
Figure 11.
3. Use the joystick to highlight Presets and press
Focus Far to select. The Select Preset to
Program screen appears (Figure 12.).
Figure 12.
4. Use the joystick to highlight Sequence Setup
Menu and press Focus Far to select. The
Sequence Setup Menu screen appears
(Figure 13.).
Figure 13.
5. Use the Joystick to highlight the SEQUENCE
NUMBER field. Press Zoom In/Out to change
values (1-16).
6. Use the joystick to highlight the STEP field.
Press Zoom In/Out to scroll through available
steps. Steps are displayed in groups of 1-4, 5-
8, 6-12, and 13-16.
7. Use the joystick to highlight the PRESET field
and press Zoom In/Out until the desired
Preset number appears (1-96).
8. Use the joystick to highlight the DWELL TIME
MIN field and press Zoom In/Out until the
number of minutes you want the Preset to
remain on screen appears (0-10 minutes).
9. Use the joystick to highlight the DWELL TIME
SEC field and press Zoom In/Out until the
number of seconds you want the Preset to
remain on screen appears (0-60 seconds in
10-second increments).
10. Repeat steps 7 through 9 above until the first
four presets have been selected for steps 1-4.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
ALARMS/AREAS/HOME/PRESETS/PZ
SET ALARM ACTIONS
SET ALARM STATES
SET HOME POSITION
SET NORTH POSITION
AREA BOUNDARIES
PRIVACY ZONES
PRESETS
SCAN LIMITS
EXIT
SELECT PRESET TO PROGRAM
PRESET PRESET NAME
NUMBER
1-96 PRESET 1-96
SEQUENCE SETUP MENU
CAMERA FUNCTIONS
FOCUS FAR to program preset
EXIT
SEQUENCE SETUP MENU
SEQUENCE NUMBER 1
STEP 1-4 DWELL TIME
STEP PRESET MIN / SEC
1 1 0 0
2 1 0 0
3 1 0 0
4 1 0 0
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 6 of 15
If more Presets are desired in the Sequence,
use the joystick to highlight the STEP field and
press Zoom In/Out to display steps 5-8, 6-12
or 13-16. Add the Preset selection to fill each
step.
11. When finished, use the joystick to highlight
EXIT and press Focus Far to select.
12. At the Dome Configuration Menu screen,
highlight EXIT AND SAVE CHANGES and
press Focus Far to save.
Note: When a zero is encountered in the Preset
column, the Sequence will stop incrementing and
return to Step 1.
Running Sequences 1-16
Two options are available for running Sequences:
•Option 1 – If your keyboard supports the
DirectSet command, you can use it to run a
Sequence immediately (see DirectSet Menu,
page 8). Consult your keyboard manual for
information on DirectSet functions.
•Option 2 - Use the Set Home Position method
to schedule one Sequence to run when the
dome returns to its home position (after a
defined period of inactivity).
Follow the steps below to run Sequences from the
Set Home Position screen:
1. Access the Dome Configuration Menu
(Figure 14.) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 14.
2. Use the joystick to highlight Alarms / Areas /
Home / Presets / PZ and Press Focus Far to
select. The Alarms / Areas / Home /
Presets/PZ screen appears (Figure 15.).
Figure 15.
3. Use the joystick to highlight Set Home
Position and press Focus Far to select. The
Set Home Position screen appears
(Figure 16.).
Figure 16.
4. On the highlighted ACTION field, press the
Zoom In/Out button until Sequence appears.
5. Use the joystick to highlight the number field.
Press the Zoom In/Out button until your
desired Sequence number appears.
6. Use the joystick to highlight the RETURN TIME
MINS field. Press the Zoom In/Out button to
specify when the dome is to return to its home
position after a period of inactivity (1-60 min.).
This will trigger the Sequence to run.
7. Use the joystick to highlight the EXIT field and
press Focus Far to select.
8. Continue to exit until completely out of all
programming menus.
Note: If a Preset or a Pattern is called by either an
alarm or motion detection while a Sequence is
running, the Sequence will be interrupted.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
ALARMS/AREAS/HOME/PRESETS/PZ
SET ALARM ACTIONS
SET ALARM STATES
SET HOME POSITION
SET NORTH POSITION
AREA BOUNDARIES
PRIVACY ZONES
PRESETS
SCAN LIMITS
EXIT
SET HOME POSITION
ACTION SEQUENCE 1
RETURN TIME MINS 10
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 7 of 15
Pattern Options: Fixed or
Variable Speed
A Pattern is a series of programmed pan/tilt/zoom
dome movements. The SpeedDome Ultra VII with
EIS allows you to create fixed speed or variable
speed Patterns (variable speed Patterns are
dependent on system capability).
The SpeedDome Ultra VII with EIS provides three
options when configuring the system for Patterns:
Setting Description
Off Allows programming of three fixed speed
Patterns. The three Patterns are limited
to a total of 99 pan/tilt/zoom movements
(e.g., if one Pattern uses 50 movements,
the remaining two Patterns are limited to
a total of 49 movements). Note: The
VM96 system only supports the OFF
setting.
3Allows programming of three variable
speed Patterns. Each Pattern can have
up to 99 pan/tilt/zoom movements.
16 Allows programming of 16 variable
speed Patterns. Each Pattern can have
up to 99 pan/tilt/zoom movements.
Use the following steps to configure the dome for
Patterns:
1. Enter the Dome Configuration Menu
(Figure 17.) by pressing Iris Open, Focus Far
and Zoom Out on your controller.
Figure 17.
2. Use the joystick to highlight On-Screen Text
Display and press Focus Far to select. The
On-Screen Text Display screen appears
(Figure 18.).
Figure 18.
3. Use the joystick to highlight the PATTERN
SELECT field and press Zoom In/Out to select
Off, 3, or 16.
4. Use the joystick to highlight EXIT and press
Focus Far to select. The Dome Configuration
Menu appears.
5. Use the joystick to highlight EXIT AND SAVE
CHANGES and press Focus Far to save.
Recording Patterns When
Configured for 16
Recording Patterns when the Pattern Select field
is set for Off, 3, or 16 is accomplished through
keyboard commands (consult your keyboard’s user
guide). However, additional steps are required
when the Pattern Select field is set for 16.
Follow the steps below to record 16 variable speed
Patterns:
1. Enter the appropriate keyboard commands to
record a Pattern, using 1, 2, or 3 as your
Pattern number (Consult your keyboard user
guide for specific steps.). The Pattern Select
screen appears (Figure 19.)
Figure 19.
DOME CONFIGURATION MENU
PAN / TILT / ZOOM / SYNC OPTS
CAMERA FUNCTIONS
ALARMS / AREAS / PRESETS / PZ
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
DOME INFORMATION
RESET TO FACTORY SETTINGS
QUIT WITHOUT SAVING
EXIT AND SAVE CHANGES
ON-SCREEN TEXT DISPLAY
STATUS DISPLAY OFF
DISABLE ALL NAMES? YES
DIAGNOSTIC DISPLAY OFF
DIRECTION INDICATOR OFF
PATTERN SELECT 16
NAME CONFIGURATION MENU
TEXT ATTRIBUTE OPTIONS
EXIT
PATTERN SELECT
1 5 9 13
1 6 10 14
3 7 11 15
4 8 12 16
EXIT

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 8 of 15
2. Use the joystick to highlight a desired Pattern
number (1-16). Press Focus Far to continue.
3. Pan/tilt/zoom the dome as desired for the
Pattern.
4. Execute the keyboard’s Pattern save
command to save the Pattern.
Running 16 Patterns
When a dome is configured for 16 Patterns,
running a Pattern requires displaying the Pattern
Select screen (Figure 19). Follow the steps below
to run a Pattern.
1. Enter the appropriate keyboard command to
run Patterns 1, 2, or 3. The Pattern Select
screen appears.
2. Move the joystick to highlight the desired
Pattern number (1-16) to run.
3. Press Focus Far to select. The Pattern Select
screen disappears and the Pattern runs.
DirectSet Menu
The DirectSet Menu provides easy access to
commonly used SpeedDome Ultra VII with EIS
features when used with compatible controllers.
This allows you to change or activate features
without starting the dome configuration menu. See
the following examples of the DirectSet menu
(Figure 20).
Figure 20: Day/Night Camera Dome DirectSet
Menu (4 screens)
To access a feature on the menu, enter the
number and press the DirectSet button (varies by
controller). Table 1 provides a description of the
available options.
0 TOGGLE DIRECT SET MENU
1 DOME CONFIG MENU
2 AUTO IRIS/AUTO FOCUS
3 FLIP
4 PEEL PATTERN
10 NIGHT MODE
11 DAY MODE
12 AUTO DAY/NIGHT MODE
15 SMOOTH SCAN
16 STEPPED SCAN
FOCUS FAR = next page
17 RANDOM SCAN
20 DOME INFORMATION
48 EIS OFF
49 EIS 5 HZ
50 EIS 10 HZ
51 SEQUENCE 1
52 SEQUENCE 2
53 SEQUENCE 3
54 SEQUENCE 4
55 SEQUENCE 5
Use FOCUS to select next page
56 SEQUENCE 6
57 SEQUENCE 7
58 SEQUENCE 8
59 SEQUENCE 9
60 SEQUENCE 10
61 SEQUENCE 11
62 SEQUENCE 12
63 SEQUENCE 13
64 SEQUENCE 14
65 SEQUENCE 15
Use FOCUS to select next page
66 SEQUENCE 16
FOCUS NEAR = previous page

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 9 of 15
Table 1: DirectSet Menu Options
Command Description
0+DirectSet Toggle DirectSet Menu: Toggles
between displaying and hiding
the DirectSet menu.
1+DirectSet Dome Config Menu: Displays the
SpeedDome Ultra configuration
menu.
2+DirectSet Auto Iris/Auto Focus: Resumes
Auto Focus/Auto Iris mode.
3+DirectSet Flip: Rotates the SpeedDome
180° from its current pointing
direction. This is the same as
pressing the Flip button on
compatible controllers.
4+DirectSet Peel Pattern: Runs the default
Apple Peel Pattern. This is the
same as pressing the Peel button
on compatible controllers.
10+DirectSet Night Mode: Sets the dome IR
mode setting to ON. The dome
switches to full-time black-and-
white (B/W) mode.
11+DirectSet Day Mode: Sets the dome IR
mode setting to OFF. The dome
switches to full-time color mode.
12+DirectSet Auto Day/Night Mode: Resumes
the most recently selected
automatic IR mode setting.
•Auto High: B/W mode activates
~30 lux.
•Auto Mid: B/W mode activates
~3 lux.
•Auto Low: B/W mode activates
~ 0.5 lux
15+DirectSet Smooth Scan: Initiates a smooth
360° clockwise rotation around
the dome axis using the current
tilt, zoom and focus settings.
Command Description
16+DirectSet Stepped Scan: Initiates a
clockwise rotation around the
dome axis pausing briefly every
10° (at 1x zoom) for 3 seconds
using the current tilt, zoom and
focus settings.
17+DirectSet Random Scan: Initiates a
clockwise or counter-clockwise
rotation around the dome axis
using the current tilt, zoom and
focus settings. The dome pauses
randomly as it rotates around the
axis.
20+DirectSet Dome Information: Displays the
Dome Information screen
available through the dome
configuration menu.
48+DirectSet Turns off Electronic Image
Stabilization.
49+DirectSet Sets Electronic Image
Stabilization sensitivity at 5 hz.
50+DirectSet Sets Electronic Image
Stabilization sensitivity at 10 hz.
51+DirectSet Sequence: Runs Sequence 1
52+DirectSet Sequence: Runs Sequence 2
53+DirectSet Sequence: Runs Sequence 3
54+DirectSet Sequence: Runs Sequence 4
55+DirectSet Sequence: Runs Sequence 5
56+DirectSet Sequence: Runs Sequence 6
57+DirectSet Sequence: Runs Sequence 7
58+DirectSet Sequence: Runs Sequence 8
59+DirectSet Sequence: Runs Sequence 9
60+DirectSet Sequence: Runs Sequence 10
61+DirectSet Sequence: Runs Sequence 11
62+DirectSet Sequence: Runs Sequence 12
63+DirectSet Sequence: Runs Sequence 13
64+DirectSet Sequence: Runs Sequence 14
65+DirectSet Sequence: Runs Sequence 15
66+DirectSet Sequence: Runs Sequence 16
255+DirectSet Admin: Reset Dome (Baxall)

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 10 of 15
SpeedDome VII with EIS Compatibility
Controller Generator/Converter Protocol Presets Patterns Camera
Range
AD2091 Manchester 64
AD2083-02B RS-422 (Duplex) 16
AD1024/MP1024 AD2083-02C (AD2083-
02B ver 11YB) RS-422 (Simplex/Duplex) 60
16 1-1024
None Manchester 64
AD2083-02B RS-422 (Duplex) 16
AD1650 AD2083-02C (AD2083-
02B ver 11YB) RS-422 (Simplex/Duplex) 60
16 1-128
Manchester
SensorNet
CCM
RS-422 (Duplex)
1-180
AD2091 Manchester
64
AD2083-02B RS-422 (Duplex) 16
AD168/MP168
AD2083-02C (AD2083-
02B ver 11YB) RS-422 (Simplex/Duplex) 60
16
1-180
AD2091 Manchester 64
AD2083-02B RS-422 (Duplex) 16
AD2050 AD2083-02C (AD2083-
02B ver 11YB) RS-422 (Simplex/Duplex) 60
16 1-1024
None Manchester
64
AD2083-02B RS-422 (Duplex) 16
AD2150
AD2083-02C (AD2083-
02B ver 11YB) RS-422 (Simplex/Duplex) 60
16 1-32
None SensorNet
RCSN422 RS-422 (Duplex) 4 16
AD32/VM32
RCSN422 (ver 1.02) RS-422 (Simplex) 0 0
1-32
None SensorNet
96
RCSN422 4
RS-422 (Duplex) 96
16
AD32E/VM32E
RCSN422 (ver 1.02) RS-422 (Simplex) 0 0
1-32
Manchester 64
SensorNet
ADMP48 (Plus) None
RS-422 (Simplex/Duplex) 96
3
(OFF
mode) 1-288

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 11 of 15
Controller Generator/Converter Protocol Presets Patterns Camera
Range
SensorNet
SensorNet-V
None
AD UTC
ADMPLT
RCSN422 (ver 1.02) RS-422 (Duplex/Simplex)
96 16 1-32
None SensorNet 96
RCSN422 4
RS-422 (Duplex) 96
16
ADTT16/VM16
RCSN422 (ver 1.02) RS-422 (Simplex) 0 0
1-16
None SensorNet
96 1-64
RCSN422 4
RS-422 (Duplex) 16
ADTT16E/VM16E
(ver 2.01) RCSN422 (ver 1.02) RS-422 (Simplex) 96 3
1-32
CCM Manchester
CCM SensorNet
CCM RS-422 (Duplex)
AD2091 Manchester
32
AD2083-02B RS-422
(Duplex) 16
AD168¹
AD2083-02C RS-422
(Simplex/Duplex)
1-180
Manchester
RS-422 (Duplex)
MP48¹
SensorNet
32 1-48
AD2091 Manchester
AD2083-02B RS-422
(Duplex)
AD1024 Matrix¹
AD2083-02C RS-422
(Simplex/Duplex)
4
16
1-1024
SensorNet
VM96TT¹ RS-422 (Duplex) 32 3
(OFF
mode) 1-96
RS422 Dome¹ RS-422 (Duplex), (Simplex) 4 1-99
SensorNet
RCSN422 RS-422 (Duplex) 96 16
VM16/ADTT16 RCSN422 v1.02 RS-422
(Simplex) 0 0
1-16
SensorNet 1-64
RCSN422 RS-422 (Duplex) 16
VM16E/ADTT16E RCSN422 v1.02 RS-422
(Simplex)
96
3 1-32
Intellex
USB CCTV Module
(ADACSNET) SensorNet 96 3 1-254

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 12 of 15
Controller Generator/Converter Protocol Presets Patterns Camera
Range
VM1 None RS-422 (Duplex) 4 16 1-58
VM8 None SensorNet 0
0 (only
Apple
Peel) 1-8
SensorNet
VM96 None RS-422 (Duplex)
9,999
(across
all
dome,
stored
by
VM96)
3
(OFF
mode) 1-96
SensorNet
RS-422 (Duplex) 96 3
VR48 None
Manchester 64 16
1-48
NOTES:
1Certain Intellex handlers do not support the setting of presets or patterns. These must be set previously by way of the
matrix switcher/controller.
Controllers and Software tested in the matrix above:
Controller/Adapter Software Version
AD1024/MP1024 ...........................................V14FR5
AD1650..........................................................UF4W6
AD168/MP168 ...............................................V3.30
AD2050..........................................................UF3M9
AD2083-02B..................................................0701-11YA-156A
AD2083-02C..................................................0701-11YB-156A
AD2150..........................................................V13HR0
ADACSNET...................................................0710-0228-0101
ADTT16/VM16...............................................F 0701-2008-0200, E 0701-2007-0200
ADTT16E/VM16E (ver 2.01and higher).........F 0701-2834-0202, E 0701-2833-0103
Intellex...........................................................version 3.2.42.158 and 3.2.88.325-SP1
MP48 Plus .....................................................v1.1.4 (future release)
MP48/VR48...................................................v1.06
MPLT.............................................................v1.1.13
RCSN422 ......................................................F 0701-2814-0101, E 0701-9070-0100
RCSN422 (ver. 1.02).....................................F 0701-2814-0102, E 0701-9070-0100
VM1...............................................................Rev. M
VM32/AD32...................................................F 0701-2493-0104, E 0701-2492-0101
VM32E/AD32E ..............................................F 0701-2836-0102, E 0701-2835-0100
VM8...............................................................0701-0088-0101
VM96.............................................................v5.20

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 13 of 15
Specifications-Indoor Dome
Operational
Pan/Tilt:
Manual Pan Speed.................... 0.2°-100° per second
(scaled to zoom position)
Manual Tilt Speed................... 0.25°-100° per second
(scaled to zoom position)
Preset Pan/Tilt Speed.......220° per second maximum
Pan Travel.............................360° continuous rotation
Tilt Travel .............................................................>90°
Pan/Tilt Accuracy................................................±0.5°
23X (Day/Night) Camera Zoom Functions:
Optical Zoom.........................................................23X
Digital Zoom..........................................................10X
Zoom Pause................. 23X selectable or 35X default
Total Zoom..........................................................230X
Zoom Stop ........ 46X, 69X, 92X (default), 115X, 138X
161X, 184X, 207X, 230X
Zoom/Focus Accuracy ......................................±0.5%
Auto Synchronization:
Line Locked....................Remote V-phase adjustment
Internal.....................................Built-in sync generator
Address Range......................................................1-255
Quick View™Access Time <1 second to position. Full
zoom in <4 seconds.
Focus on VM16, VM32
and VideoManager
systems is <1 second.
Focus on VM96 and
RV2715 systems is <7
seconds
Programmable Patterns Up to 16 depending on
host
Program Storage 256 Kbytes of Flash
memory
Data Storage 128 Kbytes of SRAM
Menu Languages English, French, German,
Spanish, Italian, and
Portuguese
Electrical
Input Voltage...................................18-30Vac, 50/60 Hz
NEC Class 2 LPS
Design Tolerance............................16-36Vac, 50/60 Hz
Power Consumption........................................16W max.
Current..........................................................0.85A max.
Allowable Drop Out..............................................100ms
Power On In-Rush Current...................................... 1.5A
Surge Protection:
Video Output.........................Low capacitance Zener
suppressor 6.5V, 1500W
Power Line............................TVS rated at 60V, 1.5
joules, 250A 8/20µs
impulse
RS-422..................................TVS rated at 9.8V/1A,
20V/25A, 500W, 8/20µs
impulse
Manchester/SensorNet 485 ..Gas discharge tube rated
at: 8/20µs impulse
discharge current of 10kA,
ten 8/20µs impulse
discharge current of 5kA
Isolation transformer
coupled 2000Vrms.
PTC fuse protects
transformer. TVS rated at
9.8V/1A, 20V/25A, 500W,
8/20µs impulse
Alarm Input............................TVS rated at 9.8V/1A,
20V/25A, 500W, 8/20µs
impulse
Alarms Inputs/Control Outputs:
When no I/O board is used:
Inputs 1 dry contact/3.5mA sink
Outputs 1 open collector driver
@ 12Vdc, 40mA
When I/O board is used:
Inputs..............................4 dry contacts/3.5mA sink
Outputs 4 open collector drivers
@ 12Vdc, 40mA
Environmental
Operating Temperature.......–10° to 50°C (14° to 122°F)
Relative Humidity.................0 to 95% non-condensing
Storage Temperature...............................–20°C to 65°C
(–4°F to 149°F)

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 14 of 15
Mechanical
Height......................................................... 20.8cm (8in)
Eyeball Diameter ........................................12cm (4.7in)
Weight:
Housing and Eyeball............................. 1.36kg (3 lbs)
Base (standard) ............................... 0.09kg (0.20 lbs)
Base (with I/O board)....................... 0.16kg (0.35 lbs)
Lens and Bubble Densities
Eyeball Lens................................................................f0
Bubbles:
RUCLR (Clear).........................................................f0
RUSLV (Silver)..............................................f1.5 to f2
RUSMK (Smoke)...................................................f0.5
RUGLD (Gold)...............................................f1.5 to f2
Specifications-23X Camera
with EIS
Type........................... Interline transfer 1/4in CCD array
Scanning Area................................ 3.2 (H) x 2.4 (V) mm
Scanning System........................................ 2:1 interlace
Video Out..........................1.0 Vp-p/75 ohms composite
Signal-to-Noise.........................................50 dB (typical)
Horizontal Resolution........................ 470 lines at center
Minimum Illumination ............. 0.5 lux (AGC On, 20 IRE)
0.03 lux with 1/4 s open shutter
0.01 lux in IR mode
0.009 lux in IR mode with 1/4 s open shutter
White Balance..........Through-the-Lens (TTL) Automatic
Tracing White balance (ATW)
NTSC:
Effective Pixels..........................962 (H) x 654 (V) pixels
Scanning.........................525 lines, 60 fields, 30 frames
Horizontal.......................................................15.734kHz
Vertical................................................................ 59.9Hz
Lens Design
Type...............................................................Aspherical
Focal Length ............................................3.6 to 82.8mm
Aperture..................... f1.6 (wide angle), f3.7 (telephoto)
Viewing Angle (equivalent to 8-80 mm on 1/2in CCD
array, or 11-110 mm on 2/3in CCD array):
3.6mm .......................................... 54.0°(H) x 40.5°(V)
82.8mm ............................................ 2.5°(H) x 1.9°(V)
Field-of-View Formulas:
3.2mm* x distance from camera (m)
Focal length (mm) = Horizontal view (m)
2.4mm** x distance from camera (m)
Focal length (mm) = Vertical view (m)
* Horizontal scanning area of pickup device (mm) in
camera.
** Vertical scanning area of pickup device (mm) in
camera.
Example: Wide angle view with lens at 6mm and viewed
object at 10m.
3.2mm x 10m
6mm = 5.33m Horizontal view (m)
2.4mm x 10m
6mm = 4.0m Vertical view (m)

SPEEDDOME ULTRA VII EIS DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-13, REV. A
OPERATOR’S MANUAL SUPPLEMENT 15 of 15
Declarations
Regulatory Compliance
Emissions ................................ 47 CFR, Part 15, Class A
ICES-003
EN55022, Class B
EN61000-3-2
EN61000-3-3
AS/NZ 3548, Class A
CISPR 22
Immunity........................................................ EN50130-4
Safety ..................................................................UL1950
CSA C22.2 No. 950
EN 60950
IEC 60950
FCC COMPLIANCE: This equipment complies with Part 15
of the FCC rules for intentional radiators and Class A digital
devices when installed and used in accordance with the
instruction manual. Following these rules provides reasonable
protection against harmful interference from equipment
operated in a commercial area. This equipment should not be
installed in a residential area as it can radiate radio frequency
energy that could interfere with radio communications, a
situation the user would have to fix at their own expense.
EQUIPMENT MODIFICATION CAUTION: Equipment
changes or modifications not expressly approved by
Sensormatic Electronics Corporation, the party responsible for
FCC compliance, could void the user's authority to operate the
equipment and could create a hazardous condition.
Other Declarations
Thank you for using American Dynamics products. We
support our products through an extensive and worldwide
network of dealers. The dealer, through whom you originally
purchased this product, is your point of contact if you have a
need for service or support. Our dealers are fully empowered
to provide the very best in customer service and support.
Dealers should contact American Dynamics at [phone]
or [phone] or on the web at
www.americandynamics.net.
WARRANTY DISCLAIMER: Sensormatic Electronics
Corporation makes no representation or warranty with respect
to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular
purpose.
NOTICE: The information in this manual was current when
published. The manufacturer reserves the right to revise and
improve its products. All specifications are therefore subject to
change without notice.
LIMITED RIGHTS NOTICE: For units of the Department
of Defense, all documentation and manuals were developed at
private expense and no part of it was developed using
Government Funds. The restrictions governing the use and
disclosure of technical data marked with this legend are set
forth in the definition of “limited rights” in paragraph (a) (15)
of the clause of DFARS 252.227.7013. Unpublished - rights
reserved under the Copyright Laws of the United States.
TRADEMARK NOTICE: American Dynamics, Sensormatic,
and SpeedDome are trademarks or registered trademarks of
Sensormatic Electronics Corporation. Other product names
mentioned herein may be trademarks or registered trademarks
of Sensormatic or other companies.
COPYRIGHT: Under copyright laws, the contents of this
manual may not be copied, photocopied, reproduced,
translated or reduced to any electronic medium or machine-
readable form, in whole or in part, without prior written
consent of Sensormatic Electronics Corporation.
RLJ 09/2005
www.americandynamics.net
