American Magnetics 430 Manual

American Magnetics, Inc.
P.O. Box 2509, 112 Flint Road, Oak Ridge, TN 37831-2509, Tel: [phone], Fax: [phone]
Rev. 9, July 2017
MODEL 430 POWER SUPPLY
PROGRAMMER
INCLUDING HIGH-STABILITY OPTION &
MULTI-AXIS APPLICATIONS
INSTALLATION, OPERATION, AND
MAINTENANCE INSTRUCTIONS
EXCELLENCE IN MAGNETICS AND CRYOGENICS

REV 9 III
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Foreword .................................................................................. ix
Purpose and Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Contents of this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Applicable Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x
General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Cryogen Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Treating Cold Burns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Handling Cryogenic Liquids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xii
Material Safety at Cryogenic Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Magnet Quenches in LHe-Cooled Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Risk of Explosion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Magnetic Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Safety Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Minimum Recommended Safety Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Safety Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xv
Introduction ...............................................................................1
Model 430 Programmer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Digitally-Controlled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Superior Resolution and Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
High-Stability Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intuitive Human-Interface Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Flexibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Standard Remote Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Programmable Safety Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Condition-Based Magnet Auto-Rampdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Model 430 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Model 430 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Model 430 Specifications @ 25 °C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Operating Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Single-Quadrant Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dual-Quadrant Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Four-Quadrant Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

iv REV 9
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Installation............................................................................... 13
Inspecting and Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Model 430 Programmer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Changing the Model 430 Programmer Operating Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Collecting Necessary Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
System Interconnects (Single-Axis Systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Unipolar Power Supply System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Bipolar Power Supply System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
High-Stability Bipolar Power Supply System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
High-Current Four-Quadrant Power Supply System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
High-Current, High-Stability 4-Quadrant Power Supply System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Low-Current, High-Resolution 4-Quadrant Power Supply System . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
System Interconnects (Multi-Axis Systems). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Load Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Instrumentation Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Standard (non-recondensing) Helium-based 2-Axis System Signal Interconnects . . . . . . . . . . . . . . 38
Standard (non-recondensing) Helium-based 3-Axis System Signal Interconnects . . . . . . . . . . . . . . 39
Recondensing Helium-based 2-Axis System Signal Interconnects . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Recondensing Helium-based 3-Axis System Signal Interconnects . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cryogen-Free 2-Axis System Signal Interconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Cryogen-Free 3-Axis System Signal Interconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Third-Party Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Special Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Superconducting Magnets with No Persistent Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Short-Circuit or Resistive Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Power-Up and Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Operation ................................................................................ 49
System Power On/Off Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Model 430 Programmer Power On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Energizing the Power Supply and Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Model 430 Programmer Default Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

REV 9 V
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Field / Current Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Voltage Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Status Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Main Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Entering Numeric Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Using the Fine Adjust Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Selecting Picklist Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Single-key Commands / Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Persistent Switch Control Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Target Field Setpoint Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Ramp / Pause Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Ramp To Zero Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
SHIFT+key Commands / Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Ramp Rate (Shift+1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Voltage Limit (Shift+2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Reset Quench (Shift+3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Increment Field (Shift+4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Field <> Current (Shift+5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Decrement Field (Shift+6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Field Units (Shift+7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Persistent Switch Heater Current (Shift+8). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Stability (Shift+9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Vs <> Vm (Shift+0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Volt Meter (Shift+.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Fine Adjust (Shift +/-) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Shift + Persist. Switch Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Power-on Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Magnet Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Shift Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Entering / Exiting Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Menu Navigation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Setup Submenu Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Supply Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Load Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Switch Submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

vi REV 9
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Protection Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Misc Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Net Settings Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Net Setup Submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Example Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Ramping Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Ramping States and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Manual Ramping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Automatic Ramping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Ramping to Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Fine Adjust of Field / Current in Holding Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Persistent Switch Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Procedure for Initial Heating of the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Procedure for Entering Persistent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Procedure for Exiting Persistent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Toggling the State of the Persistent Switch Heater. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Ramping Functions Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Quench Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Quench Detection Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
External Quench Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Disabling Internal Quench Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
External Rampdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
External Rampdown while in Persistent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
External Rampdown while not in Persistent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Summary of Limits and Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Remote Interface Reference................................................... 129
SCPI Command Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Programming Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
SCPI Language Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
SCPI Status System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Status Byte Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Standard Event Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Command Handshaking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
RS-232 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

REV 9 VII
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Serial Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Termination Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Ethernet Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143
Ethernet Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Termination Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Port Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Telnet Port 23 Broadcast Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Command Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
System-Related Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Status System Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Supply Setup Configuration Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Load Setup Configuration Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Switch Setup Configuration Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Protection Setup Configuration Commands and Queries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Misc Setup Configuration Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Lock Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Net Setup Configuration Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Ramp Target/Rate Configuration Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Measurement Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Ramping State Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Switch Heater Command and Query . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Quench State Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Rampdown State Commands and Queries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Trigger Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Command Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Query Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Execution Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Device Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Service ................................................................................... 183
System Component Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183
Troubleshooting Hints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183
Electrostatic Discharge Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Hints for Commonly Encountered Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Additional Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
Return Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191

viii REV 9
AMERICAN MAGNETICS, INC.TABLE OF CONTENTS
Appendix ............................................................................... 193
Magnet Station Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
LHe Level / Temp Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Programmer Shunt Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Current Transducer Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Program Out Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Quench I/O Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
External Quench Detection Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
External Rampdown Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
External Quench Detection Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Auxiliary Inputs Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Ethernet Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
RS-232 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Abbreviations and Acronyms used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Remote Computer Communication with the Model 430 . . . . . . . . . . . . . . . . . . . . . . . 208
Communication via RS-232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Communication via Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
Upgrading the Model 430 Firmware via FTP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Hardware and Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Upload Procedure using FileZilla . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Alternative Upload Procedure using Windows FTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Upgrading the Model 430 Firmware via Flash Card Reader . . . . . . . . . . . . . . . . . . . . 221
Hardware and Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Upgrade Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
Magnet-DAQ: Model 430 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Short-Sample Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Index...................................................................................... 233

REV 9 IX
AMERICAN MAGNETICS, INC.FOREWORD
Foreword
PURPOSE AND SCOPE
This manual contains the operation and maintenance instructions for the
American Magnetics, Inc. Model 430 Programmer and outlines various
system configurations. Since it is not possible to cover all equipment
combinations for all magnet systems offered by AMI, only the most
common configurations are discussed. The user is encouraged to
contact an authorized AMI Technical Support Representative for
information regarding specific configurations not explicitly covered in this
manual.
CONTENTS OF THIS MANUAL
Introduction introduces the reader to the functions and characteristics
of the Model 430 Power Supply Programmer. It provides illustrations of
the front and rear panel layouts as well as documenting the performance
specifications. Additional information is provided in the form of system
circuit diagrams.
Installation describes how the Model 430 Power Supply Programmer is
unpacked and installed in conjunction with ancillary equipment in typical
superconducting magnet systems. Block-level diagrams document the
interconnects for various system configurations.
Operation describes how the Model 430 Programmer is used to control
a superconducting magnet. All Model 430 Programmer displays and
controls are documented. The ramping functions, persistent switch
heater controls, and the quench detect features are also presented.

XREV 9
AMERICAN MAGNETICS, INC.FOREWORD : APPLICABLE HARDWARE
Remote Interface Reference documents all remote commands and
queries available through the Model 430 Programmer RS-232 and
Ethernet interfaces. A quick-reference summary of commands is
provided as well as a detailed description of each.
Service provides guidelines to assist the user in troubleshooting
possible system and Model 430 Programmer malfunctions. Information
for contacting AMI Technical Support personnel is also provided.
Appendix provides additional details and/or procedures in the following
areas:
• Model 430 Programmer rear panel connectors.
• Establishing RS-232 or Ethernet communications with the Model 430.
• Model 430 firmware upgrade procedures.
• Abbreviations and acronyms used in this manual.
• Persistent switch operation (flow diagram).
• Optional Short-Sample operational mode.
APPLICABLE HARDWARE
The Model 430 Programmer has been designed to operate with a wide
variety of switch mode and linear power supplies from a variety of
manufacturers. However, not all compatible power supplies have been
tested. The Model 430 Programmer has been tested and qualified with
the following power supplies or power supply systems:
AMI Model 12100PS switching power supply (12 V @ 100 A)
AMI Model 12200PS switching power supply (12 V @ 200 A)
AMI Model 7.5-140PS switching power supply (7.5 V @ 140 A)
AMI Model 10100PS switching power supply (10 V @ 100 A)
AMI Model 10200PS switching power supply (10 V @ 200 A)
AMI Model 08150PS switching power supply (1200 Watt)
AMI Model 03300PS (multiple Model 08150PS w/ Energy Absorbers; ±3 V @ 300 A)
AMI Model 05100PS (Model 08150PS w/ Energy Absorber; ±5 V @ 100 A)
AMI Model 05120PS (Model 08150PS w/ Energy Absorber; ±5 V @ 120 A)
AMI Model 05240PS (multiple Model 08150PS w/ Energy Absorbers; ±5 V @ 240 A)
AMI Model 05360PS (multiple Model 08150PS w/ Energy Absorber; ±5 V @ 360 A)
AMI Model 05400PS switching power supply w/ Energy Absorber (±5 V @ 400 A)
AMI Model 05600PS (multiple Model 08150PS w/ Energy Absorber; ±5 V @ 600 A)
AMI Model 4Q06125PS 4-quadrant switching power supply (±6 V @ ±125 A)
AMI Model 4Q06250PS 4-quadrant switching power supply (±6 V @ ±250 A)
AMI Model 4Q12125PS 4-quadrant switching power supply (±12 V @ ±125 A)
AMI Model 4Q05100PS 4-quadrant switching power supply (±5 V @ ±100 A)
Xantrex Model XFR 12-100 switching power supply (12 V @ 100 A)
Xantrex Model XFR 12-220 switching power supply (12 V @ 220 A)
Xantrex Model XHR 7.5-130 switching power supply (7.5V @ 130 A)
Hewlett-Packard 6260B linear power supply (10 V @ 100 A)
Kepco BOP 20-5M 4-quadrant linear power supply (±20 V @ ±5 A)

REV 9 XI
AMERICAN MAGNETICS, INC.FOREWORD : GENERAL PRECAUTIONS
Kepco BOP 20-10M 4-quadrant linear power supply (±20 V @ ±10 A)
Kepco BOP 20-20M 4-quadrant linear power supply (±20 V @ ±20 A)
Consult with an AMI Technical Support Representative for other
approved power supplies.
GENERAL PRECAUTIONS
CRYOGEN SAFETY The two most common cryogenic liquids used in superconducting
magnet systems are nitrogen (LN2) and helium (LHe). Both of these
cryogens are extremely cold at atmospheric pressure (−321°F and −
452°F, respectively). The following paragraphs outline safe handling
precautions for these liquids.
Personnel handling cryogenic liquids should be thoroughly instructed
and trained as to the nature of the liquids. Training is essential to
minimize accidental spilling. Due to the low temperature of these
materials, a cryogen spilled on many objects or surfaces may damage
the surface or cause the object to shatter, often in an explosive manner.
Inert gases released into a confined or inadequately ventilated space
can displace sufficient oxygen to make the local atmosphere incapable
of sustaining life. Liquefied gases are potentially extreme suffocation
hazards since a small amount of liquid will vaporize and yield a very
large volume of oxygen-displacing gas. Always ensure the location
where the cryogen is used is well ventilated. Breathing air with
insufficient oxygen content may cause unconsciousness without
warning. If a space is suspect, purge the space completely with air and
test before entry. If this is not possible, wear a forced-air respirator and
enter only with a co-worker standing by wearing a forced-air respirator.
Cryogenic liquids, due to their extremely low temperatures, will also burn
the skin in a similar manner as would hot liquids. Never permit cryogenic
liquids to come into contact with the skin or allow liquid nitrogen to soak
clothing. Serious burns may result from careless handling. Never touch
uninsulated pipes or vessels containing cryogenic liquids. Flesh will stick
to extremely cold materials. Even nonmetallic materials are dangerous
to touch at low temperatures. The vapors expelled during the venting
process are sufficiently cold to burn flesh or freeze optic tissues.
Insulated gloves should be used to prevent frost-bite when operating
valves on cryogenic tanks. Be cautious with valves on cryogenic
systems; the temperature extremes they are typically subjected to cause
seals to fail frequently.

XII REV 9
AMERICAN MAGNETICS, INC.FOREWORD : GENERAL PRECAUTIONS
TREATING COLD BURNS In the event a person is burned by a cryogen or material cooled to
cryogenic temperatures, the following first aid treatment should be given
pending the arrival and treatment of a physician or other medical care
worker:
1. If any cryogenic liquid contacts the skin or eyes, immediately flush the
affected area gently with tepid water (102°F − 105°F, 38.9°C − 40.5°C) and
then apply cold compresses.
2. Do not apply heat. Loosen any clothing that may restrict circulation. Apply a
sterile protective dressing to the affected area.
3. If the skin is blistered or there is any chance that the eyes have been
affected, get the patient immediately to a physician for treatment.
HANDLING CRYOGENIC LIQUIDS
Containers of cryogenic liquids are self pressurizing (as the liquid boils
off, vapor pressure increases). Hoses or lines used to transfer these
liquids should never be sealed at both ends (i.e. by closing valves at
both ends).
When pouring cryogenic liquids from one container to another, the
receiving container should be cooled gradually to prevent damage by
thermal shock. The liquid should be poured slowly to avoid spattering
due to rapid boil off. The receiving vessel should be vented during the
transfer.
MATERIAL SAFETY AT CRYOGENIC TEMPERATURES
Introduction of a substance at or near room temperature into a cryogenic
liquid should be done with great caution. There may be a violent gas
boil-off and a considerable amount of splashing as a result of this rapid
boiling. There is also a chance that the material may crack or
catastrophically fail due to forces caused by large differences in thermal
contraction of different regions of the material. Personnel engaged in this
type of activity should be instructed concerning this hazard and should
always wear a full face shield and protective clothing. If severe spraying
or splashing could occur, safety glasses or chemical goggles along with
body length protective aprons will provide additional protection.
The properties of many materials at extremely low temperatures may be
quite different from the properties that these same materials exhibit at
room temperatures. Exercise extreme care when handling materials
cooled to cryogenic temperatures until the properties of these materials
under these conditions are known.

REV 9 XIII
AMERICAN MAGNETICS, INC.FOREWORD : GENERAL PRECAUTIONS
Metals to be used for use in cryogenic equipment application must
posses sufficient physical properties at these low temperatures. Since
ordinary carbon steels, and to somewhat a lesser extent, alloy steels,
lose much of their ductility at low temperatures, they are considered
unsatisfactory and sometimes unsafe for these applications. The
austenitic Ni-Cr alloys exhibit good ductility at these low temperatures
and the most widely used is 18-8 stainless steel. Copper, Monel®, brass
and aluminum are also considered satisfactory materials for cryogenic
service.
MAGNET QUENCHES IN LHE-COOLED SYSTEMS
When an energized superconducting magnet transitions from
superconducting state to normal state, the magnet converts magnetic
energy to thermal energy thereby rapidly converting the liquid helium to
a vapor. When this phase transformation occurs, pressures can build
rapidly in the cryostat due to the fact that one part of liquid helium will
generate 782 parts of gaseous helium at STP (standard temperature and
pressure). The cryostat must be designed to allow the generated vapor
to rapidly and safely vent to an area of lower pressure. Cryostats are
designed with pressure relief valves of sufficient capacity so as to limit
the pressure transients within the container in order to prevent damage
to the vessel. Operating a superconducting magnet in a cryostat without
properly sized relief mechanisms or disabled relief mechanism is unsafe
for the operator as well as for the equipment. If there is any doubt as to
the sufficiency of the pressure relief system, contact the manufacturer of
the magnet and cryostat for assistance.
RISK OF EXPLOSION Ensure cryogen container and/or magnet system vent relief valves are
kept clear. An improperly ventilated cryostat/system may become
blocked by ice with subsequent RISK OF EXPLOSION and uncontrolled
release of cryogens from the system. Relief valves and rupture disks
may also discharge cold gas violently without warning. Relief valves
should always be pointed in a safe direction. Care must be taken not to
disable pressure relief devices or otherwise create a condition where
pressure buildup can occur in a magnet system or cryogen container
because of the RISK OF EXPLOSION. FAILURE TO HEED THIS
WARNING COULD RESULT IN INURY OR DEATH.
MAGNETIC FIELDS The following notices should be posted to warn personnel of the dangers
of strong magnetic fields produced by superconducting magnets:
i. WARNING: The operation of medical electronic implants, such as
cardiac pacemakers, may be affected by magnetic fields, WHICH
COULD CAUSE INJURY OR DEATH.

XIV REV 9
AMERICAN MAGNETICS, INC.FOREWORD : SAFETY SUMMARY
ii. WARNING: Medical implants, such as aneurysm clips, surgical clips or
prostheses may contain ferromagnetic materials and therefore would be
subject to strong forces near a magnet. THIS COULD RESULT IN INURY
OR DEATH. In the vicinity of rapidly changing field (e.g. pulsed gradient
fields), eddy currents may be induced in the implant resulting in heat
generation.
iii. WARNING: Metal materials in someone's body as a result of an old
injury may be affected by magnetic fields in this facility. THIS COULD
RESULT IN INURY OR DEATH.
iv. WARNING: Large attractive forces may be exerted on equipment
brought near to the magnet. The force may become large enough to
move the equipment uncontrollably towards the magnet. Pieces of
equipment may become projectiles and large equipment (e.g. gas
bottles, power supplies) could trap bodies or limbs between the
equipment and the magnet. EITHER TYPE OF OBJECT MAY CAUSE
INJURY OR DEATH. The closer to the magnet you get, the larger the
force is. The larger the mass of the equipment the larger the force pulling
it.
v. CAUTION: The operation of equipment may be directly affected by the
presence of large magnetic fields. Items such as watches, tape
recorders, and cameras may be magnetized and irreparably damaged if
exposed to magnetic fields. Information encoded magnetically on credit
cards and magnetic tape including computer floppy discs, may be
irreversibly corrupted. Electrical transformers may become magnetically
saturated. Safety characteristics of equipment may also be affected.
SAFETY SUMMARY
Superconducting magnet systems are complex systems with the
potential to seriously injure personnel or equipment if not operated
according to procedures. The use of cryogenic liquids in these systems
is only one factor to consider in safe and proper magnet system
operation. Proper use of safety mechanisms (pressure relief valves,
rupture disks, etc.) included in the cryostat and top plate assembly are
necessary. Furthermore, an understanding of the physics of the magnet
system is needed to allow the operator to properly control the large
amounts of energy stored in the magnetic field of the superconducting
coil. The Model 430 Programmer has been designed with safety
interlocks to assist the operator in safe operation, but these designed-in
features cannot replace an operator’s understanding of the system to
ensure the system is operated in a safe and deliberate manner.
MINIMUM RECOMMENDED SAFETY EQUIPMENT
• First Aid kit
• Fire extinguisher rated for class C fires

REV 9 XV
AMERICAN MAGNETICS, INC.FOREWORD : SAFETY SUMMARY
• Cryogenic gloves
• Face shield
• Signs to indicate that there are potentially hazardous magnetic fields in the
area and that cryogens are in use in the area.
SAFETY LEGEND Instruction manual symbol: the product is marked with this
symbol when it is necessary for you to refer to the instruction
manual in order to protect against damage to the product or
personal injury.
Hazardous voltage symbol.
Alternating Current (Refer to IEC 417, No. 5032).
Off (Supply) (Refer to IEC 417, No. 5008).
On (Supply) (Refer to IEC 417, No. 5007).
WARNING The Warning sign denotes a hazard. It calls attention to a
procedure or practice, which if not correctly adhered to,
could result in personal injury. Do not proceed beyond a
Warning sign until the indicated conditions are fully
understood and met.
CAUTION The Caution sign denotes a hazard. It calls attention to an
operating procedure or practice, which if not adhered to,
could cause damage or destruction of a part or all of the
product. Do not proceed beyond a Caution sign until the
indicated conditions are fully understood and met.
O
I

XVI REV 9
AMERICAN MAGNETICS, INC.FOREWORD : SAFETY SUMMARY

REV 9 1
AMERICAN MAGNETICS, INC.INTRODUCTION
Introduction
MODEL 430 PROGRAMMER FEATURES
The AMI Model 430 Programmer is a sophisticated digital power supply
controller which allows an operator to manage a superconducting
magnet system with unprecedented accuracy and ease of use. The
Model 430 Programmer provides a degree of flexibility and accuracy
previously unavailable in an economical commercial product.
Typical components of a power supply system include a Model 430
Programmer with optional zero flux current sensing system (high-stability
option), one or more energy absorbers (for bipolar systems), and one or
more power supplies (unipolar or four-quadrant) to achieve the rated
system output current.
DIGITALLY-
CONTROLLED
The Model 430 Programmer is controlled by a microcomputer which per-
forms all analog data conversion, display/keypad functions, communica-
tions I/O, generation of analog programming signals for the external
power supply, and control law computations. The Model 430 Program-
mer incorporates digital signal processing (DSP) functions that provide
for accurate control, low drift, and flexibility of use.
SUPERIOR RESOLUTION
AND STABILITY
The Model 430 Programmer incorporates high-resolution converters to
translate signals between the analog and digital domains. Precision
instrumentation techniques and potentiometer-free designs are
employed throughout the Model 430 Programmer to ensure accurate
signal translation for a wide range of conditions. The magnet current is
sampled at 24-bit resolution in hardware and is software-programmable
to 15-digits resolution. All pause and hold functions are performed in the
digital domain which provides for excellent stability and drift of the pro-
grammed magnetic field.

2 REV 9
AMERICAN MAGNETICS, INC.INTRODUCTION : MODEL 430 PROGRAMMER FEATURES
HIGH-STABILITY
OPTION
For greater stability and accuracy, the Model 430 Programmer can be
configured with a zero-flux precision current measuring device instead of
the standard resistive shunt. This option typically increases the system
stability and accuracy by an order of magnitude. The power supply sys-
tems incorporating this technique are referred to as “high-stability” sys-
tems.
INTUITIVE HUMAN-
INTERFACE DESIGN
The Model 430 Programmer was designed to simplify the interface
where possible. All functions were analyzed and subsequently
programmed so that the most commonly used functions are addressed
with the least number of keystrokes. The menus are also presented in a
logical fashion so that the operation of the Model 430 Programmer is
intuitive to the user.
The provision of a velocity-sensitive rotary encoder on the front panel
also allows the operator to interactively fine-adjust many of the operating
parameters of the magnet system.
FLEXIBILITY The Model 430 Programmer can be configured with the supporting
hardware as a two- or four-quadrant power supply system which is able
to both supply and remove electrical energy from the superconducting
magnet system. The Model 430 Programmer is engineered to be
compatible with most power supplies with remote analog programming
capabilities.
From simple single-quadrant supplies, to more elaborate four-quadrant
units, the Model 430 Power Supply Programmer is user-configurable
such that the operational paradigm complies with the specific magnet
system requirements.
STANDARD REMOTE
INTERFACES
The Model 430 Programmer provides an RS-232 serial port as well as
an Ethernet port as standard features. All settings can be controlled via
the remote interfaces and the front panel can be remotely locked to
prevent accidental operation. The Model 430 Programmer also provides
remote trigger functions for data collection and/or logging during
operation.
PROGRAMMABLE
SAFETY FEATURES
The Power Supply System is designed to be operated from the front
panel of the Model 430 Programmer or remotely with operational
parameters which must not be exceeded for the given conditions of the
system. Once set, should an operator inadvertently attempt to take the
magnet system to an excessive magnetic field strength or charge at an
excessive voltage, the Model 430 Programmer will not accept the

REV 9 3
AMERICAN MAGNETICS, INC.INTRODUCTION : MODEL 430 PROGRAMMER FEATURES
parameter and will alert the operator that a value was rejected because it
was outside the user-defined limits.
In addition, each setup parameter can be individually selected for
locking. A user-defined password is required to lock or unlock settings.
This allows an administrator to set and password protect any critical
parameters that should not be changed by the operator. Then the
administrator can be confident that an operator will not subsequently
change any of these critical parameters, and yet will be free to change
any non-critical (unlocked) parameters.
CONDITION-BASED
MAGNET AUTO-
RAMPDOWN
The Model 430 Programmer can be connected to an AMI Model 1700
Liquid Level Instrument, with the LHe measurement option, to allow
automatic rampdown of the magnet (even in persistent mode) should the
liquid helium (LHe) level drop to a preset level. This feature ensures the
magnet will be protected and not experience a quench should the LHe
level reach an unsafe level for magnet operation. A single cable is
required to use this feature and is covered in more detail on page 200 of
the Appendix. Contact AMI for more information.
In addition to low LHe level, inputs to the Model 430 Programmer can be
used with other instrumentation as well. Other uses include faults from a
cryocooler, temperature measurement limit, etc.

4 REV 9
AMERICAN MAGNETICS, INC.INTRODUCTION : MODEL 430 FRONT PANEL LAYOUT
MODEL 430 FRONT PANEL LAYOUT
SHIFT 123
45
7
8
.+/-
0
9
6
RAMP
RATE
INCR.
FIELD
FIELD
UNITS
Vs <> Vm VOLT
METER
FINE
ADJUST
P. SWITCH
HTR. CUR. STAB.
DECR.
FIELD
FIELD <>
CURRENT
VOLTAGE
LIMIT
RESET
QUENCH
MENU
ENTER
ESC
PAUSE
RAMP
TARGET
FIELD
SETPOINT
PERSIST.
SWITCH
CONTROL
RAMP
TO
ZERO
FIELD AT TARGET
MAGNET IN PERSISTENT MODE
MAGNET QUENCH
CURRENT LEADS ENERGIZED
American Magnetics, Inc. Model 430 Power Supply Programmer
Model 430 Front Panel Description
1Power Indicator LED 8Fine Adjust Knob 2280 x 16 Dot Graphic VF Display 9Persistent Switch Heater Control Key 3Shift Indicator LED 10 Target Field Setpoint Key
4Shift Key 11 Ramp/Pause Switch 54 Row x 3 Column Keypad 12 Menu Navigation and Data Entry Keys 6Power Switch 13 Ramp to Zero Key 7Magnet Status Indicator LEDs
