StorTrends 1000i
IP-SAN/NAS Storage
HIGHLIGHTS
>
>
>
>
>
Merges block and file data onto the same
storage appliance
Block and file data transferred over existing
Ethernet network
Cost-effective and scalable
Configurable snapshot
ManageTrends, storage management suite
StorTrends®1000i is an affordable 1U, rack-mount storage appliance that
offers support for both block and file data. The iSCSI networked storage solution
merges Ethernet-based Storage Area Networks (IP-SAN) and Network Attached
Storage (NAS). ManageTrends™enables an administrator to coordinate all
functions relating to discovery, management, tracking and planning for future
storage growth. StorTrends 1000i is designed for SMBs (Small and Medium
Businesses) desiring a cost-effective and scalable iSCSI networked storage solution.
StorTrends 1000i merges block and file
data onto a storage appliance that handles
all your storage needs. The merged block
and file data is transferred over the
existing Ethernet network. Setup is quite
simple via an easy web-based management
interface that enables the administrator to
control key system parameters such as
health variables, iSCSI configuration
values, NAS file share and security
configurations.
ManageTrends is AMI's storage
management suite based on Microsoft’s
.NET technology. The storage
management suite discovers and manages
StorTrends 1000i devices across the
network and assists in analyzing and
tracking enterprise wide storage usage.
ManageTrends monitors the storage and
storage-related events, provides a detailed
analysis of the storage usage and the
availability of the storage servers.
A hierarchical view of the entire
storage, both block-based and file-based, is
provided and the administrator can create
a pool of storage from either internal or
external disks. RAID levels 0 (stripe), 1
(mirrored) and 5 (redundant) are
supported. Once created, a storage pool
can be divided into block accessible and/or
file accessible partitions. The block-based
storage pool can dynamically grow in the
future as the enterprise grows. This
enables organizations and their IT
managers to plan their storage capacity in
an efficient, cost-effective and just in time
manner.
Using ManageTrends, the user can
create several zones and map the iSCSI
targets to those zones. Key features of
zoning capabilities are as follows:
• Create, view or edit zone information,
• User defined name and comments for
the zone,
• Specify the iSCSI targets/LUNs to
participate in the zone and
• Complies with the iSNS Discovery
Domains (DD).
© 2004 American Megatrends Inc. - Specifications subject to change without notice
Data Sheet
10 19 2004

© 2004 American Megatrends Inc. - Specifications subject to change without notice
StorTrends 1000i
IP-SAN/NAS Storage
2/3
Features
Software Specifications
Networking
TCP/IP
Windows
UNIX
Novell
Apple
SNMP
FTP (Web)
Event Management
Detailed Event Log
SNMP Traps (up to 4 destinations)
iSCSI Target Configurations
iSCSI Qualified Name (iqn) format
Enable/Disable individual network ports for
iSCSI traffic
iSCSI target supporting Draft 20 of iSCSI spec
Tight iSCSI and iSNS integration
iSCSI error recovery level 0 and 1
Maximum of 4 connections per session
Maximum of 128 targets per box
Maximum of 8 LUNs per target
Multiple levels of authentication including
mutual chap, user name/password chap
authentication and iSCSI Initiator WWN
name
iSCSI Portal Tag configuration from UI
View iSCSI Data & Error statistics
iSNS Configuration
Up to 16 iSNS servers are supported
Compatible with MS iSNS server RC 2.2 and
later versions
iSNS client supporting Draft 22 of iSNS
specification
iSCSI Payload
Device statistics
Error statistics
iSCSI Tunable Parameters
Maximum connections
First burst length
Maximum burst length
Default time to retransmit
Default rime to wait
Maximum outstanding ready to retransmit
Error recovery level
Data PDU in order
Data sequence in order
Initial ready to retransmit
Immediate data
Maximum receive burst
Remote Management
SNMP
Web Based User Interface
(Internet Explorer 6.0 or later versions)
Dashboard
Hardware health management panel
- periodic detail monitoring of the
hardware health parameters
- visual guide to system health of
environmental parameters as well as
storage subsystem.
Multi-language support: English, Spanish,
German, French, Japanese, Korean,
Traditional & Simplified Chinese
Browser compatibility
Storage Data Management
Storage Explorer
Storage pool
RAID 0, 1, 5
Slice storage pool for SAN & NAS
SAN Management
LUN (Logical Unit Number) creation &
management (32MB granularity)
LUN Dynamic volume expansion (block-
based only)
Security
ACL security implementation based on users
availability
- Local users
- Windows NT/2000 Domain users
- Windows 2003 Active Directory users
- NIS Domain users
ManageTrends
SNMP Discovery and Management
Discover storage resources (storage servers,
switches, routers, etc.) deployed across an
enterprise using SNMP
List of discovered storage resources is saved in
the database
Manages StorTrends® 1000i
Alerts users of network failures
Device Mapping
Displays all discovered devices
Topology View
Displays each network in hierarchical tree
format
Helps the administrator to locate, monitor
and manage the AMI Device
Shows the volume and iSCSI details
Storage View
Hierarchical display of Discovery Domain Sets
(DDS) and Discovery Domains (DD)
Displays network entities & portal
information
All the IP-SAN networks are displayed in a
hierarchical tree concept
Administrator can access any AMI managed
device by clicking on the tree node
Zoning and iSNS
Create, view or edit iSCSI zone information
Administrator can define name and comments
for the zone
Specify the iSCSI Targets/LUN’s to
participate in the zone
Complies with the iSNS Standard
Resource Management
Complete management of individual storage
resources
Analyze storage consumption
View or generate storage usage reports
Plan for future storage deployment
Security
MD5 Chap Login Authentication
Support HTTPS
Software Requirements
OS: Windows 2000 (any version) with SP3,
Window XP (SP1), Windows 2003
Windows Message Queuing Service (Available
as Component in Windows CD)
MS IIS Server 5.0 or Later
.NET 1.1 with SP2
MDAC 2.6 (SP2) or Later
IE 6.0 with SP1
MS iSNS Server 3.0
Macromedia Flash Player 7.0

American Megatrends Inc. | www.ami.com
6145-F Northbelt Parkway
Norcross GA 30071 | t: 770.246.8600
Sales & Product Information
[email protected] | t: 800.828.9264
Technical Support
[email protected] | t: 770.246.8645
© 2004 American Megatrends Inc. - Specifications subject to change without notice
StorTrends 1000i
IP-SAN/NAS Storage
3/3
Features
Hardware Specifications
Technical Specifications
Host Interface
Dual Gigabit Ethernet
Drive Interface
Four 3.5” hot-swap bays
Drive Types
Low profile 3.5”
Drive Capacity
250 GB per drive
Maximum Capacity per Enclosure
1 TB
Status LEDs
Yes
SMTP Event Notification
Yes (Email, pager)
Expansion Slots
One 64 bit/133 MHz PC
System Technical Specifications
On-board CPU
Pentium4 3.06 GHz Hyper-threaded
Data Management Ports
Two, 1 Gigabit Ethernet Data Ports
Host/Device Data Burst Rate
1 Gigabit Full Duplex per Port
Other Connectors
One RS-232 Serial; Two USB Ports
Cache Memory Size
1 GB DDR Memory
Advanced Software Features
Configurable RAID Levels
0, 1, 5
Number of iSCSI Targets
512
NAS Volume Snapshot
Optional Feature Upgrades
Memory To 3 GB
Physical Characteristics
Dimensions
16.75” x 1.75” x 23”
Weight
21.6 lbs (without drives)
