American Recorder PHO-MIC-0286 User manual

SPECIFICATION:
AMERICAN RECORDER TECHNOLOGIES, INC.
www.AmericanRecorder.com
1872 Angus Ave.
Simi Valley, CA 93063 - USA
805-527-9580 - 808-527-1433(fax)
[email protected]
THANK YOU FOR CHOOSING EM-286 VIDEO MICROPHONE
PHO-MIC-0286 is a super-cardioid condenser microphone for DSLR
camer, video recorder and phones/tablets with proper adapter cable.
The Mic-in jack allows plugging in an additional microphone or
background music, to work with this condenser microphone as
separate L and R channel outputs to camera or video recorder, and an
earphone jack for monitoring during recording.
The special designed shock mount to minimize vibrations from the
camera or motion noise from a boom pole. The shock mount adapter fits
any shoe-mount attachment, and the 1/4"-20 threaded socket fits most
boom poles.
PHO-MIC-0286
SUPER CARDIOID VIDEO MICROPHONE
USER MANUAL
PATTERN: Cardioid (NORM) / Supercardioid (TELE)
FREQUENCY RANGE: 20 -20KHz
SENSITIVITY: Cardioid -46dB (0dB=1V/Pa@1KHz)
Supercardioid -36dB (0dB=1V/Pa@1KHz)
LOW CUT FILTER: -5dB @300Hz
OUTPUT IMPEDANCE: 1.5K ohm at high level
600 ohm at low level
POWER REQUIREMENT: 1AA battery
BATTERY LIFE: approx.100 hours
OUTPUT CONNECTOR: 3.5mm stereo plug
MIC INPUT: 3.5mm stereo plug
CABLE: 90cm
DIMENSION(WITH SHOCK MOUNT) (Lx WxH): 14.4 x 3.2 x 6.7 cm
WEIGHT(WITH BATTERY): 113.4g

Functions:
1. Power ON/LOW CUT Filter/OFF
2. Gain level switch (0 dB, +10dB)
3. Polar pattern selector
4. Mic input jack
5. Headphone jack
6. Shock mount
7.Locking wheel
8. Mounting foot with 1/4"-20 threaded socket
9. Battery compartment
10. Foam windscreen
1. 2. 3.
4. 5.
6.
7.
8.
10.
9.
Installing the battery
1. Remove the battery compartment cover by
pressing down on the ridges and sliding the
cover toward the back of microphone.
2. Insert one according to the label indication
inside the compartment.
3. Replace the battery compartment cover.
