American Signature VCF WA-8215-QB User manual

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts
that may have come loose inside the carton during shipment.
PARTS LIST:
HARDWARE LIST:
No.
A
B
C
D
E
K
L
M
N
Description
Headboard 1PC
1PC
1PC
1PC
2PCS
8PCS
8PCS
10PCS
2PCS
Right Headboard Leg
(WITH “R” LABEL)
Left Headboard Leg
(WITH “L” LABEL)
Sketch Quantity
No. Description
JCBB SCREW
JCBC SCREW
JCBC SCREW
JCBC SCREW
O2PCS WOOD DOWEL
P14PCS SPRING WASHER
Q14PCS FLAT WASHER
R8PCS SCREW
S1PC ALLEN KEY
T1PC ALLEN KEY
Sketch Size Quantity
MADE IN MALAYSIA
Footboard
Footboard Leg
F2PCS
G2PCS
H2PCS
Side Rail
Support Leg
I4PCS
Slat
J4PCS
Support Leg
ASSEMBLY INSTRUCTIONS
ITEM NO:WA-8215-QB
DESCRIPTION:QUEEN UPH
BED-DREW NATURAL LINEN
PAGE 1 OF 3
TOOL REQUIRED (NOT PROVIDED):
PHILLIPS SCREW DRIVER
M4 x 100mm
M5 x 65mm
M8 x 20mm
M6 x 25mm
M6 x 35mm
M6 x 70mm
M8 x 30mm
M6 x 13mm
M6 x 19mm
M4 x 32mm
Back
Back
Open the zipper stitched on the back of
Headboard (A) and take out the Footboard (D)
from the storage space of Headboard (A).
Tear open the Velcro on the back of Footboard (D)
and take out the Side Rail (F) & (G) from the storage
space of Footboard (D).
A
D
F
F
G
G
STEP 1
Side Rail with
Hole on Right
Side Rail with
Hole on Left
1542mm x 45mm x 18mm
167mm x 30mm x 30mm
U1PC
STRAIGHT
ALLEN KEY
STRAIGHT
ALLEN KEY
Note: Straight Allen Key (U) & (V) are for use with a power drill.
M4 x 100mm
V1PC
M5 x 100mm

MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts
that may have come loose inside the carton during shipment.
PAGE 2 OF 3
STEP 3
STEP 2
STEP 4
ASSEMBLY INSTRUCTIONS
ITEM NO:WA-8215-QB
DESCRIPTION:QUEEN UPH
BED-DREW NATURAL LINEN
Left
Right
D
A
C
B
S
M
P
Q
D
O
E
NS
S
L
P
Q
H
F
G
Make sure the cleat
is on outside edge.
BACK

MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts
that may have come loose inside the carton during shipment.
PAGE 3 OF 3
STEP 5
STEP 6
STEP 7
Complete Assembly
ASSEMBLY INSTRUCTIONS
ITEM NO:WA-8215-QB
DESCRIPTION:QUEEN UPH
BED-DREW NATURAL LINEN
Note: Don’t tighten all bolts
until the end of STEP 6.
STEP 6.2
R
I
KT
STEP 6.1 M
I
J
S
