GENESIS SERIES
OWNER’S GUIDE

Congratulations on your
purchase of Genesis
ComforTech™ Home
Theater Reclining!
Be ready for hours of endless enjoyment
whether connecting a smart TV, phone,
tablet, gaming system, or other
Bluetooth® enabled devices, all
high-definition sound at its very best!
The Genesis ComforTech™ Home Theater
Reclining featuring immersive soundbar
seating embeds a state-of-the-art,
all-digital sound system developed by
one of the world’s leading producers of
high-end audio systems delivering rich,
robust sound that is incredibly pure.
1

GENESIS QUICK START
1. Unpack main product modules. Each unit comes fully assembled.
2. Check all small packages for connection parts/remote/power supplies.
3. When setting up your configuration, it is important to note the console with the control
panel should be positioned next to the right-arm-facing recliner.
4. Connect per schematic. Note that the connection wires have specific shapes.
Pay particular attention to speaker wires that screw together for proper alignment
with raised tips. Connect corresponding power supplies last. Power supply for sound
is dierent from power supply for recliners (labeled accordingly).
5. Test all recliners for operational movement using side button controls.
6. Connect to any Bluetooth® enabled device. Go to Bluetooth® menu on TV, phone or
mobile device and look for ComforTech™ by selecting on menu.
7. Test listening: each recliner has 2 speakers in the headrests, and each console has
one subwoofer.
8. All should be operating. If not, re-check all connections.
9. The Genesis Home Theater uses anti-skid legs to help prevent movement during use
in place of sectional connectors.
10. The wireless remote requires 2 AAA batteries (not included).
2

Do not plug the power source into a power outlet until your product is completely assembled
and in position where you intend to use it.
To help prevent shock and or damage to your product, only plug the power transformers into
a grounded outlet. Read the operating instructions carefully before operating your power
product! Note: When setting up your configuration, you need to leave a 1/2 inch+/- gap
between each piece to allow the motion products to work as intended.
The console w/ control panel must always be positioned and attached to the right arm
facing DP recliner. Depending on the configuration you purchased, your configuration
could look as seen below.
NOTES: Weight capacity: 360 LBS. Wall clearance required: 2.5”
WARNING: Do not allow children to play on or operate the mechanized equipment
WARNING: Care should be taken to assure there is nothing in the path of the mechanism before and during operation.
MADE IN CHINA
3
4
3
3
2
1
5
ASSEMBLY SCHEMATICS
(Illustration shows a 6pc configuration)
1PC 1PC 1PC 1PC LAF/RAF
1 EACH
1PC for CSL
W/CNTRL PNL
1PC for CSL
W/CNTRL PNL
2PCS
Parts List (No tools required)
1
LAF DP
RECLINER
CONSOLE DP ARMLS
RCLNR
CONSOLE
W/CNTRL PNL
RAF DP
RECLINER
WALL PLUG
TRANSFORMER
POWER SUPPLY
FOR SOUND
SYSTEM
REMOTE HAND
CONTROL
2 3 4 5 6 7 8

4
ASSEMBLY SCHEMATICS
Thank you for purchasing this quality product. Be sure to check all packing material carefully
for small parts that may have come loose inside the carton during shipment.
Attention: For the LAF/RAF Recliner, the wall plug transformer is packed and attached to the
mechanism at the bottom of the seat. The power supply and remote hand control are packed
and placed inside the console with control panel (W/CNTRL PNL).
Wiring Connectors
3D SHOW 3D SHOWREMARK REMARK
FOR SUBWOOFER FOR SPEAKERSA C
B DFOR SPEAKERS: AUDIO SIGNAL FOR ACTUATORS
NO. NO.
1PC 1PC 1PC 1PC LAF/RAF
1 EACH
1PC for CSL
W/CNTRL PNL
1PC for CSL
W/CNTRL PNL
2PCS
Parts List (No tools required)
1
LAF DP
RECLINER
CONSOLE DP ARMLS
RCLNR
CONSOLE
W/CNTRL PNL
RAF DP
RECLINER
WALL PLUG
TRANSFORMER
POWER SUPPLY
FOR SOUND
SYSTEM
REMOTE HAND
CONTROL
2 3 4 5 6 7 8
NOTE: For the Connector B
speaker audio signal, make sure
to align the arrows found on
each of the B connectors
before pushing them together.
D
C
B
A
B
C
A
B
C
D
5
4
1
6 6
7 7
5
4
1
6
6
32
6 6
7
4 2
53 3 1
GENESIS 3PC CONFIGURATION GENESIS 5PC CONFIGURATION
GENESIS 6PC
CONFIGURATION
B, C, D
B, C, D
B, C, D
B, C, D
B, C, D A, B, C, D
A, B, C, D A, B, C, D
A, B, C
A, B, C
B, C

5
OPERATING INSTRUCTIONS FOR THE
1200 GENESIS SECTIONAL
Caution: Read the important instructions below before operating your power mechanized equipment.
Do not allow children to play on or operate this power mechanized equipment.
Note: Headrest Function: After the headrest has extended to its maximum position, continuing
to press the headrest open button will activate the tilt forward function.
Care should always be taken to assure there is nothing in the path of the mechanism before
and during operation.
Open and Close Buttons: The open and close buttons will operate the function noted above
by simply touching the button. To stop the mechanism in your desired position, simply remove
your finger from the button.
Home Button: The home button will simultaneously return the headrest and reclining
mechanism to the closed position when pressed. To stop the function, remove your finger
from the button.
USB Charging Outlets: When using both the A and C charging ports simultaneously, the output
of each port is reduced from 2 amps to 1 amp.
DP ARMLS
RECLINER
LAF/RAF DP
RECLINER
THE HOME BUTTON IS
NOT PROGRAMMABLE
FRONT OF ARM/SEAT
FRONT OF ARM/SEAT
MECHANISM
OPEN
HEADREST
OPEN
HOME
BUTTON
MECHANISM
OPEN
HEADREST
OPEN
HOME
BUTTON
BOTH A&C USB PORTS CAN
CHARGE MOST ELECTRIC
DEVICES WITH A CHARGING
REQUIREMENT OF 2.0 AMPS
OR LESS
THE USB PORT CAN CHARGE
MOST ELECTRIC DEVICES WITH
A CHARGING REQUIREMENT
OF 2.0 AMPS
TYPE “C” USB PORTS
MECHANISM
CLOSE
HEADREST
CLOSE
MECHANISM
CLOSE
HEADREST
CLOSE

SUBWOOFER WIRE CONNECTION/BLUE MARKED SUBWOOFER
RECLINER ACTUATOR CONNECTIONS
SPEAKER CONNECTIONS: NOTE SHAPES
MODULAR AMPLIFIER UNDER LOWER BACK
MAIN CONTROL PANEL
RECLINER ACTUATOR POWER SUPPLY
SOUND SUPPLY POWER SUPPLY
GENESIS SUPPLEMENTAL
PARTS IMAGES
6

7
LAF DP RECLINER
CONSOLE
DP ARMLESS RECLINER X2
RAF DP RECLINER
6PC CONFIGURATION
GENESIS
LAF DP RECLINER
RAF DP RECLINER
3PC CONFIGURATION
GENESIS
CONSOLE W/CONTROL PANEL
LAF DP RECLINER
CONSOLE
DP ARMLESS RECLINER X2
RAF DP RECLINER
5PC CONFIGURATION
GENESIS
CONSOLE W/CONTROL PANEL
CONSOLE W/CONTROL PANEL

8
Each console with control panel will include
a wireless remote. The remote and control
panels are labeled with identical numbers
because the remote is configured to work
with the Bluetooth® music system.
If a replacement wireless remote is needed,
the replacement remote can be paired to
any Genesis music system by following the
instructions on the backside of the remote.
SOUND SYSTEM WIRELESS REMOTE
NOTE: The wireless remote requires 2 AAA batteries, not included.
ALL CONFIGURATIONS HAVE A
CONSOLE WCONTROL PANEL
The console with control panel with the host
control box is the command center of
the system. THIS CONSOLE IS WIRED TO
ALWAYS BE PLACED NEXT TO THE RAF
DP RECLINER
1. Console w/control panel
2. Hidden cupholders & wireless charging pod
3. Deep storage
4. Control panel & wireless remote
5. Subwoofer
6. Rear view, wiring & power inlet
1
3
5
2
4
6

9
All connections are labeled with dierent color labels and wording.
Each function of the connection is dierent.
CONSOLE WCONTROL PANEL
WIRING CONNECTIONS
WIRING CONNECTIONS VIEWS
CONSOLE W/ CONTROL PANEL
A B
On the rear-right side of the console, there
are 4 connections to be made. On the
rear-left side of the console, there are
3 connections to be made. All connections
have color-coded labels with wording.
Actuator: White
Speaker power: Yellow
Speaker audio signal: Blue
Actuator: White
Speaker power: Yellow
Speaker audio signal: Blue
Subwoofer: Silver (label), Blue (wire)
3 CONNECTIONS
4 CONNECTIONS
A
B
LEFT SIDE
LAF DP RECLINER
RIGHT SIDE
CONSOLE
RAF DP RECLINERCONSOLE W/ CONTROL PANEL
B

10
CONSOLE FUNCTIONS
1. Console
2. Hidden cupholders, wireless charging pod,
deep storage with power strip and
USB-A & C charging ports
3. Subwoofer
4. Rear view, wiring and power inlet
On the rear right side of the Bluetooth® control
panel console, there are 3 connections to be
made. On the rear left side of the console, there
are 4 connections to be made. All connections
have color-coded labels with wording.
CONSOLE WIRING CONNECTIONS
A
CONSOLE
B
Actuator: White
Speaker power: Yellow
Speaker audio signal: Blue
Subwoofer: Silver (label), Blue (wire)
Actuator: White
Speaker power: Yellow
Speaker audio signal: Blue
4 CONNECTIONS
3 CONNECTIONS
A
B
3 41 2
A

11
6PC CONFIGURATION ONLY:
The sound system wiring is attached across
the bottom rear of the DP armless recliners
with Velcro. On a 6pc configuration only, the
actuator connection (white) will need to be
rerouted on one of the DP armless recliners
so that it connects with the matching
connection extending from the console.
ARMLESS DUAL-POWER RECLINER
WIRING CONNECTIONS
The DP Armless Recliners come prewired
with 4 connections extending from one side,
and 3 from the other.
Actuator: White
Speaker power: Yellow
Speaker audio signal: Blue
Subwoofer: Silver (label), Blue (wire)
4 CONNECTIONS

12
LAF/RAF DP RECLINER
USES A WALL PLUG TRANSFORMER
CONSOLE W/CONTROL PANEL
USES A FLOOR TRANSFORMER
TRANSFORMERS
GENESIS 3-POSITION RATCHETING
HEADREST ENDS W/SPEAKERS
3-POSITION RATCHETING HEADREST ENDS
From the home position, the ends of the headrest feature a
ratcheting 3-position functionality. Pulling past the third position
disengages the mechanism, which then returns it to the home
position. To adjust the headrest ends, grasp them as shown
below and pull inward to select one of the three positions.
GRASP HERE
TO ADJUST
GRASP HERE
TO ADJUST
TO ADJUST THE HEADREST ENDS, GRASP AND PULL INWARD
