American Standard COLONY SOFT 2275.403 User manual

COLONY SOFT 2275.403
2275.503
Insert FAUCET (1) and CABLE CONNECTOR (2) through center hole
of mounting surface. Fig. A.
From under side of mounting surface thread the two MOUNTING
NUTS (3) onto FAUCET SHANKS (4). Fig. B.
Center FAUCET (1) and hand tighten MOUNTING NUTS (3) to
secure FAUCET (1).
1
Certified to comply with ANSI A112.18.1
Installation
Instructions
Centerset Lavatory Faucet
with Speed Connect™ Drain
INSTALL FAUCET
Adjustable WrenchScrewdriver Channel Locks
Recommended tools
Tubing Cutter
Congratulations on purchasing your American Standard faucet
with the Speed Connect drain, a features found only on
American Standard faucets.
Speed Connect Drain*
• 1/3 of the parts, installs in 1/3 of the time
• No tools needed
• Never needs adjustment
• Guaranteed to seal properly the first time, every time.
*Your new American Standard faucet is designed to work only with the Speed Connect drain.
To ensure that your installation proceeds smoothly-please read these instructions carefully
before you begin.
Fig. A.
Fig. B.
1
M968877 Rev. 1.2
Plumbers' Putty or Caulking
(HAND TIGHTEN)
3
1
2
4
3
C
H
Apply a bead of putty along the edge of the underside of the FAUCET (1).
PUTTY
Turn off water at
main supply.
CAUTION

INSTALL POP-UP DRAIN
INSTALL BLACK GASKET
3
2
Install BLACK CONE GASKET (1) onto DRAIN BODY (2)
from below.
Note: The flat side of the BLACK CONE GASKET (1) must
face down.
4
Drop DRAIN BODY (4) through sink drain
hole. Make sure WHITE FOAM GASKET (5)
is under flange of DRAIN BODY (4). Fig. B.
Note: No plumber’s putty or caulk is required.
The CABLE ATTACHMENT POINT (6) must
face towards the rear of the SINK. Fig. B.
Remove CLEAR PLASTIC COVER (1). Remove
CARDBOARD SPACER (2) from under DRAIN
POP-UP (3). Fig. A.
2
REAR OF
SINK
4
56
3
1
SINK
DRAIN
HOLE
FLAT SIDE OF GASKET
MUST FACE DOWN
1
2
Fig. A.
2
1
FLAT SIDE OF
GRAY LOCKNUT
MUST FACE UP
INSTALL GRAY LOCKNUT
5
Install GRAY LOCKNUT (1) onto DRAIN BODY (2)
from below SINK. Fig. A.
Note: The flat side of the GRAY LOCKNUT (1)
must face up.
Tighten firmly by hand. No tools are required.
Check DRAIN FLANGE in SINK to ensure that
WHITE FOAM GASKET (3) is fully compressed
and not visible. Fig. B.
POP-UP KNOB (1) must be fully down.
POP-UP KNOB
Fig. A. Fig. B.
3WHITE FOAM
GASKET
NOT VISIBLE
DRAIN
FLANGE
Fig. B.
2
1
DOWN
M968877 Rev. 1.2

Connect HOT water supply to inlet of left SHANK and COLD
water supply to right SHANK using sealant, appropriate
connectors, and COUPLING NUTS.
Connect 1-1/4” O.D. TAILPIECE (4) on POP-UP
DRAIN to “p” trap.
8
Connect water supply to INLET SHANKS (1) with 1/2" IPS
FLEXIBLE SUPPLIES (2) or 3/8" O.D. BULL-NOSE RISERS (3).
Use adjustable wrench to tighten connections. Do not over
tighten. Be careful not to kink copper supply when bending.
Use tubing cutter to cut to proper length.
MAKE WATER SUPPLY AND WASTE CONNECTIONS
NOTE: FLEXIBLE SUPPLIES OR BULL-NOSE RISERS NOT INCLUDED
AND MUST BE PURCHASED SEPARATELY.
HOT
COLD
FERRULE
COMPRESSION
NUT
COUPLING
NUT WITH
FAUCET
COUPLING
NUT ON FLEX
SUPPLIES
FLEXIBLE
SUPPLIES
1
3/8 O.D.
BULL-NOSE
RISERS
3/8 COMPRESSION
CONNECTION
2
3
Thread CABLE CONNECTOR (1) clockwise
onto DRAIN BODY CONNECTION (2) and
hand tighten. Fig. A.
Your new POP-UP DRAIN installation is
now complete. Fig. B.
Note: Tailpeice on pop-up drain is 1-1/4” O.D.
Fig. B.
Fig. A.
ATTACH CABLE CONNECTOR
6
2
1
Operate LIFT KNOB (1) to verify that STOPPER (2) opens and
closes.
Note: If STOPPER (2) does not open and close properly then refer
to the “troubleshooting section” of these instructions.
CHECK OPERATION OF POP-UP
7
1-1/4” O.D.
Fig. B.
4
2
1
“P” TRAP
M968877 Rev. 1.2

3
CHECK DRAIN CONNECTIONS
10
12
TEST INSTALLED FITTING
Operate POP-UP KNOB (5) and fill Sink with water. Check
that DRAIN STOPPER (4) makes a good seal and retains
water in Sink. If STOPPER (4) does not seal properly, please
refer to “Troubleshooting Guide” in these instructions.
Release POP-UP KNOB (5) down and check all drain
connections and "P" trap for leaks. Tighten
if necessary.
9
4
CARE INSTRUCTIONS:
DO: SIMPLY RINSE THE PRODUCT CLEAN WITH CLEAR WATER. DRY WITH A SOFT COTTON FLANNEL CLOTH.
DO NOT: DO NOT CLEAN THE PRODUCT WITH SOAPS, ACID, POLISH, ABRASIVES, HARSH CLEANERS, OR A
CLOTH WITH A COARSE SURFACE.
2
1
5
2
4
“P” TRAP
WASTE
OUTLET
With HANDLES (1) in OFF position, turn on WATER
SUPPLIES (2) and check all connections for leaks.
Ensure that AERATOR (3) is tightened completely.
Operate HANDLES (1) to allow water flow.
M968877 Rev. 1.2
11 SERVICE
If Faucet Drips Proceed As Follows:
To Clean Aerator:
Turn VALVE to OFF position.
If spout drips, operate HANDLES (1) several times from OFF to ON position. Do not force-handles they turn only 90˚.
AERATOR (6) may accumulate dirt
causing distorted and reduced water flow.
Remove AERATOR (6) and rinse clean.
1
2
3
6
FLAT
4
To Change Direction Of Handle Rotation,
Proceed As Follows:
Turn VALVE to OFF position.
Loosen SET SCREW (2) and pull HANDLE (1) off.
Turn VALVE STEM (3) 90˚ so that flat on VALVE
STEM (3) faces away from the SPOUT (4). (Water
may turn on)
Replace HANDLE (1) and tighten SET SCREW (2).

Speed Connect™ Drain
Troubleshooting Guide
1
2
Disconnect the Cable from the Drain by threading the Cable Connector (1) counter-clockwise. Fig. A.
Look at the area on the Drain Body where the Cable was attached and locate the component labeled
as “Cam” and “Cam Cap” in the illustration. Fig. B.
Use fingers or small screwdriver under either side of the Cam Cap to pry it out from the Drain. Fig. D.
Remove the Cam by pulling it straight out while wiggling gently to loosen the Rubber Seal. Fig. E.
The Stopper can now be removed by lifting it out of the Drain. Fig. F.
CAM
CAM CAP
RE-ATTACH
DISCONNECT
CABLE ADJUSTMENT PROCEDURE
If sink does not hold water even though Stopper is in the “down” position:
• Follow CABLE ADJUSTMENT PROCEDURE.
If Stopper does not raise up fully or sink drains too slowly:
• Follow CABLE ADJUSTMENT PROCEDURE.
If you need to remove the Stopper:
• Follow STOPPER REMOVAL PROCEDURE.
If you would like the ability to remove your Stopper simply by lifting it out of the drain:
• Follow STOPPER INSTALLATION PROCEDURE for “Unlocked” mode.
Fig. A.
REMOVE
CAM CAP
REMOVE
CAM
Fig. D. Fig. E. Fig. F.
Disconnect the Cable from the Drain by threading the Cable Connector (1) counter-clockwise. Fig. A.
Look at the area on the Drain Body where the Cable was attached and locate the component labeled as
“Cam” in the illustration. Fig. B.
Use a small screwdriver to rotate the Cam in the clockwise direction as far as it will go. At this point the
Stopper should be in the UP position. Fig. B, C.
Push DOWN on the Lift-Knob to make sure it is fully down. Fig. C.
Re-attach the Cable to the Drain Body Connection (2) by threading the Cable Connector (1) clockwise onto the
Drain Body Connection (2) and hand-tighten. Fig. A.
STOPPER REMOVAL PROCEDURE
5
Fig. B. Fig. C.
1
M968877 Rev. 1.2

STOPPER INSTALLATION PROCEDURE
Locked Mode:
Look at the Plastic Loop at the bottom of the Stopper and notice
that the Loop is on one side of the Stopper. Fig. G.
To install the stopper in “Locked” mode, insert the Stopper into
the Drain so that the Plastic Loop is facing toward the rear of the
Sink and the American Standard logo is facing front. Rotate
Stopper slightly if necessary so that the Stopper slides all the
way down.Fig. G.
Re-install the Cam into the Drain, rotating the Cam if necessary
to make sure it is fully inserted. Fig. J.
Re-install the Cam Cap, making sure the guide teeth are facing
outward. If the Cam Cap does not “snap” into place, then rotate
the Cam to make sure it is fully inserted. Fig. K.
Re-attach Cable. See “CABLE ADJUSTMENT PROCEDURE” in
Troubling Shooting Guide to complete installation. Stopper will be
in “Locked” mode and not be removable.
Unlocked Mode:
Look at the Plastic Loop at the bottom of the Stopper and notice
that the Loop is on one side of the Stopper. Fig. H.
To install the stopper in “Unlocked” mode, insert the Stopper into
the Drain so that the Plastic Loop is facing toward the front of the
Sink and the American Standard logo is facing rear. Rotate Stopper
slightly if necessary so that the Stopper slides all the way down.
Fig. H.
Re-install the Cam into the Drain, rotating the Cam if necessary
to make sure it is fully inserted. Fig. J.
Re-install the Cam Cap, making sure the guide teeth are facing
outward. If the Cam Cap does not “snap” into place, then rotate
the Cam to make sure it is fully inserted. Fig. K.
Re-attach Cable. See “CABLE ADJUSTMENT PROCEDURE” in
“Troublingshooting Guide” to complete installation. Stopper will be
in “Unlocked” mode and removable.
Fig. J. Fig. K.
INSTALL
CAM CAP
CAM
INSTALL CAM
The Stopper can be installed two ways, “Locked” Mode (Stopper cannot be
removed) or “Unlock” Mode (Stopper is removable).
Unlocked Mode
locked Mode
LOOP TOWARD
FRONT OF SINK
180˚
LOGO
DRAIN
Fig. H.
LOGO
DRAIN
Fig. G.
LOOP TOWARD
REAR OF SINK
6
M968877 Rev. 1.2
